I’m mostly finished a modification of the adafruit part to convert it to this. I’m done for tonite and busy tomorrow but a part should be along soon (only pcb and the fzp file to finish). I found board dimensions (if not hole nor header placement which are just guesses) on ebay so it won’t be quite correct unless you can measure the placement of the holes and the pins with calipers but it should do the job. The adafruit part looks to be the alternate layout for this same display (only 10 pins in…

In this blog I will show how to connect a 0.96" IPS color display that is 80x160 pixels to Arduino Nano. Then I will try the new Arduino Web Editor to create and later to share this project.

Sometimes it is handy to have a small screen in your Arduino project. The 0.96 inch IPS color diplay is perfect for this. You can get the original Adafruit Color TFT display with SD card readerfor this for $20 (excluding shipping costs), but you can also find a clone on Chinese reseller websites or eBay. Mine did not include a SD card reader, but it was $3 (including shipping).

To make your project better to understand, you can also add board diagrams. This can be done using Fritzing. Just download the version supported by your OS. I have used the Windows 64-bit version and just needed to unzip it and start Fritzing.exe.

In my case I also needed a part that was not in the Fritzing database. Luckily there is a community that submits parts. It is located on the forum page.  Adafruit also has parts on their Github page. To import the part just click the icon in the Parts frame and select Import...

I was now able to create the breadboard diagram. Below you see the breadboard diagram created with Fritzing app of how to connect the display to Arduino Nano.

The display part is Adafruit based, but I have created a table on how to translate the Original Adafruit 0.96" 160x80 Color TFT Display to Chinese Clone IPS 0.96 inch 7P SPI ST7735 module

This 2.2" 18-bit color TFT LCD display breakout uses 4-wire SPI to communicate and has its own pixel-addressable frame buffer, it can be used with every kind of microcontroller. The breakout has an ultra-low-dropout 3.3V regulator and a 3/5V level shifter so you can use it with 3.3V or 5V power and logic and a microSD card holder so you can easily load full-color bitmaps from a FAT16/FAT32 formatted microSD card.

These are nice displays but slow with graphics on an UNO, they recommend only text with the UNO boards due to memory. I tested the graphics on the UNO (Official) and the Elegoo variant UNO boards, both function the same.

Please do note that the Arduino shown in the image above is the classic Arduino Nano. I have this, because there is no library for Maker Nano RP2040 yet inside the Fritzing.
