best 4.3 tft lcd panel free sample

This LCD is a high resolution 800X480 IPS TFT display. The IPS technology delivers exceptional image quality with superior color representation and contrast ratio at any angle. This 24-bit true color Liquid Crystal Display is RoHS compliant and does not include a touch panel.

Enhance your user experience with capacitive or resistive touch screen technology. We’ll adjust the glass thickness or shape of the touch panel so it’s a perfect fit for your design.

Choose from a wide selection of interface options or talk to our experts to select the best one for your project. We can incorporate HDMI, USB, SPI, VGA and more into your display to achieve your design goals.

TFT Interface: 3 SPI and 16/18/24BIT RGB, WHITE LED backlight, IPS, Wide temp, Transmissive, Capacitive Touch Screen, CTP Interface: I2C, 450 NITS, RoHS Compliant

The Capacitive touch panel is activated with anything containing an inductive load such as a finger or stylus. It allows for multi-touch options. When using the capacitive touch screen, the display needs a separate controller to interface with the touch panel. The display for capacitive touch is brighter since the touch panel is transparent.

The Transmissive polarizer is best used for displays that run with the backlight on all the time. This polarizer provides the brightest backlight possible. If you have a need for a bright backlight with lower power drain, transmissive is a good choice for this TFT LCD display.

Focus LCDs can provide many accessories to go with your display. If you would like to source a connector, cable, test jig or other accessory preassembled to your LCD (or just included in the package), our team will make sure you get the items you need.Get in touch with a team member today to accessorize your display!

Focus Display Solutions (aka: Focus LCDs) offers the original purchaser who has purchased a product from the FocusLCDs.com a limited warranty that the product (including accessories in the product"s package) will be free from defects in material or workmanship.

16/18/24-bit RGB Interface, Top View, Wide Temp (-20°- 70° operating/-30°- 80° storage), Transmissive, Capacitive touch panel, 430 nits, RoHS Compliant.

TheCapacitive touch panelis activated with anything containing an inductive load such as a finger or stylus. It allows for multi-touch options. When using the capacitive touch screen, the display needs a separate controller to interface with the touch panel. The display for capacitive touch is brighter since the touch panel is transparent.

The Transmissive polarizer is best used for displays that run with the backlight on all the time. This polarizer provides the brightest backlight possible. If you have a need for a bright backlight with lower power drain, transmissive is a good choice for this TFT LCD display.

Focus LCDs can provide many accessories to go with your display. If you would like to source a connector, cable, test jig or other accessory preassembled to your LCD (or just included in the package), our team will make sure you get the items you need.Get in touch with a team member today to accessorize your display!

Focus Display Solutions (aka: Focus LCDs) offers the original purchaser who has purchased a product from the FocusLCDs.com a limited warranty that the product (including accessories in the product"s package) will be free from defects in material or workmanship.

Established in 2010, Topfoison has devoted itself to the manufacturing and development of high-quality products for the Wearable device, Smart Watch, VR, Medical device, Industrial LCD display including Color LCD modules/OLED/LCD display/Round lcd screen/Round AMOLED/ Square transflective lcd screen/ IPS full wide display/ 1080p fhd AMOLED and 2K 1440p lcd. Topfoison focus on1.22-7.0 inch small size displays, all the products produced in our company enjoys the most advanced production craft and technology as well as the strictly ISO quality management system.

※ Price Increase NotificationThe TFT glass cell makers such as Tianma,Hanstar,BOE,Innolux has reduced or stopped the production of small and medium-sized tft glass cell from August-2020 due to the low profit and focus on the size of LCD TV,Tablet PC and Smart Phone .It results the glass cell price in the market is extremely high,and the same situation happens in IC industry.We deeply regret that rapidly rising costs for glass cell and controller IC necessitate our raising the price of tft display.We have made every attempt to avoid the increase, we could accept no profit from the beginning,but the price is going up frequently ,we"re now losing a lot of money. We have no choice if we want to survive. There is no certain answer for when the price would go back to the normal.We guess it will take at least 6 months until these glass cell and semiconductor manufacturing companies recover the production schedule. (Mar-03-2021)

ER-TFT043-3 is 480x272 dots 4.3" color tft lcd module display with driver IC ILI6480BQ and optional 4-wire resistive touch panel screen,superior display quality,wide view angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO,ARM and Raspberry PI .

It can be used in any embedded systems,car,mp4,gps,industrial device,security and hand-held equipment which requires display in high quality and colorful image.It supports rgb interface. FPC with zif connector is easily to assemble or remove.Of course, we wouldn"t just leave you with a datasheet and a "good luck!".Here is the link for 4.3"TFT Touch Shield with Libraries, Examples.Schematic Diagram for Arduino Due,Mega 2560,Uno and 8051 Microcontroller Development Board&Kit.

XMA-lcd Electronic Technology Co.,Ltd is dedicated to researchanddevelopment, production and marketing of high-tech enterprises which focusing on liquid crystal display (LCD) and supporting modules (LCM).We are committed to offering a wide range of LCD and OLED products in the same standard as required by the market to satisfy your requirements. We can not only supply all kinds of standard TN, HTN, STN and FSTN Dot Matrix LCD displays and OLED displays in SMT, COB and COG type but also custom design LCD and OLED displays for specialized applications. We have a highly trained R&D team to provide any expertise necessary and their resourcefulness for you. Our in-house design capabilities will transform your initial idea into the final product within a short time.

Amulet’s capacitive 7” GEMmodule (AM070RVS01) is a fully customizable, high-performance, touch screen display module with a 7” WVGA LCD and robust capacitive touch panel. This feature rich solution, including thick protective cover glass and water resistant and glove-enabled touch panel, provides the ideal attributes required in the embedded industrial and medical equipment markets.

Amulet’s resistive 7” GEMmodule (MK-070R) is a fully integrated, production ready solution with an integrated resistive touch panel, that allows embedded product manufacturers to implement a great looking GUI in record time, regardless of the size and speed of the microprocessor.

Amulet’s resistive 7” GEMstarter-kit (STK-070R) provides everything needed to create and drive a Graphical User Interface, including a 800 x 480 TFT LCD, an integrated touch panel and controller board, stylus, power supply, and USB PC interface cable. The GEMstarter-kit also comes with a free 30-Day Trial of GEMstudio Pro.

Amulet’s resistive 7” GEMstarter-kit (STK-070R) provides everything needed to create and drive a Graphical User Interface, including a 800 x 480 TFT LCD, an integrated touch panel and controller board, stylus, power supply, and USB PC interface cable. The GEMstarter-kit also comes with a free 30-Day Trial of GEMstudio Pro.

Amulet’s capacitive 4.3” GEMmodule (MK-CY-043) consists of a fully integrated drop-in solution that allows customers to implement a GUI with smartphone-like look and feel at record time-to-market. The modules have gesture support and can be programmed using GEMstudio Pro. With Cypress TrueTouch™ technology, this module provides unparalleled signal-to-noise ratio and excellent touch performance.

Amulet’s capacitive 4.3” GEMstarter-kit (STK-CY-043) provides everything needed to create and drive a Graphical User Interface, including a 480 x 272 TFT LCD, a capacitive touch sensor, removable stands, and USB PC interface cable.The GEMstarter-kit also comes with a free 30-Day Trial of GEMstudio Pro.

Amulet’s capacitive 4.3” GEMstarter-kit (STK-CY-043) provides everything needed to create and drive a Graphical User Interface, including a 480 x 272 TFT LCD, a capacitive touch sensor, removable stands, and USB PC interface cable.The GEMstarter-kit also comes with a free 30-Day Trial of GEMstudio Pro.

If you would like to purchase a capacitive 4.3” GEMmodule (MK-CY-043) or GEMstarter-kit (STK-CY-043), please order online with one of our authorized distributors:

If you would like to purchase a capacitive 4.3” GEMmodule (MK-CY-043) or GEMstarter-kit (STK-CY-043), please order online with one of our authorized distributors:

Amulet’s resistive 4.3” GEMmodule (MK- 043R) is a fully integrated WQVGA production color display module that supports a variety of embedded control interface applications. Featuring the Amulet GEM Graphical OS Chip™ for color displays, the module supports GIF, JPEG and PNG graphic formats in 24-bit color, plus 8-bit alpha blending found in high-end consumer electronic products.

Amulet’s resistive 4.3” GEMstarter-kit (STK-043R) provides everything needed to create and drive a Graphical User Interface,  including a 480 x 272 TFT LCD, an integrated touch panel and controller board, stylus, and USB PC interface cable.The GEMstarter-kit also comes with a free 30-Day Trial of GEMstudio Pro.

Amulet’s resistive 4.3” GEMstarter-kit (STK-043R) provides everything needed to create and drive a Graphical User Interface,  including a 480 x 272 TFT LCD, an integrated touch panel and controller board, stylus, and USB PC interface cable.The GEMstarter-kit also comes with a free 30-Day Trial of GEMstudio Pro.

If you would like to purchase a resistive 4.3” GEMmodule (MK-043R) or GEMstarter-kit (STK-043R), please order online with one of our authorized distributors:

FocusLCDs.com sent me a free sample of a 4x3” TFT LCD (P/N: E43RG34827LW2M300-R) to try out. This is a color active matrix TFT (Thin Film Transistor) LCD (liquid crystal display) that uses amorphous silicon TFT as a switching device. This model is composed of a Transmissive type TFT-LCD Panel, driver circuit, backlight unit. The resolution of a 4.3” TFT-LCD contains 480x272 pixels, and can display up to 16.7M colors.

For this project, you would need the RA8875 driver board (available at AdaFruit for US$35) to interface the TFT display to the Arduino. It comes with a header which you can solder on as needed.

With the integration of Bridgetek’s next generation EVE3 BT815/BT816 Embedded Video Engine IC, Matrix Orbital EVE3 SPI TFT"s deliver clean, crisp, full color TFT screens for interactive menus, graphing, graphics and even video.

Point of Sales Machines, Multi-function Printers, Instrumentation, Home Security Systems, Graphic touch pad – remote, dial pad, Tele/Video Conference Systems, Phones and Switchboards, Medical Appliances, Breathalyzers, Gas chromatographs, Power meter, Home appliance devices, Set-top box, Thermostats, Sprinkler system displays, GPS / Satnav, Vending Machine Control Panels, Elevator Controls, and many more....

In this Arduino touch screen tutorial we will learn how to use TFT LCD Touch Screen with Arduino. You can watch the following video or read the written tutorial below.

As an example I am using a 3.2” TFT Touch Screen in a combination with a TFT LCD Arduino Mega Shield. We need a shield because the TFT Touch screen works at 3.3V and the Arduino Mega outputs are 5 V. For the first example I have the HC-SR04 ultrasonic sensor, then for the second example an RGB LED with three resistors and a push button for the game example. Also I had to make a custom made pin header like this, by soldering pin headers and bend on of them so I could insert them in between the Arduino Board and the TFT Shield.

Here’s the circuit schematic. We will use the GND pin, the digital pins from 8 to 13, as well as the pin number 14. As the 5V pins are already used by the TFT Screen I will use the pin number 13 as VCC, by setting it right away high in the setup section of code.

I will use the UTFT and URTouch libraries made by Henning Karlsen. Here I would like to say thanks to him for the incredible work he has done. The libraries enable really easy use of the TFT Screens, and they work with many different TFT screens sizes, shields and controllers. You can download these libraries from his website, RinkyDinkElectronics.com and also find a lot of demo examples and detailed documentation of how to use them.

After we include the libraries we need to create UTFT and URTouch objects. The parameters of these objects depends on the model of the TFT Screen and Shield and these details can be also found in the documentation of the libraries.

So now I will explain how we can make the home screen of the program. With the setBackColor() function we need to set the background color of the text, black one in our case. Then we need to set the color to white, set the big font and using the print() function, we will print the string “Arduino TFT Tutorial” at the center of the screen and 10 pixels  down the Y – Axis of the screen. Next we will set the color to red and draw the red line below the text. After that we need to set the color back to white, and print the two other strings, “by HowToMechatronics.com” using the small font and “Select Example” using the big font.
