cog meter lcd module for sale

128X64 (S) COG White Display Small SizeDisplay is professional Monochrome LCD display for Industry application, include digital panel meter, UPS, inverter, multi-function meter, POS machines, Fuel Dispenser, Oil Dispenser, Gas Dispenser, Flow Meter, KWH Meter, Energy Meter, Water Meter, Gas Meter, Smart Meter, Clock. Our COG Graphic LCD Module 128*64 has various different models on shelf and accept custom develop to meet your special requirement. We can develop different interface like I2C, Serial, and we also have different font available.

You don"t know which module is right for you? Contact us, we will be happy to advise you more about our products and will surely find the right product together with you.

Newhaven 160x100 graphic Chip-On-Glass (COG) Liquid Crystal Display shows dark pixels on a gray background. This reflective LCD Display is visible with high ambient light while offering a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-C160100CZ-RN-FBW display has an optimal view of 6:00 and has no backlight. This display operates at 3V supply voltage and is RoHS compliant.

A 3.9″ monochrome, 240×160 dot matrix, COG (Chip on Glass) Graphic LCD Module in FSTN Positive LCD Mode with Wide Temperature Range (Operating Temp: -20°C to 70°C, Storage Temp: -30°C to 80°C), and White LED Backlight. It has a six O’clock viewing direction and a transflective polarizer recommended for applications that will be used both indoor and outdoor. This product is assembled chip on glass with 1/160 Duty cycle and 1/12 Bias. This LCD uses controller IC UC1698 or equivalent. This is an ROHS compliant product manufactured with ISO standards and procedures.

LCM stands for Liquid Crystal Module or LCD Module. An LCM consists of an LCD or “LCD glass” and a connected LCD controller IC. In the US, LCMs are commonly called LCDs, although this is strictly incorrect. An LCM typically also includes a backlight.

Many LCMs have a PCB (printed circuit board) that functions as a mechanical chassis and connects the LCD controller IC to the LCD through zebras (conductive elastomeric strips). Mechanical tension holds the transparent conductors of the LCD against the zebra on one side and bare conductors of the PCB on the other, allowing signals from the LCD controller IC to travel to the LCD.

Mechanical tension holds the transparent conductors of the LCD against the zebra on one side and bare conductors of the PCB on the other, allowing signals from the LCD controller IC to travel to the LCD.

LCMs are not required to have a PCB or backlight. In what might be thought of as the simplest form of LCM, the LCD controller IC is mounted directly onto transparent conductors of the LCD glass using ACF (Anisotropic Conductive Film), with signals brought to the same glass through a FFC/FPC (Flat Flex Cable / Flexible Printed Circuit).
