Many of these LCD controllers differ slightly from the HD44780 controller in things like the initialization sequence, minimum delay between commands and maybe other ways I don"t know of.

try putting a 1n4148 diode between the 5V supply and the 5V of the LCD, so the LCD will get around 4.5V, that is enough for the LCD, and lowers its logical input levels enough so that it sees 3V3 logic highs as "1" reliably. The garbled letters, and blocks are due to the LCD sometimes seeing a "1" as a zero and that corrupts all communication between the PI and the LCD.

Its a well know problem when trying to drive an LCD with 3V3 levels, it actually needs minimally 3.5V when its powered with 5V (70 % of VCC = 0.7 x 5.0 = 3.5).

In the photos above the Pi is a Model B Rev 2 so should work fine with my tutorial. Random characters is usually a sign it has not been initialized correctly. Again this could be caused by intermittent connections.

I was having the same problem as the OP on my current build with an I2C back-packed LCD getting corrupted. I"d tried all kinds of things to fix the problems - changing the delays, trying different libraries, and pulling out hair with no joy in fixing it.

For anyone else with this problem, you may have what I have if you"re doing event-driven code e.g. from from a switch or rotary encoder. I was getting events triggered while the python code was trying to communicate with the LCD screen - which themselves tried to write to the LCD.

I also had the same problem with scrambled characters on my display. I found that there was a short between the data lines on the expander board where it is soldered to the display board. Once I cleaned up the messy solder, the display worked perfectly.

Previous examples connect the white LED backlight to power. The following example is specifically for those using an LCD with a RGB LED backlight. The only difference between the connection is the LED"s backlight on pins 15-18.

The Matrix Orbital Parallel display series offers a low cost display solution utilizing an industry standard communication interface for simple integration into a wide variety of new and existing applications.  The Light Emitting Diode backlight with configurable brightness and voltage controlled contrast allows the MOP Liquid Crystal Display line to offer a professional display solution with low power impact for any project.  The standard alphanumeric font set also allows up to eight custom characters to be saved in display Random Access Memory for a custom design touch.

CategorySub CategoryFile NameRevisionSizeDescriptionNotesFeaturesChange LogCategorySub CategoryFile NameRevisionSizeDescriptionNotesFeaturesChange LogMOP SeriesMOP Character LCD1.0278.43KiBAll of our Matrix Orbital Alphanumeric displays have HD44780U compatible drivers.

The Arduino board has a wide variety of compatible displays that you can use in your electronic projects. In most projects, it’s very useful to give the user some sort of feedback from the Arduino.

This is a tiny display with just 1 x 0.96 Inch. This display has a black background, and displays characters in white. There are other similar displays that can show the characters in other colors.

This particular post will cover a bit of technology that most people simply know as "the LCD display". I"m not talking about the computer monitor type of LCD display; no, I"m talking about that small screen on many common pieces of electronics, the one that looks like this.

I"m going to talk about the LCM1602C LCD. The purpose of this post is to get away from a lot of the esoteric "how tos" of this particular display. Ya see, this display is based on the Hitachi HD44780 LCD controller. The nice thing about that is the specifications are readily available. The problem is that the specifications are not readily understood. Yes, I believe that this is an example of "lost in translation".

Let"s talk about the display first. This particular display is a 16 character by 2-line display. Its memory can hold up to 80 characters, 40 on each line of the display. The actual part that displays the characters can only show 16 characters across at any one time. Using the SHIFT command, you can move the part of the lines that are displayed.

I used an Arduino to drive my LCD display simply so that I could drive the various logic lines. I didn"t use any of the specialized Arduino libraries for driving a LCD; instead, I simply used the standard digitalWrite command to send the commands and data. The digitalWrite command merely sets the targetted output pin to either 0 V (GND, or LOW) or to +5 V (HIGH). This is equivalent to opening (LOW) or closing (HIGH) a switch. The difference is that using the Arduino means you don"t have the "bounce" problem. The hard part is that you have to code each HIGH and LOW of each line.

To simplify the steps, I"m going to use a table in which each HIGH is replaced by a 1, and a LOW is replaced by a 0. After each step, the EN (enable) line on the system has to be set HIGH, then LOW. This tells the LCD to read in the data or instructions.

If you happen to be using the normal LCD library for an Arduino, or programming the LCD using a C or C++ based system, then when you program it to, say, show the letter "H", or program it to have the cursor blink, then your programming has to be setting the various lines in a manner similar to what we just did above. Think of this as "assembly language for the LCD".

The luma.OLED library interfaces with many OLED controllers (SSD1306, SSD1309, SSD1322, SSD1325, SSD1327, SSD1331, SSD1351, SSD1362, SH1106, and WS0010), so with a few adjustments (changing the device define to match your display’s controller, and having a compatible breakout board) this tutorial can be used for many of our OLED displays.

To understand the limitations, take a piece of graph paper and draw out a set of 5x7 rectangles. See if you can define ANY recognizable Japanese or Chinese characters on your graph paper.

You need a display with a lot more resolution, like an OLED graphics display. You are also struggling against a microcontroller that doesn"t have support for Unicode. It"s just not up to the job. You"d be much better off with a Raspberry Pi and a screen like a smart-phone color LCD screen. Install Linux and you can have native support for Unicode.

some are pretty obvious as to their function, the smaller sub buttons load various images I happen to randomly pick off the internet to demonstrate the ability to load to the LCD SPI screen as well as the HDMI (See the video for a demo)

In previous posts I’ve covered using HD44780 16×2 and 20×4 LCD screens with the Raspberry Pi using Python. These are relatively easy to use but require a number of connections to be made to the Pi’s GPIO header. This setup can be simplified with the use of an I2C enabled LCD screen.

The example script will allow you to send text to the screen via I2C. It is very similar to my scripts for the normal 16×2 screen. To download the script directly to your Pi you can use :wget https://bitbucket.org/MattHawkinsUK/rpispy-misc/raw/master/python/lcd_i2c.py

Once you’ve played with LEDs, switches and stepper motors the next natural step is 16×2 alphanumeric LCD modules. These modules are cheap (less than $10) and easy to interface to the Raspberry Pi. They have 16 connections but you only need to use 6 GPIO pins on your Pi.

Most of the 16×2 modules available are compatible with the Hitachi HD44780 LCD controller. This allows you to buy almost any device and be sure it is going to work in much the same way as any other. There are loads to choose from on eBay with different coloured backlights. The one I purchased had a blue backlight.

This script can be downloaded using this link or directly to your Pi using the following command :wget https://bitbucket.org/MattHawkinsUK/rpispy-misc/raw/master/python/lcd_16x2.py

Additional Notes : RS is low when sending a command to the LCD and high when sending a character. RW is always low to ensure we only ever input data into the module. 8 bit bytes are sent 4 bits at a time. Top 4 bits first and the last 4 bits second. Delays are added between certain steps to ensure the module can react to the signal before it changes.
