※Price Increase NotificationThe TFT glass cell makers such as Tianma,Hanstar,BOE,Innolux has reduced or stopped the production of small and medium-sized tft glass cell from August-2020 due to the low profit and focus on the size of LCD TV,Tablet PC and Smart Phone .It results the glass cell price in the market is extremely high,and the same situation happens in IC industry.We deeply regret that rapidly rising costs for glass cell and controller IC necessitate our raising the price of tft display.We have made every attempt to avoid the increase, we could accept no profit from the beginning,but the price is going up frequently ,we"re now losing a lot of money. We have no choice if we want to survive. There is no certain answer for when the price would go back to the normal.We guess it will take at least 6 months until these glass cell and semiconductor manufacturing companies recover the production schedule. (Mar-03-2021)

ER-TFTV043A3-3 is 480x272 pixel 4.3 inch color tft lcd display for the Raspberry Pi with optional USB port resistive or capacitive touch panel screen,optional USB cable and HDMI cable. Of course ,it is not limited to the Raspberry Pi ,it can be used for all the universal HDMI port hardwares such as mini PCs, Raspberry Pi, BB Black, Banana Pi, as well as general desktop computers.

ER-TFTM070-7 is 800x480 Pixels 7 inch color tft lcd display module with LT7683 controller board,superior display quality and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO, and ARM .It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.

It supports 8080 6800 8-bit,16-bit parallel,3-wire,4-wire,I2C serial spi interface.Built-in MicroSD card slot.It"s optional for resistive touch panel and controller XPT2046,capacitive touch panel and controller FT5316, flash chip and microsd card. We offer two types connection,one is pinheader and the another is ZIF connector with flat cable mounting on board by default and suggested.

A simple 7.0″ High Brightness / Sunlight Readable IPS Module with  HDMI / USB interface, Transmissive / All Viewing Direction / Normal Black with 1024 x (RGB) x 600 dots.

If none of these part numbers meet your requirements in terms of brightness, interface, or connection method, please email us at info@orientdisplay.com.

A simple 5.0″ High Brightness / Sunlight Readable IPS Module with VGA / HDMI / USB interface, Transmissive / All Viewing Direction / Normal Black with 800 x (RGB) x 480 dots.

If none of these part numbers meet your requirements in terms of brightness, interface, or connection method, please email us at info@orientdisplay.com.

Looking for a SPI TFT display? Need a perfectly small SPI TFT for your next Arduino project? Check out our line of full-color SPI TFT LCD modules. Our SPI TFT displays are between 2 and 3.5 inch.

Displays much larger than 3.5 inches or with higher resolutions aren"t usually driven via SPI because it"s not fast enough to provide good frame rates for larger displays. But for small TFT displays, SPI is a perfectly suited interface.

The LCD1U17-05 features a choice of 17" TFT display, keyboard, and pointing device (touchpad or trackball) integrated into one rack unit (1.75"). The display is a TFT active matrix LCD which offers a wide viewing angle, and has Sunlight LCD and contrast ratios. The display does not require special proprietary LCD peripheral cards or drivers. It connects directly to a standard VGA connector and automatically switches to the corresponding VGA mode. A Lexan shield provides protection of the LCD screen from foreign materials. During operation, the unit can be withdrawn from the rack to raise the display and then pushed back half way into the rack to minimize space usage.

1U Rack-mount 17" LCD Monitor Keyboard Drawer with Cherry keyboard & touchpad mouse in PS2 interface, black

1U Rack-mount 17" LCD Monitor Keyboard Drawer with Cherry keyboard & touchpad mouse in PS2 interface, light gray

1U Rack-mount 17" LCD Monitor Keyboard Drawer with Cherry keyboard & touchpad mouse in USB interface, black

1U Rack-mount 17" LCD Monitor Keyboard Drawer with Solidtek keyboard & touchpad mouse, in PS2 interface black

1U Rack-mount 17" LCD Monitor Keyboard Drawer with Solidtek keyboard & touchpad mouse in PS2 interface, light gray

1U Rack-mount 17" LCD Monitor Keyboard Drawer with Solidtek keyboard & touchpad mouse, in PS2 interface black

The HTT Displays are plug and play Embedded HDMI HMI TFT display with a USB touch screen interface. The resistive, capacitive, or non-touch modules are compatible with a wide range of systems including: Raspberry Pi, Windows, Linux, Asus Tinker Board and BeagleBone. From the hobbyist to the high volume industrial application, the HTT Series was designed to satisfy a wide range of customer application requirements.

You must of by now seen our incredible 12.3 inch TFT with wide temperature range, incredible resolution and more making it perfect for automation applications.

As the first in the world we do provide TFT displays with 3.2", 4.3" and 7", which are immediately running and do provide from the first minute the full functionality. These displays do require a single supply 5V= (EA eDIPTFT32: 5V= or 3.3V=) and an interface RS-232, I²C or SPI only.

Like all EA DIP modules, the EA eDIPTFT displays are simply inserted in the PCB and soldered in place. No screws, distance sleeves or cables are required, thus saves material cost and simplifies construction. This results in a saving of between 2 and 4 minutes per module during assembly!

For a standard screw mounting (e.g. together with the optional mounting bezel), the displays do come with 2 additional mounting clips for easy screw mounting.Communication via serial interface (RS-232, I²C, SPI)

Additionally to the well-proved versions with a resistive touch panel currently we do provide 2 displays with 4.3" and 7" alternatively equipped with a capacitive touch panel: EA eDIPTFT43-ATC (4.3") and EA eDIPTFT70-ATC (7").

The advantage is more transperency that leads for both sizes to again more brightness and a very contrasty display. The surface is made of glass which is hard profen against scratch, it is hygienic and resistant against all cleaning stuff. The design with its black frame grants your equipment a valuable, modern optic.

An essential detail with industrial applications ist the usability with and without hand gloves. Even when the display is put behind a 3mm glass plate it may be operated perfectly.Technology

With an extended standard temperature range of -20..+70 °C, rapid response times are guaranteed down to -20 °C. Even the essential temperature compensation is already built-in. The displays are designed for +5V single-supply operation (EA eDIPTFT32-A: 3.3~5V=).Getting started

Brand new are our graphic capability OLED displays with USB connection and integrated touchpanel. The are good for wholesome control unit or as a display only.

In addition to some serial interfaces like RS-232, SPI and I²C there are some digital and analoge in- and outputs also. With the use of those some simple control actions with fixed display content can be realized. Currently there are 2 sizes available with 2.9" and 82x67x21mm same as 1.7" with 55x54x21mm.

Our serial devices are a dot-matrix LCD series of products that are ready for operation with a driver and a bezel or a snap-in housing. They are connected to a standard RS-232C interface (or, optionally, an RS-422). The data transmission rate can be set to 300, 1,200, 2,400 or 9,600 bps. All cursor control (line feed etc.) is automatic. The displays are equipped with LED lighting that can be switched off by software means.

DISPLAY VISIONS offers 3 LCD graphics displays in different sizes in a snap-in housing: EA KIT120, KIT128 and KIT160. 3 further sizes are available with an anodized mounting panel in black or blue: EA KIT240-6, KIT240-7 and KIT320-8. They are controlled via either an RS-232 or an RS-422 interface.

A range of integrated fonts and graphics commands make it easy to program these displays: All functions are programmed with pixel accuracy by means of x/y coordinates (e.g. draw straight line: ESC G x1 y1 x2 y2). All displays are also available with an integrated touch panel: This allows you to make entries or change the contents of the screen by touching it.

LCD graphics units are intelligent graphics displays with a serial RS-232 interface. Two or three integrated character sets and a wide range of graphics functions permit the time- and cost-saving use of the latest LCD graphics displays. Apart from a supply voltage of +5V and RS-232 data, no further signals are required. No additional software or special drivers are required for their operation. All the graphics routines are integrated in the display"s in-built high-level graphics controller. This permits the creation of a clear and attractive display using only a few commands. All functions are positioned with pixel accuracy by means of x/y coordinates (e.g. draw straight line: G x1 y1 x2 y2).
