This 19 in LED Philips 19S4LCB5 monitor with a 5:4 aspect ratio gives you a high-quality display complemented by great features that enhance user convenience. It fits in well with households and serves flawlessly in the office. Great features include SmartImage and SmartContrast - all at a reasonable price. Low consumption and high contrast are then added to the great features of this model. Modern LED backlight technology promises true colour rendering.

Focus Displays offers a wide range of standard full color TFT displays. 64 million unique colors, high brightness, sharp contrast, -30C operating temperature, and fast response time are all good descriptions of a TFT display. This is why TFT technology is one of the most popular choices for a new product.

Thin Film Transistor (TFT) display technology can be seen in products such as laptop computers, cell phones, tablets, digital cameras, and many other products that require color. TFT’s are active matrix displays which offers exceptional viewing experiences especially when compared to other passive matrix technologies. The clarity on TFT displays is outstanding; and they possess a longer half-life than some types of OLEDs and range in sizes from less than an inch to over 15 inches.

CCFL’s are still available, but are becoming a legacy (obsolete) component. TFT displays equipped with a CCFL require higher MOQs (Minimum Order Quantities) than displays with LED backlights.

The majority of TFT displays contain a touch panel, or touch screen. The touch panel is a touch-sensitive transparent overlay mounted on the front of the display glass. Allowing for interaction between the user and the LCD display.

Some touch panels require an independent driver IC; which can be included in the TFT display module or placed on the customer’s Printed Circuit Board (PCB). Touch screens make use of coordinate systems to locate where the user touched the screen.

Resistive touch panels are the lowest cost option and are standard equipment on many TFT modules. They are more common on smaller TFT displays, but can still be incorporated on larger modules.

Resistive touch panels allow a single touch, although advances in new resistive technology will allow multi-touch operation in the near future. One main advantage of a resistive touch screen is the ability to be activated by the touch of any material. This includes a range of items from a bare finger, to a pencil, to even the edge of a credit card; regardless of its composition.

Contrast ratio, or static contrast ratio, is one way to measure the sharpness of the TFT LCD display. This ratio is the difference between the darkest black and the brightest white the display is able to produce. The higher the number on the left, the sharper the image. A typical contrast ratio for TFT may be 300:1. This number ratio means that the white is 300 times brighter than the black.

TFT LCD displays are measured in inches; this is the measurement of the diagonal distance across the glass. Common TFT sizes include: 1.77”, 2.4”, 2.8”, 3”, 4.3”, 5”, 5.7”, 5.8”, 7”, 10.2”, 12.1 and 15”.

TFT resolution is the number of dots or pixels the display contains. It is measured by the number of dots along the horizontal (X axis) and the dots along the vertical (Y axis).

Certain combinations of width and height are standardized and typically given a name and a letter representation that is descriptive of its dimensions. Popular names given to the TFT LCD displays resolution include:

Transmissive displays must have the backlight on at all times to read the display, but are not the best option in direct sunlight unless the backlight is 750 Nits or higher. A majority of TFT displays are Transmissive, but they will require more power to operate with a brighter backlight.

A primary job of the driver is to refresh each pixel. In passive TFT displays, the pixel is refreshed and then allowed to slowly fade (aka decay) until refreshed again. The higher the refresh frequency, the sharper the displays contrast.

The TFT display (minus touch screen/backlight) alone will contain one controller/driver combination. These are built into the display so the design engineer does not need to locate the correct hardware.

If you do not see a Thin Film Transistor (TFT) Display module that meets your specifications, or you need a replacement TFT, we can build a custom TFT displays to meet your requirements. Custom TFTs require a one-time tooling fee and may require higher MOQs.

Ready to order samples for your TFT design? Contact one of our US-based technical support people today concerning your design requirements. Note: We can provide smaller quantities for samples and prototyping.

Take your design to the next level with our range of TFT Displays including latest IPS TFT, circular and bar shape as well as large size TFT. With or without touch, these are fully customisable to your system requirements.

TFT-LCD technology is now fairly mature. As a result, manufacturing processes are efficient and production yields are high, leading to very competitive unit prices. Upgrading from a monochrome display to a TFT is now an affordable way to give your product an uplift.

Users of industrial display devices are wanting the same experience they have come to expect from a consumer device with all-round viewing angles. Switching to a superior IPS TFT display has become very cost effective as production increases and unit prices decrease.

Choosing a circular display for your next product design could really set you apart from your competition. Models are available from 1" to 4.2"in TFT, PMOLED and AMOLED, we have something to suit every application.

Large TFT display systems are increasingly being used for transportation information, retail signage and vending machines and kiosks. We can supply a large range of TFT solutions up to 65" diameter and in bar-style, square or rectangular configurations.

We are now offering increasing cover lens customisation options and processes to make your TFT LCD user interface truly stand out! Anders’ experienced marketers and engineers work with our manufacturing partners around the world to keep informed of the latest innovations, including mirrored glass,tinted glass, spot-facing, three dimension glass, and many more!

See below our range of TFT Displayswith sizes ranging from0.96" to 64.5" and including circular and bar type shape. All our displays can be tailored to suit your application antimicrobial coating technology,

A TFT display is a form of Liquid Crystal Display with thin film transistors for controlling the image formation. The TFT technology works by controlling brightness in red, green and blue sub-pixels through transistors for each pixel on the screen.

Compare IPS vs TFT displays - the TFT display is the display of choice for industrial designs, but it can have its limitations. A newer technology called IPS (in plane switching) offers better viewing angles and colours, but is it really the best choice - we discuss benefits and negatives of both types of TFT display.

LCD display doesn’t operate the same way as CRT displays , which fires electrons at a glass screen, a LCD display has individual pixels arranged in a rectangular grid. Each pixel has RGB(Red, Green, Blue) sub-pixel that can be turned on or off. When all of a pixel’s sub-pixels are turned off, it appears black. When all the sub-pixels are turned on 100%, it appears white. By adjusting the individual levels of red, green, and blue light, millions of color combinations are possible

The pixels of the LCD screen were made by circuitry and electrodes of the backplane. Each sub-pixel contains a TFT (Thin Film Transistor) element.  These structures are formed by depositing various materials (metals and silicon) on to the glass substrate that will become one part of the complete display “stack,” and then making them through photolithography. For more information about TFT LCDs, please refer to “

The etched pixels by photolith process are the Native Resolution. Actually, all the flat panel displays, LCD, OLED, Plasma etc.) have native resolution which are different from CRT monitors

Although we can define a LCD display with resolution, a Full HD resolution on screen size of a 15” monitor or a 27” monitor will show different. The screen “fineness” is very important for some application, like medical, or even our cell phone. If the display “fineness” is not enough, the display will look “pixelized” which is unable to show details.

PPI stands for number of pixels per inch. It is kind of pixel density. PPI describes the resolution of a digital image, not a print. PPI is used to resize images in preparation for printing

But you see other lower resolution available, that is because video cards are doing the trick. A video card can display a lower LCD screen resolution than the LCD’s built-in native resolution. The video cards can combine the pixels and turn a higher resolution into lower resolution, or just use part of the full screen. But video cards can’t do the magic to exceed the native resolution.

Aspect Ratio:  You might hear 4:3 which is full screen, 16:9 is for widescreen; 21:9 is for ultrawide computer monitors and televisions, as well as cinematic widescreen projectors. Some ultrawide monitors are trying to replace dual monitor.

Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Volume, Mute, Recall Defaults, Audio Select, Power LED ON/OFF, Touch Thru

Review Display Systems is now able to source, supply, and support an extensive line-up of cost-effective, industry-standard 7.0-inch TFT display modules that are suitable for use in a broad range of industry sectors, applications, and operating environments.

The 7.0-inch display modules feature a 16:9 widescreen aspect ratio and are available in a variety of resolutions including 800 x 480 pixels (WVGA), 1024 x 600 pixels (WSVGA), and 1280 x 800 pixels (WXGA). In-plane switching (IPS) is available on some of the 7.0-inch display modules which enable exceptional optical performance, highly consistent color reproduction, and wide viewing angles. Long-lifetime LED backlights with brightness specifications from 300cd/m² up to high luminance 1500cd/m² versions are supported. For harsh environments, an extended operating temperature range of -30°C to +85°C is also available.

Aspect ratio is the relationship of the width of a video image compared to its height. The two most common aspect ratios are4:3, also known as 1.33:1 or fullscreen, and 16:9, also known as 1.78:1 or widescreen. (Larger aspect ratio formats are used in the motion picture industry.)

All the older TV’s and computer monitors you grew up with had the squarish 4:3 shape– 33% wider than it was high. These are often referred to as square monitors.  4:3 LCD monitors can display analog video signals that conform to NTSC and PAL standards. They are not capable of displaying HD (high-definition) video.

The 4:3 aspect ratio dates back to 1917, when the Society of Motion Picture Engineers adopted it as the standard format for film. In the 1930’s, the television industry adopted the same 4:3 standard. But in the mid-1950’s, the motion picture industry began developing several widescreen formats to improve their decreasing audience numbers. Television broadcasting stayed with the 4:3 standard, until the recent move to HDTV and 16:9 widescreen.

16:9 is the native aspect ratio of most high-definition widescreen LCD monitors and TV’s (16:9 and 16:10 are very similar). It is 78% wider than it is tall, and fully one-third wider than a 4:3 screen. 16:9 widescreen monitors are ideally suited to display HD video signals. Some models can also display SD (standard definition) video signals, but this will require some compromises, as you will read below.

Nearly all experts agree that in order to display optimal video images, it is critical to match the aspect ratio of the monitor to the aspect ratio of the camera (or other incoming video source). Below is a example of a 16:9 image on a 16:9 widescreen lcd monitor:

However, many cameras in the industrial, commercial, security, and law enforcement industries still utilize 4:3 CCD or CMOS imagers. Therefore, to display clear, undistorted video images, it is important to utilize monitors with the same 4:3 aspect ratio to match the cameras. Failure to do so will result in distorted images, as shown below.

Unfortunately, despite the continued widespread use of 4:3 cameras, LCD monitors with a 4:3 aspect ratio are getting harder and harder to find. Many manufacturers have abandoned them in favor of the newer 16:9 widescreens. TRU-Vu Monitors still offers a complete line of industrial-grade 4:3 aspect ratio LCD monitors. These range in size from 5.5″ to 19″ screens. They are available with standard, waterproof, steel or open frame enclosures. They can be touch screen,  sunlight readable, medical-grade, or optically bonded.

16:9 widescreen LCD monitors are the ideal complement to 16:9 format HD cameras. These are increasingly used in video conferencing, broadcast and medical applications. They display superb, distortion-free, high-definition images. TRU-Vu Monitors offers these in 7″, 10.1″, 13.3″, 15.6″, 17.3″, 18.5″ and 21.5″ to 65” LCD screen sizes, in standard, touch screen, sunlight readable, medical-grade, optically bonded and open frame configurations.

You must avoid video images which are stretched, chopped, squeezed, shrunk or distorted. Be sure to choose a LCD monitor with the correct aspect ratio (4:3 aspect ratio or 16:9 aspect ratio) that matches your camera or other incoming video signal.

Whether you"re shooting still or video with your DSLR, sometimes you need a bigger screen than the tiny monitor built into your camera. The 7 inch screen gives directors and camera men a larger view finder, and the 16:9 aspect ratio.

Professional camera crews and photographers require accurate colour representation on their field monitor, and the 619AT provides just that. The LED backlit, matte display has a 500:1 colour contrast ratio so colours are rich and vibrant, and the matte display prevents any unnecessary glare or reflection.

LCDR5U09-01 is a true manufacturer of LCD CCTV monitor. This monitor is true Commercial Grade with FCC Class A Certification - Built to Run 24 x 7 x 365 continuously. The monitor is designed, engineered and manufactured with CCTV PCB boards and circuitry making these the LCD solution for your security surveillance.

The LCDR5U09-01 is dual 5U Rack Mount Ready LCD CCTV monitors with Tilt capability are designed with a Metal Cabinet and chrome handle is ready to be installed into rack mount cabinets. It is ideal for Factory Control Rooms, Automotive, Marine, Industrial Panel PC, and special Kiosk applications.
