Lenovo Thinkpad T430 comes in WXGA HD and WXGA both resolutions. These resolutions are not interchangeable. So pay attention to resolution of your existing LCD and make sure you are picking correct listing for purchase.

This guide explains how to replace the screen in a Lenovo ThinkPad T430s. The ThinkPad T430s screen has a native resolution of 1600 x 900 pixels. It also has a matte finish and a LED backlight.

Thinkpad T430 laptops (as well as T430s, T420 and T420s) are equipped with awful screens. It doesn"t matter if the screen is HD (1366x768) or HD+ (1600x900), whether the screen manufacturer is LG, Samsung or AUO: every screen has awful viewing angles, poor colors and weak brightness.

Many people have investigated the possibility of upgrading these screens, notably on Notebook Review Forum at the thread "X1 display on a T430?" and on ThinkPad-Forum at the thread "T420/T430 auf FHD-Panel umrüsten (wie Alienware 14" FHD matt) ... Gibt"s schon Infos?".

T440s/T440p 1080p FHD IPS - This 1920x1080 panel is a very high resolution display with a beautiful IPS screen to rival those equipped on the X220/X230. Unfortunately, one drawback is that these screens use the new eDP standard, instead of the T420/T430"s LVDS output.

X1 Carbon 1600x900 TN Panel - An LVDS panel requiring no conversion, though it needs the cable to be extended While it"s a TN Panel, it looks much better than anything on the T420/T430.

_Before starting to buy expensive parts (the LCD panel) and before starting to dismantle the computer, I advise anyone interested in the X1 Carbon screen to first look at extending the LCD cable, because there are multiple different methods for doing so: some work, some don"t, and some are difficult._

If you just want to replace a 1366x768 HD screen with the typical T430 1600x900 HD+ screen, follow this guide instead. This guide is an experimental mod to put a T440s FHD IPS or X1 Carbon screen in a T420/T430.

T440p and T440s feature excellent IPS/AHVA panels (1920x1080, Full-HD), that by definition are superior to the screen mounted on the X1 Carbon. They"ve been reported to have same dimensions, but use different connection standards (eDP instead of LVDS).

As of July 29th, 2015, Chinese ThinkPad modders at 51nb have developed an eDP to LVDS converter board that allows most T440s/T440p 1080p FHD IPS Panels to be installed on ThinkPad T420/T430 and T420s/T430s models. (non-s and s models use different-sized boards due to case constraints). Unfortunately, due to linguistic barriers and shipping fees, it is difficult for these modders to sell to the English-language market, much less offer support.

The following guide is based on the successful installation of the X1 screen on my T430. Nevertheless, thanks to similarities between T430, T430s, T420 and T420s the information hereby presented could be applied to them as well.

Talking about compatibility, this screen has the right connector (40-pin LVDS) and the right dimensions to fit perfectly in the T430. Besides, it can"t be screwed (the original is screwed) and, most important, its connector is on the wrong side (on the right instead of left). In the following solutions for these problems will be presented.

Instructions for replacing the LCD cable can be found on Lenovo website: "LCD panel and LCD cable removal and installation - ThinkPad T430 and T430i".

The cable connector of X1 Carbon panel is in the wrong position: on the right instead of left. In order to connect the panel to the LCD cable is therefore necessary an extension (sometimes "converter cable" or "extender cable").

If you don"t want to irreversibly remove parts of the back shell, this is the only possible arrangement that allows to connect the screen with the LCD cable using a standard "left to right" LCD cable extension. Representation not to scale.

This cable mod, while difficult, works fine (I"m using my modified T430 from a couple of month and it"s working perfectly). So if you can"t find the cable in A Simple Solution that works, this is your best alternative.

Although X1 Carbon LCD panel isn"t fitted with screw holes, placing it in the T430 body is quite straightforward. This new panel have indeed dimensions perfectly equal to the original and, once in its place, it is vertically sustained by the original vertical supports. The screen can be supported horizontally too by adding shims on its left (I"ve used folded cardboard), see the picture. Thin shims are necessary on the back of the screen too.

During Gentoo compilation your T430 may became very hot and even turn off, especially on higher CPU - so you will need to replace HSF too, to have 2 pipes:

ThinkPad T430 supports up to 16 GB of SO-DIMM DDR3/DDR3L memory. Max frequency for some machines is 2133 MHz, but personally I got black screen without loading with 2133 MHz memory, so check in shop before buy. DDR3L is better because it is 1.35V instead of 1.5V so it uses 10 percent less battery with the same performance as DDR3. To check how much of memory the laptop has:

The ThinkPad T series is a line of laptop computers. Originally developed by IBM, and introduced in 2000, the brand was sold along with the rest of IBM"s consumer computer division to Chinese technology company Lenovo in 2005, who have continued to produce and market succeeding models.

Announced in March 2003, the ThinkPad T40p represented the first in the T series" "performance" class of laptops.1400 × 1050 resolution, a maximum of 2 GiB PC2100 RAM, and a 60 GB IDE hard disk.T41 and T41p and the T42 and T42p (ATI Mobility 7500, 9600, and FireGL T2), with almost complete parts interchangeability, except for the fan (normal or p-series), keyboard (14.1" or 15"), screen (14.1" or 15"), and screen inverter. The 15-inch T42 and T42p models were offered with an optional 1400 × 1050 or 1600 × 1200 "FlexView" IPS LCD display.

The naming convention for the T Series was changed by Lenovo following the release of the ThinkPad T400 and T500 in July 2008.ThinkPad W Series laptops.Linux compatibility. The T-p lineup later returned as an irregular T##0p line with only T440p, T460p, T470p and T540p models.

The Lenovo ThinkPad 25th anniversary edition was released on Oct. 5, 2017. It was based on the ThinkPad T470, but brought back the classic 7-row keyboard.A485, which officially is not part of the T Series, but it shares the same housing as the T480. It offers a 2nd generation AMD Ryzen Pro processor and lacks Thunderbolt 3 support, but has USB-C support. The A475 had been similarly released in 2017 as a variation of the T470, but with AMD Carrizo or Bristol Ridge processors. In 2019 Lenovo officially introduced AMD CPUs in the T Series, and differentiated it with the digit 5 at the end of the model number (i.e. T495).

"ThinkPad T Series – History and Development". Archived from the original on 2012-02-05. Together with the ATI Mobility Radeon 7500 video controller with 16 MiB graphics memory and a 14.1" LCD display with as much as 1400 × 1050 resolution and the option of 1 GiB PC2100 RAM, it was a real sharp performer.link)

"ThinkPad T Series – History and Development". Archived from the original on 2012-02-05. The actual ThinkPad T43 as well as ThinkPad T43p were the very last pure IBM ThinkPad"s, being introduced in April 2005, with Lenovo concluding the acquisition of the trademark in May 2005.link)

"ThinkPad T Series – History and Development". Archived from the original on 2012-02-05. The very first Lenovo owned T Series were the ThinkPad T60 along with T60p released in February 2006, although these were nevertheless sporting the IBM badge, and also had been needless to say designed within ThinkCentre Global Head Quarters in Raleigh North Carolina, as all ongoing ThinkPads even now are.link)

"ThinkPad T Series – History and Development". Archived from the original on 2012-02-05. the very first "real" Lenovo ThinkPad"s arrived with the ThinkPad T400 and T500 in July 2008.link)

"Review Lenovo Thinkpad W500 Notebook". Until now the Thinkpad T-Model from Leonovo, which was enhanced after the short ending -p, set the standard for professional users with high performance demands. After a complete overhaul of the Lenovo product lineup, coincident with the launch of the Intel Centrino 2, Lenovo is now starting a few new notebook series. Among them are the new mobile workstations with the labels W500 and W700, which are meant to replace the Thinkpad Txxp models.

"Review Lenovo Thinkpad W500 Notebook". The new W series is ultimately designed specially for professional graphic designers who want maximum performance paired with practical mobility.

"Lenovo ThinkPad T60 Review". The ThinkPad T-series can be thought of as the flagship of the ThinkPad brand, it"s squarely targeted towards business users and professionals.

"Lenovo ThinkPad T410 Review". 27 January 2022. Once opened, ThinkPad fans will notice that Lenovo finally centered the screen, so no more thick bezel on one side and a thin bezel on the other.

"Lenovo ThinkPad T410 Review". 27 January 2022. The full-redesigned Lenovo ThinkPad T410 offers quite a few enhancements over the previous generation T400, including less keyboard flex, an updated keyboard, a nicer touchpad, huge improvement in port selection, and better component access through the chassis.

"Lenovo ThinkPad T510 review". Since Lenovo bought IBM"s PC and notebook business, not much of the ThinkPad"s iconic design has changed, and this is a good thing.

"Lenovo ThinkPad T510 review". The Lenovo ThinkPad T510 notebook has the same business-like look, the same sturdy build quality, and most of the features that make ThinkPads standout from other business laptops.

"Review Lenovo Thinkpad T420 Notebook". Essentially, the Tx20 laptops only differ from the previous models, called T410 and T510, by a hardware refresh to the new Sandy Bridge processors.

"Lenovo ThinkPad T420s, T420 and T520: up to 30 hours battery life". 21 February 2011. Battery life is up to 15 hours with the 9-cell pack on the T420, or up to 11 hours with the 9-cell on the T520; the T420s can last up to 10 hours with both the 6-cell regular battery and snap-on battery slice. Alternatively, pair the T420 with the optional 9-cell battery slice and it will run for a ridiculous 30 hours.
