320x480 tft lcd factory

* 3.5 Inch TFT LCD Module, 350cd/m2, 320*240 resolution, 24 Bit RGB interface, widely used in military industry, security, car audio and video, medical, rearview mirror, industrial control equipment, smart home, video doorbell, Building elevator advertising, SIP phones, medical equipment, serial port display modules, handheld PDAs, game consoles, Internet of Things, home appliances and other fields.

RFI350U-AYW-DNN is a 3.5-inch diagonal IPS transmissive type 320x480 TFT LCD display module. The module features wide viewing angle thanks to the IPS panel which is one of the most popular techniques on the market now. The dimension size of this module is 54.5x83 mm, size of active area is 48.96x73.44 mm. This TFT display module uses ILI9488 driver IC which supports 8/16/18-bit MCU, 3-Line SPI interface and RGB interface + 3-SPI. This 320x480 TFT LCD module has brightness 600 cd/m2 with contrast ratio (typical value) 700:1. The module works within the temperature -20 to +70℃, storage temperature ranges from -30 to +80℃.

2. It with 320x480 resolution , IPS/ Wide/ Free/ All view angle, 8-/ 9-/16-/18- 8080-MCU 4-lines / 3-lines SPI + 16-/18-bit RGB, ILI 9488 driver IC , 300 nits brightness, with capacitive touch panel/optical bonding .

Orient Display sunlight readable TFT displays can be categorized into high brightness TFT displays, high contrast IPS displays, transflective TFT displays, Blanview TFT displays etc.

The brightness of our standard high brightness TFT displays can be from 700 to 1000 nits. With proper adding brightness enhancement film (BEF) and double brightness enhancement film (DBEF) and adjustment of the LED chips, Orient Display high brightness TFT products can achieve 1,500 to 2,000 nits or even higher luminance. Orient Display have special thermal management design to reduce the heat release and largely extend LED life time and reduce energy consumption.

Our high contrast and wide viewing angle IPS displays can achieve contrast ratio higher than 1000:1 which can make readability under strong sunlight with lower backlight luminance. High brightness IPS displays have been widely accepted by our customers with its superb display quality and it has become one of the best sellers in all our display category.Transflective display is an old monochrome display technology but it has been utilized in our color TFT line for sunlight readable application. Orient Display has 2.4” and 3.5” to choose from.

Blanview TFT displays are the new technology developed by Ortustech in Japan. It can provide around 40% of energy consumption for TFT panels which can use smaller rechargeable or disposable batteries and generate less heat. The price is also lower than traditional transflective TFT displays. Orient Display is partnering with the technology inventor to provide 4.3” and 5.0”.

High Level Interfaces: Orient Display has technologies to make more advanced interfaces which are more convenient to non-display engineers, such as RS232, RS485, USB, VGA, HDMI etc. more information can be found in our serious products. TFT modules, Arduino TFT display, Raspberry Pi TFT display, Control Board.
