An excellent new compatible library is available which can render TrueType fonts on a TFT screen (or into a sprite). This has been developed by takkaO, I have created a branch with some bug fixes here. The library provides access to compact font files, with fully scaleable anti-aliased glyphs. Left, middle and right justified text can also be printed to the screen. I have added TFT_eSPI specific examples to the OpenFontRender library and tested on RP2040 and ESP32 processors, the ESP8266 does not have sufficient RAM due to the glyph render complexity. Here is a demo screen where a single 12kbyte font file binary was used to render fully anti-aliased glyphs of gradually increasing size on a 320x480 TFT screen:

Support has been added in v2.4.70 for the RP2040 with 16 bit parallel displays. This has been tested and the screen update performance is very good (4ms to clear 320 x 480 screen with HC8357C). The use of the RP2040 PIO makes it easy to change the write cycle timing for different displays. DMA with 16 bit transfers is also supported.

Smooth fonts can now be rendered direct to the TFT with very little flicker for quickly changing values. This is achieved by a line-by-line and block-by-block update of the glyph area without drawing pixels twice. This is a "breaking" change for some sketches because a new true/false parameter is needed to render the background. The default is false if the parameter is missing, Examples:

New anti-aliased graphics functions to draw lines, wedge shaped lines, circles and rounded rectangles. Examples are included. Examples have also been added to display PNG compressed images (note: requires ~40kbytes RAM).

Frank Boesing has created an extension library for TFT_eSPI that allows a large range of ready-built fonts to be used. Frank"s library (adapted to permit rendering in sprites as well as TFT) can be downloaded here. More than 3300 additional Fonts are available here. The TFT_eSPI_ext library contains examples that demonstrate the use of the fonts.

Users of PowerPoint experienced with running macros may be interested in the pptm sketch generator here, this converts graphics and tables drawn in PowerPoint slides into an Arduino sketch that renders the graphics on a 480x320 TFT. This is based on VB macros created by Kris Kasprzak here.

The RP2040 8 bit parallel interface uses the PIO. The PIO now manages the "setWindow" and "block fill" actions, releasing the processor for other tasks when areas of the screen are being filled with a colour. The PIO can optionally be used for SPI interface displays if #define RP2040_PIO_SPI is put in the setup file. Touch screens and pixel read operations are not supported when the PIO interface is used.

An Arduino IDE compatible graphics and fonts library for 32 bit processors. The library is targeted at 32 bit processors, it has been performance optimised for RP2040, STM32, ESP8266 and ESP32 types, other processors may be used but will use the slower generic Arduino interface calls. The library can be loaded using the Arduino IDE"s Library Manager. Direct Memory Access (DMA) can be used with the ESP32, RP2040 and STM32 processors with SPI interface displays to improve rendering performance. DMA with a parallel interface (8 and 16 bit parallel) is only supported with the RP2040.

For other processors only SPI interface displays are supported and the slower Arduino SPI library functions are used by the library. Higher clock speed processors such as used for the Teensy 3.x and 4.x boards will still provide a very good performance with the generic Arduino SPI functions.

"Four wire" SPI and 8 bit parallel interfaces are supported. Due to lack of GPIO pins the 8 bit parallel interface is NOT supported on the ESP8266. 8 bit parallel interface TFTs (e.g. UNO format mcufriend shields) can used with the STM32 Nucleo 64/144 range or the UNO format ESP32 (see below for ESP32).

The library supports some TFT displays designed for the Raspberry Pi (RPi) that are based on a ILI9486 or ST7796 driver chip with a 480 x 320 pixel screen. The ILI9486 RPi display must be of the Waveshare design and use a 16 bit serial interface based on the 74HC04, 74HC4040 and 2 x 74HC4094 logic chips. Note that due to design variations between these displays not all RPi displays will work with this library, so purchasing a RPi display of these types solely for use with this library is NOT recommended.

A "good" RPi display is the MHS-4.0 inch Display-B type ST7796 which provides good performance. This has a dedicated controller and can be clocked at up to 80MHz with the ESP32 (125MHz with overclocked RP2040, 55MHz with STM32 and 40MHz with ESP8266). The MHS-3.5 inch RPi ILI9486 based display is also supported, however the MHS ILI9341 based display of the same type does NOT work with this library.

Some displays permit the internal TFT screen RAM to be read, a few of the examples use this feature. The TFT_Screen_Capture example allows full screens to be captured and sent to a PC, this is handy to create program documentation.

The library supports Waveshare 2 and 3 colour ePaper displays using full frame buffers. This addition is relatively immature and thus only one example has been provided.

The library includes a "Sprite" class, this enables flicker free updates of complex graphics. Direct writes to the TFT with graphics functions are still available, so existing sketches do not need to be changed.

The "Animated_dial" example shows how dials can be created using a rotated Sprite for the needle. To run this example the TFT interface must support reading from the screen RAM (not all do). The dial rim and scale is a jpeg image, created using a paint program.

The XPT2046 touch screen controller is supported for SPI based displays only. The SPI bus for the touch controller is shared with the TFT and only an additional chip select line is needed. This support will eventually be deprecated when a suitable touch screen library is available.

The library supports SPI overlap on the ESP8266 so the TFT screen can share MOSI, MISO and SCLK pins with the program FLASH, this frees up GPIO pins for other uses. Only one SPI device can be connected to the FLASH pins and the chips select for the TFT must be on pin D3 (GPIO0).

The library contains proportional fonts, different sizes can be enabled/disabled at compile time to optimise the use of FLASH memory. Anti-aliased (smooth) font files in vlw format stored in SPIFFS are supported. Any 16 bit Unicode character can be included and rendered, this means many language specific characters can be rendered to the screen.

The library is based on the Adafruit GFX and Adafruit driver libraries and the aim is to retain compatibility. Significant additions have been made to the library to boost the speed for the different processors (it is typically 3 to 10 times faster) and to add new features. The new graphics functions include different size proportional fonts and formatting features. There are lots of example sketches to demonstrate the different features and included functions.

Configuration of the library font selections, pins used to interface with the TFT and other features is made by editing the User_Setup.h file in the library folder, or by selecting your own configuration in the "User_Setup_Selet,h" file. Fonts and features can easily be enabled/disabled by commenting out lines.

Anti-aliased (smooth) font files in "vlw" format are generated by the free Processing IDE using a sketch included in the library Tools folder. This sketch with the Processing IDE can be used to generate font files from your computer"s font set or any TrueType (.ttf) font, the font file can include any combination of 16 bit Unicode characters. This means Greek, Japanese and any other UCS-2 glyphs can be used. Character arrays and Strings in UTF-8 format are supported.

It would be possible to compress the vlw font files but the rendering performance to a TFT is still good when storing the font file(s) in SPIFFS, LittleFS or FLASH arrays.

Anti-aliased fonts can also be drawn over a gradient background with a callback to fetch the background colour of each pixel. This pixel colour can be set by the gradient algorithm or by reading back the TFT screen memory (if reading the display is supported).

The common 8 bit "Mcufriend" shields are supported for the STM Nucleo 64/144 boards and ESP32 UNO style board. The STM32 "Blue/Black Pill" boards can also be used with 8 bit parallel displays.

Unfortunately the typical UNO/mcufriend TFT display board maps LCD_RD, LCD_CS and LCD_RST signals to the ESP32 analogue pins 35, 34 and 36 which are input only. To solve this I linked in the 3 spare pins IO15, IO33 and IO32 by adding wires to the bottom of the board as follows:

If the display board is fitted with a resistance based touch screen then this can be used by performing the modifications described here and the fork of the Adafruit library:

If you load a new copy of TFT_eSPI then it will overwrite your setups if they are kept within the TFT_eSPI folder. One way around this is to create a new folder in your Arduino library folder called "TFT_eSPI_Setups". You then place your custom setup.h files in there. After an upgrade simply edit the User_Setup_Select.h file to point to your custom setup file e.g.:

You must make sure only one setup file is called. In the custom setup file I add the file path as a commented out first line that can be cut and pasted back into the upgraded User_Setup_Select.h file. The ../ at the start of the path means go up one directory level. Clearly you could use different file paths or directory names as long as it does not clash with another library or folder name.

An Arduino IDE compatible graphics and fonts library for Mega with a drivers for the HX8357B, HX8357C, ILI9481 and ILI9486 based TFT displays with a 16 bit parallel interface. This library will not run on an UNO and it does not support 8 bit UNO shields.

The library contains proportional fonts, different sizes can be enabled/disabled at compile time to optimise the use of FLASH memory. The library has been tested with the Mega.

In addition to the default fonts (1, 2, 4, 6, 7 and 8) the library includes and supports the encoded Free Fonts from the new Adafruit_GFX library. Unlike the Adafruit_GFX library these fonts can be automatically rendered with background and padding to over-write and erase old text, see the examples.

The library is based on the Adafruit GFX library and the aim is to retain compatibility. Significant additions have been made to the library to boost the speed for the Mega processor and to add new features. The new graphics functions include different size proportional fonts and formatting features. There are a significant number of example sketches to demonstrate the different features.

Configuration of the library font selections and other features is made by editting the User_Setup.h file in the library folder. Fonts and features can easily be disabled by commenting out lines.

This HX8357B based display does appear to have a bug in the silicon of the driver chip as it sometimes generates spurious pixels on the display. The only way around this is to redraw the whole screen occasionally to wipe out the duff ones, this is most noticeable for intensive updates in small screen areas (e.g. in ring meter sketch). So my suggestion is to go for the next revision driver, the HX8357C with 3" TFT which does not exhibit the same problem:

I don"t actually have a display at present. I purchased a 7in one some months ago. It had an LT7381 controller and was supplied with a Hunda LT7381 library for Arduino and some basic display design software. However, I couldn"t get the hardware to work despite it being described as Arduino compatible. As it turned out, it also didn"t display anything when used with the supplied USB adaptor and design software for the PC, so it may have been faulty anyway. I posted something at the time but the controller is quite new and there was not much feedback. I ended up sending it back and getting a refund although it still cost me to send it back to china.

The reason I posted was because the project is now at the stage where the LCD display really needs to be added and I intended to get advice before making another purchase. In the meantime I have been working on the project using a 20x4 display.

Thank you for that information. Since I am using an ESP8266, it sounds like I need to look for a board that uses SPI for the display. From what I can tell, it seems that some of the cheap ones from china only use SPI only for the SD card which further confuses things.

I don"t posses an Arduino shield which is why I was trying to ascertain whether I need something like that. What is their purpose? A lot of photos show the display plugged into one and then into typically a Mega 2560. I don"t understand what the purpose of the shield is? Is it just a convenient way to provide a means of fitting the board to an Arduino with level shifting? SPI needs only 4 wires. Can"t these be connected directly to the ESP SPI pins?

Find many great new & used options and get the best deals for 3.5 Inch TFT LCD Display Arduino Touch Screen Module UNO R3 Board Plug and Play at the best online prices at eBay! Free shipping for many products!

I suggest that you use Bodmer"s TFT_HX8357.h library. Configure User_Setup.h for ILI9486. Not inherited from Adafruit_GFX but uses similar methods.

I started with an Arduino DUE board that I"ve added WiFi and SD breakout modules to. I have a 2.8" TFT display that works fine using this GitHub - marekburiak/ILI9341_due: Arduino Due and AVR (Uno, Mega, Nano, Pro Mini,...) library for interfacing with ILI9341 SPI TFTs and JPEGDecoder. Unfortunately, this display has bad color distortion at various viewing angles so I"d like to replace it with slightly larger 3.5" 320x480 displays.

I have a WaveShare 3.5" that supposedly uses ILI9486 and appears a bit better at various viewing angles, but I"ve only gotten it working using ILI9488 from GitHub - jaretburkett/ILI9488: Arduino Library for the ILI9488 TFT controller for 4 wire SPI - mostly because I can"t find a ILI9486_DUE type of library...I believe that HX8357 can work, but I ran into trouble using it. While I can use Bodmer"s TFT_HX8357_Due version, it"s missing the ILI9486 driver that got merged into the regular TFT_HX8357 version. I can"t use the regular TFT_HX8357 since I"m on a due. (Should I be trying to merge these two?) The sample code provided with the display isn"t for due either (https://www.waveshare.com/wiki/3.5inch_TFT_Touch_Shield) but I"d rather work with something closer to what I"m used to if I can also.

The WaveShare mostly works for me; I am able to draw background colors, write text, and so on using the ILI9488 driver. This is the code that"s specifically giving me trouble with ILI9488 and the JPEGDecoder library:

I"ve tried both of the methods above and the first line (pushColor) produces distorted grey blocks with a slight resemblance of the original JPG, whereas the latter (pushColors) simply produces no output to the TFT for me.

This is all probably pretty vague, but I"m hoping someone a bit more familiar with this sort of thing can help steer me in the right direction... Should I be trying to modify the pushColor/pushColors functionality of the ILI9488 driver, or should I be using a different driver? Should I try merging the ILI9486 driver from TFT_HX8357 into TFT_HX8357_DUE? Should I be trying to use the ILI9341_DUE driver that I had working with the 2.8" display but adapting it to these WaveShare 3.5" displays?

Have been dealing with this for quite some time now but only granted with a white screen so I must do something wrong or the display is simple broken. Haven"t dealt with TFT screens before but they seemed to be easier to control then I though, if I can get one to work that is. Have gone through similar topic suggestions here but no one have used the same screen so no help there.

Have defined the pins for a the Mega but examples I have tried so are some names not existing on the TFT or vice-versa or can"t find where to put them even if i normally find the places in some .h file.

Have tested fex some examples in mcufriedn_kbv (yea I know its for UNO but hey worth a try), some UTFT and what not but the TFT I have don"t have the same pin names that many libs and examples needs so of course nothing works I guess. And the tft doesnt have "read" pin so It can"t be identified either.

Anyone have a lib or just some extremely simple example that accepts the pins the screen have and that would guaranteed work with this TFT, just so I know that it work or just anything?
