This note will discuss the operating and storage temperatures for LCDs. Each LCD has a specified operating and storage temperature listed in the specification sheet of the display and its controller. Typically, this temperature is specified as -20°C to 70°C for the operating temperature and -30°C to 80°C for the storage temperature. Considerations should be made when operating or storing the display near the maximum and minimum temperatures.

The environment a display is operated and stored in can have effects on things such as: voltage, contrast, signal integrity, and system performance. The effects of temperature on the display become more significant at the two extremes. Common display temperature ranges can be found as three common sets. Below are the three most common temperature ranges for LCDs. The temperature ranges can be confirmed in the datasheet of the display and its controller.

At very high temperatures, the effects can be seen on the electronic components and the liquid crystal of the display. The effects from an environment that is too hot will cause a darkening of the display, decreased/limited visibility, unreliable communications, and potential damage to the IC due to increased conductivity. The liquid crystal in the display will begin to degrade at very high temperatures. Overheating the display can cause dark spots to appear or result in a fully dark screen.

Both internal and external heat should be taken into consideration when operating the display. The environmental heat can contribute to overheating the device internally. The most common source of internal heat generation is from the backlight. The backlights can operate at high voltages and current consumptions to supply power to the backlight LEDs. This internal heat generation should be considered in high temperature environments.

To prevent internal and external overheating, fans and vents can be incorporated into the system to keep the display within the specified operating conditions. Precautions to avoid moisture entering the system should be taken when including vents. Moisture can cause electrical shorting, especially at high operating temperatures.

Contrast can be affected when a display is operated in ultra-high temperatures. Higher temperatures result in an increase in conductivity. This means that less voltage is required to provide the same contrast to the pixels. These effects can become more prominent when using graphic or character LCDs. Undesired effects such as a black screen can occur if the operating environment is above the specified temperature range.

Different liquid crystal fluid has different temperature properties. Extreme temperature liquid crystal exists for certain applications but can be more expensive. Twisted nematic (TN) LCD’s have the temperature ranges listed in this note.

Semiconductors operating in very low temperatures will have decreased conductivity due to increased resistance. The LCD controller, often incorporated on the glass of the LCD, will operate at lower speeds in very cold environments.

Buyers and others who are developing systems that incorporate FocusLCDs products (collectively, “Designers”) understand and agree that Designers remain responsible for using their independent analysis, evaluation and judgment in designing their applications and that Designers have full and exclusive responsibility to assure the safety of Designers" applications and compliance of their applications (and of all FocusLCDs products used in or for Designers’ applications) with all applicable regulations, laws and other applicable requirements.

Designer agrees that prior to using or distributing any applications that include FocusLCDs products, Designer will thoroughly test such applications and the functionality of such FocusLCDs products as used in such applications.

Liquid crystal displays (LCD) have become an essential component to the industry of display technology. Involved in a variety of contexts beyond the indoors like LCD TVs and home/office automation devices, the LCD has expanded its usage to many environments, such as cars and digital signage, and, thus, many temperature variations as well.

As with any substance that requires a specific molecular characteristic or behavior, LCDs have an operating temperature range in which the device, if within, can continue to function properly and well. In addition to that, there is also an ideal storage temperature range to preserve the device until used.

This operating temperature range affects the electronic portion within the device, seen as falling outside the range can cause LCD technology to overheat in hot temperatures or slow down in the cold. As for the liquid crystal layer, it can deteriorate if put in high heat, rendering it and the display itself defective.

In order for the LCD panel to avoid defects, a standard commercial LCD’s operation range and storage range should be kept in mind. Without adaptive features, a typical LCD TV has an operating range from its cold limit of 0°C (32°F) to its heat limit of 50°C (122°F) (other LCD devices’ ranges may vary a bit from these numbers).

The storage range is a bit wider, from -20°C (-4°F) to 60°C (140°F). Though these ranges are quite reasonable for many indoor and even outdoor areas, there are also quite a few regions where temperatures can drop below 0°C or rise above 32°C, and in these conditions, LCDs must be adapted to ensure functionality.

Heat, can greatly affect the electronics and liquid crystals under an LCD screen. In consideration of heat, both external heat and internally generated heat must be taken into consideration.

Seen as the liquid crystals are manipulated in a device by altering their orientations and alignments, heat can disrupt this by randomizing what is meant to be controlled. If this happens, the LCD electronics cannot command a certain formation of the liquid crystal layer under a pixel, and the LED backlighting will not pass through as expected, which can often lead to dark spots, if not an entirely dark image. This inevitably disrupts the display’s readability.

Depending on the upper limit of the operation temperature range, LCD device can be permanently damaged by extreme heat. With long exposure to extreme heat, besides the destruction of the liquid crystals, battery life can shorten, hardware can crack or even melt, response time may slow to prevent even more heat generation from the device.

The LED backlight and the internal circuitry, typically TFT-based in the common TFT LCDs, are components that can generate heat that damages the device and its display. To address this concern with overheating, many devices use cooling fans paired with vents.

In the opposite direction is extreme cold. What typically occurs in the cold is “ghosting” (the burning of an image in the screen through discoloration) and the gradual slowing and lagging of response times. Like heat-affected LCD modules, the extreme temperature can affect the liquid crystals. This layer is a medium between the liquid and solid state, so it is still susceptible to freezing.

An LCD device can be left in freezing temperatures because it will likely not be permanently damaged like in the heat, but it is important to understand the device’s limits and how to take precautions when storing the device. The standard and most common lower-bound storage range limit is -20°C, below freezing, but if possible, it would be best to keep it above that limit, or else there is still a risk of permanent damage.

If the device is not adapted for the cold, it would be good to keep it bundled up, trapping the heat within layers. However, this is only a temporary solution. Adapted, rugged devices have advantages such as screen enclosure insulation for heat level preservation and, in more extreme cases, heaters to generate extra heat to raise the internal temperature to a level above the minimum.

Display types have a lot of variation. Choices like alphanumeric or graphic LCD, human-machine interactive LCD modules and touchscreen panels capabilities, the width of the viewing angle, level of contrast ratios, types of backlighting, and liquid crystal alignment methods are often considered. For example, the twisted nematic LCD provides for the fastest response time at the lowest cost, but cannot offer the highest contrast ratio or widest viewing angle.

Environment-based factors must consider things besides the obvious temperature like UV exposure and humidity/moisture, as they all are necessary in finding the perfect fit extreme temperature LCD module.

Besides the LCD modules, recent new products have opened doors in wide temperature range displays, such as OLED displays. OLED displays offer better displays in regard to contrast, brightness, response times, viewing angles, and even power consumption in comparison to traditional LCD displays.

Has anyone else experienced LCD screens overheating, and drawing too much current? I was trying a GPIO project with my Raspberry Pi in an attempt to interface with an LCD screen but for some reason my PI"s OS shuts down while the black dots on the back quickly begins to boil (I"m guessing these black dots are heat sinks), and on top of that no characters display (thanks to my Pi being knocked out).

I know my pinouts are all correct as I used another LCD that worked great. I"m using two of the generic Hitachi HD44780s for this project, but they"re from different kits.

This happens when I connect my ribbon cable up to the Pi (the ribbon cable facilitates the wiring for the GPS), otherwise I can"t start my Pi. What I"ve been doing is starting with my ribbon cable disconnected, boot up, and then I try plugging everything back into my Pi. Of course this just leads to the power being sucked up, crashing everything, and heating up the LCD. I"m also not powering the backlight, so that doesn"t seem to be source of the problem.

Im on my third screen in a a year and yes this one began doing it again. The first screen a "burn" line appeared in the middle of the screen. Apple replaced it. The next screen started "burning" within a month. That one looked like hand prints and finger prints. Apple replaced the screen. Now this screen I hav had for a month and

I have done everything I can to keep the heat low on this machine because that was what I thought the problem was. I dont use the cool screen saver, I let the computer cool down before it sleeps. The moniter turns off in 5 minutes if I"m not using it. I have the brightness on the lowest setting. And i moniter the heat sensors with the tech tool program. If the cpu gets to hot I stop using it.

Is your projector overheating? This is a common projection concern and complication; there are several key factors to consider as to why your projector is currently or may overheat. Projectors are highly sophisticated electronic devices that have come so far in the last 10 years and even further everyday it seems; with projector companies out performing each other and lowering costs, increasing features and usability.

However one fact still remains – projectors run hot; 98% of projectors on the market ( LCD, DLP, etc. ) currently use traditional lamps and bulbs as their light engine. These bulbs produce a tremendous amount of heat and can easily reach temperatures of 200-300 degrees while in operation. It is very critical that you maintain a clear space around the projector so that you do not restrict or even limit the airflow into the projector or there is a very good chance your projector will keep overheating. Projectors require two very important basic needs; steady supply of fresh clean power and air supply.

Power is the easy one of the two requirements and is easily obtain more often than not; however there have been several recent studies that have shown an increase in premature projector failure due to improper power supply. Inconsistent power that is not stable or clean to the projector resulting in drastically reduced bulb life and the projector overheating. This can easily be solved in most cases with an accessory item that will clean up that dirty power and provide consistent clean power to your projector.

Clean Fresh Air is the second requirement because without the power you won’t need the air; however without the fresh clean air your projector can literally be overheating and shutdown in as little as a minute or two. Projector bulbs operate at extremely hot temperatures and must be kept cool to avoid overheating which will cause one of two things to happen; the projector overheating will shut down unexpectedly and if this is a consistent problem will cause the bulb to physically explode. How can you avoid this situation or even eliminate the possibility all together?

Be sure to keep the area around the projector clean and free from clutter and any items piled around it; the fans in the projector are specifically designed to cool that unit at its operating temperatures. If you restrict or block airflow the airflow sometimes even in the least bit it will result in overheating and an unplanned shutdown, warning message or premature bulb failure.

I have recently replaced the screen of my iPhone 6 with a cheap replacement part from AliExpress (it had good reviews). First thing I noticed is that the phone is now a bit thicker but in a shop I was explained that this can happen with replacement parts (I wasn’t aware of that). No biggie, I can live with that. More problematic is that the battery drains super quick (it barely charges while switched on) and the top-right corner of the device (looking from the front) becomes very hot. I read in another thread that it could be a problem with a flex cable so I went to a shop to get it checked. They confirmed the problem and supposedly replaced the flex cable but the phone still gets very hot and so they said they can’t help me because it could be a broken mainboard (according to them). Now I have this phone lying around and I don’t know how to proceed. What would you suggest me? Are there ways to identify what exactly the problem could be? Any help is appreciated.

If you’re worried about heat damage or live in an area where extreme temperatures are prevalent, consider exploring a custom solution. Manufacturers can often create screen enclosures complete with fans or an internal heating unit. Each of these elements helps air circulate within the displays, thus stabilizing the internal temperature. Some custom work can protect devices from temperatures ranging anywhere from -22 degrees to 131 degrees Fahrenheit. Thermal management technology is an ideal safeguard for when temperatures fall outside of the optimal operating zone.

Whether outside or indoors, protecting your displays from direct sunlight is crucial. Direct sunlight will not only increase a device’s overall temperature, but it can also create specific hotspots. Hotspots refer to areas of high heat that can lead to permanent scarring of the LCD, LED or plasma screen. In LCD screens specifically, direct sunlight can cause the Liquid Crystal cells inside the display to boil, leaving behind a black spot. This phenomenon is known as solar clearing. If the LCD screen overheats, it can also lead to isotropic failure, and you may need to replace the device. Position digital signage out of direct sunlight, whenever possible. Whether inside a custom screen enclosure or under a tent or awning, this tactic will extend the life of your device. At least very least, provide proper airflow to keep the displays cool and functioning properly.

Sunlight also creates a problem from a user experience perspective. Direct sunlight can obstruct the display, making it hard to view what is on the screen—whether it’s a food and drink menu or advertisement. By installing anti-glare glass, you’ll improve your customers’ experiences and ensure they see what you want to show them.

Anti-glare glass protects your screens, as well. They deflect the light, improving readability as well as keeping your digital displays cool. Do your research first, though, as some anti-glare displays will reduce visibility for people wearing polarized lenses.

The LCD pannel will survive fine, until it is left/put in direct sun, or put next to a space heater :-) or the conditions are not good for any electronics requiring cooling. any of the internal electronics can fail when not allowed to cool.

If all the capacitors look fine and you"ve gotten rid of all the dust and hair and the LCD screen is still overheating, the problem might be caused by the inverter or the transformer. The backlight uses direct current electricity, so the alternating current that comes out of your outlet needs to be inverted and then transformed to the right voltage level. Both of those components may overheat and then switch off, which would cause the backlight to stop working.

Point a fan at the back of your LCD screen while it"s running to see if the backlight stays on longer. If it does, then you know overheating is the issue. Inverters and transformers can sometimes be purchased aftermarket; if you"re comfortable installing small components you can replace them yourself. You can narrow down which one is overheating by using a small fan and pointing it at just one component at a time until you find the one that needs to be cooled. The part number is often listed on the part itself.
