128x32 Dot Matrix COG, FSTN, Gray background, Blue Edge lit, bottom (or 6:00) viewing angle, Transflective (positive), 3.0V LCD, 3.0V LED, RoHS Compliant. This display has a wide temperature range: -20° Celcius to +70° Celcius which equates to (-4° Fahrenheit to +158° Fahrenheit).

FSTN (Film-compensated Super-twisted Nematic) provides a sharper contrast than STN by adding a film. The cost is approximately 5% higher than STN. FSTN works great for indoor and outdoor applications and is mainly used in graphic displays and higher end products. The Transflective polarizer is a mixture of Reflective and Transmissive. It provides the ability to read the LCD with or without the backlight on. It will work for all lighting conditions from dark with backlight to direct sunlight which makes it the most common choice. There is no cost difference between Transflective, Transmissive and Reflective.

Focus LCDs can provide many accessories to go with your display. If you would like to source a connector, cable, test jig or other accessory preassembled to your LCD (or just included in the package), our team will make sure you get the items you need.Get in touch with a team member today to accessorize your display!

Focus Display Solutions (aka: Focus LCDs) offers the original purchaser who has purchased a product from the FocusLCDs.com a limited warranty that the product (including accessories in the product"s package) will be free from defects in material or workmanship.

Newhaven 128x32 graphic Chip-On-Glass (COG) Liquid Crystal Display shows dark pixels on a blue background. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-C12832A1Z-FSB-FBW-3V3 display has an optimal view of 6:00, operates at 3V supply voltage and is RoHS compliant.

Newhaven 128x32 graphic Chip-On-Glass (COG) Liquid Crystal Display shows white pixels on a blue background. This transmissive LCD Display requires a backlight for visibility and offers a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-C12832A1Z-NSW-BBW-3V3 display has an optimal view of 6:00, operates at 3V supply voltage and is RoHS compliant.

This blue-on-black OLED is perfect for display panels that have little space and need a high resolution 128x32 graphic display. With a 24.38mm x 7.58mm viewing area, this is one of the smallest OLEDs available.

The Solomon Systech SSD1306 controller needs only a single 3.3v supply for power and logic levels for communication, making it a top choice in low power or battery powered applications. The 3 wire / 4 wire SPI or I2C serial interfaces require only 12 lines. Coupled with a ZIF connection (0.50mm pitch), connecting this module to your host device is a simple task.

ERM1602SYG01-6 is 16 characters wide,2 rows character lcd module with Russian(Cyrillic) alphabet gererator ROM,SPLC780C controller (Industry-standard HD44780 compatible controller),6800 4/8-bit parallel interface,single led backlight with yellow green color included can be dimmed easily with a resistor or PWM,stn-lcd positive,dark blue text on the yellow green color,wide operating temperature range,rohs compliant,built in character set supports English,Russian (Cyrillic )text, see the SPLC780C datasheet for the full character set. It"s optional for pin header connection,5V or 3.3V power supply and I2C adapter board for arduino.

The EA 9707-V24S interface allows dot-matrix LCDs to be programmed easily and quickly. The interface can be soldered directly onto almost all dot-matrix modules. It is connected to a standard RS-232C interface.

A wide variety of cog lcd options are available to you, such as original manufacturer, odm and agency.You can also choose from cog, tft and tn cog lcd,

This is a monochrome OLED display that produces a very crisp image. Since this is an OLED display it doesn"t need a backlight which allows for deep black levels and therefore a very high contrast and it has a much wider viewing angle compared to LCD displays.

This module uses the SSD1306 OLED driver, which includes an internal switch-cap charge pump to create the higher voltage necessary to drive the OLEDs in the display.

Dr Pan: Hello, Greg. Character LCD module is one special dot matrix LCD Module with stationary size and resolution, operation voltage, interface, etc.

Take 20*2 character LCD module for example. There are 20 characters horizontally, 2 characters vertically. Each character is a 5*8 dot matrix. Outer dimension 116.0×37.0 mm and active area 73.5×11.5 mm. When you develop a custom dot matrix LCD module, it can be any length and width, resolution, but it takes a lot of time and great efforts to develop it. The most widely used dot matrix LCD modules with specific sizes were made public and it is very convenient for everyone to get them with no tooling fee. You will not have a lot of options when you choose a character LCD module, a custom dot matrix LCD module is still your first choice.
