Im on my third screen in a a year and yes this one began doing it again. The first screen a "burn" line appeared in the middle of the screen. Apple replaced it. The next screen started "burning" within a month. That one looked like hand prints and finger prints. Apple replaced the screen. Now this screen I hav had for a month and

I have done everything I can to keep the heat low on this machine because that was what I thought the problem was. I dont use the cool screen saver, I let the computer cool down before it sleeps. The moniter turns off in 5 minutes if I"m not using it. I have the brightness on the lowest setting. And i moniter the heat sensors with the tech tool program. If the cpu gets to hot I stop using it.

This note will discuss the operating and storage temperatures for LCDs. Each LCD has a specified operating and storage temperature listed in the specification sheet of the display and its controller. Typically, this temperature is specified as -20°C to 70°C for the operating temperature and -30°C to 80°C for the storage temperature. Considerations should be made when operating or storing the display near the maximum and minimum temperatures.

The environment a display is operated and stored in can have effects on things such as: voltage, contrast, signal integrity, and system performance. The effects of temperature on the display become more significant at the two extremes. Common display temperature ranges can be found as three common sets. Below are the three most common temperature ranges for LCDs. The temperature ranges can be confirmed in the datasheet of the display and its controller.

At very high temperatures, the effects can be seen on the electronic components and the liquid crystal of the display. The effects from an environment that is too hot will cause a darkening of the display, decreased/limited visibility, unreliable communications, and potential damage to the IC due to increased conductivity. The liquid crystal in the display will begin to degrade at very high temperatures. Overheating the display can cause dark spots to appear or result in a fully dark screen.

Both internal and external heat should be taken into consideration when operating the display. The environmental heat can contribute to overheating the device internally. The most common source of internal heat generation is from the backlight. The backlights can operate at high voltages and current consumptions to supply power to the backlight LEDs. This internal heat generation should be considered in high temperature environments.

To prevent internal and external overheating, fans and vents can be incorporated into the system to keep the display within the specified operating conditions. Precautions to avoid moisture entering the system should be taken when including vents. Moisture can cause electrical shorting, especially at high operating temperatures.

Contrast can be affected when a display is operated in ultra-high temperatures. Higher temperatures result in an increase in conductivity. This means that less voltage is required to provide the same contrast to the pixels. These effects can become more prominent when using graphic or character LCDs. Undesired effects such as a black screen can occur if the operating environment is above the specified temperature range.

Different liquid crystal fluid has different temperature properties. Extreme temperature liquid crystal exists for certain applications but can be more expensive. Twisted nematic (TN) LCD’s have the temperature ranges listed in this note.

Semiconductors operating in very low temperatures will have decreased conductivity due to increased resistance. The LCD controller, often incorporated on the glass of the LCD, will operate at lower speeds in very cold environments.

Buyers and others who are developing systems that incorporate FocusLCDs products (collectively, “Designers”) understand and agree that Designers remain responsible for using their independent analysis, evaluation and judgment in designing their applications and that Designers have full and exclusive responsibility to assure the safety of Designers" applications and compliance of their applications (and of all FocusLCDs products used in or for Designers’ applications) with all applicable regulations, laws and other applicable requirements.

Designer agrees that prior to using or distributing any applications that include FocusLCDs products, Designer will thoroughly test such applications and the functionality of such FocusLCDs products as used in such applications.

Modern LCD screens have a great many uses. Not only are they now the system of choice for our home TVs and computers but their use in digital signage has made them a common sight in many shopping malls, airports and other locations with high quantities of people.

Even outdoor locations are no barrier to the use of modern LCD screens with outdoor digital signage a rising medium now seen in many town centers, car parks, front of stores and train station platforms.

All this out of home use means many screens operate in locations test the temperature limits of LCD displays. While waterproof screens and LCD enclosures designed for rugged applications provide the ability of the screen to operate-even in outdoor locations, one consideration often overlooked, is that of temperature.

LCD screens have a limited temperature range. Not only will the electronics inside an TV screen overheat and cause failure if the screen gets too hot, but the liquid crystal itself will begin to deteriorate under hot conditions.

The same is true of environments where temperatures fall below zero, causing a screen to stop functioning. A typical LCD TV has an operating range between 0°C (32°F) and 32°C (90°F).

Of course, many indoor and outdoor locations don’t suffer temperatures outside of this range, but many locations do and placing screens in these areas can prove challenging.

One of the problems with using a screen in hot locations is that the screen itself produces quite a bit of heat. When housed in an outdoor enclosure, the heat has to be continuously removed. While cooling fans combined with an air-vent normally carry out this task on an LCD, the need to prevent moisture from getting to the screen makes the task more complicated.

To get around this problem, specially shaped vents provide an exit for hot air while preventing rainfall and other moisture from getting in. In some locations where ambient temperatures are extremely high, screens need air conditioning to ensure they don’t exceed the maximum operating temperature.

In cold climates the opposite problem occurs. The need to keep heat in often requires insulation of the screen enclosure. Often this can trap enough of the heat generated by the screen itself to keep the internal temperature above minimum, but in some locations, even this isn’t enough. Heaters, controlled by thermostats provide extra heat in these circumstances, which enables the use of LCD displays in extremely cold locations such as ski-resorts and in Arctic regions.

Has anyone else experienced LCD screens overheating, and drawing too much current? I was trying a GPIO project with my Raspberry Pi in an attempt to interface with an LCD screen but for some reason my PI"s OS shuts down while the black dots on the back quickly begins to boil (I"m guessing these black dots are heat sinks), and on top of that no characters display (thanks to my Pi being knocked out).

I know my pinouts are all correct as I used another LCD that worked great. I"m using two of the generic Hitachi HD44780s for this project, but they"re from different kits.

This happens when I connect my ribbon cable up to the Pi (the ribbon cable facilitates the wiring for the GPS), otherwise I can"t start my Pi. What I"ve been doing is starting with my ribbon cable disconnected, boot up, and then I try plugging everything back into my Pi. Of course this just leads to the power being sucked up, crashing everything, and heating up the LCD. I"m also not powering the backlight, so that doesn"t seem to be source of the problem.

LC displays (LCD) have a well-defined isotropic or operating temperature limit, above which the actual liquid crystal molecules will lose their orientation and will assume a random orientation instead of ‘twisting’ through the light valve.

The site goes on to note that temperatures above 100°C (212°F) can permanently damage the coating on LCD displays, though Samsung claims that storing your display at temperatures above 45°C (113°F) can damage it, so it"s possible that Vartech"s 100°C threshold is specifically a property of their ruggedized displays.

I have recently replaced the screen of my iPhone 6 with a cheap replacement part from AliExpress (it had good reviews). First thing I noticed is that the phone is now a bit thicker but in a shop I was explained that this can happen with replacement parts (I wasn’t aware of that). No biggie, I can live with that. More problematic is that the battery drains super quick (it barely charges while switched on) and the top-right corner of the device (looking from the front) becomes very hot. I read in another thread that it could be a problem with a flex cable so I went to a shop to get it checked. They confirmed the problem and supposedly replaced the flex cable but the phone still gets very hot and so they said they can’t help me because it could be a broken mainboard (according to them). Now I have this phone lying around and I don’t know how to proceed. What would you suggest me? Are there ways to identify what exactly the problem could be? Any help is appreciated.

Thanks for reaching Microsoft Community and taking the time posting your concerns. We are sorry to learn you experience heat-related issues issues with your Surface Pro 7 and also a diagonal crack on the screen. This is not the experience

The LCD pannel will survive fine, until it is left/put in direct sun, or put next to a space heater :-) or the conditions are not good for any electronics requiring cooling. any of the internal electronics can fail when not allowed to cool.

Unlike most desktop PCs, a laptop"s hardware components are in close proximity to each other with little room for air movement. Because they"re prone to overheating, watching for the signs of thermal stress and protecting the laptop"s fans from blockage protect your device against irreparable damage.

These issues could be from other causes, but they may point to an overheating issue, especially in combination with the laptop feeling more than warm.

If all the capacitors look fine and you"ve gotten rid of all the dust and hair and the LCD screen is still overheating, the problem might be caused by the inverter or the transformer. The backlight uses direct current electricity, so the alternating current that comes out of your outlet needs to be inverted and then transformed to the right voltage level. Both of those components may overheat and then switch off, which would cause the backlight to stop working.

Point a fan at the back of your LCD screen while it"s running to see if the backlight stays on longer. If it does, then you know overheating is the issue. Inverters and transformers can sometimes be purchased aftermarket; if you"re comfortable installing small components you can replace them yourself. You can narrow down which one is overheating by using a small fan and pointing it at just one component at a time until you find the one that needs to be cooled. The part number is often listed on the part itself.

Electronic devices suffer from temperature extremes. Liquid Crystal Displays (LCDs) of laptops, phones, and PDAs really do freeze. Laptops have been designed to work within a safe temperature range, typically between 50 to 95 degrees F (10 - 35 degrees C). This range refers to the optimal usage temperature of the outside environment and the temperature the laptop should be warmed to before using.

Do not boot up an LCD display device if you suspect the display is frozen. Don"t use heating pads or other external sources of heat to warm up or thaw the display. Allow your device to warm on its own.

As computers have become more powerful they have simultaneously been generating more heat. Portable computers are particularly susceptible to overheating, so make sure yours has room to breathe.
