A thin-film-transistor liquid-crystal display (TFT LCD) is a variant of a liquid-crystal display that uses thin-film-transistor technologyactive matrix LCD, in contrast to passive matrix LCDs or simple, direct-driven (i.e. with segments directly connected to electronics outside the LCD) LCDs with a few segments.

In February 1957, John Wallmark of RCA filed a patent for a thin film MOSFET. Paul K. Weimer, also of RCA implemented Wallmark"s ideas and developed the thin-film transistor (TFT) in 1962, a type of MOSFET distinct from the standard bulk MOSFET. It was made with thin films of cadmium selenide and cadmium sulfide. The idea of a TFT-based liquid-crystal display (LCD) was conceived by Bernard Lechner of RCA Laboratories in 1968. In 1971, Lechner, F. J. Marlowe, E. O. Nester and J. Tults demonstrated a 2-by-18 matrix display driven by a hybrid circuit using the dynamic scattering mode of LCDs.T. Peter Brody, J. A. Asars and G. D. Dixon at Westinghouse Research Laboratories developed a CdSe (cadmium selenide) TFT, which they used to demonstrate the first CdSe thin-film-transistor liquid-crystal display (TFT LCD).active-matrix liquid-crystal display (AM LCD) using CdSe TFTs in 1974, and then Brody coined the term "active matrix" in 1975.high-resolution and high-quality electronic visual display devices use TFT-based active matrix displays.

The liquid crystal displays used in calculators and other devices with similarly simple displays have direct-driven image elements, and therefore a voltage can be easily applied across just one segment of these types of displays without interfering with the other segments. This would be impractical for a large display, because it would have a large number of (color) picture elements (pixels), and thus it would require millions of connections, both top and bottom for each one of the three colors (red, green and blue) of every pixel. To avoid this issue, the pixels are addressed in rows and columns, reducing the connection count from millions down to thousands. The column and row wires attach to transistor switches, one for each pixel. The one-way current passing characteristic of the transistor prevents the charge that is being applied to each pixel from being drained between refreshes to a display"s image. Each pixel is a small capacitor with a layer of insulating liquid crystal sandwiched between transparent conductive ITO layers.

The circuit layout process of a TFT-LCD is very similar to that of semiconductor products. However, rather than fabricating the transistors from silicon, that is formed into a crystalline silicon wafer, they are made from a thin film of amorphous silicon that is deposited on a glass panel. The silicon layer for TFT-LCDs is typically deposited using the PECVD process.

Polycrystalline silicon is sometimes used in displays requiring higher TFT performance. Examples include small high-resolution displays such as those found in projectors or viewfinders. Amorphous silicon-based TFTs are by far the most common, due to their lower production cost, whereas polycrystalline silicon TFTs are more costly and much more difficult to produce.

The twisted nematic display is one of the oldest and frequently cheapest kind of LCD display technologies available. TN displays benefit from fast pixel response times and less smearing than other LCD display technology, but suffer from poor color reproduction and limited viewing angles, especially in the vertical direction. Colors will shift, potentially to the point of completely inverting, when viewed at an angle that is not perpendicular to the display. Modern, high end consumer products have developed methods to overcome the technology"s shortcomings, such as RTC (Response Time Compensation / Overdrive) technologies. Modern TN displays can look significantly better than older TN displays from decades earlier, but overall TN has inferior viewing angles and poor color in comparison to other technology.

Most TN panels can represent colors using only six bits per RGB channel, or 18 bit in total, and are unable to display the 16.7 million color shades (24-bit truecolor) that are available using 24-bit color. Instead, these panels display interpolated 24-bit color using a dithering method that combines adjacent pixels to simulate the desired shade. They can also use a form of temporal dithering called Frame Rate Control (FRC), which cycles between different shades with each new frame to simulate an intermediate shade. Such 18 bit panels with dithering are sometimes advertised as having "16.2 million colors". These color simulation methods are noticeable to many people and highly bothersome to some.gamut (often referred to as a percentage of the NTSC 1953 color gamut) are also due to backlighting technology. It is not uncommon for older displays to range from 10% to 26% of the NTSC color gamut, whereas other kind of displays, utilizing more complicated CCFL or LED phosphor formulations or RGB LED backlights, may extend past 100% of the NTSC color gamut, a difference quite perceivable by the human eye.

In 2004, Hydis Technologies Co., Ltd licensed its AFFS patent to Japan"s Hitachi Displays. Hitachi is using AFFS to manufacture high end panels in their product line. In 2006, Hydis also licensed its AFFS to Sanyo Epson Imaging Devices Corporation.

A technology developed by Samsung is Super PLS, which bears similarities to IPS panels, has wider viewing angles, better image quality, increased brightness, and lower production costs. PLS technology debuted in the PC display market with the release of the Samsung S27A850 and S24A850 monitors in September 2011.

TFT dual-transistor pixel or cell technology is a reflective-display technology for use in very-low-power-consumption applications such as electronic shelf labels (ESL), digital watches, or metering. DTP involves adding a secondary transistor gate in the single TFT cell to maintain the display of a pixel during a period of 1s without loss of image or without degrading the TFT transistors over time. By slowing the refresh rate of the standard frequency from 60 Hz to 1 Hz, DTP claims to increase the power efficiency by multiple orders of magnitude.

Due to the very high cost of building TFT factories, there are few major OEM panel vendors for large display panels. The glass panel suppliers are as follows:

External consumer display devices like a TFT LCD feature one or more analog VGA, DVI, HDMI, or DisplayPort interface, with many featuring a selection of these interfaces. Inside external display devices there is a controller board that will convert the video signal using color mapping and image scaling usually employing the discrete cosine transform (DCT) in order to convert any video source like CVBS, VGA, DVI, HDMI, etc. into digital RGB at the native resolution of the display panel. In a laptop the graphics chip will directly produce a signal suitable for connection to the built-in TFT display. A control mechanism for the backlight is usually included on the same controller board.

The low level interface of STN, DSTN, or TFT display panels use either single ended TTL 5 V signal for older displays or TTL 3.3 V for slightly newer displays that transmits the pixel clock, horizontal sync, vertical sync, digital red, digital green, digital blue in parallel. Some models (for example the AT070TN92) also feature input/display enable, horizontal scan direction and vertical scan direction signals.

New and large (>15") TFT displays often use LVDS signaling that transmits the same contents as the parallel interface (Hsync, Vsync, RGB) but will put control and RGB bits into a number of serial transmission lines synchronized to a clock whose rate is equal to the pixel rate. LVDS transmits seven bits per clock per data line, with six bits being data and one bit used to signal if the other six bits need to be inverted in order to maintain DC balance. Low-cost TFT displays often have three data lines and therefore only directly support 18 bits per pixel. Upscale displays have four or five data lines to support 24 bits per pixel (truecolor) or 30 bits per pixel respectively. Panel manufacturers are slowly replacing LVDS with Internal DisplayPort and Embedded DisplayPort, which allow sixfold reduction of the number of differential pairs.

The bare display panel will only accept a digital video signal at the resolution determined by the panel pixel matrix designed at manufacture. Some screen panels will ignore the LSB bits of the color information to present a consistent interface (8 bit -> 6 bit/color x3).

With analogue signals like VGA, the display controller also needs to perform a high speed analog to digital conversion. With digital input signals like DVI or HDMI some simple reordering of the bits is needed before feeding it to the rescaler if the input resolution doesn"t match the display panel resolution.

Kawamoto, H. (2012). "The Inventors of TFT Active-Matrix LCD Receive the 2011 IEEE Nishizawa Medal". Journal of Display Technology. 8 (1): 3–4. Bibcode:2012JDisT...8....3K. doi:10.1109/JDT.2011.2177740. ISSN 1551-319X.

Brody, T. Peter; Asars, J. A.; Dixon, G. D. (November 1973). "A 6 × 6 inch 20 lines-per-inch liquid-crystal display panel". 20 (11): 995–1001. Bibcode:1973ITED...20..995B. doi:10.1109/T-ED.1973.17780. ISSN 0018-9383.

K. H. Lee; H. Y. Kim; K. H. Park; S. J. Jang; I. C. Park & J. Y. Lee (June 2006). "A Novel Outdoor Readability of Portable TFT-LCD with AFFS Technology". SID Symposium Digest of Technical Papers. AIP. 37 (1): 1079–82. doi:10.1889/1.2433159. S2CID 129569963.

Kim, Sae-Bom; Kim, Woong-Ki; Chounlamany, Vanseng; Seo, Jaehwan; Yoo, Jisu; Jo, Hun-Je; Jung, Jinho (15 August 2012). "Identification of multi-level toxicity of liquid crystal display wastewater toward Daphnia magna and Moina macrocopa". Journal of Hazardous Materials. Seoul, Korea; Laos, Lao. 227–228: 327–333. doi:10.1016/j.jhazmat.2012.05.059. PMID 22677053.

Overview of the theory and construction of TFT display panels The main sections of this white paper are laid out follows: The assembly of LCD driving circuits. Polarity-inversion driving methods. How an LCD Panel produces colors.

While in theory an Arduino can run any LCD, we believe that some LCDs are particularly suited to being an Arduino LCD display. We"ve currated this list of LCD displays that will make any Arduino-based project shine.

First is the interface. All of these displays support SPI. Builders often ask themselves (or us) "which interface uses the fewest GPIO pins? AND is that interface fast enough to update the screen at an acceptable rate for my application?" When using the relatively small procesor of the Arduino, SPI is usually the best interface because it takes few wires (either 3 or 4) however it does limit the overall size (number of pixels) that can be quickly controlled. I2C is another choice of interface to leave GPIOs open. We tend to recommend SPI over I2C for Arduino displays because SPI is quicker and better at handling more complex data transfer, like pulling image data from an SD card.

Which brings us to the second factor in choosing an Arduino display: the number of pixels. We typically recommend a display with a resolution of 320x240 or less for use with Arduino. Take for example a 320x240 24-bit display. Such a display takes 230,400 bytes *(8 + 2) = 2,304,000 bits for a single frame. Divide that by 8,000,000 (Arduino SPI speed of 8MHZ) = 0.288 seconds per frame or 3.5 frames per second. 3.5 fps is fast enough for many applications, but is not particularly quick. Using fewer bits-per-pixel or a display with fewer pixels will result in higher frame rates. Use the calculator below to calculate the frame rate for a display using SPI with an Arduino.

Third, we want to recommend displays that are easy to connect to an Arduino. Each of these displays has a ZIF tail or easily solderable throughholes, so no fine pitch soldering is needed. These displays can either be brought up on the CFA10102 generic breakout board, or with a custom CFA breakout board.

Most character displays can be run via Parallel connection to an Arduino. You"ll want to make sure you can supply enough current to operate the backlight.

LCD stands for “Liquid Crystal Display” and TFT stands for “Thin Film Transistor”. These two terms are used commonly in the industry but refer to the same technology and are really interchangeable when talking about certain technology screens. The TFT terminology is often used more when describing desktop displays, whereas LCD is more commonly used when describing TV sets. Don’t be confused by the different names as ultimately they are one and the same. You may also see reference to “LED displays” but the term is used incorrectly in many cases. The LED name refers only to the backlight technology used, which ultimately still sits behind an liquid crystal panel (LCD/TFT).

As TFT screens are measured differently to older CRT monitors, the quoted screen size is actually the full viewable size of the screen. This is measured diagonally from corner to corner. TFT displays are available in a wide range of sizes and aspect ratios now. More information about the common sizes of TFT screens available can be seen in our section about resolution.

The aspect ratio of a TFT describes the ratio of the image in terms of its size. The aspect ratio can be determined by considering the ratio between horizontal and vertical resolution.

16:9 = wide screen formats such as 1920 x 1080 and 2560 x 1440. 16:9 is commonly used for multimedia displays and TV’s and is increasingly becoming the standard

The resolution of a TFT is an important thing to consider. All TFT’s have a certain number of pixels making up their liquid crystal matrix, and so each TFT has a “native resolution” which matches this number. It is always advisable to run the TFT at its native resolution as this is what it is designed to run at and the image does not need to be stretched or interpolated across the pixels. This helps keep the image at its most clear and at optimum sharpness. Some screens are better than others at running below the native resolution and interpolating the image which can sometimes be useful in games.

You generally cannot run a TFT at a resolution of above its native resolution although some screens have started to offer “Virtual” resolutions, for example “virtual 4k” where the screen will accept a 3840 x 2160 input from your graphics card but scale it back to match the native resolution of the panel which is often 2560 x 1440 in these examples. This whole process is rather pointless though as you lose a massive amount of image quality in doing so.

Ultra-high resolutions must be thought of in a slightly different way. Ultra HD (3840 x 2160) and 4K (4096 x 2160) resolutions are being provided nowadays on standard screen sizes like 24 – 27” for instance. Traditionally as you increased the resolution of panels it was about providing more desktop real estate to work with. However, with those resolutions being so high, and the screen size being relatively small still, the image and text becomes incredibly small if you run the screen at normal scaling at those native resolutions. For instance imagine a 3840 x 2160 resolution on a 24” screen compared with 1920 x 1080. The latter would probably be considered a comfortable font size for most users. These ultra-high resolutions nowadays are about improving image clarity and sharpness, and providing a higher pixel density (measured as pixels per inch = PPI). In doing so, you can improve the sharpness and clarity of an image much like Apple have famously done with their “Retina” displays on iPads and iPhones. To avoid complications with tiny images and fonts, you will then need to enable scaling in your operating system to make everything easier to see. For instance if you enabled scaling at 150% on a 3840 x 2160 resolution, you would end up with a screen real estate equivalent to a 2560 x 1440 panel (3840 / 1.5 = 2560 and 2160 / 1.5 = 1440). This makes text much easier to read and the whole image a more comfortable size, but you then get additional benefits from the higher pixel density instead, which results in a sharper and crisper image.

Generally you will need to take scaling in to consideration when purchasing any ultra-high resolution screen, unless it’s of a very large size. The scaling ability does vary however between different operating systems so be careful. Apple OS and modern Windows (8 and 10) are generally very good at handling scaling for ultra-high res displays. Older operating systems are less capable and may sometimes be complicated. You will also find varying support from different applications and games, and often end up with weird sized fonts or sections that are not scaled up and remain extremely small. A “standard” resolution where you don’t need to worry about scaling might be simpler for most users.

To display this content of this type, your screen needs to be able to 1) handle the full resolution naturally within its native resolution, and 2) be able to handle either the progressive scan or interlaced signal over whatever video interface you are using. If the screen cannot support the full resolution, the image can still be shown but it will be scaled down by the hardware and you won’t be take full advantage of the high resolution content. So for a monitor, if you want to watch 1080 HD content you will need a monitor which can support at least a vertical resolution of 1080 pixels, e.g. a 1920 x 1080 monitor.

Unlike on CRT’s where the dot pitch is related to the sharpness of the image, the pixel pitch of a TFT is related to the distance between pixels. This value is fixed and is determined by the size of the screen and the native resolution (number of pixels) offered by the panel. Pixel pitch is normally listed in the manufacturers specification. Generally you need to consider that the ‘tighter’ the pixel pitch, the smaller the text will be, and potentially the sharper the image will be. To be honest, monitors are normally produced with a sensible resolution for their size and so even the largest pixel pitches return a sharp images and a reasonable text size. Some people do still prefer the larger-resolution-crammed-into-smaller-screen option though, giving a smaller pixel pitch and smaller text. It’s down to choice and ultimately eye-sight.

For instance you might see a 35″ ultra-wide screen with only a 2560 x 1080 resolution which would have a 0.3200 mm pixel pitch. Compare this to a 25″ screen with 2560 x 1400 resolution and 0.2162 mm pixel pitch and you can see there will be a significant different in font size and image sharpness. There are further considerations when it comes to the pixel pitch of ultra-high resolution displays like Ultra HD and 4K. See the section on PPI for more information.

Instead manufacturers are now focusing on delivering higher resolutions in to existing panel sizes, not for the purpose of providing more desktop real-estate, but for the purpose of improving image sharpness and picture quality. Apple started this trend with their “Retina Displays” used in iPads and iPhones, improving image sharpness and clarity massively. It is common now to see smaller screens such as 24″ and 27″ for instance, but with high resolutions like 3840 x 2160 (Ultra HD) or even 5120 x 2880 (5K). By packing more pixels in to the same screen size which would typically offer a 2560 x 1440 resolution, panel manufacturers are able to provide much smaller pixel pitches and improve picture sharpness and clarity. To measure this new way of looking at resolution you will commonly see the spec of ‘Pixels Per Inch’ (PPI) being used.

Of course the problem with this is that if you run a screen as small as 27″ with a 5K resolution, the font size is absolutely tiny by default. You get a massive boost of desktop real-estate, just like when moving from 1920 x 1080 to 2560 x 1440, but that’s not the purpose of these higher resolutions now. To overcome this you need to use the scaling options in your Operating System software to scale the image and make it more usable. Windows provides for instance scaling options like 125% and 150% within the control panel. On a 3840 x 2160 Ultra HD resolution if you use a 150% scaling option for example you will in effect reduce the desktop area by a third, resulting in the same desktop area as a 2560 x 1440 display (i.e. 2560 x 150% = 3840). The OS scaling makes font sizes more comfortable and reasonable, but you maintain the sharp picture quality and small pixel pitch of the higher resolution panel. A 3840 x 2160 res panel scaled at 150% in Windows will look sharper and crisper than a 2560 x 1440 native panel without scaling, despite the fact both would have the same effective desktop area available.

While this aspect is not always discussed by display manufacturers it is a very important area to consider when selecting a TFT monitor. The LCD panels producing the image are manufactured by many different panel vendors and most importantly, the technology of those panels varies. Different panel technologies will offer different performance characteristics which you need to be aware of. Their implementation is dependent on the panel size mostly as they vary in production costs and in target markets. The four main types of panel technology used in the desktop monitor market are:

IPS was originally introduced to try and improve on some of the drawbacks of TN Film. While initially viewing angles were improved, the panel technology was traditionally fairly poor when it came to response times and contrast ratios. Production costs were eventually reduced and the main investor in this technology has been LG.Display (formerly LG.Philips). The original IPS panels were developed into the so-called Super IPS (S-IPS) generation and started to be more widely used in mainstream displays. These were characterized by their good colour reproduction qualities, 8-bit colour depth (without the need for Frame Rate Control) and very wide viewing angles. These panels were traditionally still quite slow when it came to pixel response times however and contrast ratios were mediocre. In more recent years a change was made to the pixel alignment in these IPS panels (see our detailed panel technology article for more information) which gave rise to the so-called Horizontal-IPS (H-IPS) classification. With the introduction of overdrive technologies, response times were improved significantly, finally making IPS a viable choice for gaming. This has resulted more recently in IPS panels being often regarded as the best all-round technology and a popular choice for display manufacturers in today’s market. Improvements in energy consumption and reduced production costs lead to the generation of so-called e-IPS panels. Unlike normal 8-bit S-IPS and H-IPS classification panels, the e-IPS generation worked with a 6-bit + FRC colour depth. Developments and improvements with colour depths also gave rise to a generation of “10-bit” panels with some manufacturers inventing new names for the panels they were using, including the co-called Performance-IPS (p-IPS). It is important to understand that these different variants are ultimately very similar and the names are often interchanged by different display vendors. For more information, see our detailed panel technologies guide.

Nowadays IPS panels are produced and developed by several leading panel manufacturers. LG.Display technically own the IPS name and continue to invest in this popular technology. Samsung began production of their very similar PLS (Plane to Line Switching) technology, as did AU Optronics with their AHVA (Advanced Hyper Viewing Angle). These are all so similar in performance and features that they can be simply referred to now as “IPS-type”. Indeed monitor manufacturers will normally stick to the common IPS name but the underlying panel may be produced by any number of different manufacturers investing in this type of panel tech. AU Optronics have done a good job with finally increasing the refresh rate of their IPS panels, and making them a more viable option for gamers. Native 144Hz IPS-type panels are now available and response times continue to be reduced as well. Modern IPS panels are characterized by decent response times, if not quite as fast as TN Film they are certainly more fluid than older panels. Contrast ratios are typically around 1000:1 and viewing angles continue to be the widest and most stable of any panel technology. You will find varying colour depths including 6-bit+FRC and 8-bit commonly being used, although this makes little difference in practice. One of the remaining limitations with IPS-type technologies are the so-called “IPS glow”, where darker content introduces a pale glow when viewed from an angle. It’s a characteristic of the panel technology and pretty hard to avoid without additional filters being added to the panels. On larger and wider screens some people find this glow distracting and problematic.

This technology was developed by Sharp for use in some of their TFT displays. It consists of several improvements that Sharp claim to have made, mainly to counter the drawbacks of the popular TN Film technology. They have introduced an Anti-Glare / Anti-Reflection (AGAR) screen coating which forms a quarter-wavelength filter. Incident light is reflected back from front and rear surfaces 180° out of phase, thus canceling reflection rather diffusing it as others do. As well as reducing glare and reflection from the screen, this is marketed as being able to offer deeper black levels. Sharp also claim to offer better contrast ratios than any competing technology (VA and IPS); but with more emphasis on improving these other technologies, this is probably not the case with more modern panels. There are very few ASV monitors around really, with the majority of the market being dominated by TN, VA and IPS panels.

This technology was developed by BOE Hydis, and is not really very widely used in the desktop TFT market, more in the mobile and tablet sectors. It is worth mentioning however in case you come across displays using this technology. It was developed by BOE Hydis to offer improved brightness and viewing angles to their display panels and claims to be able to offer a full 180/180 viewing angle field as well as improved colours. This is basically just an advancements from IPS and is still based on In Plane technology. They claim to “modify pixels” to improve response times and viewing angles thanks to improved alignment. They have also optimised the use of the electrode surface (fringe field effect), removed shadowed areas between pixels, horizontally aligned electric fields and replaced metal electrodes with transparent ones. More information about AFFS can be found here.

This panel technology was developed by NEC LCD, and is reported to offer wide viewing angles, fast response times, high luminance, wide colour gamut and high definition resolutions. Of course, there is a lot of marketing speak in there, and the technology is not widely employed in the mainstream monitor market. Wide viewing angles are possible thanks to the horizontal alignment of liquid crystals when electrically charged. This alignment also helps keep response times low, particularly in grey to grey transitions. Their SFT range also offers high definition resolutions and are commonly used in medical displays where extra fine detail is required.

One thing to note regarding pixel response time is that the overall performance of the TFT will also depend on the technology of the panel used. TN film panels offer response time graphs similar to that above, but screens based on traditional VA / IPSvariant panels can show response time graphs more like this (we are assuming for now non-overdriven panels):

Some reviews sites including TFTCentral have access to advanced photosensor (photodiodе + low-noise operational amplifier) and oscilloscope measurement equipment which allows them to measure response time as detailed above. See our article about response times for more information on that method. Graphs showing response time according to their equipment are produced. Other sites rely on observed responsiveness to compare how well a panel can perform in practice and what a user might see in normal use. We think it is important to study both methods if possible to give a fuller picture of a panels performance. For visual tests TFTCentral uses a program called PixPerAn (developed by Prad.de) which is good for comparing monitor responsiveness with its series of tests. The favourite seems to be the moving car test as shown here:

Movement isn’t perfectly fluid. Depending on its speed, the car is shown in several successive positions. If the car goes very fast, the positions are very close and the eye perceives a flowing movement. A monitor without ghosting effects would have previous images completely fading away when a new one appears. This is the theory and in practice, it’s often not the case as images fade progressively. Sometimes up to 5 afterglow images remain on the monitor and represent the visible white trail behind objects. Some monitors have strong overdrives in addition to image anticipation algorithms and where these are too aggressively applied, or poorly controlled, it can result in problems. In this case, an image can appear in front or behind the main object, creating a white or dark halo commonly.

In addition to pixel response time measurements and visual tests described above, it is also possible to capture the levels of blurring and smearing the human eye will experience on a display. This is achieved using a pursuit camera setup. They are simply cameras which follow the on-screen motion and are extremely accurate at measuring motion blur, ghosting and overdrive artefacts of moving images. Since they simulate the eye tracking motion of moving eyes, they can be useful in giving an idea of how a moving image appears to the end user. It is the blurring caused by eye tracking on continuously-displayed refreshes (sample-and-hold) that we are keen to analyse with this new approach. This is not pixel persistence caused by response times; but a different cause of display motion blur which cannot be captured using static camera tests. Low response times do have a positive impact on motion blur, and higher refresh rates also help reduce blurring to a degree. It does not matter how low response times are, or how high refresh rates are, you will still see motion blur from LCD displays under normal operation to some extent and that is what this section is designed to measure. Further technologies specifically designed to reduce perceived motion blur are required to eliminate the blur seen on these type of sample-and-hold displays which we will also look at.

These tests capture the kind of blurring you would see with the naked eye when tracking moving objects across the screen (example from the Asus ROG Swift PG279Q). As you increase the refresh rate the perceived blurring is reduced, as refresh rate has a direct impact on motion blur. It is not eliminated entirely due to the nature of the sample-and-hold LCD display and the tracking of your eyes. No matter how fast the refresh rate and pixel response times are, you cannot eliminate the perceived motion blur without other methods.Tests like the above would give you an idea of the kind of perceived motion blur range when using the particular screen without any bur reduction mode active.

The Contrast Ratio of a TFT is the difference between the darkest black and the brightest white it is able to display. This is really defined by the pixel structure and how effectively it can let light through and block light out from the backlight unit. As a rule of thumb, the higher the contrast ratio, the better. The depth of blacks and the brightness of the whites are better with a higher contrast ratio. This is also referred to as the static contrast ratio.

When considering a TFT monitor, a contrast ratio of 1000:1 is pretty standard nowadays for TN Film and IPS-type panels. VA-type panels can offer static contrast ratios of 3000:1 and above which are significantly higher than other competing panel technologies.

Some technologies boast the ability to dynamically control contrast (Dynamic Contrast Ratio – DCR) and offer much higher contrast ratios which are incredibly high (millions:1 for instance!). Be wary of these specs as they are dynamic only, and the technology is not always very useful in practice. Traditionally, TFT monitors were said to offer poor black depth, but with the extended use of VA panels, the improvements from IPS and TN Film technology, and new Dynamic Contrast Control technologies, we are seeing good improvements in this area. Black point is also tied in to contrast ratio. The lower the black point, the better, as this will ensure detail is not lost in dark image when trying to distinguish between different shades.

Brightness as a specification is a measure of the brightest white the TFT can display, and is more accurately referred to as its luminance. Typically TFT’s are far too bright for comfortable use, and the On Screen Display (OSD) is used to turn the brightness setting down. Brightness is measure in cd/m2 (candella per metre squared). Note that the recommended brightness setting for a TFT screen in normal lighting conditions is 120 cd/m2. Default brightness of screens out of the box is regularly much higher so you need to consider whether the monitor controls afford you a decent adjustment range and the ability to reduce the luminance to a comfortable level based on your ambient lighting conditions. Different uses may require different brightness settings as well so it is handy when reviews record the luminance range possible from the screen as you adjust the brightness control from 100 to 0%.

The colour depth of a TFT panel is related to how many colours it can produce and should not be confused with colour space (gamut). The more colours available, the better the colour range can potentially be. Colour reproduction is also different however as this related to how reliably produced the colours are compared with those desired.

The colour depth of a panel is determined really by the number of possible orientations of each sub pixel (red, blue and green). These different orientations basically determine the different shade of grey (or colours when filtered in the specific way via RGB sub pixels) and the more “steps” between each shade, the more possible colours the panel can display.

Colour gamut in TFT monitors refers to the range of colours the screen is capable of displaying, and how much of a given reference colour space it might be able to display. It is ultimately linked to backlight technology and not to the panel itself.

Laser Displays are capable of producing the biggest colour gamut for a system with three basic colours, but even a laser display cannot reproduce all the colours the human eye can see, although it is quite close to doing that. However, in today’s monitors, both CRT and LCD (except for some models I’ll discuss below), the spectrum of each of the basic colours is far from monochromatic. In the terms of the CIE diagram it means that the vertexes of the triangle are shifted from the border of the diagram towards its centre.

Traditionally, LCD monitors were capable of giving approximate coverage of the sRGB reference colour space as shown in the diagram above. This is defined by the backlighting used in these displays – Cold-cathode fluorescent lamps (CCFL) that are employed which emit radiation in the ultraviolet range which is transformed into white colour with the phosphors on the lamp’s walls. These backlight lamps shine through the LCD panel, and through the RGB sub-pixels which act as filters for each of the colours. Each filter cuts a portion of spectrum, corresponding to its pass-band, out of the lamp’s light. This portion must be as narrow as possible to achieve the largest colour gamut.

To help develop and improve on the colour space a screen is capable of displaying a new generation CCFL backlighting was introduced. These so-called “wide gamut” backlights allow a gamut coverage of typically 92 – 102% of the NTSC colour space. There is a difference in practice which all users should be able to detect. The colour space available is extended mainly in green shades as you can see from the image above. Red coverage is also extended in some cases. This extended colour space sounds appealing on face value since the screens featuring WCG-CCFL backlighting can offer a broader range of colours. Manufacturers will often promote the colour space coverage of their screens with these high figures. In practice you need to consider what impact this would have on your use.

Of course the opposite is true if in fact you are working with content which is based on a wider colour space. In photography, the Adobe RGB colour space is often used and is wider than the sRGB reference. If you are working with wide gamut content, with wide gamut supported applications, you would want a screen that can correctly display the full range of colours. This could not be achieved using a traditional CCFL backlit display with only sRGB coverage, and so a wide gamut screen would be needed. Wide gamut displays are often aimed at colour enthusiasts and professional uses as a result.

LED backlighting has now become the norm for desktop monitors and is available in a few variations. The most common is White-LED (W-LED), which is a replacement for standard CCFL backlighting. The LED’s are placed in a line along the edge of the matrix, and the uniform brightness of the screen is ensured by a special design of the diffuser. The colour gamut is limited to sRGB as standard (around 68 – 72% NTSC) but the units are cheaper to manufacturer and so are being utilised in more and more screens, even in the more budget range. They do have their environmental benefits as they can be recycled, and they have a thinner profile making them popular in super-slim range models and notebook PC’s. It is possible to extend the colour gamut of W-LED displays using “Quantum Dot” technologies which are fairly new.

RGB LED backlighting consists of an LED backlight based on RGB triads, each triad including one red, one green and one blue LED. With RGB LED backlighting the spectrum of each LED is rather wide, so their radiation can’t be called strictly monochromatic and they can’t match a laser display, yet they are much better than the spectrum of CCFL and WCG-CCFL backlighting. RGB LED backlighting is not common yet in desktop monitors, and their price tends to put them way above the budget of all but professional colour enthusiast and business users. These models using RGB LED backlights are capable of offering a gamut covering > 114% of the NTSC colour space. They are not really used at all nowadays as they were prohibitively expensive.

There are also wide gamut LED backlights available and more commonly used nowadays as they are cheaper to manufacturer than older RGB LED versions. GB-r-LED for instance is provided by LG.Display and can offer wide gamut support from an LED backlight. Other panel manufacturers have their equivalents as well. Modern LED screens with wide gamut support tend to have a percentage coverage of the Adobe RGB reference space listed in the display spec, with 99% Adobe RGB being pretty standard for wide gamut LED technologies.

Viewing angles are quoted in horizontal and vertical fields and often look like this in listed specifications: 170/160 (170° in horizontal viewing field, 160° in vertical). The angles are related to how the image looks as you move away from the central point of view, as it can become darker or lighter, and colours can become distorted as you move away from your central field of view. Because of the pixel orientation, the screen may not be viewable as clearly when looking at the screen from an angle, but viewing angles of TFT’s vary depending on the panel technology used.

TFT screens do not refresh in the same way as a CRT screen does, where the image is redrawn at a certain rate. As a TFT is a static image, and each pixel refreshes independently, setting the TFT at a common 60Hz native refresh rate does not cause the same problems as it would on a CRT. There is no cathode ray gun redrawing the image as a whole on a TFT. You will not get flicker, which is the main reason for having a high refresh rate on a CRT in the first place. Standard TFT monitors operate with a 60Hz recommended refresh rate, but can sometimes support up to 75Hz maximum (within the spec) or sometimes even further using ‘overclocking’ methods. The reason that 60Hz is recommended by all the manufacturers is that it is related to the vertical frequency that TFT panels run at. Some more detailed data sheets for the panels themselves clearly show that the operating vertical frequency is between about 56 and 64Hz, and that the panels ‘typically’ run at 60Hz (see the LG.Philips LM230W02 datasheet for instance – page 11). If you decide to run your refresh rate from your graphics card above the recommended 60Hz it will work fine, but the interface chip on the monitor will be in charge of scaling the frequency down to 60Hz anyway. Some screens will allow you to run at the maximum 75Hz as well for an additional boost in frame rates and some minor improvements in motion clarity. The support of this will really depend on the screen, your graphics card and the video connection being used. You may find the screen operates fine at the higher refresh rate setting but in reality the screen will often drop frames to meet the 60Hz recommended setting (or spec of the panel) anyway. Generally we would suggest sticking to 60Hz on standard TFT monitors.

One thing which some people are concerned about is the frames per second (fps) which their games can display. This is one of the key reasons users will look to boost their screen beyond 60Hz. This is related to the refresh rate of your screen and graphics card. There is an option for your graphics card to enable a feature called Vsync which synchronizes the frame rate of your graphics card with the operating frequency of your graphics card (i.e. the refresh rate). Without vsync on, the graphics card is not limited in it’s frame rate output and so will just output as many frames as it can. This can often result in graphical anomalies including ‘tearing’ of the image where the screen and graphics card are out of sync and the picture appears mixed as the monitor tries to keep up with the demanding frame rate from the card. To avoid this annoying symptom, vsync needs to be enabled. With vsync on, the frame rate that your graphics card is determined by the refresh rate you have set in Windows. Capping the refresh rate at 60hz in your display settings limits your graphics card to only output 60fps. If you set the refresh at 75hz then the card is outputting 75fps. What is actually displayed on the monitor might be a different matter though as we explained above.

The desire to offer higher frame rate support and higher refresh rates has lead to panel manufacturers developing panels which can natively support 120Hz+. It is common now to see 120Hz or 144Hz as natively supported refresh rates. This allows much higher frame rates to be displayed and the increase in refresh rate also brings about positive improvements in perceived motion clarity. TN Film panels have been around for many years now with high refresh rates and in recent years there has been development in IPS-type and VA-type panels to boost their refresh rates as well. You will also now see some ‘overclocked’ monitors available where manufacturers have attempted to boost the refresh rate further. For instance the native 144Hz IPS-type panel of the Asus ROG Swift PG279Q up to 165Hz, or the 144Hz native VA-type panel of the Acer Predator Z35 up to 200Hz. Results of these overclocks do vary and are not guaranteed but may provide some additional benefits.

True 120HZ technology– to have a true 120Hz screen, it must be capable of accepting a full 120Hz signal output from a device (e.g. a graphics card). Because TV’s are limited at the moment by their input sources they tend to use the above interpolation technology, but with the advent of 3D TV and higher frequency input sources, this will change. Desktop monitors are a different matter though as graphics cards can obviously output a true 120Hz if you have a decent enough card. Some models can accept a 120Hz signal but need different interfaces to cope (e.g. dual-link DVI or DisplayPort).

This relates to the connection type from the TFT to your PC or other external device. Older screens nearly all came with an analogue connection, commonly referred to as D-sub or VGA. This allows a connection from the VGA port on your graphics card, where the signal being produced from the graphics card is converted from a pure digital to an analogue signal. There are a number of algorithms implemented in TFT’s which have varying effectiveness in improving the image quality over a VGA connection. Some TFT’s with then offer a DVI input as well to allow you to make use of the DVI output from your graphics card which you might have. This will allow a pure digital connection which can sometimes offer an improved image quality. It is possible to get DVI – VGA converters. These will not offer any improvements over a standard analogue connection, as you are still going through a conversion from digital to analogue somewhere along the line. Dual-Link DVI is also sometimes used which is a single DVI connection but with more pins, allowing for higher resolution/refresh rate support than a single-link DVI.

Mobile High-Definition Link (MHL) is an industry standard for a mobile audio/video interface that allows consumers to connect mobile phones, tablets, and other portable consumer electronics (CE) devices to high-definition televisions (HDTVs) and monitors. You will sometimes see MHL listed in the spec and is often supported over the HDMI interfaces of a display.

DisplayPort is the most common monitor connection type nowadays, offering the highest bandwidth support and therefore being vital to provide the newest high resolution and high refresh rate panels. The DisplayPort (DP) connection comes in two types, either standard or Mini. They are interchangeable and a simple conversion cable can allow connection between each version.

Leadtek has paid great efforts on research and development of TFT-LCM, especially on its application of consumable and industrial products. The sizes of LCM includes 1.4”, 2.4”, 3.5", 3.51", 4.3", 4", 5", 7", 8", 10.1” and 11.6". And among them the 3.5”, 4.3", 5", 7” and 10.1" LCM has achieved the leading level of the industry, and mainly applied to vehicle-applications, tablet PCs, smartphones, medical equipment, measurement equipment, E-books, EPC and industrial products, and provides powerful and reliable supports on supplies and qualities. We are cooperating with famous foreign companies on research and developments, and will bring out the series products of industrial control. Also, we explore the overseas market, and build up a long-term relationship with our overseas partners and agents, Leadtek products will be worldwide in the near future.

Interested in a quote for a standard or modified product?Contact us at (847) 844-8795 or nhsales@newhavendisplay.com. You may also fill out the form below and we’ll respond to your request within 48 hours.

I have a 128x128 ST7735 display that I"m driving with a Seeeduino Xiao (SAMD21). I"d like to draw static fuzz, of the type found on old televisions - i.e. random pixels or squares of black and white.

(EDIT: And going even further, I"m open to using a board with a different TFT driver if it helps, provided similar pricing and availability and drivers for the samd21.)

I created a sketch for the Uno with a nameless 320x240 TFT display shield, ILI9341 controller, using the tft.writePixel (x,y,COLOR) instruction, combined with the random function.

Actually I would like on my 320240 TFT bigger grains (22 blocks of pixels) creating the impression of random (pseudo)noise. That would imply the use of small bitmaps or some complicated stuff remembering previous positions of displayed pixels; I am not sure whether my Uno is fast enough to create a realistic effect. Any suggestion?

The cell phone camera is not synchronized to the speed with which the pixels appear on the screen, this generates a sloping cross band and an apparent increase in speed, which do not really exist in the TFT. Keep in mind that 128x128 = 16,384 pixels are drawn in each step

The ESP32 manages 96fps when every pixel of the 128x128 display is updated per frame, not bad for a $5 processor board. This is at a 26.66MHz SPI clock, so the theoretical maximum is 102fps with no looping delays. This is clearly faster than an old TV frame rate so delays could be added, other code run or a lower SPI clock rate used.

TFT displays are full color LCDs providing bright, vivid colors with the ability to show quick animations, complex graphics, and custom fonts with different touchscreen options. Available in industry standard sizes and resolutions. These displays come as standard, premium MVA, sunlight readable, or IPS display types with a variety of interface options including HDMI, SPI and LVDS. Our line of TFT modules include a custom PCB that support HDMI interface, audio support or HMI solutions with on-board FTDI Embedded Video Engine (EVE2).

1. The base system is linux with Matrix_guiE demo running on top. It is based upon the TI 5.02 Linux SDK for AM1808. The linux kernel is modified to support the custom hardware including LCD display and RAM.

Let us start with the basics first; refresh the knowledge about TN and LCD displays in general, later we will talk about TFTs (Thin Film Transistors), how they differ from regular monochrome LCD displays. Then we will go on to the ghosting effect, so we will not only discuss the technology behind the construction of the TFT, but also some phenomena, like the ghosting effect, or grayscale inversion, that are important to understand when using an LCD TFT display.

Next, we will look at different technologies of the TFT LCD displays like TN, IPS, VA, and of course about transmissive and transflective LCD displays, because TFT displays also can be transmissive and transflective. In the last part we will talk about backlight.

Let us start with a short review of the most basic liquid crystal cell, which is the TN (twisted nematic) display. On the picture above, we can see that the light can be transmit through the cell or blocked by the liquid crystal cell using voltage. If you want to learn more about monochrome LCD displays and the basics of LCD displays, follow this link.

What is a TFT LCD display and how it is different from a monochrome LCD display? TFT is called an active display. Active, means we have one or more transistors in every cell, in every pixel and in every subpixel. TFT stands for Thin Film Transistor, transistors that are very small and very thin and are built into the pixel, so they are not somewhere outside in a controller, but they are in the pixel itself. For example, in a 55-inch TV set, the TFT display contains millions of transistors in the pixels. We do not see them, because they are very small and hidden, if we zoom in, however, we can see them in every corner of each pixel, like on the picture below.

On the picture above we can see subpixels, that are basic RGB (Red, Green, Blue) colors and a black part, with the transistors and electronic circuits. We just need to know that we have pixels, and subpixels, and each subpixel has transistors. This makes the display active, and thus is called  the TFT display. TFT displays are usually color displays, but there are also monochrome TFT displays, that are active, and have transistors, but have no colors. The colors in the TFT LCD display are typically added by color filters on each subpixel. Usually the filters are RGB, but we also have RGBW (Red, Green, Blue, White) LCD displays with added subpixels without the filter (White) to make the display brighter.

Going a little bit deeper, into the TFT cell, there is a part inside well known to us from the monochrome LCD display Riverdi University lecture. We have a cell, liquid crystal, polarizers, an ITO (Indium Tin Oxide) layer for the electrodes, and additionally an electronic circuit. Usually, the electronic circuit consists of one transistor and some capacitors to sustain the pixel state when we switch the pixel OFF and ON. In a TFT LCD display the pixels are much more complicated because apart from building the liquid crystal part, we also need to build an electronic part.

That is why TFT LCD display technologies are very expensive to manufacture. If you are familiar with electronics, you know that the transistor is a kind of switch, and it allows us to switch the pixel ON and OFF. Because it is built into the pixel itself, it can be done very quickly and be very well controlled. We can control the exact state of every pixel not only the ON and OFF states, but also all the states in between. We can switch the light of the cells ON and OFF in several steps. Usually for TFT LCD displays it will be 8-bit steps per color, so we have 256 steps of brightness for every color, and every subpixel. Because we have three subpixels, we have a 24-bit color range, that means over 16 million combinations, we can, at least theoretically, show on our TFT LCD display over 16 million distinct colors using RGB pixels.

Now that we know how the TFT LCD display works, we can now learn some practical things one of which is LCD TFT ghosting. We know how the image is created, but what happens when we have the image on the screen for a prolonged time, and how to prevent it. In LCD displays we have something called LCD ghosting. We do not see it very often, but in some displays this phenomenon still exists.

If some elements of the picture i.e., your company logo is in the same place of the screen for a long period of time, for couple of weeks, months or a year, the crystals will memorize the state and later, when we change the image, we may see some ghosting of those elements. It really depends on many conditions like temperature and even the screen image that we display on the screen for longer periods of time. When you build your application, you can use some techniques to avoid it, like very rapid contrast change and of course to avoid the positioning the same image in the same position for a longer time.

You may have seen this phenomenon already as it is common in every display technology, and even companies like Apple put information on their websites, that users may encounter this phenomenon and how to fix it. It is called image ghosting or image persistence, and even Retina displays are not free of it.

Another issue present in TFT displays, especially TN LCD displays, is grayscale inversion. This is a phenomenon that changes the colors of the screen according to the viewing angle, and it is only one-sided. When buying a TFT LCD display, first we need to check what kind of technology it is. If it is an IPS display, like the Riverdi IPS display line, then we do not need to worry about the grayscale inversion because all the viewing angles will be the same and all of them will be very high, like 80, 85, or 89 degrees. But if you buy a more common or older display technology type, like the TN (twisted nematic) display, you need to think where it will be used, because one viewing angle will be out. It may be sometimes confusing, and you need to be careful as most factories define viewing direction of the screen and mistake this with the greyscale inversion side.

On the picture above, you can see further explanation of the grayscale inversion from Wikipedia. It says that some early panels and also nowadays TN displays, have grayscale inversion not necessary up-down, but it can be any angle, you need to check in the datasheet. The reason technologies like IPS (In-Plane Switching), used in the latest Riverdi displays, or VA, were developed, was to avoid this phenomenon. Also, we do not want to brag, but the Wikipedia definition references our website.

We know already that TN (twisted nematic) displays, suffer from grayscale inversion, which means the display has one viewing side, where the image color suddenly changes. It is tricky, and you need to be careful. On the picture above there is a part of the LCD TFT specification of a TN (twisted nematic) display, that has grayscale inversion, and if we go to this table, we can see the viewing angles. They are defined at 70, 70, 60 and 70 degrees, that is the maximum viewing angle, at which the user can see the image. Normally we may think that 70 degrees is better, so we will choose left and right side to be 70 degrees, and then up and down, and if we do not know the grayscale inversion phenomena, we may put our user on the bottom side which is also 70 degrees. The viewing direction will be then like a 6 o’clock direction, so we call it a 6 o’clock display. But you need to be careful! Looking at the specification, we can see that this display was defined as a 12 o’clock display, so it is best for it to be seen from a 12 o’clock direction. But we can find that the 12 o’clock has a lower viewing angle – 60 degrees. What does it mean? It means that on this side there will be no grayscale inversion. If we go to 40, 50, 60 degrees and even a little bit more, probably we will still see the image properly. Maybe with lower contrast, but the colors will not change. If we go from the bottom, from a 6 o’clock direction where we have the grayscale inversion, after 70 degrees or lower we will see a sudden color change, and of course this is something we want to avoid.

To summarize, when you buy older technology like TN and displays, which are still very popular, and Riverdi is selling them as well, you need to be careful where you put your display. If it is a handheld device, you will see the display from the bottom, but if you put it on a wall, you will see the display from the top, so you need to define it during the design phase, because later it is usually impossible or expensive to change the direction.

We will talk now about the other TFT technologies, that allow us to have wider viewing angles and more vivid colors. The most basic technology for monochrome and TFT LCD displays is twisted nematic (TN). As we already know, this kind of displays have a problem with grayscale inversion. On one side we have a higher retardation and will not get a clear image. That is why we have other technologies like VA (Vertical Alignment), where the liquid crystal is differently organized, and another variation of the TFT technology – IPS which is In-Plane Switching. The VA and IPS LCD displays do not have a problem with the viewing angles, you can see a clear image from all sides.

Apart from the different organization of the liquid crystals, we also organize subpixels a little bit differently in a VA and IPS LCD displays. When we look closer at the TN display, we will just see the subpixels with color filters. If we look at the VA or IPS display they will have subpixels of subpixels. The subpixels are divided into smaller parts. In this way we can achieve even wider viewing angles and better colors for the user, but of course, it is more complicated and more expensive to do.

The picture above presents the TN display and grayscale inversion. For IPS or VA technology there is no such effect. The picture will be the same from all the sides we look so these technologies are popular where we need wide viewing angles, and TN is popular where we don’t need that, like in monitors. Other advantages of IPS LCD displays are they give accurate colors, and wide viewing angles. What is also important in practice, in our projects, is that the IPS LCD displays are less susceptible to mechanical force. When we apply mechanical force to the screen, and have an optically bonded touch screen, we push the display as well as squeeze the cells. When we have a TN display, every push on the cell changes the image suddenly, with the IPS LCD displays with in-plane switching, different liquid crystals organization, this effect is lesser. It is not completely removed but it is much less distinct. That is another reason IPS displays are very popular for smartphones, tablets, when we have the touchscreens usually optically bonded.

If we wanted to talk about disadvantages, there is a question mark over it, as some of them may be true, some of them do not rely on real cases, what kind of display, what kind of technology is it. Sometimes the IPS displays can have higher power consumption than others, in many cases however, not. They can be more expensive, but not necessarily. The new IPS panels can cost like TN panels, but IPS panels definitely have a longer response time. Again, it is not a rule, you can make IPS panels that are very fast, faster than TN panels, but if you want the fastest possible display, probably the TN panel will be the fastest. That is why the TN technology is still popular on the gaming market. Of course, you can find a lot of discussions on the internet, which technology is better, but it really depends on what you want to achieve.

Now, let us look at the backlight types. As we see here, on the picture above, we have four distinct types of backlight possible. The most common, 95 or 99 per cent of the TFT LCD displays on the market are the transmissive LCD display type, where we need the backlight from the back. If you remember from our Monochrome LCD Displays lecture, for transmissive LCD displays you need the backlight to be always on. If you switch the backlight off, you will not see anything. The same as for monochrome LCD displays, but less popular for TFT displays, we have the transflective LCD display type. They are not popular because usually for transflective TFT displays, the colors lack in brightness, and the displays are not very practical to use. You can see the screen, but the application is limited. Some transflective LCD displays are used by military, in applications where power consumption is paramount; where you can switch the backlight off and you agree to have lower image quality but still see the image. Power consumption and saving energy is most important in some kind of applications and you can use transflective LCD displays there. The reflective type of LCD displays are almost never used in TFT. There is one technology called Low Power Reflective Displays (LPRD) that is used in TFT but it is not popular. Lastly, we have a variation of reflective displays with frontlight, where we add frontlight to t
