lcd panel compatibility in stock

There are many LCD screen manufacturers for the Laptop Industry. LCD screens have different resolutions, size and type and these screens are compatible as long as the resolution and connections are the same.

For this listing, we will ship you a brand new OEM Compatible LCD screen manufactured either by Samsung, LG, Chi Mei, Chunghwa, Sharp, or AUOptronics. For more information about each LCD manufacture please click here.

If you wish to know the make of the actual LCD that will be shipped to you, please contact us by phone with your order information between 11AM - 8PM EST (Monday - Friday).

If the controller is on the back of the LCD, then you are in luck. If it"s not, then you will have to find an equivalent LCD controller and design a PCB with a microcontroller on it.

The first thing to do is find the datasheet for the LCD controller chip, without this you have a real uphill battle. If you know the manufacturer and find the package this might help you reverse engineer your module. Some companies only provide datasheets on request, some you have to have an agreement with them.

If what you have salvaged is an LCD module that is manufactured, this will be easier to interface to as the manufacturer will in all likely hood have the datasheet and drivers.

Once you have found the datasheet, you can then figure out how to interface to it. The LCD controller will either be a parallel (for the bigger screens with a faster update) or a serial (smaller screens with a slower update). Some of the serial screens use SPI. The parallel ones will have data and address lines and control lines similar to writing to memory.

Then connect your microprocessor to the data (and or address lines) and see if you can access a register and read and write data to the LCD (preferably control registers to test communication).

Remember that to implement one interface to an LCD can take man months of time to implement for a product, a project like this can really help you appreciate economies of scale.

The iPhone display is engineered together with iOS software for optimal performance and quality. A nongenuine display might cause compatibility or performance issues. For example, an issue might arise after an iOS software update that contains display updates.

The generic driver enables application programs to access the specified LCD panel as a standard display. CompuLab provides support for the driver’s setup per operating system.

CompuLab provides setup values for the graphics controller, which configure the generic driver to support a particular LCD panel. This service is provided for one panel, whose compatibility has been confirmed previously.

CompuLab’s operating system packages contain facilities and tools enabling the setup of the graphics controller to support the required panel. For Linux, the user can either set values by utility or compile them into the kernel. For Win CE, the user sets the values by registry keys. These can be fed into the operating system by the BIOS or compiled into a run-time image. In most cases, the user can accomplish panel the adaptation task merely by using the facilities provided by CompuLab. However, in certain cases, kernel compilation (Linux) or platform re-build (Windows) may be required.

Panels having resolutions lower than 320 x 240 are supported by controller; however, they sometimes require complicated adaptation, in which case CompuLab reserves the right to refuse to provide the adaptation service. For Win XP minimal supported resolution is 640 x 480.

A typical TFT panel is expected to contain signals such as: R[5:0], B[5:0], G[5:0], CLK, Hsync, Vsync & Data Enable. Check in the datasheet that these signals are available. Take into account that the naming convention may vary.

The LCD Display Upgrade provides additional information while riding, including Speedometer, Odometer, Trip Odometer, Average Speed, Max Speed, and Pedal Assist (PAS) levels 1-4. This replaces the stock LED display on the RadRunner, RadMission, and RadExpand.
