In this tutorial we"ll take you through how to connect a 16x2 LCD display up to your Raspberry Pi using GPIO pins. Being able to display a message on the LCD is not only very cool but can be pretty useful too, for example in this tutorial we"ll cover how to get your LCD display to display the IP address of your raspberry Pi.

For this exercise we are going to control the LCD display using 4-bit mode. Whilst is is possible to connect to it in other ways using I2C or the UART this is the most direct method. In order to control the display in this way will we need to use 6 pins on the GPIO port, 4 data pins and 2 control pins.

Register Select – This toggles the Lcd display between two modes, Command mode (high) and Data mode (low). Command mode gives a Instruction to the LCD. Example – “Clear the display” , “Move cursor to home” etc and Data tells the LCD to display characters.

In order for the LCD to work we will wire the circuit up in a fashion similar to the diagram above, but hold off connecting everything together for now! The list below tells you exactly what the pins on the LCD connect to:

Begin assembling the circuit by inserting the Adafruit cobbler into the breadboard. Remember to straddle the cobbler over the centre of the breadboard so that no two pin is in the same row. Next insert the LCD display into the breadboard. Connect the 5V and GND pins from the cobbler to the top of breadboard and also connect Pins 1, 2, 15 on the LCD and 16 to their respective power rails. Your circuit should look similar to the picture below:

Connect the GPIO ribbon cable from the cobbler to the Pi, if everything is working correctly the back light on the LCD should turn on like on the picture above. If it doesn"t work check everything is wired up correctly

Next wire up the potentiometer. The middle pin of the potentiometer is connected to Pin 3 on the LCD display and the other two pins are connected to ground and 5V (it doesn"t matter which way round). Check the potentiometer is working by twisting the nob until you see boxes appear in the first line of the display like in the picture below:

To get the Python code to run the LCD display we are going to "grab" it from adafruit using GitHub. Make sure your Rasp berry Pi is connected to internet and we"ll use the git command to clone the python code. Run the following commands in the terminal to download the files.

Now we can test the display is working and it is wired up correctly. One of the files we downloaded Adafruit_CharLCD.py contains python class for LCD display control. It also contains a small piece of code so when the program is run it will display a message on the LCD.

If you are using Version 2 of the Raspberry pi you will need to edit the program slightly since pin #21 has now been changed to pin #27. Open the file Adafruit_CharLCD.py with Python or use nano  Adafruit_CharLCD.py command to edit the program within the terminal. Go to line 57 of the code and replace:

Feel free to dive into the code of the program and change what"s displayed on the LCD. To do so open the program to edit like before and scroll to the last line of the code:

Simply change what is  typed in the brackets after lcd.message() to display the text you want.  The command is used to wrap the text onto a new line. A neater way of doing this is to change the last part of the program to look like the following:

This way when you run the program you will be prompted by "type your message here" to enter a message via your keyboard, which will then be displayed on the LCD. This was done by defining a new variable "message" that is equal to the command raw_input(), which allows the user to manually enter text. The part within the brackets of the raw_input() command is simply printed on the computer screen to prompt you what to write.

Getting the LCD display to display some text of your choosing is cool but not that useful. Running the program Adafruit_CharLCD_IPclock_example.py will display the date/time and the IP address of the Pi on the LCD. The program calls upon the methods from the previous program Adafruit_CharLCD.py. Feel free to open the program to look at the coding. To do so open the program in python or use the command sudo nano Adafruit_CharLCD_IPclock_example.pyin the terminal.

Note:In order to control the contrast you can adjust the voltage presented to Pin 3. This must be between 0 and 5V. We used a resistor between pin 3 of LCD to GND of PI.

In the above tutorial we saw how to display the custom message on 16 X 2 LCD using raspberry pi and python.Now we shall move on how to display the current weather info on LCD:First we will need to download the python weather api.Download thepywapilibrary using the following command on your pi.wget https://launchpad.net/python-weather-api/trunk/0.3.8/+download/pywapi-0.3.8.tar.gz

support I²C 23017 8/16/32/64/128 GPIO, I²C TMP102 Temp sensor, I²C RTC DS1307, I²C ADC ADS1015, I²C PWM, I²C EEPROM 24c32, I²C BMP085 Barometric Pressure/Temperature/Altitude Sensor, GPIO input/output, DC motor, Relay, I²C 16x16 LED matrix, I²C 24x16 Matrix, 84x48 pixels LCD, 16x2 character LCD, 20x4 character LCD, 1-Wire 18B20 Temp Sensor, Ultra Sonic distance sensor, available from

When we need to interface with sensors, motors, and displays we generally think about using an Arduino, however, there are a lot of advantages in using a Raspberry Pi instead. Today we will see how easy it is to interface devices using the Raspberry Pi GPIO.

The 3A has a full-sized HDMI port, an audio output, the CSI camera connector, and a DSI display interface. It only has one USB2 port and does not have an Ethernet RJ45 connector.

The General Purpose Input/Output bus permits your Raspberry Pi to communicate with sensors, displays and a wide variety of peripherals.  And, of course, it’s the subject of today’s article and video!

We will be using the gpiozero library for our experiments, and we’ll get our Python code directly from thegpiozero documentation “Basic Recipes” section.

TheLEDClass of thegpiozerolibrary is used, as well as theSleepClass from thetimelibrary.  We run the code in a While loop that always evaluates as TRUE so it keeps running.

The Raspberry Pi GPIO is a 40-pin connector that lets you connect your Pi to the outside world. Learn to use the GPIO and the gpiozero library to control some simple I/O devices.

This tutorial shows how to use the I2C LCD (Liquid Crystal Display) with the ESP32 using Arduino IDE. We’ll show you how to wire the display, install the library and try sample code to write text on the LCD: static text, and scroll long messages. You can also use this guide with the ESP8266.

Additionally, it comes with a built-in potentiometer you can use to adjust the contrast between the background and the characters on the LCD. On a “regular” LCD you need to add a potentiometer to the circuit to adjust the contrast.

Before displaying text on the LCD, you need to find the LCD I2C address. With the LCD properly wired to the ESP32, upload the following I2C Scanner sketch.

After uploading the code, open the Serial Monitor at a baud rate of 115200. Press the ESP32 EN button. The I2C address should be displayed in the Serial Monitor.

Displaying static text on the LCD is very simple. All you have to do is select where you want the characters to be displayed on the screen, and then send the message to the display.

The next two lines set the number of columns and rows of your LCD display. If you’re using a display with another size, you should modify those variables.

Then, you need to set the display address, the number of columns and number of rows. You should use the display address you’ve found in the previous step.

To display a message on the screen, first you need to set the cursor to where you want your message to be written. The following line sets the cursor to the first column, first row.

Scrolling text on the LCD is specially useful when you want to display messages longer than 16 characters. The library comes with built-in functions that allows you to scroll text. However, many people experience problems with those functions because:

The messageToScroll variable is displayed in the second row (1 corresponds to the second row), with a delay time of 250 ms (the GIF image is speed up 1.5x).

In a 16×2 LCD there are 32 blocks where you can display characters. Each block is made out of 5×8 tiny pixels. You can display custom characters by defining the state of each tiny pixel. For that, you can create a byte variable to hold  the state of each pixel.

In summary, in this tutorial we’ve shown you how to use an I2C LCD display with the ESP32/ESP8266 with Arduino IDE: how to display static text, scrolling text and custom characters. This tutorial also works with the Arduino board, you just need to change the pin assignment to use the Arduino I2C pins.

Let me know your suggestions for additional components and interfaces in the comments below – and use the hashtag #gpiozero to share your project code and photos!

In previous posts I’ve covered using HD44780 16×2 and 20×4 LCD screens with the Raspberry Pi using Python. These are relatively easy to use but require a number of connections to be made to the Pi’s GPIO header. This setup can be simplified with the use of an I2C enabled LCD screen.

The example script will allow you to send text to the screen via I2C. It is very similar to my scripts for the normal 16×2 screen. To download the script directly to your Pi you can use :wget https://bitbucket.org/MattHawkinsUK/rpispy-misc/raw/master/python/lcd_i2c.py

If you plan on using an LCD with your Raspberry Pi, there’s a good chance you’ll need to program it in Python at some point. Python is probably the most popular programming language for coding on the Raspberry Pi, and many of the projects and examples you’ll find are written in Python.

In this tutorial, I’ll show you how to connect your LCD and program it in Python, using the RPLCD library. I’ll start with showing you how to connect it in either 8 bit mode or 4 bit mode. Then I’ll explain how to install the library, and provide examples for printing and positioning text, clearing the screen, and controlling the cursor. I’ll also give you examples for scrolling text, creating custom characters, printing data from a sensor, and displaying the date, time, and IP address of your Pi.

You can also connect the LCD via I2C, which uses only two wires, but it requires some extra hardware. Check out our article, How to Setup an I2C LCD on the Raspberry Pi to see how.

There are two ways to connect the LCD to your Raspberry Pi – in 4 bit mode or 8 bit mode. 4 bit mode uses 6 GPIO pins, while 8 bit mode uses 10. Since it uses up less pins, 4 bit mode is the most common method, but I’ll explain how to set up and program the LCD both ways.

Each character and command is sent to the LCD as a byte (8 bits) of data. In 8 bit mode, the byte is sent all at once through 8 data wires, one bit per wire. In 4 bit mode, the byte is split into two sets of 4 bits – the upper bits and lower bits, which are sent one after the other over 4 data wires.

Theoretically, 8 bit mode transfers data about twice as fast as 4 bit mode, since the entire byte is sent all at once. However, the LCD driver takes a relatively long time to process the data, so no matter which mode is being used, we don’t really notice a difference in data transfer speed between 8 bit and 4 bit modes.

The RPLCD library can be installed from the Python Package Index, or PIP. It might already be installed on your Pi, but if not, enter this at the command prompt to install it:

The example programs below use the Raspberry Pi’s physical pin numbers, not the BCM or GPIO numbers. I’m assuming you have your LCD connected the way it is in the diagrams above, but I’ll show you how to change the pin connections if you need to.

Let’s start with a simple program that will display “Hello world!” on the LCD. If you have a different sized LCD than the 16×2 I’m using (like a 20×4), change the number of columns and rows in line 2 of the code. cols= sets the number of columns, and rows= sets the number of rows. You can also change the pins used for the LCD’s RS, E, and data pins. The data pins are set as pins_data=[D0, D1, D2, D3, D4, D5, D6, D7].

The text can be positioned anywhere on the screen using lcd.cursor_pos = (ROW, COLUMN). The rows are numbered starting from zero, so the top row is row 0, and the bottom row is row 1. Similarly, the columns are numbered starting at zero, so for a 16×2 LCD the columns are numbered 0 to 15. For example, the code below places “Hello world!” starting at the bottom row, fourth column:

The RPLCD library provides several functions for controlling the cursor. You can have a block cursor, an underline cursor, or a blinking cursor. Use the following functions to set the cursor:

Text will automatically wrap to the next line if the length of the text is greater than the column length of your LCD. You can also control where the text string breaks to the next line by inserting \n\r where you want the break to occur. The code below will print “Hello” to the top row, and “world!” to the bottom row.

This program will print the IP address of your ethernet connection to the LCD. To print the IP of your WiFi connection, just change eth0 in line 19 to wlan0:

Each character on the LCD is an array of 5×8 of pixels. You can create any pattern or character you can think of, and display it on the screen as a custom character. Check out this website for an interactive tool that creates the bit array used to define custom characters.

First we define the character in lines 4 to 12 of the code below. Then we use the function lcd.create_char(0-7, NAME) to store the character in the LCD’s CGRAM memory. Up to 8 (0-7) characters can be stored at a time. To print the custom character, we use lcd.write_string(unichr(0)), where the number in unichr() is the memory location (0-7) defined in lcd.create_char().

To demonstrate how to print data from a sensor, here’s a program that displays the temperature from a DS18B20 Digital Temperature Sensor. There is some set up to do before you can get this to work on the Raspberry Pi, so check out our tutorial on the DS18B20 to see how.

In general, you take the input variable from your sensor and convert it to an integer to perform any calculations. Then convert the result to a string, and output the string to the display using lcd.write_string(sensor_data()):

Well, that about covers most of what you’ll need to get started programming your LCD with Python. Try combining the programs to get some interesting effects. You can display data from multiple sensors by printing and clearing the screen or positioning the text. You can also make fun animations by scrolling custom characters.

@0x00129fa0:[T:0x42edb490] ti.sdo.dmai - [Display] Failed to detemine video display format on Invalid argument <------------------------------------------------------------------------ (3)

The Serial 7-Segment display is particularly useful for testing serial interfaces, because it can accept command from a UART, SPI, or I2C. Make sure to solder header pins on the 7-segment display before wiring.

Which generates an executable spitest. When we run ./spitest, it will exercise each of the segments of the display. It illuminates a segment in each digit for 5 seconds, before moving to the next segment. It takes about 40 seconds overall.

In this blog post we"ll look at how to control Raspberry Pi GPIO pins from the Python programming language using two different modules: Rpi.GPIO and Gpiozero.

A newer GPIO library for the Raspberry Pi is gpiozero [4]. Created by Ben Nuttall of the Raspberry Pi Foundation and other contributors it is released under an MIT-type free software license.

Gpiozero provides may different modules or "interfaces". You typically import the ones you use by name so you can refer to them with a short name. For example:

The GPiozero library uses Broadcom (BCM) pin numbering rather than physical pin numbers. That should not normally be a problem. It does define names based on other naming conventions like physical pins that can be used and will be converted to the BCM names. The following examples will all work for an LED that is on GPIO 17 on physical pin 11:

Gpiozero has support for many devices - you can explore the documentation and try writing programs of your own. You can also extend it for new types of devices and sensors.

I have been using an online tutorial, https://www.youtube.com/watch?v=B8Kr_3xHjqE&t=166s, to display text on a LCD. The LCD can do all the functions except the displaying of text. I know there is ...

I"m going through my box of bits to start a new project and having trouble with an LCD screen. When connected to the pi4 it doesn"t fit the screen. Thing is the no signal screen also doesn"t fit when ...

Hello I am currently trying to connect my lcd display with my soil moisture sensor to display readings it is taking. Any ideas on how to get the code to do that. Currently I can operate the LCD and ...

I connected my Pi to a 4in lcd display because the screen is split into four. I am not sure how to fix it to be in landscape mode and only one displaying. I"ve tried going into config.txt and using ...

Does anybody have experience with the Uctronics B0106 LCD 3.5" Display? I have made several attempts to install the driver software, with varying results. But now I"m stuck. I am following these ...

My camera was running alright on my pc before, but after connecting my lcd touchscreen with Raspberry Pi 3B+ and when I try running the command vcgencmd get_camera I get supported = 0 and detected = 0....

I just bought an Uctronics 3.5" LCD display for my Pi 3 model B. It is beautiful, it is bright… And it comes with an onboard fan which is HORRIBLY noisy. It rattles. Obviously defective.

I installed Buster Lite on a card. I attached a Waveshare 3.5" LCD screen. (It is known to work when used on another board.) I followed these instructions to install the driver:

A bit like this question, but different... I bought this display and the MIPI to HDMI board. It all connects fine, but I get nothing on the display. The board is getting power (green led), but I don"t ...

Problem summary: set_cursor(0,0) brings text to (2,1) and set_cursor(0,1) brings text to (3,1), texts goes to imaginary 3rd line before 2nd line as if a 20x4 display.

I have 7 inch display which I used in my car almost 10 years back I want to use it with my Rpi3b+. I tried changing various display modes in config.txt like sdtv mode =0 and other numbers. None of ...

The problem first started when I tried to change the orientation of display for retro pi. Before, the orientation was vertical. So I tried to change the resolution options in "Raspi-config" ...

I am working with a DHT 11 and LCD. When executing the code, the temperature prints one time on the pc and freezes. It does not print on the LCD though neither. Can I have someone assist me with ...

I have successfully installed latest kali Linux image for rpi4 available on offensive security website. Its 2020.1. I have also configured the display with kalipi-tft-config command but on reboot, no ...

I am testing a LCD HAT ( ST7735S ) that I bought and it is working great with fbcp, but I can´t get raspberry pi os to run at native screen resolution ( 128x128 ). I´ve been reading all documentation ...

I recently bought an lcd screen on ali express that is attached to the gpio, but the system does not detect it, screen is constantly white and output is only on hdmi. I tried turning spi on raspi-...

I"m using RPi Zero W with 3.5" LCD driver ( here ). Everything works well except the UART. Linux console is disabled and UART is enabled. When video output is on HDMI port, I can send and receive ...

Good morning, I have recently started my adventure with raspberry Pi, I am currently using raspberry pi 4B and I bought a DPI screen - LCD IPS 7 "" 1024x600px Waveshare 12885 and I do not know how to ...

I have a Raspberry Pi 4B and I"m trying to hook it up with a 4x20 character LCD using a PCF8574T-based I2C interface. The interface operates at 5V so I"m also using a logic level converter. It would ...

I just bought RPI4 and 4.3 display (https://www.waveshare.com/4.3inch-dsi-lcd.htm). I attached display as required but wasn"t able to get wifi connected. I noticed that sudo iwlist wlan0 scan shows ...

So I have an LCD screen which plugs into the pi. The pi works fine, but when I do the whole LCD-show in the terminal and it restarts it stops at either “starting login service” or “starting message ...

I"m quite new to raspberry pi and custom Projects but I"d like to use an lcd touch panel like this (https://bit.ly/39HZpe4) as a keyboard for my raspberry pi 3 model b.
