auo lcd panel free sample

We manufacture and stock backlight assemblies for many AUO LCD panels. We produce premium quality replacements to extend the life of your flat panel screen devices.  If you do not see your panel model listed here, please contact us to learn about our cost effective design and manufacturing process.  Simply mail us a sample of the backlight you are looking to replace, and we can recreate and supply you with what you need to meet you needs.

A wide variety of auo 55 lcd panel options are available to you, You can also choose from original manufacturer, odm and agency auo 55 lcd panel,As well as from tft, lcm auo 55 lcd panel.

a) We are happy to announce that all the LCD Panels and Laptop / Notebook batteries purchased from us comes with 90 days warranty from the date of invoice. Please note that the warranty only covers against defects in material and workmanship and there are other circumstances which limit its cover.

We have some updates from AU Optronics about their panel development plans which is always interesting to see. Our last update was Oct 2020. This is AUO as a panel manufacturer, as opposed to any specific monitor/display manufacturer, but it gives an indication of where monitors are likely to go in the future by looking ahead at the panel production plans. AUO make a large portion of the IPS-type panels (their ‘AHVA’ technology) in the market which is always of interest along with a range of interesting TN Film options. Please keep in mind that the production dates are not set in stone and may change, and there is then also a lag of several months before a panel is produced, then used in a display and launched to market. We will update our panel parts database with all the new information we have as well as best we can.

AU Optronics plan to push this in the coming years, with listings now of 1080p @ 480Hz, 1440p @ 360Hz and UHD (4K) @ 240Hz!The 1440p 360Hz option looks like it will be the first to go in to production sometime in 2021, with the others planned for 2022 sometime. No details on panel sized or other specs at the moment, only that these are the plans to drive refresh rates.

An interesting new addition in our last update was the M315QVR02.0. This is 31.5″ in size and is a VA technology panel with a steep 1000R curvature. It offers a 3840 x 2160 (“4K”) resolution along with a 144Hz refresh rate. Production was not planned until Q2 2021 at the time although this seems to have been brought forward slightly and should now be in production and expected to be available around Q3 2021.

While not listed last time for some reason, an alternative panel had the same specs but a less steep 1500R curvature instead. This has now re-appeared and again should be in production and expected to be available around Q3 2021.

There are also a quite a few other high refresh rate Curved VA panels of note. The focus from AUO here seems to be with a range of curvature options, including a steep 1000R to match recent Samsung VA panel developments. New planned 240Hz VA panels look particularly interesting, if response times are sufficient to keep up. Samsung have done a great job enhancing their response times on recently tested 240Hz VA panels from their range, finally clearing up the dreaded black smearing and making panels that can actually keep up with the frame rate (e.g. Samsung Odyssey G7screens). Let’s hope AUO can do the same with their new 240Hz options.

No sooner have these screens started to finally appear, do we have news from AUO that they are looking to boost that refresh rate a little up to 160Hz in the next generation of these 4K panels. These are still in planning phase with a tentative Q3/Q4 2021 date listed for now, but we’d expect this to slip a bit.

AUO have various panels planned with FALD backlights and Mini LED backlights (even more zones) for excellent HDR performance on an LCD panel. Some also have high refresh rates included:

M320QAN02.7– 32″ in size with a 576 zone LED backlight (AUO refer to this as Mini LED, although it’s a bit more like FALD options we’ve seen to date given the more limited number of zones). This panel has a 3840 x 2160 resolution, 60Hz refresh rate only, wide gamut with 99% Adobe RGB coverage, 8-bit colour depth, 600 cd/m2 brightness, 1000 cd/m2 peak brightness for HDR 1000. Originally expected to go in to production in Dec 2020 which slipped a bit but should be in production now since May 2021.

An additional 32″ sized panel with a 576 zone LED backlight is also now listed (M320QAN02.8) but this time with an expected 160Hz refresh rate. Again with 99% Adobe RGB gamut and HDR 1000 support. This one is in planning phase only, but listed for now at Q3 2021.

Another similar panel (M320QAN02.9) is listed with the same 4K at 160Hz specs but an HDR 600 capability only (but still with a 576 zone Mini LED backlight). This one is again in planning phase and penciled in for Q3 2021 at the moment.

Most exciting perhaps is a new 32″ panel (M320QAN02.A) that is currently in development with a 2304 zone Mini LED backlight and high 160Hz refresh rate. This is listed with 99% Adobe RGB gamut and HDR 1000 support again, and expected to be in production around August 2021.

M270QAN02.6 – 27″ in size with a 576 zone LED backlight. This panel has a 3840 x 2160 resolution, high 144Hz refresh rate, wide gamut with 99% Adobe RGB coverage, 8-bit colour depth, 600 cd/m2 brightness, 1000 cd/m2 peak brightness for HDR. Originally expected to go in to production in Dec 2020 but now listed for Q3 2021.

There’s not very much information listed for this at the moment, but AUO are also developing now a 24.5″ sized TN Film panel with a 360Hz native refresh rate. So far the only 360Hz panels released to market have been by AUO with their IPS-type technology, as featured in screens like the Asus ROG Swift PG259QN we tested last Sept 2020. Some gamers still prefer TN Film panels for additional snappiness and for competitive gaming so it will be interesting to see what AUO can manage in this sector too.

Another newly announced panel that looks interesting is the M315QVN02.0. This is flat format 31.5″ sized panel, and offers a 3840 x 2160 “4K” resolution combined with a 144Hz refresh rate. This is a VA technology panel though, unlike the wide range of IPS technology panels already announced from various manufacturers in this kind of size range (31.5 – 32″). So this is one of the first ~32″ sized panels with 4K @144Hz but with VA technology being used. Other specs listed include HDR 600 support and a 90% DCI-P3 colour gamut. It’s expected to be available quite soon actually with production supposedly under way since July 2021.

The 34″ size is not one that AUO has previously invested in, having concentrated their efforts in the 35″ space, and leaving 34″ to Samsung (VA) and LG.Display (IPS) until now. AUO now have several new panels in production which are 34″ in size, offering a 21:9 ultrawide aspect ratio and a 3440 x 1440 resolution. There are 4 panel variants planned:

The other two have a steeper 1000R curvature to rival what Samsung are doing at the moment with their VA panels. Again there is a 100Hz version (M340QVR01.5) and a 165Hz version (M340QVR01.6). Both slipped back from Jan/Feb 2021 slightly to March 2021 but should now be in production.

Digital devices with screens are everywhere in contemporary daily lives, especially after the pandemic. People tend to communicate online more frequently, and that leads to staring at the screen for a long time, which further increases the burden on the eyes. For this reason, AUO has exclusively developed the A.R.T. (Advanced Reflectionless Technology) with anti-glare and anti-reflection features, in the hope of protecting our next generation’s eyesight without compromising display quality. Focusing on the demands of content creator or picture/text editor, AUO has launched the world’s first(*) 32-inch 8K4K professional editing monitor panel, which reduces distractions due to the reflection or glare of ambient light, and shows sophisticated details when drawing, editing the video or viewing photos. The world’s first(*) 21.3-inch A.R.T. medical panel allows medical personnel to make more precise diagnosis and alleviate the damage to their eyesight after reading images for prolonged periods of time.

Furthermore, to achieve a better human-computer interaction, the sensing technology acting like a messenger is also a key factor in addition to display technology. Leveraging the profound TFT display technologies developed over the years, AUO presents cutting-edge sensing technology to meet the various demands in the smart verticals. For example, focusing on smart retail trends, AUO applies special CIAA (Circuits in Active Area) technology to transform the screen into an Near Field Communication (NFC) signal sensor, allowing mutual communication between the consumer and the store system through a single interface; in order to improve smart medical applications due to the pandemic, flexible, a-Si (amorphous Silicon) manufacturing process and Low-Temperature Polysilicon (LTPS) process were applied to develop X-ray sensors respectively to realize the mission of precision medicine.

The displays will soon be everywhere in the future. AUO has combined advanced OLED technology to create a 5.6-inch rollable dual-sided OLED display with double-sided displays when unrolled, and can be viewed by different users from each side. It can also be easily stored or carried around when rolled up. AUO replaces the reflection reduction circular polarizer with proprietary color filter (CF), which greatly reduced the thickness of the display module by 50% and maintain the brightness of display. It has passed the 100,000 times rolling test at a radius of 9mm curvature, proving the technology’s durability and reliability. In the future, it allows multiple users to watch different contents simultaneously, inspiring various next-generation display applications.

While pursuing innovation in display technology, AUO commits to energy conservation and environmental sustainability, and continues to develop inkjet printing OLED technology, which has a higher material utilization rate than traditional evaporation techniques. AUO’s 32-inch UHD 4K inkjet printing OLED panel is driven by oxide backplane and offers industry-leading ultra-high frame rate of 144Hz with 4K 140 PPI resolution. The inkjet printing OLED technology will meet the increasing demand for high image quality and high frame rate in both medical and gaming applications. At the same time, AUO shows world’s first(*) 10.1-inch panel that integrates inorganic wire-grid polarizers into LCD cell, thus increasing the transmittance by 1.5 times while reducing power consumption by 25%. The thickness of in cell inorganic wire-grid polarizer is less than 1um, about 1/600 of the thickness of the traditional polarizers, which greatly reduces the thickness by 120–160um, and passes the severe environment test of higher than 105°C/1000 hours. This feature is suitable for applications requiring long battery life, lightweight and slim stylish design.

As displays are indispensable in our everyday life, AUO has developed the strategy of “Go Vertical” and “Go Premium,” and the pace of innovation never falters. Recently, AUO unveiled the AUO-NTU Joint Research Center at National Taiwan University, aiming to stimulate comprehensive research on display and sensing technology while working with excellent talents from interdisciplinary backgrounds through further academia-industry collaboration. In addition to high-end technology exhibition, a series of innovative technology papers and discussions will also be held during Display Week 2021, fully shown AUO’s determination to the R&D of cutting-edge display technology and its application in the future.
