This is a page where you can find common laptop/desktop LCD panel pinouts and see if your laptop screen"s pinout matches any one of them (it likely does!).

This is a very common pinout for higher-resolution CCFL displays. If you have a 1440x900, 1400x1050 or 1680x1050 panel, it"s likely using this pinout.

This is a pinout for desktop LCD monitor screens - laptop panels do not use this pinout (if there are some, let me know). If you"re ordering a MT6820 (MT561) board, it will arrive with a cable that has this specific pinout and is therefore incompatible with laptop screens - as you"re likely here to reuse a laptop screen, you will want to either rewire the cable you get, or order a suitable cable (for either A or B pinout, whichever you need) from the beginning.

This is a pinout for older, 1024x768 and similar laptop screens, CCFL-equipped ones. 1024x768 screens used both the A pinout, this pinout and even a different pinout with a connector I haven"t made a description for yet, so if you have a 1024x768 screen you"d like to reuse, there"s three possible options and you need to check which one you have before you buy/reuse/build a cable.

This is a pinout that"s, apparently, specific to a select range of 18.5" 1366x768 displays used in desktop LCD monitors. It"s not compatible with either A, B or C pinouts, and requires a specifically wired cable.

In some datasheets, the pinout will list extra pins - one before and one after the main pins, both would be described something like "shield GND". So, for a FI-X 30-pin connector, you might find a pinout in your datasheet that lists 32 pins instead of 30. These two pins are not "real" connector pins and you shouldn"t worry about them - they"re pins that the manufacturer decided to mention for some reason, but they"re not relevant when you are actually connecting to the panel.

LCD panel interfaces have changed over the years as resolutions have moved from 640×480 to 3840×2160. The following outlines the common ones that we support with our LCD controllers and cable kits. They cover most of the large size and higher resolution LCD panels on the market:

LVDS: LVDS was introduced in the late 1990’s and enabled connection for higher resolution panels with the benefit of reducing EMI. The LVDS interface is supported by most Digital View LCD controllers and covers panel resolutions from 640×480 to 3840×2160 though newer formats are replacing it for higher resolutions. It remains very popular for HD type resolutions, ie up to around 1920×1200. Most LCD panel manufacturers have LCD panels supporting LVDS, including AUO, BOE, Innolux, JDI, Kyocera, LG, Mitsubishi, Sharp, Tianma. LVDS is Low Voltage Differential Switching.

V-by-One: Increasingly common on 4K resolution panels typically 55″ and larger though I did find a 32″ 1920×1080 panel and 28″ 3840×2160 panel listed as in production. A benefit of V-by-One compared to LVDS is the reduction in cables for high resolution signal support and reduced EMI. LCD panel brands using V-by-One include AUO, BOE, Innolux, LG, Samsung, Sharp. I thought of V-by-One as replacing LVDS but apparently it was developed to replace FPD-Link.

eDP: First introduced in 2008 it is widely adopted by LCD panels used in laptops and similar devices. We are also now seeing it being used in higher resolution and brightness LCD panels but still typically smaller sizes, ie 30″ or smaller. Digital View LCD controller models supporting eDP include SVX-4096, SVX-2560, SVH-1920v2 and the new DD-1920-HDMI-EDPT. Brands using it include AUO, BOE, Innolux, LG, Panasonic, Samsung, Sharp, Tianma.

TTL: Supported by the ALR-1400v2 and HLR-1400v2 controllers this was the common panel interface when Digital View was founded in 1995. VGA (640×480) to XGA (1024×768) resolutions were mainstream at that time. Still used in commercial and industrial display applications AUO, Innolux, Kyocera, Mitsubishi, Samsung, Sharp, Tianma have LCD panels in production with resolutions such as 640×480, 800×480, 800×600, 1024×768. The name TTL is short for Transistor-Transistor Logic.

FPD-Link: The original low voltage differential switching signal but not to be confused with the LVDS interface on many panels as described above. It is now often used in the automotive market and currently up to FPD-Link III. It is not currently supported by any Digital View’s standard controller models though we are looking at it as a custom development option.

16x2 LCD modules are very commonly used in most embedded projects, the reason being its cheap price, availability, programmer friendly and available educational resources.

16×2 LCD is named so because; it has 16 Columns and 2 Rows. There are a lot of combinations available like, 8×1, 8×2, 10×2, 16×1, etc. but the most used one is the 16×2 LCD. So, it will have (16×2=32) 32 characters in total and each character will be made of 5×8 Pixel Dots. A Single character with all its Pixels is shown in the below picture.

Now, we know that each character has (5×8=40) 40 Pixels and for 32 Characters we will have (32×40) 1280 Pixels. Further, the LCD should also be instructed about the Position of the Pixels. Hence it will be a hectic task to handle everything with the help of MCU, hence an Interface IC like HD44780is used, which is mounted on the backside of the LCD Module itself. The function of this IC is to get the Commands and Data from the MCU and process them to display meaningful information onto our LCD Screen. You can learn how to interface an LCD using the above mentioned links. If you are an advanced programmer and would like to create your own library for interfacing your Microcontroller with this LCD module then you have to understand the HD44780 IC working and commands which can be found its datasheet.

We come across Liquid Crystal Display (LCD) displays everywhere around us. Computers, calculators, television sets, mobile phones, and digital watches use some kind of display to display the time.

An LCD screen is an electronic display module that uses liquid crystal to produce a visible image. The 16×2 LCD display is a very basic module commonly used in DIYs and circuits. The 16×2 translates a display of 16 characters per line in 2 such lines. In this LCD, each character is displayed in a 5×7 pixel matrix.

Contrast adjustment; the best way is to use a variable resistor such as a potentiometer. The output of the potentiometer is connected to this pin. Rotate the potentiometer knob forward and backward to adjust the LCD contrast.

A 16X2 LCD has two registers, namely, command and data. The register select is used to switch from one register to other. RS=0 for the command register, whereas RS=1 for the data register.

Command Register: The command register stores the command instructions given to the LCD. A command is an instruction given to an LCD to do a predefined task. Examples like:

Data Register: The data register stores the data to be displayed on the LCD. The data is the ASCII value of the character to be displayed on the LCD. When we send data to LCD, it goes to the data register and is processed there. When RS=1, the data register is selected.

Generating custom characters on LCD is not very hard. It requires knowledge about the custom-generated random access memory (CG-RAM) of the LCD and the LCD chip controller. Most LCDs contain a Hitachi HD4478 controller.

CG-RAM address starts from 0x40 (Hexadecimal) or 64 in decimal. We can generate custom characters at these addresses. Once we generate our characters at these addresses, we can print them by just sending commands to the LCD. Character addresses and printing commands are below.

LCD modules are very important in many Arduino-based embedded system designs to improve the user interface of the system. Interfacing with Arduino gives the programmer more freedom to customize the code easily. Any cost-effective Arduino board, a 16X2 character LCD display, jumper wires, and a breadboard are sufficient enough to build the circuit. The interfacing of Arduino to LCD display is below.

The combination of an LCD and Arduino yields several projects, the most simple one being LCD to display the LED brightness. All we need for this circuit is an LCD, Arduino, breadboard, a resistor, potentiometer, LED, and some jumper cables. The circuit connections are below.

As an Industrial LCD module distributor, we can supply a wide range of TFT LCDs in many sizes. Common resolutions are QVGA, VGA, SVGA and XGA. Wide aspect ratio displays are also available in many similar sizes and resolutions such as WQVGA, WVGA, WSVGA, and WXGA.

Our industrial LCD suppliers are manufacturers with different capabilities specially designed for a wide variety of industrial applications. High-brightness, sunlight readability and long life product guarantees are some of the special features available.

Get in touch to work closely with one of our LCD Solutions Specialists to determine the perfect display for your project. We can also recommend and supply the proper LCD controller board, inverter, LED driver, cables, touch screen, or other associated enhancement.

Character LCD modules are one of the most popular LCD technologies thanks to their ease of programming, low cost, low power consumption, and short lead times. They can be seen in a wide variety of products.

Most character LCDs are driven by an eight-bit parallel interface which makes use of the standard HD44780 protocol. The display has sixteen pins/connections to drive both the LCD and the optional LED backlight.

A character LCD contains several 5x8 pixel character blocks. Each block has five (5) dots across and eight (8) dots up and down. These dots are turned on and off to generate all possible characters.

Monochrome character, graphic and static displays require different input voltages. All the different LCD voltage symbols can be confusing, but believe it or not, there is a system to the madness.

This LCD voltage terminology originated from the terminals of each type of transistor and their common connections in logic circuits. In other words, VCC is often applied to BJT (Bipolar Junction Transistor) collectors, VEE to BJT emitters, VDD to FET (Field-Effect Transistor) drains and VSS to FET sources. Most CMOS (Complementary metal–oxide–semiconductor) IC data sheets now use VCC and GND to designate the positive and negative supply pins.

In the Pleistocene era (1960’s or earlier), logic was implemented with bipolar transistors. NPN (Negative-Positive-Negative) were used because they were faster. It made sense to call positive supply voltage VCC where the “C” stands for collector. The negative supply was called VEE where “E” stands for emitter.

When FET transistor logic came around a similar naming convention was used, but now positive supply was VDD where “D” stands for drain. The negative supply was called VSS where “S” stands for source. Now that CMOS is the most common logic this makes no sense. The “C” in CMOS is for “complementary” but the naming convention still persists. In practice today VCC/VDD means positive power supply voltage and VEE/VSS is for negative supply or ground.

Pin three (3) is Vo and is the difference in voltage between VDD and VSS. This LCD voltage is adjusted to provide the sharpest contrast. The adjustment can be accomplished through a fixed resistor or a variable potentiometer. Many products have firmware that monitor the temperature and automatically adjust the contrast voltage.

In a Liquid Crystal Display (LCD), V0 is used to vary the screen brightness or contrast. Contrast, simply put is the ratio of the light areas to the dark areas in a LCD. This is usually done in a production setting with values which are optimized for most users. Temperature can have an undesirable effect on the display brightness and for this reason a varying resister or potentiometer is used to accommodate the desires of the user.

Below is a data sheet of a 16x2 Character LCD module that shows various recommended driving voltages. The LCD voltage can range from MIN (minimum) to TYP (Typical) to Max (maximum).

If the supplied LCD voltage drops too low, the display is ‘under-driven’ and will produce segments that are ‘grey’. The lower the LCD voltage falls below the acceptable threshold, the lower the contrast will be.

If the LCD is over-driven, you may see ghosting. This is where segments that should not be ‘on’ are gray. They are not as dark as the segments that should be on, but they can be seen and may cause confusion for the end user.

There are times when a customer needs to replace a display that has been discontinued or EOL (End-Of -Life) by their previous LCD supplier. The previous LCD’s pin-outs may be different than Focus’ standard, off-the-shelf display. This is not a large problem to overcome.

LED backlights are DC (Direct Current) driven and can be supplied from any one of three locations. The most popular is from pins 15 and 16. The second most popular option is to draw power from the ‘A’ and ‘K’ connections on the right side of the PCB.

The third option is to pull power from pins one and two. This is the same location from which the LCD is pulling its power. Focus does not recommend this option and can modify the PCB for the customer to connect the backlight from a different location.

Many LCD Modules will require more than one internal voltage/current. This may make it necessary for the customer to supply the needed inputs. They may need to supply 3V, 5V, 9V, -12V etc.

The solution for this is to integrate a charge pump (or booster circuit) into the LCD circuitry. This solution works in most applications, but if the product will be operating in an intrinsic environment, care must be taken with layout of the circuit board.

Intrinsically-safe LCDs are Liquid Crystal Displays that are designed to operate in conditions where an arc or spark can cause an explosion. In these cases, charge pumps cannot be employed. In fact, the total capacitive value of the display needs to be kept to a minimum.

Focus Display Solutions does not build a display that is labeled ‘Intrinsically safe’ but we do design the LCD to meet the requirements of the engineer. In meeting the design engineer’s requirements, the display may need to contain two or three independent inputs. Focus can redesign the PCB and lay out the traces to allow for these additional inputs.
