Many backup camera with monitor today are sold as a package that includes the camera, wiring, and in-car rear view monitor. Some cameras, on the other hand, are stand-alone and you need to purchase a monitor separately or use an existing display in your car if you have one.

A sat nav system and monitor are standard features in most current cars. If your vehicle has one of these, you should be able to plug your camera directly into it as long as the two are compatible.

If you purchase an OEM (Original Equipment Manufacture) camera for your car, chances are it will work with the monitor currently in your dash if you have one.

If you don’t currently have a dashboard monitor, you should consider purchasing an aftermarket one. And there are plenty of aftermarket reverse camera monitors that can be retrofitted.

For the system to be useful, you want it to provide a clear image of what’s behind you. The clarity of the picture will be determined by the quality of the camera and the resolution of the display.

TFT-LCD displays produce the best images, especially when combined with a high-quality CCD camera. They are digital and hence easy to repair if something goes wrong.

Note: When looking for monitors, you will almost certainly come across the term “LED Panel” at some point. An LED panel is an LCD screen with a backlight made of LEDs (Light Emitting Diodes).

Almost all rear view monitors will have two inputs to facilitate the usage of two cameras. Some advanced monitors would allow for up to four cameras to be displayed in a split screen or quad screen layout.

A rear view mirror monitor is ideal for all vehicle types since it can be reflective (serving as both a rear view mirror and a monitor for the backup camera) or unreflective (serving only as a monitor for the backup camera).

If you’re interested in learning more about car backup camera monitors, you can take a look at some of these commercial-grade backup camera monitors to see if they would be the right fit for you.

The RVS Systems rearview camera system has two viewing options: camera view can be triggered when the vehicle is put into reverse, or remain on continuously. System includes 7” LED color monitor with distance grid lines and mirror image capability, 3-channel multiplexer with automatic system switch, CCD backup camera with 50-ft. Infrared night vision, and mounting wires and connectors. Camera is completely waterproof.

ear view cameras, also known as reversing cameras or backing cameras, make parking, driving and backing up a safer experience for everyone. If you are in the market for this type of product, we highly recommend our Esky 7-Inch TFT LCD Monitor Car Rear View Backup Camera System! What’s more, one camera of this system can be used as the side camera to make a turn safely for Trailer Tow, RV Truck. (NOT FOR COMPACT CARS)

– CCD camera with 2.1mm wideangle lens. This offers a super wide field of view angle at 135°. Most other manufacturers use 3.6mm or 2.8mm lens, the view angle is much narrower. You can see more areas by using 2.1mm lens

– 2 X CCD cameras with IR LEDs; 1 X 7″ TFT LCD color monitor; 1 X Mount; 2 X 66ft cables; 1 X Remote control; 1 X Power connection wire(video connectors are built-in this wire); 1 X Screw kit; 1 X User manual
