Appendix C, “Notices.” Seventh Edition (February 2004) This edition applies to the IBM 4820 SurePoint Solution and to all subsequent releases and modifications until otherwise indicated in new editions. This publication is available on the IBM Retail Stores solutions electronic Support Web site.

Routing the cables for the integrated pedestal 1. Attach the video cable to the appropriate port on the system unit. 2. Route the video cable and the power cable for the 4820 display through the opening of the system unit.

Figure 2-37 on page 2-32. Follow these steps to attach the pointing device to the 4820 SurePoint Solution: 1. Before you begin, locate the tabs for the pointing device on the rear of the 4820 (see Figure 2-36).

Notes: 1. Models 2xx and 5xx do not support an audio kit. 2. The optional audio kit is a replacement for the mounting cover of the 4820 SurePoint Solution. If this is an initial installation of the 4820 SurePoint Solution, install the audio kit when you install the covers.

Adjust frequently because it automatically fine tunes your settings based on your PC’s video signal. DOS users: To run the 4820 Video Quality Test Pattern program for DOS users, follow these steps: 1. Download the 4820Patt.exe program from the support Web site: www.ibm.com/solutions/retail/store, then click Support, and create a diskette.

January 14, 2005 IBM POS Device Diagnostics tool The IBM POS Device Diagnostics is a diagnostics tool that allows you to test the 4820 when it is attached to the SurePOS 700 Series system unit. This tool installs as ® ®...

5xx. Features of the IBM Advanced Touch Screen Configurator The IBM Advanced Touch Screen Configurator program is available from the support web site and provides additional features for your touch software. The readme.htm file provides complete installation and user instructions. The program...

Make sure the MSR is securely attached to the display. v Run the MSR test using the service diskette. v Replace the MSR. v For models 48D, 48T, see the IBM POS Device Diagnostics, which came with the POSS for Windows installation. Keypad malfunctioning All Models: v Check that the cable is securely connected.

Assembly 1: (continued) January 14, 2005 Asm– Part Index Number Units Description – Power cords (1.8M) for models 1xx: –11 6952301 v Power cord, US/Canada –11 36L8879 v Power cord, LA –11 13F9939 v Power cord, AP –11 34G0231 v Power cord, AP –11 13F9978 v Power cord, Europe and Korea...

Gevaar Voordat u begint met het installeren van dit produkt, dient u eerst de veiligheidsrichtlijnen te lezen die zijn vermeld in de publikatie IBM Safety Information — Read This First, GA27-4004. In dit boekje vindt u veilige procedures voor het aansluiten van elektrische appratuur.

January 14, 2005 Vigyázat Mielôtt megkezdi a berendezés üzembe helyezését, olvassa el a IBM Safety Information — Read This First, GA27-4004 könyvecskében leírt biztonsági információkat. Ez a könyv leírja, milyen biztonsági intézkedéseket kell megtenni az elektromos berendezés huzalozásakor illetve csatlakoztatásakor.

Varning—livsfara Innan du börjar installera den här produkten bör du läsa säkerhetsinformationen i dikumentet Säkerhetsföreskrifter—Läs detta först, GA27-4004. Där beskrivs hur du på ett säkert sätt ansluter elektrisk utrustning. 4820 Planning, Installation and Service Guide...

January 14, 2005 using 4820 Video Quality Test Pattern program 2-36 manual adjust 2-35 VESA mounting 2-26 video frequencies 2-36 voltage for USB power 4-6 warranty information 1-9 Web site, support 2-37 win_pat.exe 2-37 Windows auto set-up 2-37 Index...

Thank you for your responses. May we contact you? h Yes h No When you send comments to IBM, you grant IBM a nonexclusive right to use or distribute your comments in any way it believes appropriate without incurring any obligation to you. Name...

Looking for wholesale ibm touch screen? Look no further than Alibaba.com, one of the largest collections of wholesale shipment suppliers in the world. We have a huge range of lcd computer monitor options and lcd display screen options to choose from. Whether you need a small lcd screen or a large one, we have you covered.

These ibm touch screen products have become the go to display types for computers today. With tft color monitors slowly being phased out, lcd computer monitor displays are the standard in the industry. All customers need a flat screen computer monitor to interact with their personal computers. For ardent gamers that require high refresh rates to minimize lagging and make use of high performance computers there are a range of lcd gaming monitors available.

We also have more specialised products like rack mounted monitors for IT administrators and network administrators working in commercial settings. These monitors are used to oversee large server rooms and network infrastructure. New transparent lcd screen options are also coming on the market that are futuristic and allow for a sleek look to fit modern aesthetics.

So, start ordering your shipment of ibm touch screen today from our suppliers. They are ready and willing to answer any questions you may have about their products and get you started today!

1 Small cash register huge progress: Epson IR-700 A revolutionary generation of Epson all-in-one cash registers enters the market with the Epson IR-700. At first glance, the new cash register flagship is characterised by its straightforward design. Upon closer inspection, it becomes clear that Epson has succeeded in combining maximum benefit with minimal size. The ergonomic cash register system features convenient use of all functions and options. But not only the sophisticated design distinguishes the Epson IR-700 from its established predecessor IR-320: Intel Celeron M and Pentium M processors ensure high performance at extremely low noise level and power consumption. In addition to the brilliant 12.1 inch SVGA or 15 inch XGA display featuring a touch screen, the increased flexibility of the system via an integrated CompactFlash slot and new wireless LAN and peripheral options facilitate everyday work. The performance, adaptability and reliability of an outstanding brand on a footprint of just 250 x 340 mm: The Epson IR-700 provides convenience and efficiency in the cash register operation of specialty retailers and resellers, grocery markets and the hospitality segment as well as point of information stations. Anything is possible outstanding cash register! The features set standards: the rapid high-performance of the Epson IR-700 s Intel Pentium M 1.8 GHz and Intel Celeron M 1.3 GHz processors is reflected neither in the noise level nor power consumption on the contrary. On average, Intel Pentium M processors consume less than a tenth of the energy of a comparable Pentium 4 processor. Based on daily 24-hour cash register operation, this results in annual savings of up to EUR 200! The cash register system s 15-inch TFT touch screen is extremely bright and is also suitable for use in light rooms. In addition to toughness with regard to splashing, the specially-treated screen is also fingerprint resistant. The standard Dual Screen Function even enables operation of a further screen, for example to display promotions to customers via an additional application, generating improved sales. The integrated Epson TM-T88IIIX thermal printer is based on the leading global PoS-printer Epson TM-T88III. Maintenance-free and featuring drop in paper changing, it ensures rapid printing of neatly-edged receipts in usual Epson quality! Versatile in every respect Thanks to its manifold easily accessible interfaces, the Epson IR- 700 is extremely flexible. Users can deploy precisely the peripherals and storage media they want. As standard PC components are The compact high-end PoS system with 12 TFT, receipt printer, 28 key pad, MSR, customer display. The IR-700 in dark grey with 15 TFT and e.g. 60 POS-keyboard, MSR and customer display. A look to the many interfaces and HDDs (opened rear cover)

2 used, upgrading the system is easy the Epson IR-700 is perfectly equipped for the future. In combination with the RAID controller, a further 3.5-inch hard drive ensures outstanding reliability as well as automatic data storage and easy installation. This system also puts an end to cable clutter at PoS: One single power cable is required for the entire cash register system and network integration is even simple for novices thanks to the network interface or the optional Epson wireless LAN card. Furthermore, 4 rapid USB 2.0 and 4 free serial ports, parallel and PS/2 interfaces fulfil all requirements regarding peripheral connections. At 250 x 340 mm, the footprint of the Epson IR-700 is extremely compact. This can even be reduced to 250 x 260 mm thanks to the kiosk kit for positioning the cash register vertically. Thus, the cash register system is also ideal for the smallest spaces. Furthermore, it features a minimal profile due to its compact dimensions and does not impede eye contact with customers. The integrated DM-D customer display proven innumerable times can be retained. Key criterion: reliability Reliability is THE key criterion of excellent cash register systems if the cash register is unstable, sales are at risk. Thus, every component of the Epson IR-700 is extremely robust and durable. The operating life of components is well above average even when in use around the clock. Epson s comprehensive maintenance software reduces failures and provides extensive remote diagnosis and backup functions via ISDN, internet or LAN. The system s serviceability is beneficial in case upgrade is required. Whether motherboard, hard drives, printers or monitors, all components can be accessed or exchanged rapidly and easily. Time required: less than 5 minutes. On-site service into the bargain For an entire year, on-site service is included in the purchase price of the IR-700 as well as the other cash register systems SR and MR. Qualified technicians replace, wherever possible, any defective components right where the cash register is installed, thus ensuring quick resumption of smooth operation at the check-out and keeping turnover losses to a minimum. For those wishing longer-lasting dependability, there is also the option of extending the on-site service to three or more years. Branch solutions Meanwhile, there are a large number of software programmes, which have been designed for use with the IR and cover all important business needs from general merchandising solutions to branch related applications. You can find the complete solution, which is most suitable for your business sector in the EPSON Solution partner table. Upgrade memory or insert CompactFlash card? No problem with the easy accessible motherboard. The vertical setting kit (option) once more reduces the footprint. The receipt is presented to the user. The HDDs are easy to reach an ensure protection of the important data via RAID Controller.

3 Features of IR-700 Your benefit All-in-one concept Compact design, minimized footprint Modular structure, many options User friendly and future oriented stylish design No cable knots at PoS, protection of inadvertent disconnection Minimal footprint (25 x 34 cm) saves space on the counter, that can be used for additional revenue The IR can be individually customised, all components are specially built to work with each other Good looking for many years, smart appearance for the customers, easy to clean 2 colours available You can select: cool white or dark grey Integrated high-resolution TFT touch screen Programmable an adjustable userinterface Easy handling by touch of the finger Protected against fingerprints High-end PC-technology with Intel Pentium M and Celeron M CPU Advantages of M CPU Dual-display controller integrated Based on standard PC technology Integrated Ethernet card (10Base-T, 100Base-TX) Powered USB card (Option) External USB 2.0 CD-ROM or floppy drive (option) Up to two 3,5 HDDs with RAID controller on board HDDs are lockable (option) CompactFlash interface placed on the motherboard Worldwide proved thermal PoSprinter with a easy paper handling is integrated Integrated sound function Many integrated interfaces like 4 serial and 4 x USB 2.0 free Brilliant, large display of graphics, text and photos. Very sensible and easy to touch Colour coding and large on-screen buttons minimise learningcurves and maximise ease-of-use, Photos and symbols can be shown as well, especially useful for often changing staff Quicker introduction of personnel, easy to clean Finger prints do not disturb the clear graphics Strong and approved; based on industry standards; long term availability, worldwide support Compared to desktop CPUs at similar clock rate double performance; produces less heat; needs less fan power (= less noise); much less power consumption saves up to 200,- per year Enable to run 2 applications simultaneously; promotions can be shown on second display to increase business Open standard architecture for a save investment Easy to connect to networks, Wake-on-LAN-function allows to boot the system by network Saves the power supplies of external peripherals like scanners or credit card terminals Update, installation or maintenance on-site becomes a Childs play Perfect for permanent data mirroring; high security level ensures ongoing business transactions High security level to prevent data loss and unauthorised use of the system, no access to confidential data Bootable via CompactFlash also without any HDD; CF-memory is more durable than HDDs Easy to use and reliable, avoids waiting time for your customers in case of paper end, high printing performance Sound files or spoken remarks for trainings and presentations can be used Flexibility and upgradeability through open PC-architecture saves the investment; bootable via USB and CompactFlash 2 internal PCI ports Easy upgrade with ISDN or other PCI cards Strong integrated power supply Integrated 3-track MSR (option) Cable cover Only one power connection for the complete system Best ergonomic position, easy to use e.g. for EC cards No cable knots, protection of inadvertent disconnection

4 Programming tools free of charge Remote maintenance and diagnostic tools free of charge Extremely service friendly, only few screws Free programmable 60 PoS-keyboard with 2 integrated USB ports and manager key lock (option) Free programmable 28 PoS-keyboard attached to LCD (option) Extremely robust construction ("Heavy Duty") 1 year On-site-service included; 3-year On-site-service as option Affordable price scheme An Epson product Saves time and money for application development Saves on-site service cost; updates can be easily done per remote via LAN or the Internet Reduced service- and maintenance costs, quick and easy adaptation of the system For applications that require a keyboard; additional peripherals can be connected to keyboard; high security level through manager key lock Combines comfortable touch-input and quick numeric data input Reliable and sturdy; also for use in tough environment like fast food restaurants or DIY- garden markets Ensures ongoing business at the POS in case of defect; for 3 years and also on weekends Specific configurations are possible to cover individual needs, quick ROI ( Return on Investment ) The performance of a strong partner, long availability; worldwide experience, service and support

5 Technical data Epson IR-700 CPU Intel Celeron M 1.3 GHz or Intel Pentium M 1.8 GHz (FSB: 400 MHz) Memory 2 x 184 Pin DDR SDRAM DIMM, max 1 GB Drives CompactFlash interface on board (bootable) 1 HDD 3,5 or 2 HDDs 3,5" (serial ATA) Floppy drive external (option) USB 2.0 CD-ROM or CD-RW external (option) Extensions 2 x PCI (also for 3,3 Volt) Interfaces 4 serial free, with +5V or +12V 2 PS/2 1 for cash drawer 1 parallel (ECP, EPP) 4 USB 2.0 high-speed, 2 of them bootable 1 for ext. CRT/LCD 1 24V for TM-printer 1 Ethernet 10Base-T/100 Base-TX, wake-on-lan 1 Microphone in, line-out 1 power in Video Video controller with dual-display-function 15 : , 260,000 colours (up to 16 Mio.) 12,1 : , 260,000 colours (up to 16 Mio.) Touch screen LCD 15,0 (38 cm) TFT (XGA) resistive or 12,1 (30,7 cm) TFT (SVGA) resistive Standard features Power switch on front side Main reset switch on front side TM-printer reset switch on front side integrated power supply V integrated adjustable speaker OS Windows2000 professional Sp4 / WindowsXP professional Sp2 Dimensions WxDxH mm 250 mm 340 mm 254 mm (main unit without LCD, including cable cover) Weight approx. 6,4 kg (without HDD) Colour Epson cool white (ECW) or Epson dark grey (EDG) Options 3-track MSR ISO Thermal printer TM-T88IIIX Printer Tray for other TM-printers Dummy-Cover (if printer is not integrated) Integrated customer display DM-D Pole extension for DM-D Kiosk kit for vertical setting 2nd HDD 3,5 (RAID) Epson Powered USB-card (PCI) Epson programmable 28 key unit Epson programmable 60 keyboard External Epson TM-printer External CD-ROM or floppy drive 3 years On-site-service
