For decades, we’ve lived with an inconvenient technological truth: Cameras and other sensors cannot occupy the same space as our screens. It’s why, increasingly, smartphones rely on the dreaded “notch” as a way of maximizing screen-to-body ratios while preserving the front-facing camera and other sensors.

Some phone makers, from Oppo to OnePlus, get around this problem by using motorized pop-up cameras, while others have resorted to punching holes in displays to provide the camera with its own peephole. It’s also why even the latest high-end laptops still have pronounced bezels around their displays. The webcam needs a home and it seems no one is willing to live with a notch or hole-punch on a computer.

But it turns out that cameras and screens aren’t quite as incompatible as they seem. Thanks to improvements in manufacturing techniques, these two adversaries are about to end their long-standing territorial dispute. This isn’t a far-flung prediction; it’s happening right now.

Complaining about a phone notch, hole-punch or a large screen bezel is the very definition of a first-world problem. And judging from Apple’s stellar sales numbers, none of these side effects of forward-facing cameras are dealbreakers for buyers.

First, it lets you make phones that have true edge-to-edge screens. Videos and photos look better, and app developers can make use of every square millimeter for their designs — all while keeping the phone’s body as small as possible.

Second, from a design and manufacturing point of view, if cameras and sensors can be placed anywhere, with fewer restrictions on their size and visibility, it redraws the map for phone design. Bigger batteries, thinner phones, more sensors, and much better cameras are all potential upsides.

Cameras placed in bezels or notches create the now all-too-familiar, awkward downward gaze that happens during video calls. “Most of the time, you’re not actually looking at each other when you’re talking over video chat,” Michael Helander, CEO at Toronto-based OTI Lumionics told Digital Trends. “The current placement of videoconferencing cameras in all of these devices is really suboptimal.”

Helander has probably thought about this problem more than most. His company creates specialty materials that enable what was once impossible — making displays transparent enough that you can place a camera behind them.

Once a camera is sitting behind the display, it will finally make our video interactions look and feel like real, in-person interactions — a game changer that couldn’t come at a better time in our COVID-restricted world.

Screen technology is dominated by two kinds of displays. The most common are liquid crystal displays (LCD), which include LED TVs and QLED TVs. The second, organic light-emitting diode (OLED), dominates smartphones and tablets, and is growing in use in laptops and even desktop monitors

LCDs are actually transparent when not in use — that’s why you see a gray background on a calculator screen wherever the black digit segments aren’t active. But taking advantage of this transparency to take a photo poses big technical hurdles, especially once you factor in the need for a backlight.

One solution favored by Xiaomi and Oppo in their UDC prototypes is to rely on an OLED pixel’s inherent transparency. When an OLED pixel isn’t being used to emit light, it lets light in. So you can place a camera behind an OLED display and it will be able to gather enough light to capture images. But there’s a catch: You still need to place the camera at the top or bottom of the screen, because when the camera is active, the OLED pixels above it must be shut off, which creates a temporary black area on the screen. That approach is a solution to the notch and hole-punch problem, but it does nothing to solve the downward gaze issue.

The first commercially available phone with an under-display camera — the ZTE Axon 20 5G — uses this technique, but it also suffers from a less-than-ideal compromise. Modern smartphones have incredibly densely packed pixels. The iPhone 12 Pro has a 460ppi (pixels per inch) display, which means that there are more than 200,000 pixels in one square inch. Sony’s Xperia XZ Premium had a whopping 807ppi screen (more than 650,000 pixels per square inch).

Punching holes in between those pixels, even with a laser, is so tricky that ZTE had to remove some pixels from the area above the camera to buy some extra room. The result is a noticeably lower-resolution square on the screen.

A lower-resolution section of the screen might not bother you when it’s near the top, in an area that’s used mostly for inconsequential information. But few people would accept such an obvious reduction of resolution in the center of their phone’s display, which is what we would need to counteract the downward-gaze problem.

Helander claims the self-assembly process works on any screen size, and lets manufacturers decide how many openings are needed — from just one to 1 billion.

As exciting as it is to think that we’ll soon be able to have much more natural video calls, placing a camera under a display puts an even bigger onus on manufacturers to provide trustworthy privacy measures.

We’ll need some kind of reliable indicator of when the camera is active and an equally reliable way of disabling it. Because it’s under the screen, there’s no way to physically block the lens without blocking content on the screen as well.

Apple recently updated iOS to show a small green dot near the notch when its forward-facing camera is in use, and an orange dot to show when the mic is active. That’s a good way to inform us of what’s going on, but we need something more.

Smart speakers like the Google Nest mini ship with physical switches that can be used to disable the microphones. Assuming that there’s no way to remotely overcome the switch’s position, it provides a very good level of trust. A similar mechanism on TVs, monitors, and laptops should come standard once cameras become invisible.

OTI Lumionics already has agreements in place with several Chinese smartphone manufacturers, but due to confidentiality restrictions, these companies can’t be named just yet. “Many of them have prototype phones that have been built and everything looks great,” Helander notes, “but none of them want to disclose anything publicly until they’re ready for their actual official product announcements.” He’s confident that we’ll see these new under-display camera models sometime in 2021, although they may remain a Chinese market exclusive until 2022.

As is often the case with new technology, under-display cameras didn’t make a great first impression. It’s a nice idea in theory, of course — you don’t need a notch or a hole-punch if you can put a selfie camera under the display — but the earliest efforts had some issues.

ZTE’s Axon 20 last year was the first phone to ship with one, and it was bad. The camera quality was incredibly poor, and the area of the screen looked more distracting than a notch. Samsung followed up this year with the Galaxy Z Fold 3, which had similar issues.

But things are actually getting better. Two newer phones on the market, Xiaomi’s Mix 4 and ZTE’s Axon 30, use a different approach to the technology, and it’s an improvement on the previous generation. Instead of having a lower resolution area of the screen that allows light through to the camera, they shrink the size of the pixels without reducing the number.

This means that the part of the screen that covers the camera is really difficult to see in normal use. Look at how the Axon 30 compares to the Axon 20 on a white background, which was the most challenging situation for the older phone to disguise the camera in. It’s also much harder to make out than the camera on Samsung’s Galaxy Z Fold 3:

ZTE’s Axon 20 on the left, and the newer Axon 30 on the right. The area of the screen that covers the selfie camera is much less noticeable on the Axon 30.

Now, the camera is clearly still compromised compared to one that doesn’t have to gather light from behind a screen. ZTE and Xiaomi lean hard on algorithms for post-processing — you can tell because the live image preview looks much worse than the final picture. The results still look over-processed and unnatural, even if they’re more usable than their predecessors’. Video quality is also bad, because it’s probably too much to ask for these phones to do the processing in real time.

There’s more to the idea than just reducing the size of your phone bezels, though. We spoke to Steven Bathiche from Microsoft’s Applied Sciences group on how the company is working on under-display cameras for an entirely different reason — so you can maintain eye contact while looking at your screen on video calls.

At Rostra, we’re pleased to announce a large expansion to our factory-installed LCD screen interface camera system program. Now available for ordering, our RearSight® interface application listing includes plug-and-play kits for many popular GM, Chrysler, Hyundai, Mazda, Ford, Subaru, and Toyota vehicles. The applications found in the guide below include either our discrete wedge-shaped CMOS camera, our teardrop CMOS or CCD camera, or a custom tailgate-handle integrated CMOS camera (available in black and chrome) to retain the factory look of a truck’s tailgate.

Please note that some of these systems do require programming by a dealership to activate the camera once installed, but the necessary steps for these procedures are outlined in the instructions included with each kit and labeled as “DAR: Yes or No” on this guide.

Installer is advised to remove the factory LCD screen and verify that the original Ford screen part number matches those in the list below before ordering:

Note: The 250-8420-MOD system requires a vehicle to have a pre-existing, original equipment backup camera. 250-8420-MOD is only for use as an auxiliary camera such as a side or front-view system.

Note: The 250-8420-MOD system requires a vehicle to have a pre-existing, original equipment backup camera. 250-8420-MOD is only for use as an auxiliary camera such as a side or front-view system.

Please note, our RearSight® factory LCD screen interface systems are only sold through authorized distributors. Please contact Rostra to locate a distributor in your area for your original equipment touch screen camera interface system.

Under-display cameras are poised to be The Hot New Feature, following up on the similar success of the in-display fingerprint sensor. It almost seems like science fiction: You can"t see the camera, but it can see you. The technology promises to eliminate the last impediment in the all-screen phone dream. But how does it work, and when will you actually be able to buy a phone that has one?

According to Helander, there are two engineering approaches to designing under-display cameras: You either do everything you can to make the entire display as transparent as possible above the camera, or you essentially make tiny transparent holes in an otherwise opaque screen between the pixels.

In the first case, that means changing materials and rearranging things in the area above the camera. Certain metals in the various layers can be replaced by transparent conducting materials like indium tin oxide, and the structure of the display itself can be rearranged to reroute anything that might interfere with optimal transparency in that area. Anything that can"t ultimately be moved or made transparent can be made as small as possible.

There are a few limitations to this route: primarily brightness, uniformity, and resolution. Typically, OLED pixels are designed to be reflective on one side and transparent on the other, ensuring most of the light produced goes in one direction: toward you. Making the display transparent in one section interferes with that sort of design, and it can make the area the camera is in look distinctly different and less bright than the rest of the screen. Compensating for that effect by cranking brightness and calibrating differently in that tiny area can result in other long-term issues like burn-in around the transparent camera area. We"re also told that all the rerouting and transparency-increasing steps often mean accepting a lower display resolution in that particular spot — a handful of big pixels in a sea of smaller ones. This is allegedly the approach that ZTE is taking in devices like the Axon 20 5G.

The second method is a little different. Rather than making an entire stack of the display transparent across one area, you can carve out individual transparent "holes" between the pixels and rely on them to transmit light through the screen. You can do this in a few different ways, like cutting down on display resolution to carve out an area for one in every X number of pixels, or just shuffling and rerouting things to make regular patterned spaces.

As before, this means rerouting some components to ensure you have a clear line through the screen, but you don"t have to worry about the whole display stack being transparent, just specific spots at regular intervals. If your resolution is low enough, you can accommodate these extra holes without any loss, but at very high densities, it can also mean giving up some pixels and accepting a lower resolution. Importantly, though, this route means the individual pixels above the camera have the same individual brightness and performance characteristics of the pixels elsewhere on the display, so you shouldn"t have as many issues with uniformity. This second route is what we"re told Xiaomi is planning for its upcoming phones, and it sounds like it may work the best out of the possible solutions available right now.

Now, whichever route manufacturers take, under-display cameras won"t work quite the same as they did before. Either way, the camera is going to get a little less light with more stuff in the way, and there are other optical effects these designs have to fight. There are issues like reflection and diffraction from all the various materials, layers, and holes that the light travels through. These are problems that can"t be fully eliminated, but Helander tells us they can be compensated for in software and reduced by advances in material science and engineering. Some of these issues also result in "softer" looking images, mimicking some of the effects of the beauty filters so many people enjoy, so it isn"t all bad. Helander also claims that machine learning models can compensate for many of these issues pretty well.

This also opens a pretty big door for us in the future. Right now, most under-display prototypes just put the camera in the same place and extend the screen to cover it, but nothing is stopping us from using some of these solutions to make the entire display transparent and putting the camera wherever we like. Ultimately, we could move the camera down to the center of the screen, making it easier to keep the effect of eye contact when in video calls, or we could even toss several cameras under the screen in different places. Some day other optical sensors, like the infrared cameras used for face unlock systems, could also be moved under the screen. Eventually, we could do the same with desktop computer monitors, too.

Before this technology can replace the notch or the hole-punch cutout, it needs to be scaled up. And given the sort of engineering costs involved, Helander tells us that, counter-intuitively, we"ll see this technology roll out in the mid-range market first. Right now, sacrifices required when it comes to resolution and brightness mean this technology probably won"t be a good fit in the flagship space for a while, where customers expect the very best. Issues like a big gray square or circle in the screen at max brightness, a resolution drop in one corner, or an overall lower display resolution all won"t play at the thousand-dollar price point, but they"re more acceptable in a mid-range product, and the details of ZTE"s upcoming device lend further evidence to that argument.

In Helander"s estimation, it could be 2022 or 2023 before this technology becomes mainstream, engineering problems are solved, production ramps up, and the feature works its way up and down the market. In the meantime, most of us will have to make do with being able to actually see our camera in a bezel, notch, or hole-punch cutout.

This kit allows you to easily add a camera system to your Audi A3. This kit allows the new camera to interface directly with the Audi A3 factory display screen that is in your dash, giving you the look and feel of a factory installed camera system.  This kit comes with a dual mount license plate camera system that uses a hidden style bracket, allowing only the small 1"x1" camera to be visible.  When the vehicle is placed in reverse the factory 8.4" screen will display the camera image to give you a clear view of your surroundings.

Excellent swimmers, these small birds are seen throughout the sequence both hunting for aquatic insects and flying behind the falls to deliver this food to their young.

Even as the sky becomes almost cloud-free, behind, the low, early sun is periodically obscured by moving clouds, causing a play of sunlight and deep shadow on the distant mountains, the intermediate ponderosa pines, and the sage and grass in the foreground.

high desert, mountain lake, sagebrush, Oregon Sunshine wildflowers, tall grasses, aspen trees, Oregon, blue sky with clouds, noon, 24p, Red One camera, HD, 4k, 1080p

high desert, hills, Oregon, large clouds, small clouds, blue sky, noon, afternoon, evening, sunset, ground squirrel, 24p, Red One camera, HD, 4k, 1080p

Apparently it"s in the display. Like I described earlier, when i look at the LCD monitor to view pictures that I"ve just taken, it appears like there are several tiny specks of dirt or dust. They don"t affect how much pictures look. it"s just distracting to have them there.

Backup cameras and blind spot cameras provide a level of visibility that a simple rearview mirror can never approach. This versatile, universally compatible factory mount replacement mirror is equipped with a 7.3” LCD monitor, giving you a crystal clear view of what’s behind your car. Backing up and parking have never been safer than now.

Designed to mimic the factory look while providing extra functionality, the mirror features an auto-dimming display, three display modes and adjustable parking lines. The 3 video inputs, allow simultaneous use with front, rear, and side-view cameras. Three individual triggers switch video displays automatically, and an included remote control lets you select manually. When feeding side blind spot cameras, the camera feeds will show on the mirror’s monitor. The image on the mirror corresponds with which turn signal is being used, and which side camera is being shown. The right turn signal activates the right camera, and is shown on the mirror’s monitor.

On the screen, you can enable and adjust special parking lines, which tell you the exact trajectory of the back of your vehicle. If you’re at risk of running into another car, you’ll know far ahead of time.

The PMM-7333-PL is included as part of EchoMaster’s Blind Spot and Lane Change Assistance System, along with a set of PCAM-BS1-N side blind spot cameras and a PCAM-10L-N license plate mount backup camera. This kit provides everything drivers need to make the driving experience safer and easier than ever before. All three cameras feed into the rearview replacement mirror and are triggered by driver behavior. The two PCAM-BS1-N cameras can be mounted under side mirrors and assist during lane changing. Triggered on by the turn signal, the side blind spot is eliminated and a clear view of the side of the vehicle is displayed on the rearview mirrors split screen mode, depending on which side turn signal is used. PCAM-10L-N license plate mount camera can be used as a reverse camera, or a front camera. The front or rear image is displayed on the full 7.3” view mode on the mirror monitor.

For years, smartphone manufacturers have tried numerous ways to create a truly edge-to-edge display. The ultimate aim is to have a smartphone with a screen that reaches to all four edges of the frame, with no interruption.

The only issue has been the need for a selfie camera. That inevitably has be be put somewhere, and we"ve seen any number of inventive methods that aim to try to hide it, make it less of an obstruction, or at least, reduce its visual impact.

There have been pop-up camera mechanisms, tiny dewdrop notches, flip cameras, and punch-hole cameras put on the front of phones. But there is one new technology aimed at hiding it completely: the under-display camera. Also known as USC (under-screen camera) or UPC (under-panel camera).

Thankfully, the clue is very clearly in the description. The UPC/USC or under display camera is a camera that"s hidden behind the display panel of the smartphone.

In basic terms, it"s similar to in-display optical fingerprint sensors. A small portion of the display panel is transparent, and lets light through to a camera that"s sat behind the display. Or to be more technically accurate, a small portion near the top of the screen is actually a second, tiny transparent display.

If you"re wondering why they can"t do what they do with optical fingerprint sensors and just make a transparent portion of the main screen yet, it"s because standard OLED panels aren"t yet able to let enough light through to the other side to create a decent coloured image. So for now, companies like ZTE and Xiaomi have resorted to using a secondary, much smaller "invisible" display within a display.

And, if they used this display as the entire panel, that would have dire consequences for the fidelity of the image on the display. So they put it in a part of the screen where - most of the time - the quality of the image doesn"t matter: in the status bar.

While the eventual aim is surely to have it implemented in a way that makes it completely invisible, early iterations haven"t quite managed it. It"s mostly invisible on darker days, but once you shine light on the area of the display hiding the camera, you can clearly see the area that"s allowing light through. As technology develops, we expect this to improve.

The first phone to have the under-screen camera was the ZTE Axon 20 5G. So far it"s also the only commercially available product with the under-display camera.

As mentioned already, part of the reason is that it"s not possible (yet) to completely hide that secondary transparent screen. The other problem is to do with image quality from the camera that"s behind it.

By adding a layer of material that"s not completely clear in front of a camera, it makes it harder to get a really good photo. After all, cameras require light to take pictures, but crucially, also need that light to come through to the sensor without any disturbance to the signal in order produce sharp and accurate results.

This is an extreme over-simplification, but it"s almost like covering the camera with a really thin layer of tracing paper and asking it to take as good a picture as if you hadn"t. It just can"t be done. Or hasn"t been so far.

The aim undoubtedly is to make the transparent display portion more transparent, but also develop better AI/algorithms to correct the issues that arise from filtering light through the screen.
