Mercury"s military-grade LCD modules improve operational safety, enhance end-user efficiency, and reduce complete lifecycle costs by customizing active matrix LCD characteristics to your unique application. Whether it is in the air, on the ground, under the sea, day or night, hot or cold, displays built with Mercury"s LCD modules illuminate mission-critical data, regardless of where you work.

Safety-certifiable up to DAL-A, rugged, and NVIS compatible, Mercury"s LCD modules operate in demanding environments and enhance user situational awareness.

full active lcd displays in stock

An AMLCD) is a type of flat-panel display, the only viable technology for high-resolution TVs, computer monitors, notebook computers, tablet computers and smartphones with an LCD screen, due to low weight, very good image quality, wide color gamut and response time.

The concept of active-matrix LCDs was proposed by Bernard J. Lechner at the RCA Laboratories in 1968.thin-film transistors was made by T. Peter Brody, Fang-Chen Luo and their team at Westinghouse Electric Corporation in 1972.

The most common type of AMLCD contains, besides the polarizing sheets and cells of liquid crystal, a matrix of thin-film transistors to make a thin-film-transistor liquid-crystal display.pixel on the display while all the other pixels are being updated. This method provides a much brighter, sharper display than a passive matrix of the same size. An important specification for these displays is their viewing-angle.

Thin-film transistors are usually used for constructing an active matrix so that the two terms are often interchanged, even though a thin-film transistor is just one component in an active matrix and some active-matrix designs have used other components such as diodes. Whereas a passive matrix display uses a simple conductive grid to apply a voltage to the liquid crystals in the target area, an active-matrix display uses a grid of transistors and capacitors with the ability to hold a charge for a limited period of time. Because of the switching action of transistors, only the desired pixel receives a charge, and the pixel acts as a capacitor to hold the charge until the next refresh cycle, improving image quality over a passive matrix. This is a special version of a sample-and-hold circuit.

"History of TFT LCD". Archived from the original on 2013-08-23. Retrieved 2011-02-22. There are many kinds of AMLCD. For their integrated switching devices most use transistors made of deposited thin films, which are therefore called thin-film transistors (TFTs).

full active lcd displays in stock

This is another story just like those, except this one involves the very screen you’re probably looking at, especially if it’s based on LCD technology.

In the 1970s, a pair of engineers that worked for Westinghouse, T. Peter Brody and Fang-Chen Luo, came to develop the first active-matrix LCD screen. Brody, born in Hungary, had gained an interest in the fledgling technology of thin film transistors, an experimental technology that had come to be seen as a potential avenue for visually displaying content in a more compact form than a cathode-ray tube.

“It has been apparent for some time that a solid-state flat panel display is conceptually achievable,” the patent filing stated. “Efforts to utilize silicon technology to this end are limited by the size limitation problems of the silicon wafer, which negates achievement of large area displays.”

But it was the starting point of the technology that stuck. By the mid-1990s, active-matrix displays that relied on color became the norm in laptops, thanks to their combination of vivid color and thinness. But despite the concept coming from an American company’s R&D department and improved by other American R&D departments, nearly all panels were developed by Japanese manufacturers even at the beginning of their mainstream use cases.

In fact, Westinghouse’s efforts with the flat-panel LCD display ended way back in the 1970s, as did similar efforts at other large U.S. companies. “Both large corporations and venture capital-backed start-ups have quit the field, usually after hitting production difficulties,” authors Richard Florida and David Browdy wrote.

full active lcd displays in stock

Planar® CarbonLight™ VX Series is comprised of carbon fiber-framed indoor LED video wall and floor displays with exceptional on-camera visual properties and deployment versatility, available in 1.9 and 2.6mm pixel pitch (wall) and 2.6mm (floor).

From cinema content to motion-based digital art, Planar® Luxe MicroLED Displays offer a way to enrich distinctive spaces. HDR support and superior dynamic range create vibrant, high-resolution canvases for creative expression and entertainment. Leading-edge MicroLED technology, design adaptability and the slimmest profiles ensure they seamlessly integrate with architectural elements and complement interior décor.

From cinema content to motion-based digital art, Planar® Luxe Displays offer a way to enrich distinctive spaces. These professional-grade displays provide vibrant, high-resolution canvases for creative expression and entertainment. Leading-edge technology, design adaptability and the slimmest profiles ensure they seamlessly integrate with architectural elements and complement interior decor.

Carbon fiber-framed indoor LED video wall and floor displays with exceptional on-camera visual properties and deployment versatility for various installations including virtual production and extended reality.

a line of extreme and ultra-narrow bezel LCD displays that provides a video wall solution for demanding requirements of 24x7 mission-critical applications and high ambient light environments

Since 1983, Planar display solutions have benefitted countless organizations in every application. Planar displays are usually front and center, dutifully delivering the visual experiences and critical information customers need, with proven technology that is built to withstand the rigors of constant use.

full active lcd displays in stock

a line of extreme and ultra-narrow bezel LCD displays that provides a video wall solution for demanding requirements of 24x7 mission-critical applications and high ambient light environments

full active lcd displays in stock

From their discovery in 1888 to their first application within displays in the 1960s, liquid crystals have become a mainstream material choice with many impactful applications in the world of electronics.

As the key component behind liquid crystal displays (LCD), these materials change light polarization to create vibrant, high-resolution images on digital screens. The growth of LCD technology has helped propel the larger display panel market enormously, with industry valuation projected to reach $178.20 billion by 2026.

A prolific variety of LCD types has been developed to best meet their exact use-cases and end-environments. Displays may be optimized for power consumption, contrast ratio, color reproduction, optimal viewing angle, temperature range, cost, and more.

Passive Matrix LCDs are addressed with common and segment electrodes. A pixel or an icon is formed at the intersection where a common and a segment electrode overlap. Common electrodes are addressed one-at-a-time in a sequence. Segment electrodes are addressed simultaneously with the information corresponding to all pixels or icons connected to the current common electrode. This method is referred to as multiplexing.

Passive Matrix LCDs offer a cost advantage (both parts and tooling) and are highly customizable. The counterpart to Passive Matrix displays are Active Matrix displays.

Active-Matrix LCDs were developed to overcome some of the limitations of Passive Matrix LCDs – namely resolution, color, and size. Within an Active-Matrix LCD, an “active element” is added to each pixel location (the intersection between a horizontal row and vertical column electrode). These active elements, which can be diodes or transistors, create a threshold and allow control of the optical response of the liquid crystal structure to the applied voltage. Transistors are used as switches to charge a capacitor, which then provides the voltage to the pixel. Whenever a row is turned on, one at a time, all transistor switches in that row are closed and all pixel capacitors are charged with the appropriate voltage. The capacitor then keeps the voltage applied to the pixel after the row is switched off until the next refresh cycle.

Furthermore, the processes used for manufacturing Active-Matrix LCDs can create much finer details on the electrode structure. This allows splitting each pixel in three sub-pixels with different color. This together with the better voltage control allows full color displays.

The transistor switches used in Active Matrix Displays must not protrude significantly above the surface of the display substrates lest they might interfere with a uniform liquid crystal layer thickness. They must be implemented in thin films of suitable materials. Hence, the name Thin Film Transistors (TFT). While AM and TFT have a different meaning, they are often used interchangeably to indicate a higher performance display.

Currently the most common Electronics Display Technology on the market is LCD technology and among LCD technologies, TFT display technology is the most widely used across consumer applications (laptops, tablets, TVs, Mobile phones, etc.) as well as many industrial, automotive, and medical applications.

As the first commercially successful LCD technology, Passive Matrix Twisted Nematic (TN) LCDs use a 90° twist of the nematic LC fluid between two polarizers to display information. The twist of the LC fluid either blocks light from passing through the LCD cell or allows light to pass, depending on the applied voltage. The applied voltage changes the twisted nematic orientation into an orientation that does not change the polarization of tight. This is called the TN effect.

TN displays can be normally white (NW) when they use two orthogonal liner polarizers or normally black (NB) when parallel linear polarizers are used. ‘Normally’ refers to what happens when no voltage is applied.

Initially, Passive TN LCDs were used in segmented, icon, or character displays where an image element was turned “on” and “off” depending on how the fluid was driven. Improvements were made along the way to address the limited viewing angle of TN technology, which can suffer from contrast loss or even inversion at shallow angles.

It can be advantageous to twist the director of the nematic phase a bit more than 90 degrees, but less than 180 degrees. Displays like this are a subset of TN displays and are sometimes caller Hyper Twisted Nematic Displays.

The numbers of rows or icons that can be addressed in a TN display without Active Matrix addressing is very limited. This is related to how strongly the liquid crystal responds to the applied voltage. Twisting the LC nematic fluid more than 180 degrees (typically between 210 and 270 degrees) causes the display to require a much smaller voltage difference between on and off pixels. This in turn allows addressing of many more rows without an active matrix. Displays with a twist between 210 and 270 degrees are called Super Twisted Nematic displays.

The higher display resolution of STN displays comes at a price. The optical effect is no longer neutrally black and white as in a TN display. Rather these displays are naturally yellow and black or blue and white. The color can be somewhat compensated with colored polarizers, but that comes at the expense of brightness and contrast.

The color in STN displays is caused by birefringence. Adding the same birefringence in the opposite direction can compensate for the effect. Initially this was done by stacking two STN displays on top of each other. This is referred to as Double STN or DSTN, but this is of course thicker and more expensive.

The birefringence of an STN display can be approximated with a stretched transparent plastic film. Adding such a film to an STN display instead of the 2nd STN display is a lot more attractive and has almost the same performance. This is referred to as a Film Compensated STN display (FSTN, or sometimes if two films are used as FFSTN).

FSTN displays are used commonly in consumer, medical and industrial display applications that require low cost and do not need high resolution images or full color.

Another development to the TN display was to use the same concept as in FSTN displays on TN displays. However, the film cannot just be a stretched polymer. Instead, a twisted liquid crystal structure is made and polymerized into a film that is used as a compensation film for TN displays. As this method mostly improves the display characteristics at shallow viewing angles while preserving the excellent performance in straight on viewing, this technology is called Wide View Twisted Nematic (WVTN).

The above display technologies have liquid crystal molecules that are aligned nearly parallel to the display surface with more or less twisting when going from one substrate to the other. In VA (also called VAN) displays, the liquid crystal molecules are aligned vertically with respect to the display surface. Applying a voltage causes the molecules to lay flat, with or without twist.

The advantage of this arrangement is a very dark black state with very little light leakage. This allows making displays with a black mask and colored icons or symbols. These displays look like color displays with brilliant colors, however each image element or icon can only have its assigned color or black.

Due to the ability in AM displays to address one row while the other rows are isolated, the demands on the electro-optical performance of the Liquid Crystal Configuration are less stringent. In principle, all the above mentioned configurations can be used in AM displays. In practice, TN, and WVTN are frequently used as well as some versions of VA technology described below. (MVA, AIFF-MVA, PVA, ASV).

The advantage of these technologies is a much wider and more symmetrical viewing angle along with the elimination of the contrast inversion (or color shift) seen in TN TFT LCDs when viewed from various angles. IPS and FFS displays also are less sensitive to pressure, which is a big advantage in touchscreen displays.

Here, each color sub-pixel is further divided into zones (called domains) having a different direction of the molecular movement when voltage is applied. Again, the purpose is a much wider and more symmetric viewing performance and the elimination of color shifts and contrast inversion at shallow angles. MVA technology achieves that with carefully designed protrusions on the inside surfaces of the display, while PVA uses fine patterning of the electrodes on both substrates.

The integrated circuit is a patterned piece of silicon or other type of semiconducting material. A modern IC contains millions or even billions of tiny transistors. Their tiny size allows for the fabrication of smaller, faster, more efficient, and less expensive electronic circuits. The driver chips addressing electronics displays are ICs.

Legacy LCDs normally have the driver ICs (integrated circuit) mounted on a printed circuit board (PCBA) which consists of a flat sheet of insulating material used to mount and connect the driver IC and electronic periphery to the LCD. PCBs can be a single-sided, double-sided or multi-layer.

Low Voltage Differential Signaling (LVDS) is an interface to the display, not a display technology itself. This technology is not specific to displays, as it’s used in many other applications as well. It’s a high-speed signal that provides some noise immunity for the display. It also allows for longer distances compared to parallel interfaces.

full active lcd displays in stock

T. Tsukada: State-of-the-art of a-Si TFT/LCD. Transaction of the Institute of Electronics, Information and Communication Engineers (Japan), J76-C-II, 177–183, 1993.

2.9 M. Ohta, M. Oh-e, K. Kondo: Development of Super-TFT-LCDs with in-plane-switching display mode, Proc. Int. Display Res. Conf., S30–2, 707–710, 1995 (Hamamatsu).

Y. Kaneko, A. Sasano, and T. Tsukada: Analysis and design of a-Si TFT/LCD panels with a pixel model. IEEE Transaction Electron Devices, ED-36, 2953–2958, 1989.

Y. Kaneko, Y. Tanaka, N. Kabuto, and T. Tsukada: A new address scheme to improve the display quality of a-Si TFT/LCD panel. IEEE Transaction Electron Devices, ED-36, 2949–2952, 1989.

Y. Nanno, Y. Mino, E. Takeda, and S. Nagata: Characterization of sticking effects of TFT-LCD. In Digest of Technical Papers of the Society for Information Display International Symposium (Las Vegas, 1990), 404–407, California: SID, 1990.

Y. Kanemori, M. Katayama, K. Nakazawa, H. Kato, K. Yano, Y. Fukuoka, et al.: 10.4-in-diagonal color TFT-LCDs without residual images. In Digest of Technical Papers of the Society for Information Display International Symposium (Las Vegas, 1990), 408–411, California: SID, 1990.

Y. Nasu, S. Kawai, S. Kisumi, K. Oki, and K. Hori: Color LCD for character and TV display addressed by self-aligned a-Si:H TFT. In Digest of Technical Papers of the Society for Information Display International Symposium (San Diego, 1986), 289–292, California: SID, 1986.

K. Asama, T. Kodama, S. Kawai, Y. Nasu, and S. Yanagisawa: A self-alignment processed a-Si TFT matrix circuit for LCD SID panels. In Digest of Technical Papers of the Society for Information Display International Symposium (Philadelphia, 1983), 144–145, California: SID, 1983.

W. H. Dumbaugh, P. L. Bocko: Substrate glasses for flat-panel displays. In Digest of Technical Papers of the Society for Information Display International Symposium (Las Vegas, 1990), 70–72, California: SID, 1990.

Y. Okubo, T. Nakagiri, Y. Osada, M. Sugata, N. Kitahara, and K. Hatanaka: Large-scale LCDs addressed by a-Si TFT array, In Digest of Technical Papers of the Society for Information Display International Symposium (San Diego, 1982), California: SID, 1982.

M. Ohta, M. Tsumura, J. Ohida, J. Ohwada, and K. Suzuki: Active matrix network simulator considering non-linear C-V characteristics of TFTs intrinsic capacitances, In Proceedings of the 12th International Display Research Conference (Hiroshima, 1992), 431–434. California: SID, 1992.

M. Katayama, H. Morimoto, S. Yasuda, T. Takamatu, H. Tanaka, M. Hi-jikigawa: High-resolution full-color LCDs addressed by double-layered gate-insulator a-Si TFTs, In Digest of Technical Papers of the Society for Information Display International Symposium (Anaheim, 1988), 310–313, California: SID, 1988.

2.44 S. Morozumi, T. Ohta, R. Araki, T. Sonehara, K. Kubota, Y. Ono, T. Nakazawa, H. Ohara: A 250 × 240 element LCD addressed by lateral MIM, Proc. Intn’l Display Res. Conf., 10–3, 404–407, 1983 (Kobe).

N. Szydlo, E. Chartier, J. N. Perbet, N. Proust, J. Magarino, and M. Hareng: Integrated matrix-addressed LCD using amorphous-silicon back-to-back diodes, Proc. SID (Society for Information Display), 265–268, 1984.

K. Katoh, S. Imagi and N. Kobayashi: Active-matrix-addressed color LCDs for avionic application. In Digest of Technical Papers of the Society for Information Display International Symposium (Anaheim, 1988), 238–241. California: SID, 1988.

F. Funada, M. Okada, N. Kimura and K. Awane: Selection and optimizing of liquid crystal display modes for the full color active-matrix LCDs, Journal of the Institute of Television Engineers, 42, 1029–1034, 1988 (In Japanese).

C. C. Yang: Two-domain twisted nematic and tilted homeotropic liquid crystal displays for active matrix applications. In Proc. International Display Research Conference (San Diego, 1991), 68–72, California: SID, 1991.

Y. Koike, T. Kamada, K. Okamoto, N. Ohashi, I. Tornita and M. Okabe: A full-color TFT-LCD with a domain-divided twisted-nematic structure. In Digest of Technical Papers of the Society for Information Display International Symposium (Boston, 1992), 798–801, California: SID, 1992.

K. Ohmuro, S. Kataoka, T. Sasaki, Y. Koike: Development of super-high-image-quality vertical-alignment-mode LCD, Digest Tech. Papers Society for Information Display Intn’l Symposium, 845–848, 1997.

2.68 M. Ohta, M. Oh-e, K. Kondo: Development of Super-TFT-LCDs with in-plane switching display mode, Proc. Intn’l Display Res. Conf., S. 30–2, 707–710, 1995 (Hamamatsu).

J. Nehring, A. R. Kmetz: Ultimate limits for matrix addressing of rms-responding liquid-crystal displays, IEEE Transactions on Electron Devices, ED-26, 795–802, 1979.

F. Leenhouts and M. Schadt: Electro-optics of supertwist displays; dependence on liquid crystal material parameters, In Proc. 6th International Display Research Conference (Tokyo, 1986), 388–391. California: SID, Tokyo: ITE, 1986.

K. Kinugawa, Y. Kondo, M. Kanasaki, H. Kawakami and E. Kaneko: 640×480 pixel LCD using highly twisted birefringence effect with low pretilt angle, In Digest of Technical Papers of the Society for Informatio Display International Symposium (San Diego, 1986), pp. 122–125. California: SID, 1986.
