A polarizer removing device according to the present invention includes a fixing member fixing a liquid crystal display including a panel and a polarizer attached to the panel, a separator which separates an edge of a polarizer from the panel by inserting itself between the polarizer and the panel, a first moving member transferring the separator, a clamping member clamping the edge of the polarizer separated from the panel, and a second moving member moving the clamping member to separate the polarizer from the panel.

The clamping member has a fixing member coupled to the separator, a moving member installed to the fixing member with a gap, and a clamping cylinder coupled to the moving member to move toward or away from the fixing member.

A device for removing a polarizer of the present invention removes the polarizer from the panel. When the liquid crystal display is fixed by adsorption plate of vacuum adsorber of holder, a sharp edge of the separator is located in the edge part of the liquid crystal display. The separator gets inserted between the polarizer and the panel to separate the corner of the polarizer from the panel. When the clamping member clamps the edge of the polarizer separated from the panel, the second moving member moves the clamping member.

As shown in FIGS. 1-4, a polarizer remover of a liquid crystal display according to the present invention includes a fixing member fixing a liquid crystal display 2, a separator 20 which separates an edge of a polarizer 6 from the panel 4 by inserting itself between the polarizer 6 and panel 4, a first moving member transferring the separator 20, a clamping member clamping the edge of the polarizer 6 separated from the panel 4, and a second moving member moving the member to separate the polarizer 6 from the panel 4.

As shown in FIG. 3, the second moving member has a servomotor and a ball screw system. A ball screw shaft 34 is provided at the frame 8, and the servormotor 32 rotates the ball screw shaft 34. A ball nut 36 is coupled to the ball screw shaft 34 and moves according to the rotation of the ball screw shaft 34. A moving bracket 38 is provided at the ball nut 36.

The ball screw shaft 34 makes an angle with the liquid crystal display 2 such that the clamping member clamping the polarizer separated from the panel moves away from the working plate 10.

As shown in FIG. 2, the second moving member further includes at least one guide bar 35 and a connecting member 37. The guide bar 35 is parallel to and separated from the ball screw shaft 34. The connecting member 37 is movably coupled to the guide bar 35 and moves together with the ball nut 36.

As shown in FIG. 3, the first moving member includes a separating cylinder 42, a guide rail 44 and a separating bracket 48. The separating cylinder 42 is provided at the moving bracket 38 of the second moving member. The guide rail 44 is installed at the moving bracket 38 parallel to the working plate. The separating bracket 48 is movably installed along the guide rail 44 and coupled to a piston rod 43 of the separating cylinder 42.

As shown in FIG. 3, the clamping member includes a fixing member 54, a clamping bracket 58, a clamping cylinder 52 and a moving member 56. The fixing member 54 is installed at the separating bracket 48, and the separator 20 is provided at one end of the fixing member 54. The clamping bracket 58 is installed separated from the fixing member 54. The clamping cylinder 52 is installed at the clamping brackets 58. The moving member 56 is installed on the piston rod 53 of the clamping cylinder 52 and moves toward or away from the fixing member 54.

At an end portion of clamping bracket 58 corresponding to an end of separating member 20, a sensor 60 for detecting an edge of the polarizer is located.

For example, when the separator 20 separates the polarizer 6 of the panel 4, the separator 20 remains fixed by a torsion spring (not shown). When the second moving member moves the fixing member 54, the separator 20 rotates about the rotating pin 28 by the moving force of the second moving member. This overcomes elasticity force of torsion spring. So the sharp edge of the separator 20 is prevented from damaging the porarizer 6 (shown FIG. 9).

As shown in FIG. 1, the polarizer remover comprises a pushing member. The pushing member operates in response to the operation of the second moving member and push the liquid crystal display 2 to protect deformation of panel 4 while the polarizer 6 is separated from the panel 4.

When a polarizer of a liquid crystal display turns out to be wrong due to impurities accidentally involved between a panel and the polarizer, misattachment of the polarizer, or damages on the polarizer, as shown in FIG. 5, the liquid crystal display is loaded on the adsorb plate 12 by using a transferring system (not shown). At this time, the liquid crystal display 2 is located on the adsorbing plate 12 such that the polarizer 6 is projected over the fixing jig 16, and an edge of the polarizer 6 closely contact the fixing jig 16. The liquid crystal display 2 is adsorbed on the adsorbing plate 12 by the vacuum adsorber, and the servomotor 32 of the second moving member begins to rotate by a control signal of the controller (not shown). The ball screw shaft 34 rotates according to the rotation of the servomotor 32, the separator 20 moves toward the liquid crystal display 2.

As shown in FIG. 6, the working plate 10 rotates along the corner of polarizer such that the corner rotates from the dot-dash line to the solid line. As shown in FIG. 7, the separating bracket 48 moves toward the polarizer 6 along the guide rail by the separating cylinder 42 of the first moving member in response to the signal from the controller.

Then, the fixing member 54 and the separator 20 move toward the polarizer 6 and the separator 20 is inserted between the polarizer and the panel 4 to separate the corner of the polarizer 6 from the panel 4. When the separated portion of the polarizer 6 is placed between the clamping surfaces 55 of the fixing member 54 and the moving member 56 and the size of the separated portion becomes proper, the clamping cylinder 52 of the clamping member operate in response to the control signal of controller to move the moving member 56 toward the fixing member until the separated portion of the polarizer is clamped between the clamping surfaces 55.

The servomotor 32 of the second moving member rotates in response to the control signal of the controller to move the moving bracket 38 via the ball nut 36 coupled to the ball screw shaft 34. The moving direction of the moving bracket 38 is left in FIG. 8 such that the polarizer 6 is detached from the panel 4. Since the ball screw shaft 34 makes an angle with the working plate 10, the clamping surfaces 55 moves upward and left.

The pushing cylinder 72 operates according to the control signal from the controller when the second moving member operates, and the pushing roller 72 moves left to prevent the panel 4 from being damaged.

The polarizer 6 is completely detached from the panel the vacuum adsorber stops its operation, and the liquid crystal display 2 can be removed from the adsorb plate 12 to proceed to the next process.
