There are many kinds of LCD interfaces, with wide range of applications. The classification criteria mainly depends on the driving mode and control mode of the LCD. At present, there are generally several connection modes for color LCDs on mobile phones: MCU mode, RGB mode, SPI mode, VSYNC mode, MDDI mode, DSI mode, etc. and only the TFT module has RGB interface.

It is mainly used in the field of single-chip microcomputers. Later, it is widely used in low-end mobile phones, and its main feature is that it is cheap. The standard term for the MCU-LCD interface is the 8080 bus standard proposed by Intel.

Therefore, 8080 is used to refer to the MCU-LCD screen in many documents. It can be mainly divided into 8080 mode and 6800 mode, and the difference between the two is mainly the timing. There are 8 bits, 9 bits, 16 bits, 18 bits, and 24 bits for data bit transfer. Connections are divided into: CS/, RS (register selection), RD/, WR/, and data lines. The advantages are: the control is simple and convenient, no clock and synchronization signals are required. The disadvantage is: it consumes GRAM, so it is difficult to achieve a large screen (above 3.8). For LCM with MCU interface, the internal chip is called LCD driver. The main function is to transform the data/command sent by the host into the RGB data of each pixel, so that it can be displayed on the screen. This process does not require point, line, frame clocks.

The LCD Driver IC of the MCU interface is equipped with GRAM. As a co-processor of the MCU, it accepts the Command/Data sent by the MCU and can work relatively independently. Pay attention to, the internal chip of LCD Module (LCM) is called the LCD driver. The main function is to transform the data/commands sent by the host computer into the RGB data of each pixel, so that it can be displayed on the screen. This process also does not require point, line, frame clocks.

In fact, this mode is to add a VSYNC signal to the MCU mode and applied to the update of the moving picture, which is very different from the above interface. This mode supports the function of direct animation display. It provides a solution for animation display with minimal changes to the MCU interface. In this mode, the internal display operation is synchronized with the external VSYNC signal. Animation display at a higher rate than internal operations can be achieved. However, due to the difference in its operation mode, this mode has a limit on the speed, that is, the write speed to the internal SRAM must be greater than the speed of the display read internal SRAM.

The large screen adopts more modes, and the data bit transmission also has the 6-, 16- and 18-, 24-bit. The connections are generally: VSYNC, HSYNC, DOTCLK, CS, RESET, some also need RS, and the rest is the data line. Its advantages and disadvantages are just the opposite of MCU mode. The main difference between the MCU-LCD screen and the RGB-LCD screen is the location of the video memory. The video memory of RGB-LCD is acted by system memory, so its size is only limited by the size of system memory. Where RGB-LCD can be made larger, such as 4.3" can only be regarded as entry-level, and 7" in MID, 10" screens have begun to be widely used. At the beginning of the design of MCU-LCD, it was only necessary to consider that the memory of the single-chip microcomputer was small, so the video memory was built into the LCD module, and then the software updated the video memory through special display commands with small MCU screen. At the same time, the display update speed is slower than RGB-LCD. The display data transmission mode is also different. RGB screen only needs to organize the data in the video memory. After starting the display, the LCD-DMA will automatically transfer the data in the video memory through the RGB interface to the LCM, while the MCU screen needs to send a drawing command to modify the internal RAM of the MCU (that is, the RAM of the MCU screen cannot be directly written).

Therefore, the RGB display speed is significantly faster than that of the MCU, and the MCU-LCD is also slower in terms of video playback. For the LCM of the RGB interface, the host directly outputs the RGB data of each pixel without conversion (except for GAMMA correction, etc.). For this interface, an LCD controller is required in the host part to generate RGB data and sync signals.

Here gives a note. The color TFT LCD screen mainly has 2 kinds of interfaces: TTL interface (RGB color interface), and LVDS interface (differential signal transmission). The TTL interface is mainly used for small-sized TFT screens below 12.1 inches, and the LVDS interface is mainly used for large-sized TFT screens above 8 inches. The TTL interface has many lines and the transmission distance is short, while the LVDS interface has a long transmission distance and a small number of lines. The large screen adopts more modes, the control pins are VSYNC, HSYNC, VDEN, VCLK, S3C2440 supports up to 24 data pins, and the data pin is VD[23-0].

The image data sent by the CPU or graphics card is a TTL signal (0-5V, 0-3.3V, 0-2.5V, or 0-1.8V), and the LCD itself also receives a TTL signal, which is transmitted at a high rate over long distances. However, its performance is poor, and the anti-interference ability is relatively poor. With the time goes by, a variety of transmission modes were proposed, such as LVDS, TDMS, GVIF, P&D, DVI and DFP. They actually just encode the TTL signal sent by the CPU or graphics card into various signals for transmission, and decode the received signal on the LCD side to obtain the TTL signal. No matter what transmission mode is used, the essential TTL signal is the same. Note: TTL/LVDS are two signal transmission modes: TTL is a mode in which high level means 1, and low level means 0; LVDS is the difference of a positive and negative corresponding waveform used to indicate the 1 or 0.

Qualcomm"s MDDI, which can improve the reliability of mobile phones and reduce power consumption by reducing wiring. It will replace SPI mode as a high-speed serial interface in the mobile field.

2) When using the MCU mode, since the data can be stored in the IC"s internal GRAM first and then written to the screen, the LCD in this mode can be directly connected to the memory bus. It is different when using RGB mode, and has no internal RAM, HSYNC, VSYNC, ENABLE, CS, RESET, RS can be directly connected to the GPIO port of memory, and use the GPIO port to simulate waveforms.

RGB interface mode: The display data is not written into DDRAM, but directly written to the screen, which is fast and often used to display video or animation.

The commonly used interfaces of TFT-LCD, including TTL (RGB), LVDS, EDP, and MIPI. Here roughly talk about the basic principles of the signal composition of these interfaces.

The TTL interface is an interface for transmitting data in parallel. When using it, it is not necessary to use a dedicated interface circuit at the driver board end and the LCD panel end of the liquid crystal display, but the TTL data signal output by the main control chip of the driver board is transmitted through the cable. It is directly transmitted to the input interface of the LCD panel. Due to the high signal voltage, many connections and long transmission cables of the TTL interface, the anti-interference ability of the circuit is relatively poor, and it is easy to generate electromagnetic interference (EMI). In practical applications, TTL interface circuits are mostly used to drive small-size (below 15in) or low-resolution LCD panels. The highest pixel clock of TTL is only 28MHz.

The TTL output interface of the driver board generally includes three types of signals: RGB data signal, clock signal and control signal. As shown below:

As for it, there are 18 RGB data lines in total, including 6 R0~R5 red primary color data lines, 6 G0~G5 green primary color data lines, 6 B0~B5 blue primary color data lines, a total of 18 strips. Since the primary color RGB data is 18bit, it is also called 18-bitTTL interface.

For it, there are a total of 24 RGB data lines, including 8 R0~R7 red primary color data lines, 8 B0~B7 green primary color data lines, 8 BO~B7 blue primary color data lines, a total of 24 strips. Since the primary color RGB data is 24-bit, it is also called 24-bit TTL interface.

It has 36 RGB data lines in total, including 18 odd RGB data lines, 18 even RGB data lines. Since the primary color ROB data is 36-bit, it is also called 36-bitTTL interface.

It has 48 RGB data lines, including 24 odd RGB data lines and 24 even RGB data lines. Since the primary color RGB data is 48bit, it is also called 48-bit TTL interface.

It refers to the pixel clock signal, which is the benchmark for transmitting data and reading the data signal. When using odd/even pixel dual way to transmit RGB data, different output interfaces use different methods of pixel clock. Some output interface odd/even pixel dual data share a pixel clock signal, and the others set odd pixel data clock and even pixel two clock signals to meet the needs of different LCD panels.

LVDS is a low-voltage differential signaling technology interface. A digital video signal transmission method developed to overcome the shortcomings of large power consumption and large EMI electromagnetic interference when transmitting broadband high bit rate data in TTL level mode. The LVDS output interface uses a very low voltage swing (about 350mV) to transmit data differentially on two PCB traces or a pair of balanced cables, that is, low-voltage differential signaling. Using the LVDS output interface, the signal can be transmitted at a rate of several hundred Mbit/s on the differential PCB line or balanced cable. Due to the low-voltage and low-current driving method, low noise and low power consumption are achieved.

In a liquid crystal display, the LVDS interface circuit includes two parts, the LVDS output interface circuit (LVDS transmitter) on the motherboard side and the LVDS input interface circuit (LVDS receiver) on the LCD panel side. The LVDS emitter converts the TTL signal into an LVDS signal, and then transmits the signal to the LVDS decoding IC on the receiving end through the flexible cable (line) between the driver board and the LCD panel, and the LVDS receiver then serializes the serial signal which is converted into a parallel signal of TTL level, and sent to the LCD screen timing control and row and column drive circuit. In other words, TFT only recognizes TTL (RGB) signals.

When LVDS transmits data with higher resolution, the anti-interference ability is relatively strong. But when the resolution is higher than 1920×1080, the single channel is overwhelmed, so there is a dual interface. Its purpose is very simple, speed up and enhance anti-interference ability.

EDP is a communication interface of the computer display screen. The resolution of the computer using the EDP display interface will be higher than that of the LVDS interface. Generally, high-definition screens use this communication interface. It is a fully digital interface based on the DisplayPort architecture and protocol. It can transmit high-resolution signals with simpler connectors and fewer pins, and can achieve simultaneous transmission of multiple data, so the transmission rate is much higher than LVDS.

Compared with the LVDS interface, the MIPI interface is rare, but in fact, it has many advantages. The MIPI interface module has the advantages of high speed, large amount of data transmission, low power consumption, and good anti-interference when compared with the parallel port. It is more and more favored by customers and is growing rapidly. For example, an 8M module with both MIPI and parallel port transmission requires at least 11 transmission lines and an output clock of up to 96M to achieve a full pixel output of 12FPS when using an 8-bit parallel port. Channel 6 transmission lines can achieve a frame rate of 12FPS at full pixels, and the current consumption will be about 20MA lower than that of parallel port transmission. Since MIPI uses differential signal transmission, the design needs to be strictly designed according to the general rules of differential design. The key is to achieve differential impedance matching. The MIPI protocol stipulates that the differential impedance of the transmission line is 80-125 ohms.

16x2 LCD means that there are two rows in which 16 characters can be displayed per line, and each character takes 5X7 matrix space on LCD. ... In this tutorial we are going to connect 16X2 LCD module to the 8051 microcontroller (AT89S52).

LCD Displays that use a parallel interface include Character, Graphic and TFT. ... The initial step is to energize the LCD. Reads and Writes are sent via 8 data lines and 3 control lines. These control lines are Read/Write (R/W), Enable (E) and Register Select (RS).

A TFT LCD display module consists of a TFT LCD panel, one or more COG (chip-on-glass) or COB (chip-on-board) driver ICs, a backlight, and an interface. Several TFT display interface technologies exist today. Picking the right interface depends on specific end-product concerns.

The MCU interface hastwo standard types, theIntel-8080 and Motorolla-6800 series. These interfaces communicate through read, write and chip-select signals to address registers or display RAM. The slight difference between the two pertains to the direction and separation of the write and read signals.

These interfaces communicate through read, write and chip-select signals to address registers or display RAM. Depending on color depth (8, 9, 16 or 18-bit), MCU sends RGB signals directly to LCM"s display memory.

TFT is a kind of LCD. The TFT(Thin Film Field-effect Transistor) is a video in which every single pixel in the liquid crystal display is actuated by a Thin Film Transistor embedded in the rear. Thus can achieve high speed, high brightness, high contrast display screen information.

Display size, contrast, color, brightness, resolution, and power are key factors in choosing the right display technology for your application. However, making the right choice in how you feed the information to the display is just as vital, and there are many interface options available.

All displays work in a similar manner. In a very basic explanation, they all have many rows and columns of pixels driven by a controller that communicates with each pixel to emit the brightness and color needed to make up the transmitted image. In some devices, the pixels are diodes that light up when current flows (PMOLEDs and AMOLEDs), and in other electronics, the pixel acts as a shutter to let some of the light from a backlight visible. In all cases, a memory array stores the image information that travels to the display through an interface.

According to Wikipedia, "an interface is a shared boundary across which two separate components of a computer system exchange information. The exchange can be between software, computer hardware, peripheral devices, humans, and combinations of these. Some computer hardware devices such as a touchscreen can both send and receive data through the interface, while others such as a mouse or microphone may only provide an interface to send data to a given system.” In other words, an interface is something that facilitates communication between two objects. Although display interfaces serve a similar purpose, how that communication occurs varies widely.

Serial Peripheral Interface (SPI) is a synchronous serial communication interface best-suited for short distances. It was developed by Motorola for components to share data such as flash memory, sensors, Real-Time Clocks, analog-to-digital converters, and more. Because there is no protocol overhead, the transmission runs at relatively high speeds. SPI runs on one master (the side that generates the clock) with one or more slaves, usually the devices outside the central processor. One drawback of SPI is the number of pins required between devices. Each slave added to the master/slave system needs an additional chip select I/O pin on the master. SPI is a great option for small, low-resolution displays including PMOLEDs and smaller LCDs.

Philips Semiconductors invented I2C (Inter-integrated Circuit) or I-squared-C in 1982. It utilizes a multi-master, multi-slave, single-ended, serial computer bus system. Engineers developed I2C for simple peripherals on PCs, like keyboards and mice to then later apply it to displays. Like SPI, it only works for short distances within a device and uses an asynchronous serial port. What sets I2C apart from SPI is that it can support up to 1008 slaves and only requires two wires, serial clock (SCL), and serial data (SDA). Like SPI, I2C also works well with PMOLEDs and smaller LCDs. Many display systems transfer the touch sensor data through I2C.

RGB is used to interface with large color displays. It sends 8 bits of data for each of the three colors, Red Green, and Blue every clock cycle. Since there are 24 bits of data transmitted every clock cycle, at clock rates up to 50 MHz, this interface can drive much larger displays at video frame rates of 60Hz and up.

Low-Voltage Differential Signaling (LVDS) was developed in 1994 and is a popular choice for large LCDs and peripherals in need of high bandwidth, like high-definition graphics and fast frame rates. It is a great solution because of its high speed of data transmission while using low voltage. Two wires carry the signal,  with one wire carrying the exact inverse of its companion. The electric field generated by one wire is neatly concealed by the other, creating much less interference to nearby wireless systems. At the receiver end, a circuit reads the difference (hence the "differential" in the name) in voltage between the wires. As a result, this scheme doesn’t generate noise or gets its signals scrambled by external noise. The interface consists of four, six, or eight pairs of wires, plus a pair carrying the clock and some ground wires. 24-bit color information at the transmitter end is converted to serial information, transmitted quickly over these pairs of cables, then converted back to 24-bit parallel in the receiver, resulting in an interface that is very fast to handle large displays and is very immune to interference.

Mobile Industry Processor Interface (MIPI) is a newer technology that is managed by the MIPI Alliance and has become a popular choice among wearable and mobile developers. MIPI uses similar differential signaling to LVDS by using a clock pair and one to eight pairs of data called lanes. MIPI supports a complex protocol that allows high speed and low power modes, as well as the ability to read data back from the display at lower rates. There are several versions of MIPI for different applications, MIPI DSI being the one for displays.
