This 7" touchscreen cape creates a fully integrated system when combined with your BeagleBone Black. Provides full Angstrom support for easy BeagleBone prototyping and projects. A secondary set of header pins gives built-in stacking cape-ability.

Utilizing pre-existing Linux drivers, this 800 x 480 touchscreen cape will help you hit the ground running. Front-facing mechanical buttons and capacitive touch function give the user full control over the BeagleBone Black. Supports Angstrom, Android 4.2, Windows CE7, TI linux and Debian (default).

The Cape for 7 inch displays is neat interface to connect the Waveshare 7 inch displays to your Beaglebone Black. We have not tested any other LCD"s, but the interface is designed for 7 inch resistive touchscreen LCD displays

NHD-7.0CTP-CAPE-N | BeagleBone Black Cape with TFT Display | 7.0" Sunlight Readable LCD | Capacitive Touchscreen | EEPROM with On-Board Dip Switches | Developing with Android & Linux

Engineered in Elgin IL USA, we designed this BeagleBone Cape to be a perfect fit for our 7.0” TFT displays and upgraded it with the sunlight readable NHD-7.0-800480EF-ASXN#-CTP display model. With capacitive 5-point multi-touch functionality and 800x480 resolution screen, this cape works seamlessly while developing with operating systems like Android and Linux. It includes an on-board dip switch for configuring EEPROM and secondary headers for additional cape connections. In addition to the secondary cape slot, we added four 3.5mm mounting holes that are compatible with standard M3 screws, a reset button, write protection pins, PWM backlight control, and an LED power indicator. With this cape we’ve made it easy to take your design process from concept to reality. When paired with the BeagleBone Black board (sold separately by beagleboard.org) you’ll have everything you need to plug-in and start developing.

Choose from a wide selection of interface options or talk to our experts to select the best one for your project. We can incorporate HDMI, USB, SPI, VGA and more into your display to achieve your design goals.

Equip your display with a custom cut cover glass to improve durability. Choose from a variety of cover glass thicknesses and get optical bonding to protect against moisture and debris.

Announced in the end of October 2011, the BeagleBone is a barebone development board with a Sitara ARM Cortex-A8 processor running at 720 MHz, 256 MB of RAM, two 46-pin expansion connectors, on-chip Ethernet, a microSD slot, and a USB host port and multipurpose device port which includes low-level serial control and JTAG hardware debug connections, so no JTAG emulator is required. The BeagleBone was initially priced at US$89.

A number of BeagleBone "Capes" have recently been released. These capes are expansion boards which can be stacked onto the BeagleBone Board (up to four at one time). BeagleBone capes include but are not limited to:

Launched on April 23, 2013, at a price of $45. Among other differences, it increases RAM to 512 MB, it increases the processor clock to 1 GHz, and it adds HDMI and 2 GB of eMMC flash memory. The BeagleBone Black also ships with Linux kernel 3.8, upgraded from the original BeagleBone"s Linux kernel 3.2, allowing the BeagleBone Black to take advantage of Direct Rendering Manager (DRM).

BeagleBone Black Revision C (released in 2014) increased the size of the flash memory to 4 GB. This enables it to ship with Debian GNU/Linux installed. Previous revisions shipped with Ångström Linux.

Launched in September 2017, PocketBeagle offers identical computing performance to BeagleBone Black in a physical form factor that offers over 50% reduction in size and 75% reduction in weight, along with over 40% cheaper purchase price (December 2018 MSRP US$25 vs. US$45 for BeagleBone Black). The miniaturization was made possible by using the Octavo Systems OSD3358-SM that shrinks all major subsystems of the BeagleBone Black into a single ceramic package attached using ball grid array. The advantages of the miniaturization come at the cost of removal of all built-in connectors except for a single micro USB port, the removal of on-board eMMC flash storage, and a reduction of header pins from 92 down to 72 due to space constraints, meaning that most capes will either not work at all or need heavy modifications to work with PocketBeagle. Just as the BeagleBone Black"s printed circuit board (PCB) is cut to fit snugly in an Altoids mint tin, PocketBeagle"s PCB is cut to fit snugly in an Altoids Smalls mint tin. Recommended use cases for PocketBeagle include embedded devices where size and weight considerations are most critical, such as quadcopter drones and other miniaturized robotics, along with handheld gaming applications.
