ERM1602DNS-3 is 16 characters wide,2 rows character lcd module,SPLC780C controller (Industry-standard HD44780 compatible controller),6800 4/8-bit parallel interface,single led backlight with white color included can be dimmed easily with a resistor or PWM,ffstn-lcd negative black,white text on the black color,high contrast,wide operating temperature range,wide view angle,rohs compliant,built in character set supports English/Japanese text, see the SPLC780C datasheet for the full character set. It"s optional for pin header connection,5V or 3.3V power supply and I2C adapter board for arduino.

ERM1602FS-3 is 16 characters wide,2 rows character lcd module,SPLC780C controller (Industry-standard HD44780 compatible controller),6800 4/8-bit parallel interface,single led backlight with white color included can be dimmed easily with a resistor or PWM,fstn-lcd positive,black text on the white color,high contrast,wide operating temperature range,wide view angle,rohs compliant,built in character set supports English/Japanese text, see the SPLC780C datasheet for the full character set. It"s optional for pin header connection,5V or 3.3V power supply and I2C adapter board for arduino.

This expansion module features a 16×2 Alphanumeric LCD Module which can be added to your custom project using a 2×6 pin connector. It is designed to be used with Numato Lab’s FPGA/Microcontroller boards featuring 2×6 pin Expansion connectors. This module can be used with other boards as well by using manual wiring. This product is compatible with most of the Numato Lab’s FPGA boards.

This module realizes a fast I2C interface with the familiar LCD displays (16x02, 16x04 and 20x04), which makes the control of these displays much easier and more economical with I / O pins.

Because this module has 8 options for the address (0X20-0X27), it is possible to control 8 of these interface modules simultaneously with only 2 connections. By means of the built-in potentiometer on this module it is possible to adjust the backlight and contrast of the LCD.

The MPC830x-TLCD graphical LCD module provides an easy way for designers to add an LCD interface to their TWR-MPC830x designs. It features a color 240 x 320 TFT LCD Display plus a 12-point capacitive touch keypad and attaches directly to the TWR-MPC830x main processor board.

This is another great blue/yellow backlight LCD display. As the pin resources of Arduino controller is limited, your project may be not able to use normal LCD shield after connected with a certain quantity of sensors or SD card. However, with this I2C interface LCD module, you will be able to realize data display via only 2 wires. If you already has I2C devices in your project, this LCD module actually cost no more resources at all. It is fantastic for Arduino based project.

Here is pic shows how to connect an Arduino 1602 I2C module.The following is a table describing which pins on the Arduino should be connected to 1602 I2C LCD module.

LCD display doesn’t operate the same way as CRT displays , which fires electrons at a glass screen, a LCD display has individual pixels arranged in a rectangular grid. Each pixel has RGB(Red, Green, Blue) sub-pixel that can be turned on or off. When all of a pixel’s sub-pixels are turned off, it appears black. When all the sub-pixels are turned on 100%, it appears white. By adjusting the individual levels of red, green, and blue light, millions of color combinations are possible

The pixels of the LCD screen were made by circuitry and electrodes of the backplane. Each sub-pixel contains a TFT (Thin Film Transistor) element.  These structures are formed by depositing various materials (metals and silicon) on to the glass substrate that will become one part of the complete display “stack,” and then making them through photolithography. For more information about TFT LCDs, please refer to “

The etched pixels by photolith process are the Native Resolution. Actually, all the flat panel displays, LCD, OLED, Plasma etc.) have native resolution which are different from CRT monitors

Although we can define a LCD display with resolution, a Full HD resolution on screen size of a 15” monitor or a 27” monitor will show different. The screen “fineness” is very important for some application, like medical, or even our cell phone. If the display “fineness” is not enough, the display will look “pixelized” which is unable to show details.

But you see other lower resolution available, that is because video cards are doing the trick. A video card can display a lower LCD screen resolution than the LCD’s built-in native resolution. The video cards can combine the pixels and turn a higher resolution into lower resolution, or just use part of the full screen. But video cards can’t do the magic to exceed the native resolution.

The 161A is a 16 character x 1 row chip on board (COB) alphanumeric display. These classic LCD modules are available in a multitude of LCD and LED backlight color combinations to achieve the perfect look for your product. Some of our most popular combinations are STN yellow-green LCD with yellow-green LED backlight, STN blue LCD with white LED backlight, and STN grey LCD with either blue, amber or pure green LED backlight.

a line of extreme and ultra-narrow bezel LCD displays that provides a video wall solution for demanding requirements of 24x7 mission-critical applications and high ambient light environments

Welcome to the inaugural Serious Integrated blog! Our hope is that these blogs will help reframe the way you think about developing embedded systems and lead you to develop more polished, efficient and modern embedded systems from user friendly human machine interfaces (HMI) through communication and control. Let’s kick-off this first blog with a look at the hardware that makes up the anatomy of a display module.

A display module is not just a Liquid Crystal Display (LCD) that will present a picture to a user and a touch screen for human interaction. A display module is a highly integrated real-time embedded system that is tuned to efficiently interact and communicate with its environment. The LCD and touch screen are certainly important, outward facing factors but behind the scenes, there is much more to a display module than meets the eye. Let’s examine the major hardware components that are included in a display module using the Serious Integrated Module 543 (SIM543) as an example.

It turns out that this isn’t even an exhaustive list but just a quick summary of the major components. The complete list can be gleaned from the SIM543 block diagram shown below:

As you have probably already surmised, a display module is a complicated embedded system and not something that a development team should lightly decide to develop on their own. Let’s take a few moments to discuss a few of these major components.

First, let’s look at the SIM543’s heart, the Renesas Synergy™ S7G2 microcontroller. This real-time microcontroller provides the SIM543 module with an efficient, 32-bit microcontroller that provides all the peripherals and capabilities that one would expect from a modern real-time processor. These capabilities are made accessible to the HMI developer to communicate and interact with external devices through various peripheral interfaces. This makes it possible for the display module to interact in complex ways with its environment and even the cloud if the designer so desires. These capabilities are available through the 60-pin expansion connector or through other connectors available on the SIM.

As would be expected, the S7G2 has a very powerful graphics subsystem that can generate beautiful graphics and interface to a wide variety of LCD’s. To ensure that the graphics and application run smoothly, the SIM543 has several different memory sources that are available for application and storage purposes. These include an internal 3-megabyte flash storage for application code and graphics, an external 2 gigabyte e.MMC flash memory chip which expands this capability and then 640 kilobytes of internal RAM with an additional 32 megabytes of external SDRAM.

Each SIM will also vary slightly in the additional capabilities that are built into the display module. For example, the SIM543 also includes a piezo electric buzzer, an RGB LED and an ambient light sensor. These can be used in an HMI to notify a user audibly or visually that their device requires their attention or even to adjust the backlight duty cycle based on lighting conditions.

While the capabilities that are available in a SIM may at first seem a bit overwhelming, the SIM provides a simple and elegant manner for interacting with it. For example, examine the diagram below. You’ll quickly notice that there are just five connections that a developer needs to be familiar with. First, there is a device USB port that can be used to load a GUI, update the module’s firmware, and communicate with the module during development, production programming, and even in the final system. The SHIP programming port (SPP) also exposes the same USB device port but with a fast attach/detach magnetic connector generally used in the production line equipping of the module as it is installed in the final system. Next, depending on the application, a developer can use the JST 16-pin expansion connector and/or the FCI-60 pin expansion connector to interface to external devices such as control boards, communication devices and so on. The expansion capabilities are left only to the imagination and the requirements of the end application. Finally, there is also a USB host connector available on some models where an application may require an external USB thumb drive for in-system GUI and firmware updates.

As we’ve started to explore, there is far more to a display module than simply an LCD and touch screen. Properly utilizing these capabilities in an application successfully and quickly will dramatically depend upon the software that is used to develop the HMI and that runs the display module. In our next post, we’ll start exploring the software that is required to drive the SIM543 module along with the SHIP Tide software that allows a developer to quickly create an HMI.

As we have seen in today’s post, a display module is not a simple device. Developing one from scratch will take considerable time and be filled with unknown issues; For example, the ability to easily scale the solution and / or support multiple LCD’s. The quickest way to market is to leverage existing technologies and not try to create the entire solution yourself. Ask yourself where your value add is in the design and for everything else, leverage what already exists.
