Model upgrade. Despite its slim build, there is plenty of computing power in Lenovo"s gaming laptop. The combination of powerful hardware, 4K screen, and decent connectivity is to make potential buyers curious.

Lenovo offers relatively compact gaming laptops in a 15.6-inch size within its Y50-70 lineup. We previously tested various models from this range, and are now facing a new model that is equipped with a graphics core from Nvidia"s GeForce 900M lineup. To be precise, it is the GeForce GTX 960M. Our report reveals whether the new GPU has any advantages.

Since we have tested several models of the Y50-70, we will not go in-depth about casing, connectivity, input devices, screen or speakers. The corresponding information can be found in the reviews of the Lenovo Y50-70 and Lenovo Y50-70 (59424712).

1 USB 2.0, 2 USB 3.0 / 3.1 Gen1, 1 HDMI, 1 Kensington Lock, Audio Connections: headphone-out, microphone-in, Card Reader: SD, Sensors: brightness sensor

Speakers: 2 speakers + subwoofer, Keyboard: chiclet, Keyboard Light: yes, external DVD burner, Cyberlink Media Story, Cyberlink Power2Go 8, McAfee LiveSafe-Internet Security (trial), MS Office (trial), 24 Months Warranty

Since the Y50 does not have a maintenance cover, the casing has to be opened for maintaining/upgrading the hardware. Lenovo has complicated this matter unnecessarily. After all screws have been released from the bottom, the base unit"s tray comes off at three sides by itself. There are no clips. Solely the rear is not released. The fans" covers are part of the bottom tray. Since the tray could not be removed without effort, we did not make any further attempts in order to prevent damaging the casing.

We have previously tested a 4K model of the Y50-70. It features the same Samsung screen as in our present review sample. The rates differ slightly, which is normal. Two identically built screens will never correspond to one hundred percent. The installed Samsung screen can only serve with an average brightness and average contrast.

A review about the Full HD model of our present review sample will be published within the next few days. Basically, the 4K and the Full HD screen are identical. The latter has a higher contrast and lower brightness than the 4K screen.

Lenovo"s 15.6-inch Y50-70 gaming laptop has more than enough computing power for every day, and renders all up-to-date games smoothly. Our review sample is available for approximately 1500 Euros. Lenovo also has many other configurations. The currently lowest priced model from the lineup is sold for just below 800 Euros.

As in the previously tested models of Lenovo"s Y50, Intel"s Core i7 4710HQ (Haswell) quad-core processor is also inside our present review sample. It is a standard mobile processor with a TDP of 47 watts. It has more than enough computing power for all common application scenarios. The installed quad-core processor only provides a slight advantage over dual-core processors in single-thread performance, which is more important for routine use. It can first clearly distance itself in applications optimized for multiple cores.

The CPU operates at a base speed of 2.5 GHz, which can be boosted to 3.3 GHz (four cores), 3.4 GHz (two cores), and 3.5 GHz (one core) via Turbo. The CPU processes single-thread applications at full speed in AC mode. However, the laptop only exhibits the same behavior as its sister models in multi-thread applications, which are only processed at the base speed (2.5 GHz). Thus, the CPU clearly remains behind its potential in multi-thread applications. Laptops from the competition, such as Acer"s Aspire VN7-591G, do not have this problem. The Y50 shows a slightly different behavior in battery mode. The processor begins processing at 800 MHz, and gradually increases that up to 2.8 GHz only to suddenly drop to 800 MHz again. That is then repeated from the beginning.

The system runs smoothly, and we did not encounter any problems. The PCMark benchmark scores are good. However, the Y50 clearly lags behind comparable contenders, such as the Aspire VN7-591G, which also features a 4K screen. It becomes evident here that the processor in Lenovo"s laptop does not utilize its Turbo in the multi-thread tests. Both the Aspire and the Y50 generally score worse than its sister models that have a Full HD screen. When the desktop resolution of the 4K models is reduced to Full HD, the PCMark scores climb to a comparable level. The system performance of our review sample cannot be increased; Lenovo has utilized all possibilities.

The Y50 sports a solid state drive from Samsung. It is a 2.5-inch model with a capacity of 512 GB. The laptop"s owner can use approximately 410 GB of that. The remaining storage capacity is divided among the Windows installation, recovery partition and a partition for the Y50"s drivers and applications. The SSD can serve with overall good transfer rates.

The installed GeForce GTX 960M graphics core is an entry-level model from the GPU upper range. It clocks at a base rate of 1097 MHz, which can be increased to 1176 MHz via Turbo. The GPU"s maximum speed is only a few percent higher than that of the former GeForce GTX 860M graphics core. Since the cores only differ in speed, the 960 core only scores marginally better than its precursor in the 3DMark benchmark. However, the difference between the 960 and 860 models in the Y50 is greater than among the comparable models of Acer"s Aspire VN7-591G lineup. The reason: The GeForce GTX 860M GPUs in the Y50 models do not clock at their maximum possible speeds.

In addition to the GeForce core, Intel"s HD Graphics 4600 GPU has also found its way into the laptop. Both cores form a graphics switching solution (Optimus). Intel"s GPU is intended for routine and battery mode. The GeForce GPU is enabled in performance-driven applications, such as computer games. Switching is automatic, but the user can always intervene manually.

Lenovo"s Y50 is explicitly aimed at gamers. Thus, it is not surprising that it can render all current games smoothly. It is normally possible to select the Full HD resolution and high to very high quality settings. The resolution and/or quality level has to be reduced in some games, for example "The Witcher 3". The frame rates are only slightly higher than that of laptops equipped with a GeForce GTX 860M graphics core. However, the advantage over 860 models of the Y50 is greater, like in the 3DMark benchmarks, because the GeForce GTX 860M GPUs in the Y50 models do not clock at their maximum possible speeds.

The screen"s maximum resolution (3840 x 2160 pixels) can only be fully utilized in rare cases. This option is at most possible in games that only have moderate hardware requirements. The Y50 only achieves just below 70 fps in the benchmark of the game "Dirt Rally" in very low quality settings. The rates drop to 25.3 fps in medium and 22.8 fps in high settings.

It sometimes happens that the fans in the Y50 are inactive, and then not a noise is heard. However, the fans usually spin at a low speed. It should not be surprising that they speed up under load; after all, the laptop features high-performance hardware. We measured a noise level of 49.2 dB during the stress test, which is an acceptable rate in this performance category.

The Y50 performed the stress test (Prime95 and Furmark run for at least one hour) differently in AC and battery mode. The processor clocked at 2.5 GHz and the graphics core at 1085 MHz in AC mode. They were throttled to 1.4 to 1.5 GHz (CPU) and 836 (GPU) in battery mode. The laptop"s temperatures are acceptable in view of the hardware configuration. Several measuring points on the casing surpassed fifty degrees Celsius.

(-) The average temperature for the upper side under maximal load is 43.8 °C / 111 F, compared to the average of 33.8 °C / 93 F for the devices in the class Gaming.

(-) The maximum temperature on the upper side is 58.8 °C / 138 F, compared to the average of 40.4 °C / 105 F, ranging from 21.2 to 68.8 °C for the class Gaming.

The energy requirement reached up to 15.9 watts in idle mode - a very low rate for a high-performance gaming laptop. We normally measure rates of over 20 watts from the contenders. Lenovo appears to have the energy requirement well under control. The power consumption climbed up to 115.5 watts in the stress test. That is apparently too much for the 135 watt power supply because the battery was drained during the stress test. This problem did not occur in gaming routine; the laptop consumed approximately 100 watts in this scenario.

Currently we use the Metrahit Energy, a professional single phase power quality and energy measurement digital multimeter, for our measurements. Find out more about it here. All of our test methods can be found here.

The Y50 managed an idle runtime of 6:28 hours. It thus clearly outperforms its rival Acer Aspire VN7-591G (3:36 h). Idle mode is ascertained using Battery Eater"s Reader"s test. The screen is set to minimum brightness, the energy-savings profile is enabled, and the wireless modules are off. The Y50 shut down after 1:24 hours of load. The Aspire (0:58 h) is depleted sooner. The load runtime is checked with Battery Eater"s Classic test. The screen runs in maximum brightness, the high-performance profile and radio modules are enabled.

Lenovo"s laptop stopped our real-life Wi-Fi test after 3:23 hours. Again, the Aspire (2:46 h) lags behind. This test simulates the load induced when websites are opened. The "Balanced" profile is enabled, and the screen"s brightness is set to approximately 150 cd/m². We test the video playback time by running the short movie Big Buck Bunny (H.264 encoding, 1920 x 1080 pixels) in a loop. The wireless modules are disabled, and the screen"s brightness is set to approximately 150 cd/m². The Y50 lasted 3:27 hours. The Aspire (2:56 h) shut down earlier.

Lenovo is quite able to convert the relatively low idle energy requirement in decent battery runtimes for a gaming laptop. The contender Acer is outperformed here. The battery capacity of both laptops ais almost identical (Lenovo: 55 Wh, Acer: 52 Wh).

Lenovo"s Y50-70 59441231 is a 15.6-inch gaming laptop. The installed processor has more than enough computing power for all common application scenarios. The GeForce GTX 960M graphics core renders all current games smoothly. It also produces slightly higher frame rates than the GeForce GTX 860M precursor. It should not be surprising that the laptop reaches relatively high temperatures and produces noise in view of the hardware configuration. The installed 4K screen made a mixed impression. On the one hand, it is a viewing angle stable IPS screen, and on the other, its brightness and contrast could be better. It is rarely possible to use it in in games, and primarily boosts the purchase price. Like its direct contender Acer Aspire VN7-591G, the lack of a maintenance cover has to be criticized. The casing of both laptops has to be opened for replacing or installing a hard drive.All things considered, the present device can be filed under "model upgrade". The only real innovation is the GeForce GTX 960M graphics core. Owners of a laptop with the former GPU do not really have a reason for switching to a GTX 960M graphics core. The performance gain is marginal.

What started as a side job during my computer science studies later became my main job: For more than 20 years now I have been working as an editor and author in the IT sector. While working in the print sector I also contributed to the creation of various loose-leaf publications and published original written pieces. I have been working for Notebookcheck since 2012.

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller"s listing for full details.See all condition definitionsopens in a new window or tab

Afghanistan, Albania, Algeria, Andorra, Angola, Anguilla, Antigua and Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan Republic, Bahamas, Bahrain, Bangladesh, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, British Virgin Islands, Brunei Darussalam, Bulgaria, Burkina Faso, Burundi, Cambodia, Cameroon, Cape Verde Islands, Cayman Islands, Central African Republic, Chad, Chile, China, Colombia, Costa Rica, Cyprus, Czech Republic, Côte d"Ivoire (Ivory Coast), Democratic Republic of the Congo, Denmark, Djibouti, Dominican Republic, Ecuador, Egypt, El Salvador, Equatorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France, Gabon Republic, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Greenland, Grenada, Guatemala, Guinea, Guinea-Bissau, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Indonesia, Iraq, Ireland, Israel, Italy, Jamaica, Japan, Jordan, Kazakhstan, Kenya, Kiribati, Kuwait, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macau, Macedonia, Madagascar, Malawi, Malaysia, Maldives, Mali, Malta, Mauritania, Mauritius, Mexico, Moldova, Monaco, Mongolia, Montenegro, Montserrat, Morocco, Mozambique, Namibia, Nauru, Nepal, Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Niue, Norway, Oman, Pakistan, Panama, Papua New Guinea, Paraguay, Peru, Philippines, Poland, Portugal, Qatar, Republic of Croatia, Republic of the Congo, Romania, Rwanda, Saint Helena, Saint Kitts-Nevis, Saint Lucia, Saint Pierre and Miquelon, Saint Vincent and the Grenadines, San Marino, Saudi Arabia, Senegal, Serbia, Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, Solomon Islands, South Africa, South Korea, Spain, Sri Lanka, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania, Thailand, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey, Turkmenistan, Turks and Caicos Islands, Tuvalu, Uganda, United Arab Emirates, United Kingdom, United States, Uzbekistan, Vanuatu, Vatican City State, Vietnam, Wallis and Futuna, Western Sahara, Western Samoa, Yemen, Zambia, Zimbabwe

• Before using this information and the product it supports, be sure to read the general information under “Notices” on page 76. • This manual applies to the following models: Lenovo Y70-70 Touch/Y70-80 Touch. The illustrations used in this manual are for Lenovo Y70-70 Touch unless otherwise stated.

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual • Alwayslookcarefullyforpossiblehazardsinyourworkarea.Examplesof thesehazardsaremoistfloors,nongroundedpowerextensioncables,power surges,andmissingsafetygrounds. • Do not touch live electrical circuits with the reflective surface of a plastic dentalmirror.Thesurfaceisconductive;suchtouchingcancausepersonal injuryandmachinedamage. • Donotservicethefollowingpartswiththepoweronwhentheyareremoved fromtheirnormaloperatingplacesinamachine: – Powersupplyunits – Pumps – Blowersandfans – Motorgenerators andsimilarunits.(Thispracticeensurescorrectgroundingoftheunits.) • Ifanelectricalaccidentoccurs: – Caution:donotbecomeavictimyourself.

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Safety notice 2 DANGER Some standby batteries contain a small amount of nickel and cadmium. Do not disassemble a standby battery, recharge it, throw it into fire or water, or short- circuit it. Dispose of the battery as required by local ordinances or regulations.

Safety information Safety notice 3 DANGER The battery pack contains small amounts of nickel. Do not disassemble it, throw it into fire or water, or short-circuit it. Dispose of the battery pack as required by local ordinances or regulations. Use only the battery in the appropriate parts listing when replacing the battery pack.

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Safety notice 4 DANGER The lithium battery can cause a fire, an explosion, or a severe burn. Do not recharge it, remove its polarized connector, disassemble it, heat it above 100°C (212°F), incinerate it, or expose its cell contents to water. Dispose of the battery as required by local ordinances or regulations.

Safety information Safety notice 5 If the LCD breaks and the fluid from inside the LCD gets into your eyes or on your hands, immediately wash the affected areas with water at least for 15 minutes. Seek medical care if any symptoms caused by the fluid are present after washing. Si le panneau d’affichage à...

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Safety notice 6 DANGER To avoid shock, do not remove the plastic cover that protects the lower part of the inverter card. Afin d’éviter tout risque de choc électrique, ne retirez pas le cache en plastique protégeant la partie inférieure de la carte d’alimentation.

Safety information Safety notice 8 DANGER Before removing any FRU, turn off the computer, unplug all power cords from electrical outlets, remove the battery pack, and then disconnect any interconnecting cables. Avant de retirer une unité remplaçable en clientèle, mettez le système hors tension, débranchez tous les cordons d’alimentation des socles de prise de courant, retirez la batterie et déconnectez tous les cordons d’interface.

Safety information ACD-ROMdrive,aDVD-ROMdrive,oranyotherstoragedeviceinstalledmay containanembeddedClass3AorClass3Blaserdiode.Notethefollowing: DANGER Emits visible and invisible laser radiation when open. Do not stare into the beam, do not view directly with optical instruments, and avoid direct exposure to the beam. Radiação por raio laser ao abrir. Não olhe fixo no feixe de luz, não olhe diretamente por meio de instrumentos óticos e evite exposição direta com o feixe de luz.

Lenovo Y70-70 Touch/Y70-80 Touch Table 1. Specifications (continued) Feature Description Ethernet(onthe • 10/100/1,000Mbps systemboard) Bluetooth • Combinedincombocard wireless Keyboard • 6rowISOfullsizekeyboard Touchpad • Multi-touchtype Integrated • HD(720p) camera Battery • 4cell,54Wh ACadapter • 20V,135W Pre-installed operating • Windows8.1 system...

Lenovo Y70-70 Touch/Y70-80 Touch Table 2. Status indicators (continued) Indicator Charge Indicator Meaning status status On(solidwhite) Thetouchpadisenabled. 3  Touchpad Theharddiskdriveisreadingor writingdata. 4  HardDiskDrive Theharddiskdriveisreading Blinking orwritingdata.

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Note: Applying labels to the base cover ThenewbasecoverFRUisshippedwithakitcontaininglabelsofseveral kinds. When you replace the base cover, you need to apply the following label: Thefollowinglabelsneedtobepeeledofffromtheoldbasecoverandputon thenewbasecover. GMLlabel KRKCClabel Wlan/BTlabel ( 1 5x10mmforMalaysia/Indonesia 20x10mmforSouthAfrica 32x10mmforIsrael/US/CA/TW 35x15mmforBrazil) Indonesiaratinglabel Ratinglabel Forsomemodels,youalsoneedtoapplyoneortwoFCClabels.Checkthe...

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Figure 3. Removal steps of hard disk drive (continued) Removetheharddiskdrive3. Remove the screws 4anddetachthemetalframefromtheharddiskdrive. Step Screw (quantity) Color Torque M3×3mm,flat-head,nylok-coated(4) Sliver 2.5kgf*cm HDDbrackettoHDD When installing:Ifaharddiskdrivemylarlabelispresent,donotreuseit.Use thenewharddiskdrivemylarlabelincludedwiththeharddiskdrivebeinginstalled.

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Figure 4. Removal steps of PCI Express Mini Card for wireless LAN (continued) Remove the card in the direction shown by arrow 3. When installing: • In models with a wireless LAN card that has two antenna connectors, plug theblackcable(1st)(MAIN)intothejacklabeledMAIN, and the white cable (2nd)(AUX)intothejacklabeledAUX on the card.

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Figure 9. Removal steps of fan assembly and heat sink assembly (continued) Remove the screws 5. Step Screw (quantity) Color Torque M2.0×6.5mm,flat-head,nylok-coated(6) Black 2.5kgf*cm THERMALMODULE(CPU)toMB Removetheheatsinkassemblyinthedirectionshownbyarrow6. When installing: • Route the antenna cables along the cable guides. As you route the cables, makesurethattheyarenotsubjectedtoanytension.Tensioncouldcause...

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Figure 10. Removal steps of system board (continued) RemovetheRJ-45doorandthesystemboardinthedirectionshownbyarrows5. Open the creased adhesive tab in the direction shown by arrow 6. RemovetheDC-incable7.

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Figure 12. Removal steps of power board and touchpad (continued) Remove the power board in the direction shown by arrow 3. Remove the screws 4,thenremovethetouchpadbracketinthedirection shown by arrow 5. Step Screw (quantity) Color Torque M2.0×3.0mm,flat-head,nylok-coated(3)

Lenovo Y70-70 Touch/Y70-80 Touch Figure 12. Removal steps of power board and touchpad (continued) Remove the screws 6, then remove the touchpad module in the direction shown by arrow 7. Step Screw (quantity) Color Torque M2.0×2.0mm,flat-head,nylok-coated(3) Black 1.5kgf*cm CLICK PAD FRAME TO LOGIC UP...

Lenovo Y70-70 Touch/Y70-80 Touch Figure 13. Removal steps of upper case (continued) Open the hinge in the direction shown by arrows 2. Remove the upper case in the direction shown by arrow 3.

Lenovo Y70-70 Touch/Y70-80 Touch Figure 14. Removal steps of LCD unit (continued) Remove the screws 2. Then push the LCD module slightly in the direction shown by arrow 3. Step Screw (quantity) Color Torque M2.5×3.5mm,flat-head,nylok-coated(3) Black 2.5kgf*cm Bezel to LCD COVER Remove the screws 4 and 5.

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Figure 14. Removal steps of LCD unit (continued) Then release the hinges in the direction shown by arrows 6. Remove the LCD module 7.

Lenovo Y70-70 Touch/Y70-80 Touch Figure 14. Removal steps of LCD unit (continued) Liftthecameraalittleinthedirectionshownbyarrow8. Disconnect the camera connector in the direction shown by arrow 9. Then remove the camera. Note: T heintegratedcameraisstuckonthetopcenteroftheLCDcover. Disconnect the connectors in the direction shown by arrows j.

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Table 4. Parts list—Overall No. FRU FRU no. CRU ID. a-h See“Miscellaneousparts”onpage71. LCDunit(see“LCDFRUs”onpage69.) UpperCaseCY70-70TW/KB-US 5CB0G59766 UpperCaseCY70-70TW/KB-GRK 5CB0G59768 UpperCaseCY70-70TW/KB-INT"E 5CB0G59771 UpperCaseCY70-70TW/KB-KOR 5CB0G59784 UpperCaseCY70-70TW/KB-T-CH 5CB0G59787 UpperCaseCY70-70TW/KB-RUS 5CB0G59789 UpperCaseCY70-70TW/KB-ARE 5CB0G59791 UpperCaseCY70-70TW/KB-HEB 5CB0G59792 UpperCaseCY70-70TW/KB-THAI 5CB0G59793 UpperCaseCY70-70TW/KB-INDIA 5CB0G59794 UpperCaseCY70-70TW/KB-UK...

Lenovo Y70-70 Touch/Y70-80 Touch Table 4. Parts list—Overall (continued) No. FRU FRU no. CRU ID. MB C Y70-70T NOK 4710 4G 5B20G59754 MB C Y70-70T W8P 4710 4G 5B20G59761 MB C Y70-70T W8S 4710 4G 5B20G59763 MB C Y70-70T NOK 4200 4G...

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Table 4. Parts list—Overall (continued) No. FRU FRU no. CRU ID. Intel72602x2AC+BTPCIEM.2WLANV2 20200552 LtnNFA3451x1AC+BT4.0PCIEM.2WLAN 20200579 CbtBCM431621x1AC+BT4.0PCIEM.2WLAN 20200573 CbtBCM43522x2AC+BT4.0PCIEM.2WLAN 20200480 LtnNFA3442x2AC+BT4.0PCIEM.2WLAN 20200580 LtnNFA3351x1BN+BT4.0PCIEM.2WLAN 20200558 CbtBCM431421x1BN+BT4.0PCIEM.2WLAN 20200557 CbtRTL8723BE1x1BN+BT4.0PCIEM.2WLAN 20200570 Battery,Y50SP/AL13M4P027.4V54Wh4cellbty 121500250 Battery,Y50SNL13N4P017.6V54Wh4cellbty 121500251 LowerCaseCY70-70T 5CB0G59916 —...

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Table 5. Parts list—17.3-in. Touch HD LED No. FRU FRU no. CRU ID. HingeCoverCY70-70T 5CB0G59913 HingeCY70-70TL+R 5H50G59905 LCDModuleCY70-70T 5D10G59769 CameraCY70-70TW/Tape 5C20G59755 LCDCableCY70-70T 5C10G59752 AntennaCY70-70T 5C10G59790 LCDCoverCY70-70T 5CB0G59753...

Y70-70 Touch/Y70-80 Touch Hardware Maintenance Manual Table 9. Parts list—3-pin power cords (continued) Region CRU ID. Japan 145000530 •VOLEXVAC5S+VCTF+M7551m Japan 145500005 •lux0018(E)+VCTF0.75/3C+00211m Australia 145000589 •LINETEKLS15+H03VV-F+LP-23A1m Australia 145000557 •LongwellLP-23A+LFC-3R+LS-181m Australia 145000532 •VOLEXAU10S3+H03VV-F+VAC5S1m Australia 145500006 •lux0038+H03VV-F0.75/3C+00111m Taiwan 145000588 •LINETEKLS15+VCTF+LP-531m Taiwan 145000556 •LongwellLP-71+VCTF+LS-331m...

Lenovo Y70-70 Touch/Y70-80 Touch Table 9. Parts list—3-pin power cords (continued) Region CRU ID. Brazil 145000564 •LongwellLP-46+H03VV-F+LS-181m Brazil 145000527 •VOLEXCH10S3+H03VV-F+VAC5S1m Brazil 145500011 •lux0034+H03VV-F0.75/3C+00111m Israel 145000595 •LINETEKLS15+H03VV-F+LP-411m Israel 145000563 •LongwellLP-41+H03VV-F+LS-181m Israel 145000526 •VOLEXSI16S3+H03VV-F+VAC5S1m Israel 145500012 •lux0041+H03VV-F0.75/3C+00111m Switzerland 145000597 •LINETEKLS15+H03VV-F+LP-371m Switzerland 145000565 •LongwellLP-37+H03VV-F+LS-181m...

Y70-80 TouchHardwareMaintenanceManual Notes: Before using this information and the product it supports, be sure to read the general information under Notices on page 76. This manual applies to the following models: Lenovo Y70-70 Touch/Y70-80 Touch. The illustrations used in this manual are for Lenovo Y70-70 Touch unless otherwise stated.

First Edition (July. 2014) Copyright Lenovo 2014. All rights reserved.LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a GeneralServices Administration GSA contract, use, reproduction, or disclosure is subject to restrictions setforth in Contract No. GS-35F-05925. 2014 LenovoContentsAbout this manual........................................ iv 1040 PCI Express Mini Card for wireless LAN......................................................39Safety information......................................... 1 1050 DIMM........................................................41 1060 LED board................................................42General safety................................................. 2 1070 Subwoofer................................................43Electrical safety............................................... 3 1080 USB board................................................44Safety inspection guide................................... 5 1090 Fan assembly and Heat Sink assembly.... 45Handling devices that are sensitive to 1100 System board............................................. 47electrostatic discharge..................................... 6 1110 Speakers...................................................49Grounding requirements.................................. 6 1120 Power board and touchpad.......................51 1130 Upper case................................................54Safety notices: multilingual translations.......... 7 1140 LCD unit....................................................56Laser compliance statement......................... 14 1150 Antenna assembly....................................61 Locations....................................................... 62Important service information.................... 16 Front view and right-side view...........................62Strategy for replacing FRUs.......................... 16 Bottom and Left-side view ................................63 Strategy for replacing a hard disk drive.............17 Parts list......................................................... 64 Important notice for replacing a system Overall...............................................................65 board ................................................................17 LCD FRUs.........................................................69Important information about replacing Miscellaneous parts...........................................71RoHS compliant FRUs.................................. 18 AC adapters.......................................................72 Screws...............................................................72General checkout ....................................... 19 Power cords.......................................................73What to do first.............................................. 20Power system checkout................................ 21 Notices......................................................... 76 Checking the AC adapter . ................................21 Trademarks................................................... 77 Checking operational charging..........................21 Checking the battery pack.................................22

Related service information....................... 23Restoring the factory contents by using OneKey Recovery......................................... 23 Restore of factory default..................................23Passwords..................................................... 24 Power-on password...........................................24 Hard-disk password...........................................24 Administrator password.....................................24Power management...................................... 25 Screen blank state.............................................25 Putting the computer to sleep or shutting it down..................................................................25 Putting your computer to sleep..........................25 Shutting down the computer..............................25

Lenovo Y70-70 Touch/Y70-80 Touch......... 26Specifications................................................ 26Status indicators............................................ 28Fn key combinations..................................... 30FRU replacement notices.............................. 31 Screw notices ...................................................31Removing and replacing an FRU.................. 32 1010 Base cover................................................33 1020 Battery pack..............................................35 1030 Hard disk drive..........................................37

iiiAbout this manual This manual contains service and reference information for the following Lenovo product: Lenovo Y70-70 Touch/Y70-80 Touch Use this manual to troubleshoot problems. The manual is divided into the following sections: The common sections provide general information, guidelines, and safety information required for servicing computers. The product-specific section includes service, reference, and product-specific parts information.

Important: This manual is intended only for trained servicers who are familiar with Lenovo products. Use this manual to troubleshoot problems effectively. Before servicing a Lenovo product, make sure to read all the information under Safety information on page 1 and Important service information on page 16.

Safety information This chapter presents the following safety information that you need to get familiar with before you service a Lenovo Y70-70 Touch/Y70-80 Touch computer: General safety on page 2 Electrical safety on page 3 Safety inspection guide on page 5 Handling devices that are sensitive to electrostatic discharge on page 6 Grounding requirements on page 6 Safety notices: multilingual translations on page 7 Laser compliance statement on page 14

General safety Follow these rules below to ensure general safety: Observe a good housekeeping in the area where the machines are put during and after the maintenance. When lifting any heavy object: 1. Make sure that you can stand safely without slipping. 2. Distribute the weight of the object equally between your feet. 3. Use a slow lifting force. Never move suddenly or twist when you attempt to lift it. 4. Lift it by standing or pushing up with your leg muscles; this action could avoid the strain from the muscles in your back. Do not attempt to lift any object that weighs more than 16 kg (35 lb) or that you think is too heavy for you. Do not perform any action that causes hazards to the customer, or that makes the machine unsafe. Before you start the machine, make sure that other service representatives and the customer are not in a hazardous position. Please remove covers and other parts in a safe place, away from all personnel, while you are servicing the machine. Keep your toolcase away from walk areas so that other people will not trip over it. Do not wear loose clothing that can be trapped in the moving parts of the machine. Make sure that your sleeves are fastened or rolled up above your elbows. If your hair is long, fasten it. Insert the ends of your necktie or scarf inside clothing or fasten it with the nonconductive clip, about 8 centimeters (3 inches) from the end. Do not wear jewelry, chains, metal-frame eyeglasses, or metal fasteners for your clothing. Attention: Metal objects are good electrical conductors. Wear safety glasses when you are hammering, drilling, soldering, cutting wire, attaching springs, using solvents, or working in any other conditions that may be hazardous to your eyes. After service, reinstall all safety shields, guards, labels, and ground wires. Replace any safety device that is worn or defective. Reinstall all covers correctly before returning the machine to the customer. Fan louvers on the machine help to prevent the overheating of internal components. Do not obstruct fan louvers or cover them with labels or stickers.

Important: Use only approved tools and test equipments. Some hand tools have handles covered with a soft material that does not insulate you when working with live electrical currents. Many customers have rubber floor mats near their machines that contain small conductive fibers to decrease electrostatic discharges. Do not use such kind of mat to protect yourself from electrical shock.

Find the room emergency power-off (EPO) switch, disconnecting switch or electrical outlet. If an electrical accident occurs, you can then operate the switch or unplug the power cord quickly. Do not work alone under hazardous conditions or near the equipment that has hazardous voltages. Disconnect all power before: Performing a mechanical inspection Working near power supplies Removing or installing main units Before you start to work on the machine, unplug the power cord. If you cannot unplug it, ask the customer to power-off the wall box that supplies power to the machine, and to lock the wall box in the off position. If you need to work on a machine that has exposed electrical circuits, observe the following precautions: Ensure that another person, familiar with the power-off controls, is near you. Attention: Another person must be there to switch off the power, if necessary. Use only one hand when working with powered-on electrical equipment; keep the other hand in your pocket or behind your back. Attention: An electrical shock can occur only when there is a complete circuit. By observing the above rule, you may prevent a current from passing through your body. When using testers, set the controls correctly and use the approved probe leads and accessories for that tester. Stand on suitable rubber mats (obtained locally, if necessary) to insulate you from grounds such as metal floor strips and machine frames. Observe the special safety precautions when you work with very high voltages; instructions for these precautions are in the safety sections of maintenance information. Be extremely careful when you measure the high voltages. Regularly inspect and maintain your electrical hand tools for safe operational condition. Do not use worn or broken tools and testers. Never assume that power has been disconnected from a circuit. First, check it to make sure that it has been powered off.

Always look carefully for possible hazards in your work area. Examples of these hazards are moist floors, nongrounded power extension cables, power surges, and missing safety grounds. Do not touch live electrical circuits with the reflective surface of a plastic dental mirror. The surface is conductive; such touching can cause personal injury and machine damage. Do not service the following parts with the power on when they are removed from their normal operating places in a machine: Power supply units Pumps Blowers and fans Motor generators and similar units. (This practice ensures correct grounding of the units.) If an electrical accident occurs: Caution: do not become a victim yourself. Switch off the power. Send the victim to get medical aid.

Safety inspection guide The purpose of this inspection guide is to assist you in identifying potential unsafe conditions. As each machine was designed and built, required safety items were installed to protect users and service personnel from injury. This guide addresses only those items. You should use good judgment to identify potential safety hazards according to the attachment of non-Lenovo features or options not covered by this inspection guide.

If any unsafe conditions are present, you must determine how serious the apparent hazard could be and whether you can continue without first correcting the problem.

Consider these conditions and the safety hazards they present: Electrical hazards, especially primary power (primary voltage on the frame can cause serious or fatal electrical shock) Explosive hazards, such as a damaged CRT face or a bulging capacitor Mechanical hazards, such as loose or missing hardware

To determine whether there are any potential unsafe conditions, use the following checklist at the beginning of every service task. Begin the checks with the power off, and the power cord disconnected.

Checklist: 1. Check exterior covers for damage (loose, broken, or sharp edges). 2. Turn off the computer. Disconnect the power cord. 3. Check the power cord for: a. A third-wire ground connector in good condition. Use a meter to measure third-wire ground continuity for 0.1 ohm or less between the external ground pin and the frame ground. b. The power cord should be the type specified in the parts list. c. Insulation must not be frayed or worn. 4. Check for cracked or bulging batteries. 5. Remove the cover. 6. Check for any obvious non-Lenovo alterations. Use good judgment as to the safety of any non-Lenovo alterations. 7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage. 8. Check for worn, frayed, or pinched cables. 9. Check that the power-supply cover fasteners (screws or rivets) have not been removed or tampered with.

Handling devices that are sensitive to electrostatic discharge Any computer part containing transistors or integrated circuits (ICs) should be considered sensitive to electrostatic discharge (ESD). ESD damage can occur when there is a difference in charge between objects. Protect against ESD damage by equalizing the charge so that the machine, the part, the work mat, and the person handling the part are all at the same charge.

Notes: 1. Use product-specific ESD procedures when they exceed the requirements noted here. 2. Make sure that the ESD protective devices you use have been certified (ISO 9000) as fully effective.

When handling ESD-sensitive parts: Keep the parts in protective packages until they are inserted into the product. Avoid contact with other people. Wear a grounded wrist strap against your skin to eliminate static on your body. Prevent the part from touching your clothing. Most clothing is insulative and retains a charge even when you are wearing a wrist strap. Use the black side of a grounded work mat to provide a static-free work surface. The mat is especially useful when handling ESD-sensitive devices. Select a grounding system, such as those listed below, to provide protection that meets the specific service requirement.

Attach the ESD ground clip to any frame ground, ground braid, or green- wire ground. When working on a double-insulated or battery-operated system, use an ESD common ground or reference point. You can use coax or connector- outside shells on these systems. Use the round ground prong of the ac plug on ac-operated computers.

Grounding requirements Electrical grounding of the computer is required for operator safety and correct system function. Proper grounding of the electrical outlet can be verified by a certified electrician.

Safety notices: multilingual translations The safety notices in this section are provided in English, French, German, Hebrew, Italian, Japanese, and Spanish.

Safety notice 1 Before the computer is powered on after FRU replacement, make sure all screws, springs, and other small parts are in place and are not left loose inside the computer. Verify this by shaking the computer and listening for rattling sounds. Metallic parts or metal flakes can cause electrical shorts. Avant de remettre lordinateur sous tension aprs remplacement dune unit en clientle, vrifiez que tous les ressorts, vis et autres pices sont bien en place et bien fixes. Pour ce faire, secouez lunit et assurez-vous quaucun bruit suspect ne se produit. Des pices mtalliques ou des copeaux de mtal pourraient causer un court-circuit. Bevor nach einem FRU-Austausch der Computer wieder angeschlossen wird, mu sichergestellt werden, da keine Schrauben, Federn oder andere Kleinteile fehlen oder im Gehuse vergessen wurden. Der Computer mu geschttelt und auf Klappergerusche geprft werden. Metallteile oder-splitter knnen Kurzschlsse erzeugen.

Prima di accendere lelaboratore dopo che stata effettuata la sostituzione di una FRU, accertarsi che tutte le viti, le molle e tutte le altri parti di piccole dimensioni siano nella corretta posizione e non siano sparse allinterno dellelaboratore. Verificare ci scuotendo lelaboratore e prestando attenzione ad eventuali rumori; eventuali parti o pezzetti metallici possono provocare cortocircuiti pericolosi.

Antes de encender el sistema despues de sustituir una FRU, compruebe que todos los tornillos, muelles y dems piezas pequeas se encuentran en su sitio y no se encuentran sueltas dentro del sistema. Comprubelo agitando el sistema y escuchando los posibles ruidos que provocaran. Las piezas metlicas pueden causar cortocircuitos elctricos.

Safety notice 2 DANGER Some standby batteries contain a small amount of nickel and cadmium. Do not disassemble a standby battery, recharge it, throw it into fire or water, or short- circuit it. Dispose of the battery as required by local ordinances or regulations. Use only the battery in the appropriate parts listing. Use of an incorrect battery can result in ignition or explosion of the battery. Certaines batteries de secours contiennent du nickel et du cadmium. Ne les dmontez pas, ne les rechargez pas, ne les exposez ni au feu ni leau. Ne les mettez pas en court-circuit. Pour les mettre au rebut, conformez-vous la rglementation en vigueur. Lorsque vous remplacez la pile de sauvegarde ou celle de lhorloge temps rel, veillez nutiliser que les modles cits dans la liste de pices dtaches adquate. Une batterie ou une pile inapproprie risque de prendre feu ou dexploser. Die Bereitschaftsbatterie, die sich unter dem Diskettenlaufwerk befindet, kann geringe Mengen Nickel und Cadmium enthalten. Sie darf nicht zerlegt, wiederaufgeladen, kurzgeschlossen, oder Feuer oder Wasser ausgesetzt werden. Bei der Entsorgung die rtlichen Bestimmungen fr Sondermll beachten. Beim Ersetzen der Bereitschafts-oder Systembatterie nur Batterien des Typs verwenden, der in der Ersatzteilliste aufgefhrt ist. Der Einsatz falscher Batterien kann zu Entzndung oder Explosion fhren.

Alcune batterie di riserva contengono una piccola quantit di nichel e cadmio. Non smontarle, ricaricarle, gettarle nel fuoco o nellacqua n cortocircuitarle. Smaltirle secondo la normativa in vigore (DPR 915/82, successive disposizioni e disposizioni locali). Quando si sostituisce la batteria dellRTC (real time clock) o la batteria di supporto, utilizzare soltanto i tipi inseriti nellappropriato Catalogo parti. Limpiego di una batteria non adatta potrebbe determinare lincendio o lesplosione della batteria stessa.

Algunas bateras de reserva contienen una pequea cantidad de nquel y cadmio. No las desmonte, ni recargue, ni las eche al fuego o al agua ni las cortocircuite. Deschelas tal como dispone la normativa local. Utilice slo bateras que se encuentren en la lista de piezas. La utilizacin de una batera no apropiada puede provocar la ignicin o explosin de la misma.

Safety notice 3 DANGERThe battery pack contains small amounts of nickel. Do not disassemble it, throwit into fire or water, or short-circuit it. Dispose of the battery pack as required bylocal ordinances or regulations. Use only the battery in the appropriate parts listingwhen replacing the battery pack. Use of an incorrect battery can result in ignitionor explosion of the battery.La batterie contient du nickel. Ne la dmontez pas, ne lexposez ni au feu ni leau.Ne la mettez pas en court-circuit. Pour la mettre au rebut, conformez-vous larglementation en vigueur. Lorsque vous remplacez la batterie, veillez nutiliserque les modles cits dans la liste de pices dtaches adquate. En effet, unebatterie inapproprie risque de prendre feu ou dexploser.Akkus enthalten geringe Mengen von Nickel. Sie drfen nicht zerlegt,wiederaufgeladen, kurzgeschlossen, oder Feuer oder Wasser ausgesetzt werden.Bei der Entsorgung die rtlichen Bestimmungen fr Sondermll beachten. BeimErsetzen der Batterie nur Batterien des Typs verwenden, der in der Ersatzteillisteaufgefhrt ist. Der Einsatz falscher Batterien kann zu Entzndung oder Explosionfhren.

La batteria contiene piccole quantit di nichel. Non smontarla, gettarla nel fuocoo nellacqua n cortocircuitarla. Smaltirla secondo la normativa in vigore (DPR915/82, successive disposizioni e disposizioni locali). Quando si sostituisce labatteria, utilizzare soltanto i tipi inseriti nellappropriato Catalogo parti. Limpiegodi una batteria non adatta potrebbe determinare lincendio o lesplosione dellabatteria stessa.

Las bateras contienen pequeas cantidades de nquel. No las desmonte, nirecargue, ni las eche al fuego o al agua ni las cortocircuite. Deschelas tal comodispone la normativa local. Utilice slo bateras que se encuentren en la lista depiezas al sustituir la batera. La utilizacin de una batera no apropiada puedeprovocar la ignicin o explosin de la misma.

Safety notice 4 DANGER The lithium battery can cause a fire, an explosion, or a severe burn. Do not recharge it, remove its polarized connector, disassemble it, heat it above 100C (212F), incinerate it, or expose its cell contents to water. Dispose of the battery as required by local ordinances or regulations. Use only the battery in the appropriate parts listing. Use of an incorrect battery can result in ignition or explosion of the battery. La pile de sauvegarde contient du lithium. Elle prsente des risques dincendie, dexplosion ou de brlures graves. Ne la rechargez pas, ne retirez pas son connecteur polaris et ne la dmontez pas. Ne lexposez pas une temperature suprieure 100C, ne la faites pas brler et nen exposez pas le contenu leau. Mettez la pile au rebut conformment la rglementation en vigueur. Une pile inapproprie risque de prendre feu ou dexploser. Die Systembatterie ist eine Lithiumbatterie. Sie kann sich entznden, explodieren oder schwere Verbrennungen hervorrufen. Batterien dieses Typs drfen nicht aufgeladen, zerlegt, ber 100 C erhitzt oder verbrannt werden. Auch darf ihr Inhalt nicht mit Wasser in Verbindung gebracht oder der zur richtigen Polung angebrachte Verbindungsstecker entfernt werden. Bei der Entsorgung die rtlichen Bestimmungen fr Sondermll beachten. Beim Ersetzen der Batterie nur Batterien des Typs verwenden, der in der Ersatzteilliste aufgefhrt ist. Der Einsatz falscher Batterien kann zu Entzndung oder Explosion fhren.

La batteria di supporto e una batteria al litio e puo incendiarsi, esplodere o procurare gravi ustioni. Evitare di ricaricarla, smontarne il connettore polarizzato, smontarla, riscaldarla ad una temperatura superiore ai 100 gradi centigradi, incendiarla o gettarla in acqua. Smaltirla secondo la normativa in vigore (DPR 915/82, successive disposizioni e disposizioni locali). Limpiego di una batteria non adatta potrebbe determinare lincendio o lesplosione della batteria stessa.

La batera de repuesto es una batera de litio y puede provocar incendios, explosiones o quemaduras graves. No la recargue, ni quite el conector polarizado, ni la desmonte, ni caliente por encima de los 100C (212F), ni la incinere ni exponga el contenido de sus celdas al agua. Deschela tal como dispone la normativa local.

Safety notice 5If the LCD breaks and the fluid from inside the LCD gets into your eyes or on yourhands, immediately wash the affected areas with water at least for 15 minutes.Seek medical care if any symptoms caused by the fluid are present after washing.Si le panneau daffichage cristaux liquides se brise et que vous recevez dans lesyeux ou sur les mains une partie du fluide, rincez-les abondamment pendant aumoins quinze minutes. Consultez un mdecin si des symptmes persistent aprs lelavage.Die Leuchtstoffrhre im LCD-Bildschirm enthlt Quecksilber. Bei der Entsorgungdie rtlichen Bestimmungen fr Sondermll beachten. Der LCD-Bildschirmbesteht aus Glas und kann zerbrechen, wenn er unsachgem behandelt wirdoder der Computer auf den Boden fllt. Wenn der Bildschirm beschdigt ist unddie darin befindliche Flssigkeit in Kontakt mit Haut und Augen gert, solltendie betroffenen Stellen mindestens 15 Minuten mit Wasser abgesplt und beiBeschwerden anschlieend ein Arzt aufgesucht werden.

Nel caso che caso lLCD si dovesse rompere ed il liquido in esso contenutoentrasse in contatto con gli occhi o le mani, lavare immediatamente le partiinteressate con acqua corrente per almeno 15 minuti; poi consultare un medico se isintomi dovessero permanere.

Si la LCD se rompe y el fluido de su interior entra en contacto con sus ojos o susmanos, lave inmediatamente las reas afectadas con agua durante 15 minutoscomo mnimo. Obtenga atencin medica si se presenta algn sntoma del fluidodespues de lavarse.

Safety notice 6 DANGER To avoid shock, do not remove the plastic cover that protects the lower part of the inverter card. Afin dviter tout risque de choc lectrique, ne retirez pas le cache en plastique protgeant la partie infrieure de la carte dalimentation. Aus Sicherheitsgrnden die Kunststoffabdeckung, die den unteren Teil der Spannungswandlerplatine umgibt, nicht entfernen.

Safety notice 7 DANGER Though the main batteries have low voltage, a shorted or grounded battery can produce enough current to burn personnel or combustible materials. Bien que le voltage des batteries principales soit peu lev, le court-circuit ou la mise la masse dune batterie peut produire suffisamment de courant pour brler des matriaux combustibles ou causer des brlures corporelles graves. Obwohl Hauptbatterien eine niedrige Spannung haben, knnen sie doch bei Kurzschlu oder Erdung genug Strom abgeben, um brennbare Materialien zu entznden oder Verletzungen bei Personen hervorzurufen.

Sebbene le batterie di alimentazione siano a basso voltaggio, una batteria in corto circuito o a massa pu fornire corrente sufficiente da bruciare materiali combustibili o provocare ustioni ai tecnici di manutenzione.

Aunque las bateras principales tienen un voltaje bajo, una batera cortocircuitada o con contacto a tierra puede producir la corriente suficiente como para quemar material combustible o provocar quemaduras en el personal.

Safety notice 8 DANGERBefore removing any FRU, turn off the computer, unplug all power cords fromelectrical outlets, remove the battery pack, and then disconnect any interconnectingcables.Avant de retirer une unit remplaable en clientle, mettez le systme hors tension,dbranchez tous les cordons dalimentation des socles de prise de courant, retirezla batterie et dconnectez tous les cordons dinterface.Die Stromzufuhr mu abgeschaltet, alle Stromkabel aus der Steckdose gezogen,der Akku entfernt und alle Verbindungskabel abgenommen sein, bevor eine FRUentfernt wird.

Prima di rimuovere qualsiasi FRU, spegnere il sistema, scollegare dalle preseelettriche tutti i cavi di alimentazione, rimuovere la batteria e poi scollegare i cavidi interconnessione.

Antes de quitar una FRU, apague el sistema, desenchufe todos los cables delas tomas de corriente elctrica, quite la batera y, a continuacin, desconectecualquier cable de conexin entre dispositivos.

Laser compliance statement Some models of Lenovo computer are equipped from the factory with an optical storage device such as a CD-ROM drive or a DVD-ROM drive. Such devices are also sold separately as options. If one of these drives is installed, it is certified in the U.S. to conform to the requirements of the Department of Health and Human Services 21 Code of Federal Regulations (DHHS 21 CFR) Subchapter J for Class 1 laser products. Elsewhere, the drive is certified to conform to the requirements of the International Electrotechnical Commission (IEC) 825 and CENELEC EN 60 825 for Class 1 laser products.

CAUTION Use of controls or adjustments or performance of procedures other than those specified herein might result in hazardous radiation exposure. O uso de controles, ajustes ou desempenho de procedimentos diferentes daqueles aqui especificados pode resultar em perigosa exposio radiao.

Pour viter tout risque dexposition au rayon laser, respectez les consignes de rglage et dutilisation des commandes, ainsi que les procdures dcrites. Werden Steuer- und Einstellelemente anders als hier festgesetzt verwendet, kann gefhrliche Laserstrahlung auftreten.

El uso de controles o ajustes o la ejecucin de procedimientos distintos de los aqu especificados puede provocar la exposicin a radiaciones peligrosas.

Opening the CD-ROM drive, the DVD-ROM drive, or any other optical storage device could result in exposure to hazardous laser radiation. There are no serviceable parts inside those drives. Do not open.

DANGER Emits visible and invisible laser radiation when open. Do not stare into the beam, do not view directly with optical instruments, and avoid direct exposure to the beam. Radiao por raio laser ao abrir. No olhe fixo no feixe de luz, no olhe diretamente por meio de instrumentos ticos e evite exposio direta com o feixe de luz.

Rayonnement laser si carter ouvert. vitez de fixer le faisceau, de le regarder directement avec des instruments optiques, ou de vous exposer au rayon. Laserstrahlung bei geffnetem Gert. Nicht direkt oder ber optische Instrumente in den Laserstrahl sehen und den Strahlungsbereich meiden. Kinyitskor lzersugr ! Ne nzzen bele se szabad szemmel, se optikai eszkzkkel. Kerlje a sugrnyalbbal val rintkezst! Aprendo lunit vengono emesse radiazioni laser. Non fissare il fascio, non guardarlo direttamente con strumenti ottici e evitare lesposizione diretta al fascio.

Important service information This chapter presents the following important service information: Strategy for replacing FRUs on page 16 Strategy for replacing a hard disk drive on page 17 Important notice for replacing a system board on page 17 Important information about replacing RoHS compliant FRUs on page 18

Important: BIOS and device driver fixes are customer-installable. The BIOS and device drivers are posted on the customer support site: http://support.lenovo.com.

Strategy for replacing FRUs Before replacing parts: Make sure that all software fixes, drivers, and BIOS downloads are installed before replacing any FRUs listed in this manual. After a system board is replaced, ensure that the latest BIOS is loaded to the system board before completing the service action. To download software fixes, drivers, and BIOS, follow the steps below: 1. Go to http://support.lenovo.com. 2. Enter the serial number or select a product or use Lenovo smart downloading.
