Folding screens have become a common sight in recent years, thanks in large part to Samsung’s two lines of foldable phones, the Z Flip and Z Fold. As other manufacturers join in, foldable device prices are quickly going down, promising a new age of personal computing. But how do folding screens actually work?

Whether you’ve always been curious about how folding screens work or have yet to consider it, we’ll give you a crash course in foldable displays and the cool tech that makes them possible.

Simply put, millions of specks of color combine to form the images we see on screen. There are different ways to achieve this, resulting in the various displays you see out there, including LCD, OLED, and, more recently, micro-LED and mini-LED.

Then over the last decade, display manufacturers produced display substrates made of flexible plastic that can bend without breaking. Plastic-based displays made possible the creation of the first phones with curved displays, like the Galaxy Note Edge of 2014.

As technology advanced, display makers figured out ways to increase the amount of flex they could safely build into a screen. Crucially, they also solved the problem of durability, allowing screens to bend thousands of times without breaking. Eventually, this path led us to today’s folding screens, which can fold almost like a sheet of paper.

The flexible substrate is only part of the equation. Scientists and engineers had to solve ridiculously hard problems like manufacturing substrates that are light and flexible but can withstand years of mechanical stress; ensuring that all the bending and folding doesn’t affect image quality over time; creating an equally flexible protective layer for the screen; and making sure that all the other tech that goes into the display still works. When all this was done, other smart people had to devise ways to incorporate the flexible displays into folding phones while maintaining the insanely high standards we expect from our electronics. A very tough job indeed.

Before we look at the individual components of a foldable screen, it’s important to note that all folding screens you see on the market today are of the OLED variety. OLED screens do not have a backlight like LCDs — instead, the pixels themselves emit light when power is applied to them. Because of this, OLEDs can be made about 30% thinner and lighter than LCDs. Coupled with other benefits over LCD, OLED is the first choice for flexible screens, but flexible LCD displays do exist.

To understand how foldable OLED displays function, it’s helpful to visualize the display as a very thin (and probably not very tasty) layer cake. Each layer of this high-tech cake has a specific role. These layers are laminated together in a very thin package that’s fractions of a millimeter thick. Let’s go through them.

Substrate layer — Also called the board, this is the very base of the screen, which supports all the other layers. On a flexible display, the substrate is made of plastic or, less commonly, metal. Most flexible screen devices today use a substrate made of a polymer plastic called polyimide (PI). In addition to being flexible and insulating, polyimide features high mechanical strength and thermal stability.

TFT layer — Applied on top of the flexible substrate, the TFT (thin-film transistor) layer controls power delivery to each pixel. Think of it as a “power grid” that connects all the pixels in the display. On an OLED screen, unlike on LCD, each pixel can be controlled individually, allowing for high contrast rates and lower power consumption.

OLED layer — The light-emitting layer is made up of individual pixels, each of which comprises red, green, and blue subpixels. Each pixel can hit a certain color and luminosity by varying the amount of power its subpixels receive. In turn, pixels combine to form the image we see on the display. The OLED layer is made of several sub-layers, including a cathode, an anode, and a layer of organic light-emitting material sandwiched between them.

Folding screens can be of the in-folding or out-folding variety. On an in-folding display like the Galaxy Z Flip series, the display is hidden inside the device when folded, which helps with durability, but it does tend to create a slight crease on the screen. On an out-folding display (like the Huawei Mate XS 2), the display bends around the outside of the device when folded. That leaves it exposed to scratches, but it provides a crease-free aspect.

Not all flexible display devices fold. We’ve seen devices with rollable displays that roll up and disappear inside the device’s body. Examples include the Oppo X rollable phone or LG’s crazy OLED R rollable TV.

The display is a key aspect of how folding screens work, but it’s not the only one. The hinge may be just as important to the user experience. Manufacturers have poured a lot of resources into ensuring that hinges in their foldable products work smoothly and consistently, have the right amount of “snap,” and provide a smooth surface for the display to sit on.

Another key factor is durability. By definition, foldable screens feature moving parts, which opens up the possibility of water, dust, and other contaminants entering the device. Indeed, we’ve seen issues with debris getting lodged below the screen on some devices, which ruins the user experience and can damage the screen.

Numerous manufacturers have already released or at least teased foldable screen products, including phones, laptops, and even TVs. It’s easy to envision a future where tablets, wearables, gaming consoles, and even home appliances feature screens that bend. Innovation will also come from stretchable, wearable, and even skin-embeddable displays. In the meantime, as more resources are invested in the technology, folding screens will only get better.

3In contrast to the standard flat screen displays used in several electrical gadgets, a flexible display or bendable display is an electronic visual display manufactured by flexible display brands. Several consumer electronics firms have expressed enthusiasm in using this display technologies in e-readers, smart phones, and other electronic goods in recent times. Such screens may be rolled up like a scroll without distorting the image or text. Electronic ink, Gyricon, Organic LCD, and OLED are among the technologies used to create a bendable display.

With the flat panel screen having been extensively used for more than 40 years, many desirable advances in display technology have been made, with the goal of creating lighter, thinner products that are simpler to carry and store. Scientists and engineers think that flexible flat panel display innovation has a large commercial possibility in the future, thanks to recent advancements in flexible display technique.

Flexible displays offered by the flexible display brands are still somewhat costly as contrasted to their rigid equivalents, and visual quality is frequently sacrificed. When the screen is bent at a specific angle, this is extremely evident. However, in comparison to standard displays, flexible screens have a shorter lifespan.

Current models should endure a long time for the majority of users’ demands. However, most flexible display brands still require tackling this issue, particularly given the rising pricing of flexible display devices.

views itself as a supplier of intelligent vertical systems underpinned by premium display technology as an optoelectronics specialist. The company’s vast expertise, innovative skills, and corporate sustainability set it apart and set it out from the competition.

In terms of display as a networking and communication interface, AUO offers a wide range of alternatives in retail, healthcare, transport, and other industries, with the goal of forming eco-systems with partnerships across all sectors and ushering the world into a new smarter lifestyle.

Through its novel panel-centric and vertical integration operation style,unifies the product production supply chain and offers clients with full solutions. Innolux has a clear emphasis on handling technology and elements, as well as superior administration skills, in addition to a solid TFT-LCD basis and manufacturing quality. Innolux develops standards, sets market trends, and offers a comprehensive product portfolio and services to their suppliers’ clients in the data and electronic goods industries. ​

Japan Display Incorporateddevelops, designs, manufactures, and sells displays where a user interface is required to transmit a large amount of data in a short amount of time and to a worldwide market. They design engaging settings that go above and beyond the ordinary, enrich people’s lives, and stir their hearts.

LG Displayis the world’s top inventor of display technologies, comprising TFT-LCD and OLED screens, as well as the worldwide leader in OLED lighting. The firm makes display screens in a variety of dimensions and standards for usage in televisions, laptop computers, desktop workstations, and other purposes, such as tablets and mobile phones. It also manufactures OLED light screens for the automobile and interior decorating industries.

Visionoxis the globe’s renowned provider of sophisticated display systems that are both integrated and interactive. The company’s objective is to lead China’s OLED industry via technical innovation” and its ambition is to “push limits to enrich the experience of eyesight.

FlexEnable’s glass-free organic LCD (OLCD) delivers high-brightness, long lifetime flexible displays that are low cost and scalable to large areas, while also being thin, lightweight and shatterproof.

OLCD is a plastic display technology with full colour and video-rate capability. It enables product companies to create striking designs and realise novel use cases by merging the display into the product design rather than accommodating it by the design.

Unlike flexible OLED displays, which are predominantly adopted in flagship smartphones and smartwatches, OLCD opens up the use of flexible displays to a wider range of mass-market applications. It has several attributes that make it better suited than flexible OLED to applications across large-area consumer electronics, smart home appliances, automotive, notebooks and tablets, and digital signage.

OLCD can be conformed and wrapped around surfaces and cut into non-rectangular shapes during the production process. Holes can be also added to fit around the functional design of the system – for example around knobs and switches.

As with glass-based LCD, the lifetime of OLCD is independent of the display brightness, because it is achieved through transmission of a separate light source (the backlight), rather than emission of its own light. For example OLCD can be made ultra-bright for viewing in daylight conditions without affecting the display lifetime – an important requirement for vehicle surface-integrated displays.

OLCD is the lowest cost flexible display technology – it is three to four times lower cost that flexible OLED today. This is because it makes use of existing display factories and supply chain and deploys a low temperature process that results in low manufacturing costs and high yield.

Unlike other flexible display approaches, OLCD is naturally scalable to large sizes. It can be made as small or as large as the manufacturing equipment used for flat panel displays allows.

The flexibility of OLCD allows an ultra-narrow bezel to be implemented by folding down the borders behind the display. This brings huge value in applications like notebooks and tablets where borderless means bigger displays for the same sized device. The bezel size allowed by OLCD is independent of the display size or resolution. In addition, OLCD can make a notebook up to 100g lighter and 0.5mm thinner.

OLCD is the key to the fabrication of ultra-high contrast dual cell displays with true pixel level dimming, offering OLED-like performance at a fraction of the cost. The extremely thin OLCD substrate brings advantages in cost, viewing angle and module thickness compared to glass displays. At the same time OLCD retains the flexibility required for applications such as surface-integrated automotive displays.

Due to its unique properties, OLCD has the potential to transform how and where displays are used in products. The videos below give a glimpse into this innovative technology.

OLCD brings the benefits of being thin, light, shatterproof and conformable, while offering the same quality and performance as traditional glass LCDs. The mechanical advantages of plastic OLCD over glass LCD are further enhanced by the technology’s excellent optical performance, much of which originates from the extreme thinness of plastic TAC substrates compared to glass.

Foldable OLED displays can be bent by the user. These innovative displays enable new form factors, such as - such as phones that open into tablets, smart bands that open into smartphones and laptops with large displays. In 2019 the first foldable smartphones were launched, and after a rocky start, device markers are now introducing new devices to market as analysts expect increased adoption in the future.

In 2019 Samsung finally introduced the first device, the Galaxy Fold - which had a problematic launch. Since then Samsung followed up with several new foldable phones, for example the Galaxy Z Fold 2 which sports an internal foldable display at 7.6" 1768x2208 HDR10+ 120Hz Dynamic AMOLED and also a larger 6.23" 816x2260 Super AMOLED cover display. Samsung also launched the clamshell-style Galaxy Z Flip.

Several companies offer foldable phones besides Samsung, including Motorola, Huawei and others. Huawei for example launched the Mate X2 in 2021, which features an inside-folding AMOLED display, a 8-inch 90Hz 2480 x 2200 one. There is also an external 6.45-inch 1160 x 2700 90Hz (240Hz touch sampling rate) AMOLED display.

Foldable OLED laptops is another promising market segment. In 2021 Lenovo started shipping the $2,499 foldable ThinkPad X1 Fold laptop, with its 13.3" 2048x1536 foldable OLED display (produced by LG Display). Hopefully more companies will follow suit and we"ll see more such devices on the market soon.

If you want to learn more about the foldable OLED technology, industry and market, check out ourWhy flexible displays and lighting panels are so exciting
