Newhaven 40x2 character Liquid Crystal Display shows characters with dark pixels on a bright yellow/green background when powered on. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-0240AZ-FL-GBW display has an optimal view of 6:00. This display operates at 5V supply voltage and is RoHS compliant.

Newhaven 40x2 character Liquid Crystal Display shows characters with dark pixels on a bright yellow/green background when powered on. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-0240AZ-FL-YBW display has an optimal view of 6:00. This display operates at 5V supply voltage and is RoHS compliant.

If you need to display a lot of information on your device, this extra wide LCD will do the job with an active area of 5.8-inches (147.50 millimeters). Like all transflective displays, the 5x8 character matrix on this 40 x 2 LCD screen can be read in direct sunlight, is good for typical office lighting, and is easy to read in dark locations. One of our customers bought a display in the CFAH4002A series to use in an environmental control system for irrigation management.

Our goal is to keep every product available as long as possible. We"ve sold the CFAH4002A series since 2008 and it is still going strong. With a white LED backlight, this FSTN (Film compensated Super-Twisted Neumatic) display module has a higher contrast ratio than the standard STN, resulting in superior sharpness and contrast. A simple current limiting resistor in line with the voltage source works well in most applications. The white LEDs do not demand a current source, although one may be used. For details, see the backlight section starting on page 22 of the datasheet.

ERM4002DNS-1 is 40 characters wide,2 rows character lcd module,SPLC780C controller (Industry-standard HD44780 compatible controller),6800 4/8-bit parallel interface,single led backlight with white color included can be dimmed easily with a resistor or PWM,ffstn-lcd negative,white text on the black color,high contrast,wide operating temperature range,wide view angle,rohs compliant,built in character set supports English/Japanese text, see the SPLC780C datasheet for the full character set. It"s optional for pin header connection,5V or 3.3V power supply and I2C adapter board for arduino.

Our serial devices are a dot-matrix LCD series of products that are ready for operation with a driver and a bezel or a snap-in housing. They are connected to a standard RS-232C interface (or, optionally, an RS-422). The data transmission rate can be set to 300, 1,200, 2,400 or 9,600 bps. All cursor control (line feed etc.) is automatic. The displays are equipped with LED lighting that can be switched off by software means.

LCD graphics units are intelligent graphics displays with a serial RS-232 interface. Two or three integrated character sets and a wide range of graphics functions permit the time- and cost-saving use of the latest LCD graphics displays. Apart from a supply voltage of +5V and RS-232 data, no further signals are required. No additional software or special drivers are required for their operation. All the graphics routines are integrated in the display"s in-built high-level graphics controller. This permits the creation of a clear and attractive display using only a few commands. All functions are positioned with pixel accuracy by means of x/y coordinates (e.g. draw straight line: G x1 y1 x2 y2).

DISPLAY VISIONS offers 3 LCD graphics displays in different sizes in a snap-in housing: EA KIT120, KIT128 and KIT160. 3 further sizes are available with an anodized mounting panel in black or blue: EA KIT240-6, KIT240-7 and KIT320-8. They are controlled via either an RS-232 or an RS-422 interface.

The Displaytech 204G series is a lineup of 20x4 character LCD modules. These modules have a 98x60 mm outer dimension with 77x25.2 mm viewing area on the display. The 204G 20x4 LCD displays are available in STN or FSTN LCD modes with or without an LED backlight. The backlight color options include yellow green, white, blue, pure green, or amber color. Get a free quote direct from Displaytech for a 20x4 character LCD display from the 204G series.

The 204B is one of our 20 character x 4 row chip on board (COB) alphanumeric displays. These classic LCD modules are available in a multitude of LCD and LED backlight color combinations to achieve the perfect look for your product. Some of our most popular combinations are STN yellow-green LCD with yellow-green LED backlight, STN blue LCD with white LED backlight, and STN grey LCD with either blue, amber or pure green LED backlight.

Hey everyone... When I arrived home from work today my two Crystalfontz CFAP2002A-Y-ECS PLED / OLED Modules were waiting for me. Well, after dinner I added a header to one and tried it out with one of the test MIDIbox SID-NUXX PCBs. I must say, I"m really, really happy. Since there"s no room taken up by a backlight the display is really thin (metal box is 4.9mm), and (also because of the lack of a backlight) it requires considerably less power. This means less draw on the linear regs and less heat dissapated. This is good.

I had no problems using the same cable for either an LCD or the OLED. Not all the pins are used with the OLED (A and K), but they are left unconnected on the OLED side, so there"s no harm in making a cable with them.

My understanding is that the life of OLEDs is less than that of LCDs. I can"t say how much shorter, though. In my opinion, the better display of the OLED is probably worth the possibility of maybe having to replace the display a few years down the line.
