In recent years, smartphone displays have developed far more acronyms than ever before with each different one featuring a different kind of technology. AMOLED, LCD, LED, IPS, TFT, PLS, LTPS, LTPO...the list continues to grow.

There are many display types used in smartphones: LCD, OLED, AMOLED, Super AMOLED, TFT, IPS and a few others that are less frequently found on smartphones nowadays, like TFT-LCD. One of the most frequently found on mid-to-high range phones now is IPS-LCD. But what do these all mean?

LCD means Liquid Crystal Display, and its name refers to the array of liquid crystals illuminated by a backlight, and their ubiquity and relatively low cost make them a popular choice for smartphones and many other devices.

LCDs also tend to perform quite well in direct sunlight, as the entire display is illuminated from behind, but does suffer from potentially less accurate colour representation than displays that don"t require a backlight.

Within smartphones, you have both TFT and IPS displays. TFT stands for Thin Film Transistor, an advanced version of LCD that uses an active matrix (like the AM in AMOLED). Active matrix means that each pixel is attached to a transistor and capacitor individually.

The main advantage of TFT is its relatively low production cost and increased contrast when compared to traditional LCDs. The disadvantage of TFT LCDs is higher energy demands than some other LCDs, less impressive viewing angles and colour reproduction. It"s for these reasons, and falling costs of alternative options, that TFTs are not commonly used in smartphones anymore.Affiliate offer

IPS technology (In-Plane Switching) solves the problem that the first generation of LCD displays experience, which adopts the TN (Twisted Nematic) technique: where colour distortion occurs when you view the display from the side - an effect that continues to crop up on cheaper smartphones and tablets.

The PLS (Plane to Line Switching) standard uses an acronym that is very similar to that of IPS, and is it any wonder that its basic operation is also similar in nature? The technology, developed by Samsung Display, has the same characteristics as IPS displays - good colour reproduction and viewing angles, but a lower contrast level compared to OLED and LCD/VA displays.

According to Samsung Display, PLS panels have a lower production cost, higher brightness rates, and even superior viewing angles when compared to their rival, LG Display"s IPS panels. Ultimately, whether a PLS or IPS panel is used, it boils down to the choice of the component supplier.

This is a very common question after "LED" TVs were launched, with the short answer simply being LCD. The technology used in a LED display is liquid crystal, the difference being LEDs generating the backlight.

One of the highlights from TV makers at the CES 2021 tradeshow, mini-LED technology seemed far removed from mobile devices until Apple announced the 2021 iPad Pro. As the name implies, the technique is based on the miniaturization of the LEDs that form the backlight of the screen — which still uses an LCD panel.

Despite the improvement in terms of contrast (and potentially brightness) over traditional LCD/LED displays, LCD/mini-LEDs still divide the screen into brightness zones — over 2,500 in the case of the iPad and 2021 "QNED" TVs from LG — compared to dozens or hundreds of zones in previous-generation FALD (full-array local dimming) displays, on which the LEDs are behind the LCD panel instead of the edges.

However, for even greater contrast control, done individually at each point on the screen, it is necessary to go to panels equipped with microLED technologies – still cost-prohibitive in 2021 – or OLED, which until recently were manufactured on a large scale only in sizes for smartphones or televisions.Affiliate offer

AMOLED stands for Active Matrix Organic Light-Emitting Diode. While this may sound complicated it actually isn"t. We already encountered the active matrix in TFT LCD technology, and OLED is simply a term for another thin-film display technology.

OLED is an organic material that, as the name implies, emits light when a current is passed through it. As opposed to LCD panels, which are back-lit, OLED displays are "always off" unless the individual pixels are electrified.

This means that OLED displays have much purer blacks and consume less energy when black or darker colours are displayed on-screen. However, lighter-coloured themes on AMOLED screens use considerably more power than an LCD using the same theme. OLED screens are also more expensive to produce than LCDs.

Because the black pixels are "off" in an OLED display, the contrast ratios are also higher compared to LCD screens. AMOLED displays have a very fast refresh rate too, but on the downside are not quite as visible in direct sunlight as backlit LCDs. Screen burn-in and diode degradation (because they are organic) are other factors to consider.Affiliate offer

OLED stands for Organic Light Emitting Diode. An OLED display is comprised of thin sheets of electroluminescent material, the main benefit of which is they produce their own light, and so don"t require a backlight, cutting down on energy requirements. OLED displays are more commonly referred to as AMOLED displays when used on smartphones or TVs.

As we"ve already covered, the AM part of AMOLED stands for Active Matrix, which is different from a Passive Matrix OLED (P-OLED), though these are less common in smartphones.

Super AMOLED is the name given by Samsung to its displays that used to only be found in high-end models but have now trickled down to more modestly specced devices. Like IPS LCDs, Super AMOLED improves upon the basic AMOLED premise by integrating the touch response layer into the display itself, rather than as an extra layer on top.

As a result, Super AMOLED displays handle sunlight better than AMOLED displays and also require less power. As the name implies, Super AMOLED is simply a better version of AMOLED. It"s not all just marketing bluster either: Samsung"s displays are regularly reviewed as some of the best around.

The technology debuted with the obscure Royole FlexPai, equipped with an OLED panel supplied by China"s BOE, and was then used in the Huawei Mate X (pictured above) and the Motorola Razr (2019), where both also sport BOE"s panel - and the Galaxy Flip and Fold lines, using the component supplied by Samsung Display.Affiliate offer

Resolution describes the number of individual pixels (or points) displayed on the screen and is usually presented for phones by the number of horizontal pixels — vertical when referring to TVs and monitors. More pixels on the same display allow for more detailed images and clearer text.

To make it easier to compare different models, brands usually adopt the same naming scheme made popular by the TV market with terms like HD, FullHD and UltraHD. But with phones adopting a wide range of different screen proportions, just knowing that is not enough to know the total pixels displayed on the screen.Common phone resolutions

But resolution in itself is not a good measure for image clarity, for that we need to consider the display size, resulting in the pixel density by area measured by DPI/PPI (dots/points per inch).Affiliate offer

Speaking of pixel density, this was one of Apple"s highlights back in 2010 during the launch of the iPhone 4. The company christened the LCD screen (LED, TFT, and IPS) used in the smartphone as "Retina Display", thanks to the high resolution of the panel used (960 by 640 pixels back then) in its 3.5-inch display.

The name coined by Apple"s marketing department is applied to screens which, according to the company, the human eye is unable to discern the individual pixels from a normal viewing distance. In the case of iPhones, the term was applied to displays with a pixel density that is greater than 300 ppi (dots per inch).

With the iPhone 11 Pro, another term was introduced to the equation: "Super Retina XDR". Still using an OLED panel (that is supplied by Samsung Display or LG Display), the smartphone brings even higher specs in terms of contrast - with a 2,000,000:1 ratio and brightness level of 1,200 nits, which have been specially optimized for displaying content in HDR format.

As a kind of consolation prize for iPhone XR and iPhone 11 buyers, who continued relying on LCD panels, Apple classified the display used in the smartphones with a new term, "Liquid Retina". This was later applied also to the iPad Pro and iPad Air models, with the name defining screens that boast a high range and colour accuracy, at least based on the company"s standards.

Nit, or candela per square meter in the international system (cd/m²), is a unit of measurement of luminance, i.e. the intensity of light emitted. In the case of smartphone screens and monitors in general, such a value defines just how bright the display is - the higher the value, the more intense the light emitted by the screen.

The result is smoother animations on the phone, both during regular use and in games, compared to screens that have a 60 Hz refresh rate which remains the standard rate in the market when it comes to displays.

Originally touted to be a "gimmick" in 2017, with the launch of the Razer Phone, the feature gained more and more momentum in due time, even with a corresponding decrease in battery life. In order to make the most of this feature, manufacturers began to adopt screens with variable refresh rates, which can be adjusted according to the content displayed - which is 24 fps in most movies, 30 or 60 fps in home video recordings, and so forth.

To further muddy the alphabet soup that we"ve come across, you will also run into other less common terms that are often highlighted in promotional materials for smartphones.

TFT(Thin Film Transistor) - a type of LCD display that adopts a thin semiconductor layer deposited on the panel, which allows for active control of the colour intensity in each pixel, featuring a similar concept as that of active-matrix (AM) used in AMOLED displays. It is used in TN, IPS/PLS, VA/PVA/MVA panels, etc.

IGZO(Indium Gallium Zinc Oxide) - a semiconductor material used in TFT films, which also allows higher resolutions and lower power consumption, and sees action in different types of LCD screens (TN, IPS, VA) and OLED displays

LTPO(Low Temperature Polycrystaline Oxide) - a technology developed by Apple that can be used in both OLED and LCD displays, as it combines LTPS and IGZO techniques. The result? Lower power consumption. It has been used in the Apple Watch 4 and the Galaxy S21 Ultra.

LTPO allows the display to adjust its refresh rate, adapting dynamically to the content shown. Scrolling pages can trigger the fastest mode for a fluid viewing, while displaying a static image allows the phone to use a lower refresh rate, saving the battery.

In 2022, flagship phones started using the so-called LTPO 2.0 tech, whose main advantage is being able to go down to a 1 Hz refresh rate, instead of the 10 Hz available in first-generation LTPO panels. Found in phones like the OnePlus 10 Pro and the Galaxy S22 Ultra, LTPO 2.0 promises even further energy savings.

Among televisions, the long-standing featured technology has always been miniLED - which consists of increasing the number of lighting zones in the backlight while still using an LCD panel. There are whispers going around that smartphones and smartwatches will be looking at incorporating microLED technology in their devices soon, with it being radically different from LCD/LED displays as it sports similar image characteristics to that of OLEDs.

A microLED display has one light-emitting diode for each subpixel of the screen - usually a set of red, green, and blue diodes for each dot. Chances are it will use a kind of inorganic material such as gallium nitride (GaN).

By adopting a self-emitting light technology, microLED displays do not require the use of a backlight, with each pixel being "turned off" individually. The result is impressive: your eyes see the same level of contrast as OLED displays, without suffering from the risk of image retention or burn-in of organic diodes.

Another thing to be wary of is the price - at 170 million Korean won (about US$150,330 after conversion), that is certainly a lot of money to cough up for a 110-inch display.

Each technology has its own advantages and disadvantages but in recent years, OLED screens have gained prominence, especially with the adoption of the component in high-end flagship smartphones. It gained an even greater degree of popularity after the launch of the iPhone X, which cemented the position of OLED panels in the premium segment.

As previously stated, OLED/AMOLED screens have the advantage of a varied contrast level, resulting from individual brightness control for the pixels. Another result of this is the more realistic reproduction of black, as well as low power consumption when the screen shows off dark images - which has also helped to popularize dark modes on smartphones.

In addition, the organic diodes that give OLED screens their name can lose their ability to change their properties over time, and this happens when the same image is displayed for a long period of time. This problem is known as "burn-in", tends to manifest itself when higher brightness settings are applied for long periods of time.

In the case of LCD displays, the main advantage lies in the low manufacturing cost, with dozens of players in the market offering competitive pricing and a high production volume. Some brands have taken advantage of this feature to prioritize certain features - such as a higher refresh rate - instead of adopting an OLED panel, such as the Xiaomi Mi 10T.

AMoled display screen is always problematic, twice I had to get the display changed as it starts becoming pink and then dark, ultimately abandon the phone, LCD displays are more durable

AnonD-628531, 10 Aug 2017Oooooh, very very good point. Sorry I forgot about all the factors lol I don"t know that much ... moreIps display are known to last longer. No wonder why some old entry level phones are still operational

This is what I think and like, my name is Jerry btw and I"m from. The US. I"ve had all types of smartphones. Ive had some with really good IPS LCD screens. I"ve also had some phones with Amoled displays. And I"m sorry. I LOVE my Amoleds. Right now I am using a Motorola Nexus 6 with a quad HD AMOLED display and it is just absolutely amazing. The vibrance and warm colors and infinite blacks on the AMOLED, beat out the display on my Moto g7 power, which is an IPS LCD panel LIKE ANYDAY. The Nexus 6 also has a 1440p display compared to a 720p on the g7. For me, there is just something so amazingly vivid and clear about a phone with a high res Amoled than a phone with IPS LCD. Don"t get me wrong though. There are really good IPS panels like the essential phone had a very nice and colorful IPS lcd. But overall I will always want phone with an Amoled, it just kind of changes my entire smartphone experience somehow. I love to look a HD wallpapers and black outter space pictures much better.

Is nobody aware of amoled"s hidden flickering? Nobody says anything about PWMs? (pulse width modulation? Deep blacks are good in amoleds but everything else is better in a IPS LCD

ithehappy, 07 Aug 2017It shows who is the uneducated or whatever. Most accurate monitors in the world are LCD LoL. A... moreSo Displaymate was obviously lying when then said that SAMOLED is the best display out there. I"d like to see some factual evidence to support your claim as I"ve showed you mine. If you can"t, then don"t even speak to your betters like this ever again.

kupfernigk, 06 Aug 2017No, because life expectancy is important too. Sony quantum dot displays are supposed to last a... moreOooooh, very very good point. Sorry I forgot about all the factors lol I don"t know that much about displays

Back to subject matter, I would never go back to LCD, sadly, no matter how great the phone is otherwise. It"s just too big of a deal to go back to. I don"t care if it"s Samsung or anyone else, it just has to have a modern OLED screen.

AnonD-261377, 07 Aug 2017There are LG amoled screens that use AMOLED as single pixel backlight and filter-polarise it t... moreYeah, people are really blind if they don"t buy your burn in theory. I couldn"t find any burn in or whatever degradation a screen can have in 28 months of heavy usage of S6E.... I faced only one issue with its screen.... Lack of screen protectors... So i won"t buy your theory that all Samsung"s AMOLEDS get burn in within few months. My iphone"s motherboard died after 15 months of heavy usage, so can i use your same logic and say all iPhones will have motherboard issues and they will die within few months so no one should buy it or they are Inferior? LOL. If your phone has an issue get it replaced or if you do not like AMOLEDs, then don"t buy.

only quality matters and here is why, I used a OP 3 and thought wow finally amoled and then that phones" display was utterly trashed by even samsungs old S5 display, now I use a Quantum dot display on my XZ Premium and the difference is night and day, the LCD outclasses the amoled in every way, but then again samsungs S8 display would be better than my Sony display, it"s not depending on which technology but the quality of the display

AnonD-39937, 06 Aug 2017I owned a Sony Xperia Z2(made in 2014) which had Quantum dot...Lol. Almost every reviewer has said that the screen of z2 is LCD IPS.

AnonD-345931, 07 Aug 2017I can"t believe some people still believe that LCD is better than AMOLEDs. I mean, Displaymate... moreI can"t believe that people still believe that AMOLED is better than LCD. At least not in every way. When I and some of my friends prefer using LCD cause they are smoother than AMOLED it shows a technical downside of this technology. Some people are more sensitive to screen flickering than others and even a Galaxy S7 screen appears to me like a low resolution LCD. I really hope that future AMOLED will be better in this regard. Don"t believe everything you read. Trust your own eyes.

I selected "Only Quality matters", because a mobile phone is not just display, its a collection of other tech aspects too. You can never get the right setup in one phone.

Vineet290, 07 Aug 2017Really??? You need to learn so much about display technology.hush..you just a samsung fan...you"re a fan of a brand not fan of tech

It can be argued that the display on your smartphone is its most important feature, as it is the principle way in which you interact with your device. A poor display means a poor user experience. As with all tech, it is easy to spot an under-performer, however the differences between a good display and a truly excellent display are harder to discern.

Roughly speaking there are two main types of displays used in smartphones: LCD and LED. These two base technologies have been refined and tweaked to give us AMOLED and IPS LCD. The former stands for Active Matrix Organic Light-Emitting Diode, while the latter means In-Plane Switching Liquid Crystal Display.

All of this hasn’t gone unnoticed by the marketing people, which means that plain old AMOLED or regular IPS LCD aren’t the terms used in the marketing fluff. Instead, we have Super AMOLED, Dynamic AMOLED, Super LCD, Super Retina OLED, Super Retina XDR, Infinity Display, and so on. But what’s any of that actually mean?

The LED part of AMOLED stands for Light Emitting Diode. It’s the same tech as you find on many home appliances that show that the power is on with a little red light. An LED display takes this concept, shrinks it down, and arranges the LEDs in red, green, and blue clusters to create an individual pixel.

The image above is a close-up shot of the AMOLED display on the Samsung Galaxy S8. The RGB triangular pattern is clearly shown. Towards the bottom of the image, the green and red LEDs are off and the blue LEDs are on only slightly. This is why AMOLED displays have deep blacks and good contrast.

Super AMOLED is a marketing term from Samsung. It means a display that incorporates the capacitive touchscreen right in the display, instead of it being a separate layer on top of the display. This makes the display thinner.

Dynamic AMOLED is another marketing term from Samsung. It denotes Samsung’s next-generation AMOLED display which includes HDR10+ certification. According to Samsung, Dynamic AMOLED also reduces the harmful blue light emitted from the display, which helps reduce eye strain and helps lessen sleep disturbances if you’re using your phone late in the day!

As for Infinity Display (or Infinity-O Display), it is more marketing from Samsung. It means “a near bezel-less, full-frontal, edge-to-edge” display. However, it is still a Super AMOLED unit.

LCD displays work with a backlight that shines through some polarizing filters, a crystal matrix, and some color filters. Liquid crystals untwist when an electric charge is applied to them, which affects the frequency of the light that can pass through. Since the crystals can be twisted to varying degrees depending on the voltage used, a display can be built when they are used with polarized panels. A grid of integrated circuits is then used to control each pixel, by sending a charge down into a specific row or column. Colors are created by the use of red, green, and blue filters, known as sub-pixels, which are then blended by varying degrees to produce different colors.

The above image is of an LCD display from a Huawei Mate 8. Notice how the pixels are made up of equally-sized sub-pixels, one for each of the colors: red, green, and blue.

Like Super AMOLED, a Super LCD display also incorporates the touchscreen. There is no “air gap” between the outer glass and the display element, which means it has similar benefits to Super AMOLED.

Samsung isn’t the only company that is good at marketing, there is another! Apple has coined the term “Retina” for its displays. The term was first used for its smartphones with the launch of the iPhone 4, as it offered a significantly greater pixel density (over 300 ppi) when compared to the iPhone 3GS. Later came Retina HD, which applies to iPhones with at least a 720p screen resolution.

All Retina and Retina HD displays on the iPhone are LCD IPS displays. However, things have changed a bit with the iPhone X as it features an AMOLED display, now marketed under the term Super Retina. It’s still an AMOLED display. It just has extra adjectives. With the launch of the iPhone 11 Pro, Apple coined the term Super Retina XDR. The XDR part means Extended Dynamic Range, as they have better contrast ratios and higher peak brightness.

Not all Retina displays use OLED. Although the MacBook Pro is marketed with a “Retina” display, as you can see from the magnified image above, it is a regular LCD, even if it uses the latest Apple silicon.

Both technologies can be used to build displays with 720p, 1080p, Quad HD, and 4K resolutions. And OEMs have made handsets that support HDR10 using both LCD and AMOLED displays. So from that point of view, there isn’t much difference between the two.

When it comes to color, we know that the blacks will be deeper and the contrast ratios higher on AMOLED displays. But, overall color accuracy can be high on both types of display.

One of the main weaknesses of AMOLED displays is the possibility of “burn-in”. This is the name given to a problem where a display suffers from permanent discoloration across parts of the panel. This may take the form of a text or image outline, fading of colors, or other noticeable patches or patterns on the display. The display still works as normal, but there’s a noticeable ghost image or discoloration that persists. It occurs as a result of the different life spans between the red, green, and blue LED sub-pixels used in OLED panels.

Blue LEDs have significantly lower luminous efficiency than red or green pixels, which means that they need to be driven at a higher current. Higher currents cause the pixels to degrade faster. Therefore, an OLED display’s color doesn’t degrade evenly, so it will eventually lean towards a red/green tint (unless the blue sub-pixel is made larger, as you can see in the first image in this post). If one part of the panel spends a lot of time displaying a blue or white image, the blue pixels in this area will degrade faster than in other areas.

The theoretical lifespan of an AMOLED display is several years, even when used for 12 hours a day. However, there is anecdotal evidence that some displays suffer from burn-in quicker than others. Displays that show signs of burn-in after only a few months should be considered defective because they certainly aren’t normal.

While owners of devices with LCD screens might congratulate themselves for picking a smartphone that is immune to burn-in, there can be a problem with LCD panels called “image retention.” Put simply, liquid crystals can develop a tendency to stay in one position when left at the same voltage for extended periods. Thankfully this phenomenon is normally temporary and can usually be reversed by allowing the liquid crystals to return to their relaxed state.

Picking a winner can be hard as there are many factors to consider, not only about the display technologies but also about the other components in a handset. For example, if you are an AMOLED fan, then would you consider a device with large storage and a good processor, but with an LCD display? The same argument works the other way for LCD fans. Generally, you’ll be fine with either display type, so just pick the handset you like.

Higher-end devices typically sport AMOLED displays and mid-range/budget devices usually use LCD. But that isn’t set in concrete as there are plenty of high-end devices that have LCD displays. With OLED production costs dropping dramatically in recent years, more and more budget options will be offering OLED panels in the future.

Companies like LG and Samsung have seen this trend coming and are rapidly expanding their OLED (and flexible OLED) production capabilities. LCD might still have a bright future in televisions and other large-panel applications, but for now, it looks like mobile will be increasingly dominated by OLED screens.

What do you think? AMOLED or LCD? What about the terms like Retina vs Infinity Display? Are they meaningful to you? Please let me know in the comments below.
