Active Matrix TFT Colour LCD Display is becoming more pervasive for indoor or outdoor applications, especially the demand in wide temperature TFT LCD is growing in many fields. Winstar Display offers a full range of wide temperature TFT LCD modules; available in various sizes from 3.5" to 12.3". These TFT modules can be operating at Wide Temperature Range from -30℃ to 80℃ or up to 85℃.

The T-57152GD042H-LW-AAN and the T-55923GD050J-LW-ABN, small-format TFT LCD modules designed for use in harsh environments, have been introduced by Kyocera.

The T-57152GD042H-LW-AAN, which measures 4.2”, features a resolution of 480x272px, a brightness of 700cd/m², a digital 18-bit RGB interface, a contrast ratio of 1200:1, and horizontal and vertical viewing angles of 160° each. The design is based on automotive requirements and boasts an expanded operating temperature range of -30 to +85°C and a storage temperature range of -40 to +95°C. In addition, the anti-glare surface treatment improves readability in bright surroundings.

Measuring 5.0”, the T-55923GD050J-LW-ABN is a portrait-mode display that features a resolution of 480x640px. Optical characteristics include 800cd/m² brightness and a 500:1 contrast ratio. The viewing angle amounts to 140º horizontally and 110° vertically. This module comes with a 24-bit digital RGB interface and has a wide operating temperature range of -30 to +80°C.

“Portable outdoor devices are liable to fall down and are exposed to low temperatures, heat and humidity. Even in these conditions, they should always work reliably, and our components are designed for that purpose,” says Eberhard Schill, Manager Distribution and Marketing, Kyocera Display Europe.

The new 10.1” display uses IPS technology, LVDS connectivity and has 1,000 cd brightness making it sunlight readable. It also features an extended backlight half-like of 50K hours, making it suitable for industrial, always-on display applications. All of these features, combined with its extended temperature range, make it the product of choice for harsh environments and outdoor applications.

Made for any rugged application this 7.0″ TFT comes with a high resolution of 1280x768dot, super-wide viewing angles, high brightness 1000cd, high contrast 1000:1 and a wide operating temperature range of -40 to +80C. It also manages high vibration and shock for outdoor industrial devices.

Mitsubishi Electric also offers 7.0” / 8.0” / 12.1” / 15.0” and 19” TFT with pcap-touch for rugged applications! In total they have more than 34 TFT-LCD modules with super-wide viewing angles.

RFF700A9-AWW-DNN is a 7-inch wide temperature TFT LCD display with aspect ratio: 15:9, resolution 800x480 dots. This TFT module uses IPS screen which allows users to see the display clearly at wider angles. The brightness is 500 cd/m2 with contrast ratio 1,000:1. With the help of a anti-glare display surface, the screen doesn’t reflect light and preserves better image quality.

This wide temperature LCD module uses HX8249-A + HX8678-C IC which supports 24 bit R.G.B interface. VCC voltage of RFF700A9-AWW-DNN ranges from 2.7V to 3.6V; typical value is 3.3V. The module works within wide temperature range from -30℃ to +80℃; storage temperature is -40℃ to +85℃. In this RFF700A9 series, there are resistive touch screen (RTP) and capacitive touch screen (PCAP) options available. We also provide a high brightness version.

DLC Display (DLC), together with its sales and marketing channels in Americas and in Europe, announced the development of a new 5.0 inch (TFT) liquid crystal display (LCD) modules. This module is ideal for use in high-end industry equipment.

The new TFT LCD module is well suited for use in high-end industry display applications. They are equipped with high brightness, full viewing angle and wide temperature range to achieve better display effect.

The new module features wide operating temperature range of -30 to +85 degrees C which guarantees stable operation even in very low and very high temperature environments.

DLC Display has responded to this market demand by developing and releasing products that achieve the full viewing angle, high Luminance and wide operating temperature range by optimizing the panel and the backlight.

The 5.0 inch TFT LCD is the important size in DLC’s product family. The display’s feature allows more easily to read content on the display with better display effect by any direction. It is ideal for use as a industry equipment that shows a variety of information and data on the display.

In low temperature environment, liquid crystals will be condensed and cause the screen blanked out. In order to prevent the problem, you may need to add a Glass Heater to your TFT LCD Module.

It can optimize the LCD visual clarity and operate normally by heating up to the right temperature. With Glass Heater, displays and touch screens remain usable in cold, high humidity/low dew point environments and locations where ambient temperature can change quickly.

TOKYO, October 3, 2019 - Mitsubishi Electric Corporation (TOKYO: 6503) announced today the launch of a 12.1-inch WXGA TFT-LCD module designed for use in harsh outdoor environments, such as on construction sites and in heavy-duty vehicles, as well as in industrial applications and in agricultural use.

The new modules will offer an unprecedented combination of advanced features, including high-resolution WXGA (1,280 × 800 pixels), super-wide 176-degree horizontal/vertical viewing angles and a high luminosity of 1,500 cd/m2. They will additionally feature a high contrast ratio of 1,000:1, a versatile operating-temperature range of -40 to +80 degrees Celsius and will have high resistance to vibration, attributes for which there is increasing market demand.

Optimized mechanical design achieves high vibration resistance of 6.8Gs (7x greater than 1.0Gs of existing Mitsubishi Electric "AA-" products) allowing compression mounting (LCD peripherals attached to chassis from behind) or 1.5Gs for side mounting (attached to chassis via side openings).

Re-engineered modules with custom components that include the light guide plate, custom high-brightness LED backlights, optical films, mold frames, and mechanical structure. Engineering considerations include environmental factors such as altitude, temperature, and vibration. Inadequate attention to critical details can result in premature degradation of LCD performance such as retardation film and polarizer abrasion, image retention, or Mura.

Display Technology Ltd has recently added 2 new wide temperature range AUO TFTs to their high bright range. The new G215HVN01.3 (21.5”) offers an operating temperature of -20 to 80°C and the G156HAN04.0 (15.6”) offers an operating temperature of -30 to 85°C making them suitable for outdoor applications.

Using only high-tech factories that we partner with, we provide clients with the service of designing liquid crystal display panel (LCD) and liquid crystal display modules (LCM), and are committed to the customized service, R&D, sales and after-sales service of display products.

Our factories have hundreds of engineers focusing on creating the highest quality displays including monochrome LCD (TN, STN), colour LCD (CSTN and TFT), LCD module (both COG* and COB*) which are widely used in mobile phones and many other applications.

Our state of the art factory produces TFT glass panel cells, has TN, HTN, STN and TFT technologies, have class 1000 clean rooms, high accuracy bonding, pre-bonding and heat seal machinery, many production lines specifically for TFT production, OCA and OCF bonding machines, in-House LCD glass cleansing process and output thousands of pieces per month.

For many years, TFT displays have been the dominating technology in visualization. TFT LCDs are all around in our daily lives — in consumer and automotive applications, in our business environments, in healthcare, and within communication devices, home appliances, and factory automation products. While there are many LCD products available today, they’re not all suitable for every application. This is especially the case for industrial LCD monitors. To determine the best LCD display for your application, it’s important to understand your target market and its unique design issues.

The vast majority of LCD displays are designed for consumer devices such as smartphones, cameras, tablet computers, and gaming devices. But they have very different requirements than those for industrial applications. Due to very competitive pricing and quick production cycles, consumer display modules don’t always incorporate the durability, reliability, and advanced features required to survive in an industrial environment. Product life cycles are also typically much shorter in consumer applications. Screens manufactured for these applications are generally only available for one, in best case two years.

The ability to withstand temperature variations as well as shock and vibration is also a key consideration when selecting displays for today’s industrial applications. They must be resilient enough to withstand frequent bumps or jiggles by machine operators and surrounding equipment, and also must be able to handle various operating temperatures.

Industrial displays are typically housed in an enclosure as part of a larger piece of equipment. In these situations, the heat generated by the surrounding equipment gets trapped within the enclosure, which can be detrimental to many displays. Therefore, it’s important to keep the real storage and operating temperature requirements in mind when choosing a display. While measures can be taken to dissipate the generated heat — such as using fans within the enclosure — the most efficient way to ensure compliance with the storage and operating temperature requirements is to select a display that is optimized for these types of environments. Fortunately, improvements in liquid-crystal materials have made it possible to extend the operating temperature ranges of LCDs from –30 to 80°C presently.

It’s important that displays used in industrial applications support clear and precise viewing from multiple angles under a variety of ambient light conditions. The brighter the environment, the more difficult it can be to read a standard transmissive LCD display with a typical brightness of 250 to 300 cd/m2. NVD has developed displays that can perform in the 800-cd/m2-and-higher range by implementing high-efficiency LEDs for the backlight unit– if necessary, in combination with special brightness enhancement films.

Increasing the display’s contrast ratio is another effective way that display manufacturers can improve display readability in bright environments. Typical contrast ratios for non-industrial displays are in the range of 200:1 to 300:1, which may not be sufficient when a machine operator is viewing the display from a distance. Displays with contrast ratios around 500:1 or greater are better suited for industrial environments. Another benefit of this method is that it doesn’t increase power consumption.

Transflective LCDs are a good solution for environments with variable lighting. Having both transmissive and reflective characteristics, transflective LCDs have the option of using a backlight in dim lighting (transmissive mode), as well as using reflective properties in bright lighting (reflective mode). This reduces power consumption and heat production in reflective mode since the backlight isn’t used.

TFT (Thin Film Transistor) LCD (Liquid Crystal Display) dominates the world flat panel display market now. Thanks for its low cost, sharp colors, acceptable view angles, low power consumption, manufacturing friendly design, slim physical structure etc., it has driven CRT(Cathode-Ray Tube) VFD ( Vacuum Fluorescent Display) out of market, squeezed LED (Light Emitting Diode) displays only to large size display area. TFT LCD displays find wide applications in TV, computer monitors, medical, appliance, automotive, kiosk, POS terminals, low end mobile phones, marine, aerospace, industrial meters, smart homes, handheld devices, video game systems, projectors, consumer electronic products, advertisement etc. For more information about TFT displays, please visit our knowledge base.

There a lot of considerations for how to choose a most suitable TFT LCD display module for your application. Please find the check list below to see if you can find a right fit.

It is the start point for every project. There aretwo dimensions to consider: outside dimension (width, height, thickness) and AA (active area or pixel area). Orient Display’s standard product line ranges from 1.0” to 32”. Our OLED size can go down to 0.66” which fit for wearable devices.

Resolution will decide the clearance. Nobody likes to see a display showing pixel clearly. That is the reason for better resolution, going from QVGA, VGA to HD, FHD, 4K, 8K. But higher resolution means higher cost, power consumption, memory size, data transfer speed etc. Orient Display offers low resolution of 128×128 to HD, FHD, we are working on providing 4K for our customers. For full list of resolution available, please see Introduction: LCD Resolution

TFT screen brightness selection is very important. You don’t want to be frustrated by LCD image washout under bright light or you drain the battery too fast by selecting a super brightness LCD but will be used indoor only. There are general guidance listed in the table below.

Orient Display offers standard brightness, medium brightness , high brightness, and high end sunlight readable IPS TFT LCD display products for our customers to choose from.

If the budget is tight, TN type TFT LCD can be chosen but there is viewing angle selection of either 6 o’clock or 12 o’clock. Gray scale inversion needs to be taken of carefully. If a high-end product is designed, you can pay premium to select IPS TFT LCD which doesn’t have the viewing angle issue.

It is similar to viewing angle selection, TN type TFT LCD has lower contrast but lower cost, while IPS TFT LCD has much high contrast but normally with higher cost. Orient Display provides both selections.

Normal TFT LCD displays provide wide enoughtemperature range for most of the applications. -20 to 70oC. But there are some (always) outdoor applications like -30 to 80oC or even wider, special liquid crystal fluid has to be used. Heater is needed for operating temperature requirement of -40oC. Normally, storage temperature is not an issue, many of Orient Display standard TFT display can handle -40 to 85oC, if you have any questions, feel free to contact our engineers for details.

Power consideration can be critical in some hand-held devices. For a TFT LCD display module, backlight normally consumes more power than other part of the display. Dimming or totally shutdown backlight technology has to be used when not in use. For some extreme power sensitive application, sleep mode or even using memory on controller consideration has to be in design. Feel free to contact our engineers for details.

High Level Interfaces: Orient Display has technologies to make more advanced interfaces which are more convenient to non-display engineers, such as RS232, RS485, USB, VGA, HDMI etc. more information can be found in our serious products. TFT modules, Arduino TFT display, Raspberry Pi TFT display, Control Board.

If you can’t find a very suitable TFT LCD Display in our product line, don’t be discouraged. The products listed on our website is only small part of standard products. We have thousands of standard products in our database, feel free to contact our engineers for details.

If you like to have a special display, Orient Display is always flexible to do partial custom solution. For example, to modify the FPC to different length or shape, or use as fewer pinouts as possible, or design an ultra-bright LCD display, or a cover lens with your company logo on it, or design an extreme low power or low cost TFT display etc. our engineers will help you to achieve the goals. The NER cost can start from hundreds of dollars to Thousands. In rare case, it can be tens of thousands of dollars.

A fully custom TFT LCD panel can have very high NRE cost. Depending on the size of the display, quantity and which generation production line to be used. The tooling cost can start from $100,000 to over $1M.

March 23, 2015 – Plymouth, MI - Kyocera today introduced two small-form-factor TFT LCD displays that offer high performance and robust design for industrial markets. Available now, both products are designed to perform in harsh environment and extreme temperature applications including outdoor control panels, construction and agricultural equipment, avionics, and other devices that require reliable performance in the most punishing environments.

The new 4.2-inch TFT LCD panel (T-57152GD042H-LW-AAN) features a 480 x 272 resolution, brightness of 700cd/m², and contrast ratio of 1200:1. Featuring Kyocera"s Advanced Wide Viewing (AWV) technology, this panel offers a wide viewing angle of 160 degrees in both vertical and horizontal directions. It features a standard 18-bit digital RGB interface, along with a wide operating temperature range of -30°C to +85°C and anti-glare surface treatment. The design is based on automotive specifications, with a storage temperature range of -40°C to 95°C, making it ideal for even the most extreme outdoor applications.

The new 5-inch TFT LCD panel (T-55923GD050J-LW-ABN) is a portrait mode display that features a 480 x 640 resolution. Its optical characteristics include 800cd/m2 brightness, a 500:1 contrast ratio and a viewing angle of 140 degrees horizontally and 110 degrees vertically. It features a standard 24-bit digital RGB interface and a wide operating temperature range of -30°C to +80°C, giving another option for devices that must perform reliably in harsh operating environments.

"Kyocera brings almost 40 years of experience in LCD technology innovation, helping to make the company a preferred supplier of displays for industrial applications as well as automotive and medical equipment," said Cynthia Ferrell, Vice President of Kyocera Industrial Ceramics Corporation"s Display Division. "We continue our commitment to developing environmentally friendly products, and all of Kyocera"s TFT LCDs are RoHS compliant to reduce potentially hazardous substances."

Kyocera expanded its global LCD business in 2012 with the acquisition of Japan-based Optrex Corporation (now Kyocera Display Corporation) - a manufacturing, sales, marketing and R&D enterprise with nearly four decades of LCD innovations. Kyocera Industrial Ceramics Corporation, Display Division, is the sales, marketing and value-added assembly arm for these products in the Americas, with LCD sales offices in Plymouth, MI; Atlanta, GA; Vancouver, WA; and San Diego, CA. LCD warehouse, distribution center and value-added assembly services are located in Plymouth, MI, with company headquarters in Hendersonville, NC.

Kyocera Corporation, the parent and global headquarters of the Kyocera Group, was founded in 1959 as a producer of fine (or "advanced") ceramics. By integrating these engineered materials with other technologies, Kyocera has become a leading supplier of LCDs, industrial ceramics, electronic components, semiconductor packages, cutting tools, solar power generating systems, printers, copiers and telecommunications equipment. During the year ended March 31, 2014, the company"s net sales totaled 1.45 trillion yen (approx. US$14.1 billion). The company appears on the latest "Top 100 Global Innovators" list by Thomson Reuters, and is ranked #531 on Forbes magazine"s current "Global 2000" listing of the world"s largest publicly traded companies.

1. Wide application range, from -20 ° C to +50 ° C temperature range can be used normally, the temperature-hardened TFT-LCD low temperature working temperature can reach minus 80 ° C. It can be used as a mobile terminal display, a desktop terminal display, or a large-screen projection TV. It is a full-size video display terminal with excellent performance.

2. The degree of automation of manufacturing technology is high, and large-scale industrial production characteristics are good. The TFT-LCD industry is mature in technology, and the yield of large-scale production has reached 90% or more.

3. TFT-LCD is easy to integrate and update, and it is a perfect combination of large-scale semiconductor integrated circuit technology and light source technology, and has great potential for further development. At present, there are amorphous, polycrystalline and single crystal silicon TFT-LCDs, and there will be TFTs of other materials in the future, both glass substrates and plastic substrates.
