I tie wrapped mine to my rear view mirror (truck with cap - zero rearward visibility), camera on license plate. I very carefully wrapped the camera in electrical tape in an effort to stave off the moisture some have said they had. I even taped the edges of the lens, that looked to be the likeliest point of entry.

I initially had the camera powered from an always on source but then got wondering about the current draw (10 mA maybe????) and how long it would take to drain the battery if the truck sat for awhile. I then was also thinking about the lifetime of the LED"s themselves.

So then I moved the power to a reverse wire (disconnected from a piercing backup horn). This was great but I soon realized that I wanted the screen on at other times too. So I was going to get a toggle switch and pull another cable into the cab but then I realized that this F150 XL doesn"t have daytime running lights (really). So I opened up a taillight assembly and tapped off one of the lights. Now my switch is the headlamp switch, they should be on all the time anyway, if you ask me.

I had one gotcha with the video cable. With the camera plugged right into the display it was great but when using the long cable there was no device seen. Seeing how some have written about quality of the video cables I ended up cutting the RCA plugs off and soldering the cables together. One of the ends was bent badly and the connector was loose inside the plastic piece, so I just went ahead and did it.

It didn"t work, still no picture. Totally perplexed I changed inputs on the display and there was the image. Yikes! The camera is a female end, when plugging into the display pigtail directly the male end on the display in input #1. However, the long video cable is male-male which means it uses the other connector on the display, the female one. This is input #2. Oh well.

A nice feature of this unit is the mirror image reversing that can be done both up and down and left - right. I have the display upside down and I was able to invert the image and also remove the mirror image effect. A comical point is that the text on the screen is mirror imaged now, it inverts everything, not just the camera image. You would think it would invert the image and then superimposes the text on top of that. Also, the grid lines don"t move as you flip the image. Not a big deal.

Now I wait to see if it lasts. I am going to get a pinhole camera for the second input - put it on the right front corner. I"m terrified of scraping a car as I turn into a parking spot.

The Accele camera easily mounts over your license plate and produces a nice image in every type of lighting, with good color reproduction and contrast.

No matter which display we hooked the Accele RVCLPMBS up to, it provided the best image across the most lighting conditions, with good color reproduction and enough contrast and dynamic range for us to see the detail of objects behind us. It installs quickly to the top of any standard US-size license plate without blocking registration tags in the corners, and you can tilt the center-mounted camera without much effort, so dialing in just the right view is easy. Since the Accele camera needs to be wired directly to a display, you can have a pro set it up for about $150, or you can install the system yourself (we did it in an afternoon).

If you’re on a tight budget, the Pyle PLCM38FRV is an adequate backup camera that you can buy for about the price of a multi-topping pizza. In pretty much every aspect, this camera is “just okay,” providing a usable image with fair color accuracy. But it avoids some of the flaws we saw in other, more-expensive cameras, such as low-light static, weird color casts, and blown-out images in bright sunlight. The Pyle model has better dynamic range at night than in bright sun, but otherwise it consistently did the job in all of our testing. If you choose to use the center-mount bracket, you’ll need to bend the bracket to aim the camera properly, or you can drill a hole to mount the camera right into your trunk lid.

If you want something that’s easier to install, the Look-It Wireless Rear Vision System doesn’t require any wiring: The battery-powered camera, embedded in a custom license-plate frame, transmits video via Bluetooth to any iOS or Android device (presumably sitting in a smartphone car mount). However, it’s not as seamless to use, as you must activate the camera using a remote that you mount to your car’s dash or steering wheel; video appears on the phone’s screen within a couple seconds.

If your car has a built-in display, the Accele camera may be able to connect to it either directly or with an adapter module. Otherwise, we found that the Esky ES-15 4.3-inch display is the best value available. Despite a relatively low resolution of 480×272, the Esky had the best color reproduction of any display we tried; others had too little saturation. It’s bright enough for use during the day but still has enough contrast at night for you to make out details. You can mount the Esky display on your dash or windshield, or even upside down at the top of the windshield if you prefer. And unlike fixed displays, it has a tilting arm that lets you adjust the viewing angle; this feature is nice for a single driver but crucial if two people of different heights share a car. We looked at more-expensive displays with higher resolutions, but the Esky offered the best overall performance in the most scenarios.

About this item This fits your . Make sure this fits by entering your model number. AUTO-VOX M1 4.3” TFT LCD Backup Camera Kit Parking Assistance System with Night Vision, Easy ...

Today, there are many vehicles that now come standard with a backup camera system.  In fact, the National Highway Traffic Safety Administration announced that all cars must have the technology by 2018.

If you want to take advantage of a backup camera and install it on your vehicle, it can be done often by installing a third-party product, either at your local dealer or independent retailer.

Most third-party backup cameras, depending on the brand and where you purchase it, can cost around $20 to more than $700+ without professional installation.  The costs, like any technology gadget, will depend on the brand, its features and where you purchase it.  A lower end camera, often in the $20 to $40 range, often includes minimal wiring and no monitor, while a higher end camera setup will include a larger monitor, multiple cameras and many features.  For instance, a Garmin GPS with a backup camera can cost $400 for the part alone.

For example, the highest rated backup cameras online on Amazon.com retail for $20 to $40.  Most of these cameras are mounted on a license plate frame and will need to connect the car’s power source, which according to the reviews, many recommend hiring a professional to help.

For example, the Geek Squad at Best Buy charges $99 for a basic rear camera installation only.  This wouldn’t include the camera as you would have to purchase on directly at Best Buy.

Browsing the Amazon Home Services quote generated, many audio professionals were willing to install a customer provided a backup camera for $180 to $240.Type of InstallationAverage Price for Parts and InstallationInstalling a 3.5-inch screen and a backup camera$250 to $400

A backup camera, as an aftermarket device, is either mounted to your back bumper or via a license plate holder.  The screen, meanwhile, will either replace your existing rear-view mirror, a third-party video screen that’s able to mount to your dashboard or as a replacement for your car stereo.

The professional estimates mentioned above may or may not include the backup camera, wiring, materials, concealing all wiring, testing the camera and cleaning the area being worked on once done.  The average installation should take one to two hours.

If using a professional, the backup camera will either be mounted to an existing or new video monitor, which is installed in the car.  All of the wiring, from there, will be secured and concealed beneath the trim and carpeting.

Lower end backup cameras, as stated, often won’t include a monitor, forcing you to use a cellphone app instead.  If you were to want a monitor, then you will want to budget for one.

While a wireless camera may sound like an easy installation option, the picture quality is often terrible and wires will still need wires in order to power the unit.

Because a backup camera is considered a safety feature, you may be able to get a discount on your car insurance.  Check with your provider to see if you qualify.

Welcome to the Thomas guide to the best backup camera 2023. Thomas has been connecting North American industrial buyers and suppliers for more than 120 years. When you purchase products through our independent recommendations, we may earn an affiliate commission.

Way more effective than just using a rearview mirror, backup cameras are a relatively new innovation that make car handling safer and give drivers more insight to what’s around them. For cars that aren’t already equipped with backup camera systems, aftermarket backup cameras are a great way to supplement and upgrade their car’s technology.

A wireless or wired camera system can be added to a car post-purchase. With crystal clear image quality, a good backup camera is a supportive tool to have on top of an existing rearview mirror and side mirrors.

These backup cameras can pick up on hazardous objects, people, especially kids and pets walking by that are often harder to spot, and can even guide drivers into parking spaces or help them with parallel parking. Some varieties of cameras are more expensive but others come at an affordable price, meaning anyone on any budget can find a quality backup camera.

From wireless connections to wired backup cameras and plenty of helpful features in between, this list is a compilation of highly rated backup cameras.

Seeing the space around a car is critical at any time of the day, but nighttime driving is often more dangerous because of the lack of visibility. This wired backup camera from Natika is a backup camera fit for night and day driving.

RVs and camper vans are great fun but backing them up is a different story. With reduced visibility, accidents are more prone to happen. For preventative measures, a rear camera is an absolute must, such as this one from Furrion.

The set has multiple cameras to outfit an RV, including a sharkfin camera mount, side cameras, and a seven-inch viewing screen. It’s also a wireless configuration, which takes away the stress of sorting out cords for a long vehicle. Even still, it has a great connection, according to multiple buyers.

“This camera and screen has taken the guesswork out of towing a pull-behind RV,” wrote a reviewer. “The connection on this camera is also much better. My S model would occasionally lose connection between camera and monitor. Usually right when I needed the visibility. I used this new camera this weekend on a two-hour out-and-back trek. I never once lost contact between camera and monitor. It gave me total confidence while pulling my camper.”

Users can hang up the screen in the cab or mount it to the dashboard and, thanks to infrared lights, getting a good view during stormy evenings and night drives won’t be an issue. The wide viewing angle on this reverse camera is also highly rated by buyers.

“We install this type of camera on all of our asphalt distributors and we never had an issue,” wrote a customer. “I like the mounting bracket that the monitor has, it is very convenient because it gives you the option to install on different surfaces… Overall this is a great camera system for commercial, industrial, and heavy equipment.” Another reviewer added, “The night vision works well for our operators that start before sunrise.”

The 14,800+ five-star ratings for this eRapta backup camera are certainly a testament to its quality, despite it being the least expensive on the list. While many reversing camera options have a single camera, this one consists of a multi-camera system (six to be exact).

“The picture quality is crystal clear, and the ability to adjust the tilt of the camera means you can pin-point your sweet spot so that you can back up with certainty,” commented a reviewer. “The camera generates its own distance guides which make it even more useful (you can clip a wire to turn these off if your car/monitor already generates its own guides). The install is drop-dead simple.”

The camera simply hooks through reverse light wiring and relies on connectivity. It has an encrypted transmission and can’t be interrupted by external signals—it also has reliable night vision and can dim glare caused by sunlight on bright days.

“The iBEAM license plate camera does an exceptional job,” explained one reviewer. “It produces a detailed scene, regardless of light conditions. The active parking lines curve as you turn your steering wheel.” Another added, “Impressed with the easy integration…was not expecting the lines to work as well as they do.”

The front and rearview cameras also record audio and files can be saved on microSD cards and recorded over when they’re no longer needed. Though it pulls power from the car, in the event of an emergency it triggers a G-sensor that notifies the camera to record and save the footage.

“I bought this dash cam for my friend who does Uber and wanted them to feel secure,” wrote a customer. “For a general store brand, this dashcam has great night vision and picks up sound really well. You just position it in a space that gives you the full view of the road, and also you and the passengers in the backseat, and you"re all set. The build of the camera is nice as well. It didn"t feel flimsy in my hands and it can take high-level memory cards.”

Its six separate cameras project a crystal clear image and the contrast and brightness can be altered, which is great for changing weather conditions.

“Installed this camera on my Can-Am Maverick off-road vehicle,” described a reviewer. “Installed on the roof back to avoid mud and works very well. Picture quality is good and I can see well beyond the area visualized by mirrors alone. [It’s] wired so I can see while driving, backing up, or at a stop.”

The separate screen and lenses show video and record images simultaneously, making it the complete package for drivers who want recording capabilities as well as a backup cam.

“This is one of the best dash cams I have owned,” explained a customer. “So good that I, in fact, decided to buy a second one. I love the GPS logging and wifi feature. It allows you to instantly download the video footage to show to the police. The night vision on this camera is also good.”

High image quality camera feeds, good connectivity, sturdy camera mounts, and great clarity in dark or stormy situations are all key features of a quality wired or wireless camera. These cameras may not be a replacement rearview mirror but they’re an essential addition for increasing safety and visibility.

Hundreds of backup cameras exist out there but not all of them are worth it. Before settling on a rearview camera, here are the options most shoppers are likely to be deciding between.

There are a handful of backup camera systems available; it all depends on the car, the preferred location of the camera, and what key features are important to each buyer. Once the right choice is decided upon, seeking out professional installation can be helpful to ensure it gets set up correctly. That being said, most cameras have a simpler user setup nowadays.

A wired camera gets hardwired to the car as opposed to wireless cameras which only need a signal in order to work. A wired system can be much more reliable in places where connectivity is spotty and their picture tends to be better quality.

Wireless cameras on the other hand have wireless connectivity and no wiring setup is needed (which can save some aggravation). The video is still clear and, if the connection isn’t too much of a concern, it can be a good choice. Wireless systems tend to be cheaper as well.

These cameras are attached to a car’s license plate frame or hover above it and capture video to relay back to a screen inside the car. License plate attachments are one of the most common backup camera setups for passenger vehicles.

Installed to the rear window, side mirrors (or doors), or another part of the interior, these cameras capture footage from a different angle but still provide a visual to improve rear view safety. This is another popular setup option for cars but is commonly found in RV backup camera kits, too.

We hope our review of the best backup camera has been helpful. For more suppliers of related products, including automotive security systems, industrial cameras, and high-resolution cameras, consult our additional guides, or visit the Thomas Supplier Discovery Platform.
