​You"re on the right track to successfully repairing your Vizio D43N-E1! Now that you"ve identified your model, we highly recommend matching the part number on the part(s) you"re replacing to ensure compatibility. ​If you don"t see your part listed below, please try searching by your part number or contact us for help!

That said, there"s been a lot sacrificed here to keep the price down. The design, menus, and remote are dressed down a bit compared to Vizio"s 2017 E Series, which uses a "Smart Cast" system that requires a second screen and Google Cast to operate the TV"s menus and smart system. The 55-inch 4K set we tested also just didn"t perform very well over all, which is bad news considering performance is just about the only possible upside with a series that"s this stripped down.

There"s a TON of D Series TVs this year (just like last year), and they vary a lot across the range of sizes. About half of them are 1080p or less resolution, though you"ll find the key picture quality ingredient—full-array local dimming, or FALD—on most models. Most of them are smart, as well, but none of them include the Vizio "Smart Cast" system nor the second-screen functionality you"ll find with the 2017 E Series, M Series, and P Series.

Included with the TV, you"ll also get the standard Vizio remote: a shiny, black-plastic clicker that features a reliable button layout and the usual volume/channel rockers, plus app hotkeys for things like Netflix and Hulu Plus. It"s also not going to drop any jaws, but it works great.

However from a picture quality/screen contrast perspective, any FALD TV is almost always a better option, than an edge-lit model, and that"s still the case here. That said, while contrast is one of the D Series" best qualities—it produces rich, satisfying shadow tones and good, neutral highlights—it"s not going to blow you away. In Calibrated Dark mode, I measured average black levels around 0.0063 nits and a reference white point of about 125 nits. While this is definitely not a bad result for a budget-range LCD TV, it lacks the really impressive black level of some of Vizio"s other models.

It also doesn"t help that the D Series delivers its usual somewhat narrow viewing angle (which is to be expected with this kind of LCD tech), and being locked at a 60 Hz refresh rate is not the best choice for motion during non-standard content like Blu-rays.

Good alternatives here are to spend a little more on Vizio"s slightly pricier but HDR-equipped E Series, or check out the comparably priced models from manufacturers like Hisense and TCL, which we"ll be reviewing a little later in the summer.

This single stud articulating arm wall mount fits Vizio D43n-E1 43 inch displays. This 31.5 inch long extending arm offers maximum adjust ability, including horizontal extension, 90� of side to side swivel, as well as having adjustable tilt capabilities to help reduce overhead glare. This wall plate attaches to a single stud. Fits VESA 100x100mm up to 600x400mm

Vizio’s D-Series 43n-E1 is meant to offer a basic option for customers who don’t need the most cutting edge TV set. While the brand offers many UHD sets with various other features. The D43n is a bare bones television that promises to deliver only where it counts, but we’ll see how much it delivers on that promise.

The picture quality of the D43n is very impressive for its price range and for being an LCD TV. The technology referred to as “full array LED lighting” means that the screen produces its light from behind the glass in a uniformed manner, making the image look vibrant and crystal clear from any viewing angle.

Anyone who doesn’t want to spend over $1000 on a television should definitely consider getting Vizio’s D43n. While it doesn’t have many features, what it does do for the most part is quite impressive. It’s one of the best 1080p screens in its price range and size, and will satisfy anyone who doesn’t need 4K or the perks of wi-fi compatibility. The D43n won’t impress everyone, but it will certainly please the specific audience it’s aiming for. Check Current Price on Amazon

The design of the Vizio D Series 1080p 2017 is similar to most other recent Vizio TVs. The stand looks the same as the E Series 2017 and is slightly more stylish than the 2016 model. The whole body of the TV is plastic, and the TV appears a bit thick when viewed from the side.

The stand of this Vizio is very similar to other Vizio TVs from this year and previous years. It is almost as wide as the TV, and is made of plastic but supports the TV well and feels stable.

The borders of this Vizio have an average thickness and look quite basic. They do have a slight textured finish on the side though, which is a good touch.

The 2017 Vizio D 1080p TV has a disappointing contrast ratio. With a contrast ratio of 800:1, this place this TV in the lower ranking of the 2017 TV we have tested, even when compared to other IPS TVs. When set in a dark room, blacks look more like gray and dark scene really suffer. When set in a brighter room setting, the picture quality is a bit better, but the image won"t have as much of an impact than other IPS with a higher contrast ratio.

Update 01/24/2018: The 50" model (D50f-E1) likely uses a VA panel, as explained in this Q&A. We expect it to have a much higher contrast ratio, similar to last year"s D50-D1, but a worse viewing angle.

The Vizio D 1080p 2017 does not have a local dimming feature. There is an option named "Backlight Control", but this is not a local dimming feature, but more a frame dimming, which dims all the screen depending on what is displayed on the screen.

Decent viewing angle, even for a TV with an IPS panel, and far better than all TVs with a VA panel. Blacks stay black, and colors and brightness remain decent when the TV is viewed at moderate angles. This makes this TV a good choice for a room where people often sit to the side of the TV and view it from an angle.

The black uniformity of the Vizio D 1080p 2017 is poor. Flashlighting is visible on each corner and near the edge of almost all the screen leaving almost only the center of the screen free of real uniformity issues.

The Vizio D Series 1080p 2017 is decent at handling reflections. It has a semi-gloss finish which diffuses reflections across the screen, reducing their intensity. It should be fine for an average-lit room but may be an issue in a bright room.

After calibration, the Vizio D 1080p 2017 has an excellent accuracy. The white balance dE was brought down to 0.87, which is accurate enough that most people would not notice the inaccuracy. The Color dE was brought down to 1.49, which is a big improvement over the dE of 5.06, but with a dE of 1.49, professional would still notice some color inaccuracy. As for the gamma, it is now tracking more closely our 2.2 target, but the dip in the brighter IRE points could not be corrected to bring the gamma curve completely flat.

The Vizio D 1080p 2017 perform well displaying our gradient test image. 8-bit banding is visible, particularly in the blue shade of color, leaving the rest of the color and grayscale free of issues. Since this TV does not support HDR, an 8-bit panel does cause any issues as SDR content only support 8-bit content.

The Vizio D series is great at showing content smoothly, without stutter. For 60Hz content such as sports the image appears very smooth, as the image doesn"t remain static (the frame changes before the transition completes). For 24Hz content such as movies the image is also smooth, as the static image time is reduced by half.

The 2017 Vizio D 1080p TV can display without judder 24p movies playing from 24p sources like DVD and Blu-ray players. When 24p movies play via 60p/60i sources, they do present judder and there is no way to remove it, unfortunately.

Only basic resolutions are supported. The TV cannot show 4k as it has a 1080p panel, and it cannot properly show 4:4:4 color, even in the computer picture mode, so when using the TV as a PC monitor text may appear a little unclear.

There are various panel technologies. Each has its own specific features - viewing angles, color reproduction, response time, brightness/contrast, production cost, etc. The image quality depends directly on the type of the display panel used.IPS

The most widely used panels are those with 6, 8, and 10 bits for each of the RGB components of the pixel. They provide 18-, 24-, and 30-bit color, respectively.8 bits

Frame Rate Control (FRC) is a method, which allows the pixels to show more color tones. With quick cyclic switching between different color tones, an illusion for a new intermediate color tone is created. For example, by using FRC, a 6-bit display panel is able to show 16.7 millioin colors, which are typical for 8-bit display panels, and not the standard 262200 colors, instead. There are different FRC algorithms.No

The maximum number of colors, which the display is able to reproduce, depends on the type of the panel in use and color enhancing technologies like FRC.16777216 colors

The backlight is the source of light of the LCD display panels. The type of backlight determines the image quality and the color space of the display. There are various backlights such as CCFL, LED, WLED, RGB-LED, and etc.Direct LED
