lcd panel at vizio e390 manufacturer

Approximate diagonal size of the display. If the manufacturer does not provide such information, the diagonal is calculated from the width and height of the screen.980 mm (millimeters)

Approximate width of the display. If the manufacturer does not provide such information, the width is calculated from the diagonal and the aspect ratio.853.92 mm (millimeters)

Approximate height of the display. If the manufacturer does not provide such information, the height is calculated from the diagonal and the aspect ratio.480.83 mm (millimeters)

The most widely used panels are those with 6, 8, and 10 bits for each of the RGB components of the pixel. They provide 18-, 24-, and 30-bit color, respectively.8 bits

The maximum number of colors, which the display is able to reproduce, depends on the type of the panel in use and color enhancing technologies like FRC.16777216 colors

The ratio between the horizontal and the vertical side of the display. Some of the standard and widely used aspect ratios are 4:3, 5:4, 16:9 and 16:10.1.778:1

Information about the number of pixels on the horizontal and vertical side of the screen. A higher resolution allows the display of a more detailed and of higher quality image.1920 x 1080 pixels

The pixel pitch shows the distance from the centers of two neighboring pixels. In displays, which have a native resolution (the TFT ones, for example), the pixel pitch depends on the resolution and the size of the screen.0.445 mm (millimeters)

Information of the number of pixels in a unit of length. With the decrease of the display size and the increase of its resolution, the pixel density increases.57 ppi (pixels per inch)

The backlight is the source of light of the LCD display panels. The type of backlight determines the image quality and the color space of the display. There are various backlights such as CCFL, LED, WLED, RGB-LED, and etc.Direct LED

The dynamic contrast shows the ratio between the brightest and the darkest color, which the display can reproduce over time, for example, in the course of playing a video.2000000 : 1

Information about the minimum amount of time, in which the pixels change from one color to another. Very often the manufacturer provides the response time for transition from grey-to-grey (G2G).6.5 ms (milliseconds)

Desktop monitors and smart TVs experience a latency/lag in visualizing the information. The time in milliseconds that the display needs to visualize the signal input.40 ms (milliseconds)

The vertical frequency/refresh rate shows how many times in a second the image on the screen is refreshed.50 Hz / 60 Hz (hertz)Power supply and consumption

Information about the dimensions and the weight of the specific model with and without stand as well as the colors, in which it is offered to the market.Width

The TV tuner is a device, which allows the receiving and visualization of a certain type of television signal. There are tuners for digital, analog, cable and satellite television.TV tuner

The operating systems of the smart TV sets feature user interface technologies for navigation and other ways of interaction with the smart TV - installing applications, internet browsing, video calls, sharing content with other users, playing videos and music, etc.V.I.A. PlusAudio

Information about the network technologies and standards supported by the model, which allow for it to connect to and communicate with other devices.LAN

Information about the available connectivity ports, slots and interfaces such as USB, infrared port, SD card slot, audio/video and network interfaces, etc.1 x USB 2.0

Albania, Andorra, Austria, Belgium, Bermuda, Bosnia and Herzegovina, Bulgaria, Canada, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Gibraltar, Greece, Greenland, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Malta, Mexico, Moldova, Monaco, Montenegro, Netherlands, Norway, Poland, Portugal, Republic of Croatia, Romania, Saint Pierre and Miquelon, San Marino, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, United Kingdom, United States, Vatican City State

The Vizio E390i-B1 really has the full array LED backlighting to thank for the picture quality here. The full-array LED backlighting achieves much better peak whites and deeper blacks than seen on previous versions of the E series. Colors are also going to benefit from this backlighting scheme, as there will be less washout and uniformity issues. E series models with smart TV features also have 6 Active LED zones for local dimming. This small number of zones may not create a highly noticeable effect. It"s important to note that this series has 60Hz and 120Hz TVs. The 39 inch E series TVs with Vizio Internets Apps Plus have an effective 120Hz refresh rate thanks to backlight scanning. Non smart TV models have a 60Hz refresh rate. That may sound like a big drawback, the benefits are harder to notice on a 39 inch screen. The Clear Action Rate may produce negative effects in some circumstances and is probably better left off for movies and regular TV programs.

The E390i-B1 has a great picture after calibration, but it doesn"t render the picture depth of a plasma display. What"s important here is the picture quality and screen size for the price. It"s one of the best deals around right now for the size. Dark scenes can look a bit flat and blacks can seem to have a film over them interfering with overall immersion. The colors are not what I would call rich either.

Black levels are somewhat flexible with the Black Detail advanced picture setting. It adds some much needed contrast and three dimensionality and colors pop, so I made a rare exception and use the Black Detail on the high setting. Normally, we would have such a setting off.

The Film Mode does cut down slightly on judder from movie-source programming with no noted side effects. We"re typically sceptical of this type of de-judder feature but on the Vizio e-series the effects are subtle enough to be of good use.

Side Angle Viewing, better than expected especially with the Black Detail setting on high. Nevertheless , there is contrast reduction starting at around 20 degrees off center, but becoming pronounced at 30.

Choosing the best picture mode for your calibration is extremely important and Vizio provides some nice choices: Standard (energy saving mode), Calibrated, Calibrated Dark, Game, Computer, and Vivid. The calibrated and calibrated dark modes are the best choices with only the backlight strenght being the difference between the two. Calibrated mode will probably be the choice mode for most situations as the dark shadow detail and full backlight give the picture some needed punch. Overall, I am very pleased with the selection of picture modes, especially the two calibrated modes for this price point of TV. From Calibrated Mode use the following settings for calibrated picture settings:

The OPC (Optimum Power Control) control is very hidden in the menu of the E-series Vizio TV, but it can and should be turned off due to the distracting influx and outflow of light/brightness produced by the backlight. Out of the box, it will be set to On position for any of the preset picture settings. When I recently retested the e-series from Vizio I found it added unnecessary picture noise when light flow moved up or down lagging the picture image. The OPC"s purpose is to save energy by manipulating the backlight through the 18 backlight zones, or probably more accurately to lower the Energy rating for Vizio"s TVs. But at less than $1 a month total, and just a few cents per month for the OPC feature, you probably prefer a better picture. To turn it off: Go to Picture Settings, scroll down to More, Scroll down and click Advanced Picture at he bottom of the menu, this will finally bring up the Backlight Control as the very last setting. Turn Off.

The Vizio E390i has the Vizio Internet Apps Plus platform included. The built-in wifi allows for instant access and plenty of speed for HD content streaming. The "Plus" in the name means the interface is much more user friendly and the overall performance is faster than before. Some of the most useful apps included are Netflix, Amazon Instant Video, VUDU, MGO, Hulu Plus, YouTube, Pandora, iHeartRadio, and Facebook. There are plenty more too.

The Smart TV gets good marks as far as performance goes. There were a few initial hiccups in the set up process, but all was smooth once we got past those and connected to our wifi network. Streaming content loaded up quickly and provided a high quality image over wifi. This is a big plus since not all smart TV platforms handle streaming so well.

The Vizio E-series does not include a remote with any special capabilities. No motion control, voice recognition, or QWERTY keyboard. But that"s okay. It"s a small remote with efficiently laid out small keys that give quick access to the necessary controls. That"s really all we need in a remote after all. The buttons to access video streaming apps quickly will be some of the most used.

The E390i-B1 has also recieved some upgrades to the appearance. The bezels are now slimmer than they were last year, at a mere 10mm thin. Not bad for an entry level set. The profile has also seen a reduction of 30%. These aren"t nearly as bulky as they have been in the past. The black plastic square stand is nothing special, but it doesn"t take away from the sleek look here. All in all, this is an average looking value LED TV.

The Vizio E390i-B1 presents a solid value across the board. Picture quality for the $369-$399 price tag is excellent. Strong contrast and picture depth from front and center is the highlight in the picture quality realm. Vizio Internet Apps Plus don"t do anything new for the platform, but everything works well and doesn"t leave much to be desired. Some downsides are a non-backlit remote, 2-point white balance, and a non-swivel stand. But these are dealbreakers by any means.

Jack Burden has been reviewing and writing reviews in the consumer electronics category for 7 years with CEAG. He considers grayscale gradation, film patterned retarders, and focus field drives to be fun topics. Read more about Jack

We include brief instructions in red text on some listings (also displayed below without the red font). Please look for these instructions to confirm any important info that you"ll need to identify on your original part. Additionally, we highlight the part number in our photos.

This product qualifies for ENERGY STAR in the “factory default” setting and this is the setting in which power savings will be achieved. Changing the factory default picture settings or enabling other features will increase power consumption that could exceed the limits necessary to qualify for ENERGY STAR rating.

Your TV is designed and manufactured to operate within defined design limits. Misuse may result in electric shock or fire. To prevent To get the most out of your new VIZIO product, read these your TV from being damaged, the following instructions should...

• Use only with the cart, stand, tripod, bracket, or local power company. or table specified by the manufacturer, or sold • Do not apply pressure or throw objects at your TV. with the apparatus. When a cart is used, use This may compromise the integrity of the display.

your TV, unplug the power cord and contact your dealer. • This apparatus shall not be exposed to dripping or Continuous use in this case may result in fire or electric splashing and no objects filled with liquids, such as vases, shock.

Adjusting the CEC Settings ..........40 Turning the Power Indicator On or Off ......40 Using the Reset & Admin Menu .......... 41 Restoring the TV to Factory Default Settings ....41 Using the Guided Setup Menu ........42 Using Guided Setup ............42 Using the Info Window ............

To install the base: 1. It is recommended that two people take part in the 3. Align the base with the neck and tighten the three base installation. (3) included M4 10mm Phillips screws using a Phillips screwdriver as shown. 2.

COMPONENT CABLE HDMI CABLE Component cables are designed to carry high HDMI is the intelligent, all-digital interface that delivers definition video signals along with additional both dazzling quality and unmatched ease of use. HDMI audio connections. Colors are delivered with color technology transmits crystal-clear digital video along information split up three different ways over three with multi-channel surround audio.

To adjust the 11 Point White Balance settings: To enable/disable the SMPTE Test Pattern: 1. From the Color Tuner menu, use the Arrow buttons to 1. From the Color Tuner menu, use the Arrow buttons to highlight Color Tuner, and then press the Left/Right Arrow highlight Color Tuner, and then press the Left/Right Arrow buttons until the 11 Point White Balance menu is displayed.

Sources the previous screen. Current Folder the Arrow and OK buttons Displays Displays the folder path. on the remote. connected USB devices. To VIZIO change source, Photo VIZIO_2GB\Photo\root highlight it and USB1: press OK. Current Folder root A.jpg B.jpg...

The image quality is not good. I see “noise” or static on the screen. • For the best image quality, view high-definition • When your TV’s digital capabilities exceed a programs using digital sources. Connect your devices digital broadcast signal, the signal is up-converted with HDMI cables.

E390-B0 OSD Language: English, Spanish, French Ambient Light Sensor: Remote Control Model: XRT010 CSA, CSA-US, FCC Class B, Certifications: HDMI, Dolby Digital Compliance: Energy Star Voltage Range: 108~132V @ 50/60 Hz Power Consumption: 52.1W Standby Power: <1W...

If there is "Google" just the numbers (or whatever you have found), do not mention Vizio in the search as most probably the results will focus on it rather than on the numbers. With a bit of luck you may get supplier info, as the screen is probably not made by Vizio anyway.

This is the only panel manufacturer that I can find that has TVP listed in their products, so perhaps they are the makers or perhaps not. How this helps you I"m not sure as I"m thinking that even if they were that they wouldn"t supply on a one off basis.

VIZIO’s Full-Array LED backlight technology delivers brilliant picture quality as it distributes LEDs across the entire screen for superior light uniformity and picture performance.

The all-new 2014 E-Series design introduces a side profile that’s up to 30% thinner, an ultra-narrow 10mm frame, and a new space-saving slimmer base. The new design puts the focus right where it should be—on the screen—and is the perfect upgrade to any room.

HDTVs have really become affordable over time and gained many new features too, which can often lead to some degree of technical problems later on. Most consumers can get an incredibly large, 4K Smart TV for under $1000, but less expensive models mean lesser quality components and more troubleshooting.

On a value-per-dollar basis, Vizio ranks at the top, delivering a satisfying mix of quality and cost. In addition to featuring great visual screens, their HDTVs include some of the best software you can get. However, they too have some problems from time to time.

Smart TVs have been popular for years, and in that time, the software from all brands has gone from sluggish and confusing to sleek and speedy. Of course, no Smart TV has perfect software, and as much as Vizio’s features stand out, they aren’t perfect either. Their HDTVs can occasionally run into issues too, including but not limited to the following:

A soft reset clears the memory, allows any residual charge to dissipate, and restarts the device, all of which can easily fix a large percentage of the device’s problems. That’s why the process becomes the first suggestion that any technical support person gives. Performing a soft reset is easy.All you need to do is switch the device off and keep it that way for a few seconds.

A hard reset is more serious. Not only does it do everything a soft reset does, but it will also reset the firmware or configuration of the device to their factory defaults, clear the memory, and reset the device entirely. A hard reset is basically the same as going back in time to when you first took the Vizio Smart TV out of the box.

A hard reset of a Vizio Smart TV will wipe all configurations and settings. It will remove all account details for any smart apps, reset network data, and trigger a firmware update if one is available. You should always do a soft reset first to see if that resolves the issues you are having with your TV.

The above method should work on most of the recent Vizio Smart TVs. If you’ve lost or damaged the original remote, you may be able to use an RCA universal remote to reset your TV too.

Regardless, the Vizio Smart TV reset options mentioned here should “refresh” your model without trouble, whether they fix the problem or not. Bear in mind that the processes don’t work on all Vizio HDTVs, but they usually function with newer models. Some older Vizio TVs don’t have an actual reset option listed in the menu directly, but the choice is still there under a certain category or wording.

Furthermore, older Vizio TVs have other buttons on the front panel so read the manual for more information on resetting to factory defaults. Lastly, if you have issues such as when your Vizio TV won’t turn on, it doesn’t mean the Smart TV is broken. Therefore, there is no need to panic just yet! Try some of the above steps and see if you can get things back up and running!
