Resistive touch screens were launched about 20 years ago with a lower cost-benefit and a pressure-sensitive surface to react with various objects such as your finger, glove, pencil or specialist tools. Resistive touch technology remains the popular choice for factory automation. Some drawbacks for resistive touch technology include the need for calibration from time to time, a driver is needed for new installations, and the surface of the resistive touch display has a limited lifetime. The resistive touch technology also suffers from reduced light transmittance in comparison with PCAP, therefore, decreases the sought-after high brightness of the underlying TFT-LCD.

Assured Systems provide 3 different surface coatings for PCAP touch screen computers; Anti-Reflection, Anti-Glare and Anti-Fingerprint. These surface coatings can be utilised in both indoor and outdoor environments by enhancing the optical performance of displays.

A chemical-based surface treatment, otherwise known as a chemical AG process, is applied directly to the glass display surface to form micro asperities and give the glass an anti-glare effect under the likes of sunlight. It does not generate any of the minute flaws or micro-cracks that are characteristic of mechanical AG processes and therefore maintains the high surface strength of the glass.

The other way for AG treatment is manufactured by a controlled acid etching process yielding uniform diffused surfaces for anti-glare. Varying levels of diffusion specified as gloss yield different levels of reduced glare. A lower gloss reading denotes a more diffuse panel. The haze ratio of AG glass used on OGS touch screen products cannot be too high, because high levels of haze would affect LCM transmittance. See below figure to have more understanding of specification categories for anti-glare glass.

An Anti-Reflection (AR) coating is a type of optical coating applied to the surface and other optical elements to reduce reflection by the vacuum evaporation process. In typical imaging systems, this improved efficiency since less light is lost due to reflection. In a complex system such as telescopes and microscopes, the reduction in reflections also improves the contrast of the image by elimination of stray light.

The Anti-Fingerprint coating constructions of the advantages of the preferred embodiments like the user are prevented from being imprinted on the surface, and it remains clean and aesthetically pleasing. AFP coating makes it possible to wipe up smudge on the surface very quickly and also has a tremendous hydrophobic performance and protects AR layers and reduced friction and low surface energy and improves scratch resistance. The hydrophobic performance is evaluated each lot by measuring the contact angle. The AF effect is realized by applying a nano-coating to reduce the optical contrast of fingerprints.

The AFP effect means that fingerprint on the surface cannot be seen at all by the naked eye, or only very slightly. Although the fingerprint is on the surface, it is essentially “invisible.” The colour to be coated under visible and infrared light is transparent. The coating is with characteristics like low coefficient of friction, contact angle >100 degrees. It utilizes a vacuum coating process which is also thinner and more even than spread coating.

Anti-Vandal display protective films work by protecting the glass substrate from damage and can be easily removed and replaced by a new film. This provides a quick on a cost-effective solution for those required to maintain public and private spaces from the damage and visual distortion caused by graffiti and reckless vandalism.

Anti-UV protective films are applied for outdoor Panel PCs which are operating in both outdoor and semi-outdoor applications. Even though that is indirect sunlight for the touch surface, there are still ultraviolet light that can damage the structure of touch and cause OCA film yellowing and aging issues. Anti-UV films also reject up to 97% of infrared light coming from sunlight and insulation up to 60% of the heat keep touch surface and system away from heat issues.

The Aegex Anti-Glare Screen Protector is VMAX tempered glass that is bubble free, anti-scratch, dust-proof, and water-proof. Suitable for the aegex™10 Intrinsically Safe Tablets.

AR Coating, with the advanced magnetron-sputtering technology, is tocoat anti-reflecting layer on the tempered glass, for efficientlydecreasing reflectance but increasing transmittance, making the colorthrough the glass much purer.

AF Coating is to make pollutant stick to the surface more difficultly, in order toachieve anti-fingerprint. With the coating layer on it, the glass also becomes anti-scratch
