Retina Display is a brand name used by Apple for its series of IPS LCD and OLED displays that have a higher pixel density than traditional Apple displays.trademark with regard to computers and mobile devices with the United States Patent and Trademark Office and Canadian Intellectual Property Office.

The Retina display debuted in 2010 with the iPhone 4 and the iPod Touch (4th Generation), and later the iPad (3rd generation) where each screen pixel of the iPhone 3GS, iPod touch (3rd generation), iPad 2 was replaced by four smaller pixels, and the user interface scaled up to fill in the extra pixels. Apple calls this mode HiDPI mode. In simpler words, it is one logical pixel = four physical pixels. The scale factor is tripled for devices with even higher pixel densities, such as the iPhone 6 Plus and iPhone X.

The Retina display has since expanded to most Apple product lines, such as Apple Watch, iPhone, iPod Touch, iPad, iPad Mini, iPad Air, iPad Pro, MacBook, MacBook Air, MacBook Pro, iMac, and Pro Display XDR, some of which have never had a comparable non-Retina display.marketing terms to differentiate between its LCD and OLED displays having various resolutions, contrast levels, color reproduction, or refresh rates. It is known as Liquid Retina display for the iPhone XR, iPad Air 4th Generation, iPad Mini 6th Generation, iPad Pro 3rd Generation and later versions,Retina 4.5K display for the iMac.

Apple"s Retina displays are not an absolute standard for display sharpness, but vary depending on the size of the display on the device, and at what distance the user would typically be viewing the screen. Where on smaller devices with smaller displays users would view the screen at a closer distance to their eyes, the displays have more PPI (Pixels Per Inch), while on larger devices with larger displays where the user views the screen further away, the screen uses a lower PPI value. Later device versions have had additional improvements, whether an increase in the screen size (the iPhone 12 Pro Max), contrast ratio (the 12.9” iPad Pro 5th Generation, and iMac with Retina 4.5K display), and/or, more recently, PPI count (OLED iPhones); as a result, Apple uses the names “Retina HD display", "Retina 4K/5K display", “Retina 4.5K display", "Super Retina HD display", “Super Retina XDR display”, and "Liquid Retina display" for each successive version.

When introducing the iPhone 4, Steve Jobs said the number of pixels needed for a Retina display is about 300 PPI for a device held 10 to 12 inches from the eye.skinny triangle with a height equal to the viewing distance and a top angle of one degree will have a base on the device"s screen that covers 57 pixels. Any display"s viewing quality (from phone displays to huge projectors) can be described with this size-independent universal parameter. Note that the PPD parameter is not an intrinsic parameter of the display itself, unlike absolute pixel resolution (e.g. 1920×1080 pixels) or relative pixel density (e.g. 401 PPI), but is dependent on the distance between the display and the eye of the person (or lens of the device) viewing the display; moving the eye closer to the display reduces the PPD, and moving away from it increases the PPD in proportion to the distance.

In practice, thus far Apple has converted a device"s display to Retina by doubling the number of pixels in each direction, quadrupling the total resolution. This increase creates a sharper interface at the same physical dimensions. The sole exception to this has been the iPhone 6 Plus, 6S Plus, 7 Plus, and 8 Plus, which renders its display at triple the number of pixels in each direction, before down-sampling to a 1080p resolution.

The displays are manufactured worldwide by different suppliers. Currently, the iPad"s display comes from Samsung,LG DisplayJapan Display Inc.twisted nematic (TN) liquid-crystal displays (LCDs) to in-plane switching (IPS) LCDs starting with the iPhone 4 models in June 2010.

Apple markets the following devices as having a Retina display, Retina HD display, Liquid Retina display, Liquid Retina XDR display, Super Retina HD display, Super Retina XDR display or Retina 4K/5K/6K display:

Reviews of Apple devices with Retina displays have generally been positive on technical grounds, with comments describing it as a considerable improvement on earlier screens and praising Apple for driving third-party application support for high-resolution displays more effectively than on Windows.T220 and T221 had been sold in the past, they had seen little take-up due to their cost of around $8400.

Writer John Gruber suggested that the arrival of Retina displays on computers would trigger a need to redesign interfaces and designs for the new displays:

The sort of rich, data-dense information design espoused by Edward Tufte can now not only be made on the computer screen but also enjoyed on one. Regarding font choices, you not only need not choose a font optimized for rendering on screen, but should not. Fonts optimized for screen rendering look cheap on the retina MacBook Pro—sometimes downright cheesy—in the same way they do when printed in a glossy magazine.

Raymond Soneira, president of DisplayMate Technologies, has challenged Apple"s claim. He says that the physiology of the human retina is such that there must be at least 477 pixels per inch in a pixelated display for the pixels to become imperceptible to the human eye at a distance of 12 inches (305 mm).Phil Plait notes, however, that, "if you have [better than 20/20] eyesight, then at one foot away the iPhone 4S"s pixels are resolved. The picture will look pixelated. If you have average eyesight [20/20 vision], the picture will look just fine... So in my opinion, what Jobs said was fine. Soneira, while technically correct, was being picky."

Apple fan website CultOfMac hosts an article by John Brownlee"Apple"s Retina Displays are only about 33% of the way there."visual acuity in the population saying "most research suggests that normal vision is actually much better than 20/20" when in truth the majority have worse than 20/20 vision,WHO considers average vision as 20/40.presbyopia

The first smartphone following the iPhone 4 to ship with a display of a comparable pixel density was the Nokia E6, running Symbian Anna, with a resolution of 640 × 480 at a screen size of 62.5mm. This was an isolated case for the platform however, as all other Symbian-based devices had larger displays with lower resolutions. Some older Symbian smartphones, including the Nokia N80 and N90, featured a 2.1 inch display at 259 ppi, which was one of the sharpest at the time. The first Android smartphones with the same display - Meizu M9 was launched a few months later in beginning of 2011. In October of the same year Galaxy Nexus was announced, which had a display with a better resolution. By 2013 the 300+ ppimark was found on midrange phones such as the Moto G.Samsung Galaxy S4 and HTC One (M8) had 1080p (FHD) screens around 5-inches for a 400+ PPI which surpassed the Retina density on the iPhone 5. The second major redesign of the iPhone, the iPhone 6, has a 1334 × 750 resolution on a 4.7-inch screen, while rivals such as the Samsung Galaxy S6 have a QHD display of 2560 × 1440 resolution, close to four times the number of pixels found in the iPhone 6, giving the S6 a 577 PPI that is almost twice that of the iPhone 6"s 326 PPI.

The larger iPhone 6 Plus features a "Retina HD display", which is a 5.5-inch 1080p screen with 401 PPI. Aside from resolution, all generations of iPhone Retina displays receive high ratings for other aspects such as brightness and color accuracy, compared to those of contemporary smartphones, while some Android devices such as the LG G3 have sacrificed screen quality and battery life for high resolution. Ars Technica suggested the "superfluousness of so many flagship phone features—the move from 720p to 1080p to 1440p and beyond...things are all nice to have, but you’d be hard-pressed to argue that any of them are essential".

One of today’s modern technological wonders is the flat-panel liquid crystal display (LCD) screen, which is the key component we find inside televisions, computer monitors, smartphones, and an ever-proliferating range of gadgets that display information electronically.What most people don’t realize is how complex and sophisticated the manufacturing process is. The entire world’s supply is made within two time zones in East Asia. Unless, of course, the factory proposed by Foxconn for Wisconsin actually gets built.

Liquid crystal display (LCD) screens are manufactured by assembling a sandwich of two thin sheets of glass.On one of the sheets are transistor “cells” formed by first depositing a layer of indium tin oxide (ITO), an unusual metal alloy that you can actually see through.That’s how you can get electrical signals to the middle of a screen.Then you deposit a layer of silicon, followed by a process that builds millions of precisely shaped transistor parts.This patterning step is repeated to build up tiny little cells, one for each dot (known as a pixel) on the screen.Each step has to be precisely aligned to the previous one within a few microns.Remember, the average human hair is 40 microns in diameter.

On the other sheet of glass, you make an array of millions of red, green, and blue dots in a black matrix, called a color filter array (CFA).This is how you produce the colors when you shine light through it.Then you drop tiny amounts of liquid crystal material into the cells on the first sheet and glue the two sheets together.You have to align the two sheets so the colored dots sit right on top of the cells, and you can’t be off by more than a few microns in each direction anywhere on the sheet.The sandwich is next covered with special sheets of polarizing film, and the sheets are cut into individual “panels” – a term that is used to describe the subassembly that actually goes into a TV.

For the sake of efficiency, you would like to make as many panels on a sheet as possible, within the practical limitations of how big a sheet you can handle at a time.The first modern LCD Fabs built in the early 1990s made sheets the size of a single notebook computer screen, and the size grew over time. A Gen 5 sheet, from around 2003, is 1100 x 1300 mm, while a Gen 10.5 sheet is 2940 x 3370 mm (9.6 x 11 ft).The sheets of glass are only 0.5 - 0.7 mm thick or sometimes even thinner, so as you can imagine they are extremely fragile and can really only be handled by robots.The Hefei Gen 10.5 fab is designed to produce the panels for either eight 65 inch or six 75 inch TVs on a single mother glass.If you wanted to make 110 inch TVs, you could make two of them at a time.

The fab is enormous, 1.3 km from one end to the other, divided into three large buildings connected by bridges.LCD fabs are multi-story affairs.The main equipment floor is sandwiched between a ground floor that is filled with chemical pipelines, power distribution, and air handling equipment, and a third floor that also has a lot of air handling and other mechanical equipment.The main equipment floor has to provide a very stable environment with no vibrations, so an LCD fab typically uses far more structural steel in its construction than a typical skyscraper.I visited a Gen 5 fab in Taiwan in 2003, and the plant manager there told me they used three times as much structural steel as Taipei 101, which was the world’s tallest building from 2004- 2010.Since the equipment floor is usually one or two stories up, there are large loading docks on the outside of the building.When they bring the manufacturing equipment in, they load it onto a platform and hoist it with a crane on the outside of the building.That’s one way to recognize an LCD fab from the outside – loading docks on high floors that just open to the outdoors.

LCD fabs have to maintain strict standards of cleanliness inside.Any dust particles in the air could cause defects in the finished displays – tiny dark spots or uneven intensities on your screen.That means the air is passed through elaborate filtration systems and pushed downwards from the ceiling constantly.Workers have to wear special clean room protective clothing and scrub before entering to minimize dust particles or other contamination.People are the largest source of particles, from shedding dead skin cells, dust from cosmetic powders, or smoke particles exhaled from the lungs of workers who smoke.Clean rooms are rated by the number of particles per cubic meter of air.A class 100 cleanroom has less than 100 particles less than 0.3 microns in diameter per cubic meter of air, Class 10 has less than 10 particles, and so on. Fab 9 has hundeds of thousands of square meters of Class 100 cleanroom, and many critical areas like photolithography are Class 10.In comparison, the air in Harvard Square in Cambridge, MA is roughly Class 8,000,000, and probably gets substantially worse when an MBTA bus passes through.

The Hefei Gen 10.5 is one of the most sophisticated manufacturing plants in the world.On opening day for the fab, BOE shipped panels to Sony, Samsung Electronics, LG Electronics, Vizio, and Haier.So if you have a new 65 or 75-inch TV, there is some chance the LCD panel came from here.

CUPERTINO, CALIFORNIA Apple today announced the new 14- and 16-inch MacBook Pro featuring M2 Pro and M2 Max, Apple’s next-generation pro silicon that brings even more power-efficient performance and battery life to pro users. With M2 Pro and M2 Max — the world’s most powerful and efficient chip for a pro laptop — MacBook Pro tackles demanding tasks, like effects rendering, which is up to 6x faster than the fastest Intel-based MacBook Pro, and color grading, which is up to 2x faster.1 Building on the unprecedented power efficiency of Apple silicon, battery life on MacBook Pro is now up to 22 hours — the longest battery life ever in a Mac.2 For enhanced connectivity, the new MacBook Pro supports Wi-Fi 6E,3 which is up to twice as fast as the previous generation, as well as advanced HDMI, which supports 8K displays for the first time. With up to 96GB of unified memory in the M2 Max model, creators can work on scenes so large that PC laptops can’t even run them.4 Rounding out the unrivaled features of MacBook Pro are its renowned Liquid Retina XDR display, extensive array of connectivity, 1080p FaceTime HD camera, six-speaker sound system, and studio-quality mics. When combined with macOS Ventura, the MacBook Pro user experience is unrivaled. Customers can order the new 14- and 16-inch MacBook Pro today, with availability beginning Tuesday, January 24.

MacBook Air features a new, strikingly thin design in four beautiful finishes, larger 13.6-inch Liquid Retina display, 1080p HD camera, MagSafe charging, and more

CUPERTINO, CALIFORNIA Apple today introduced a completely redesigned MacBook Air and an updated 13-inch MacBook Pro, both powered by the new M2 chip — which takes the breakthrough performance and capabilities of M1 even further. MacBook Air takes everything users love about the world’s best-selling laptop to the next level. With an all-new, strikingly thin design and even more performance, MacBook Air also features a larger 13.6-inch Liquid Retina display, a 1080p FaceTime HD camera, four-speaker sound system, up to 18 hours of battery life,1 and MagSafe charging. It is now available in four finishes — silver, space gray, midnight, and starlight. M2 also comes to the 13-inch MacBook Pro, the world’s second best-selling laptop — delivering incredible performance, up to 24GB of unified memory, ProRes acceleration, and up to 20 hours of battery life,2 all in a compact design. The new MacBook Air and updated 13-inch MacBook Pro join the even more powerful 14- and 16-inch MacBook Pro with M1 Pro and M1 Max to round out the strongest lineup of Mac notebooks ever offered. Both laptops will be available next month.

The new MacBook Air features a gorgeous 13.6-inch Liquid Retina display, which has been expanded closer to the sides and up around the camera to make room for the menu bar. The result is a larger display with much thinner borders, giving users more screen real estate to view their content in brilliant detail. At 500 nits of brightness, it is also 25 percent brighter than before. In addition, the new display now supports 1 billion colors, so photos and movies look incredibly vibrant.

With macOS Monterey and Apple silicon, MacBook Air and the 13-inch MacBook Pro deliver even more performance and productivity for users. Continuity tools like Universal Control make it easy for users to work effortlessly across Mac and iPad, while AirPlay to Mac enables users to play just about anything from their iPhone or iPad right to their Mac’s stunning Retina display. FaceTime includes audio and video features, including Portrait mode and Spatial Audio that make calls feel more natural and lifelike, while SharePlay enables Mac users to have shared experiences through FaceTime.14 Live Text and Visual Look Up use intelligence to surface useful information, Safari includes powerful tab organization with Tab Groups, and Shortcuts brings the ease of automation to the Mac.

So, naturally, questions arise: Why are we seeing Retina displays in iPads but not in Samsung"s own Galaxy-branded tablets? Why would Samsung allow itself to be trumped by a mere customer?

Example: While Samsung pumps out tens of thousands of high-end LCD panels for Apple, the two companies remain embroiled in longstanding intellectual property litigation, with Apple accusing Samsung of blatantly ripping off the iOS user interface, as well as Apple"s iconic product designs.

Apple has used Retina Display screens in the iPhone and other devices for years, but it launched the iPhone 11 with a different type of screen: a Liquid Retina Display (LRD), which is a type of Liquid Crystal Display (LCD) only Apple uses.

Liquid Retina Display differs from other types of screens in some subtle, background ways; to understand what an LRD is, you first have to understand what a basic Retina Display is.

Essentially, a basic Retina Display is a screen with so many pixels packed tightly next to each other that you can"t see individual pixels or jagged lines on the screen, even when looking very closely. The result is a super-high-resolution screen with a high pixel density, which makes the images and videos appear much more clearly than with other types of displays.

A Liquid Retina Display builds upon that basic retina display by adding a Liquid Crystal Display (LCD), a standard type of screen found in computer monitors, laptop screens, smartphones, tablets, and other devices for many years. It"s a tried and true technology that"s been around for years.

LRD uses 10,000 LEDs in its pixelated display and combines the haptic effects and contrast ratios from basic retina displays to produce a higher level of pixels per inch (PPI). That can give a screen a paper-like effect with improved brightness and color.

The technologies used to manufacture the screen are the major difference between the Liquid Retina Display screen in, say, a standard iPhone and the Super Retina XDR display of an iPhone Pro.

The Super Retina XDR screens found in some Apple products use Organic Light Emitting Diode (OLED) screens, a more modern screen technology that delivers brighter colors and deeper blacks while using less power than LCDs.

Screen Technology:Liquid Retina Display screens are made using the older LCD technology rather than the newer OLED used in Super Retina XDR and HD displays.

Pixel Density:Liquid Retina Displays have a pixel density of either 326 pixels per inch (ppi) or 264 ppi (on iPads). Both the Super Retina HD and XDR displays sport 458 ppi pixel density.

Contrast Ratio:The contrast ratio on Liquid Retina Displays is 1400:1. A Super Retina HD display has a 1,000,000:1 ratio, while a Super Retina XDR has a 2,000,000:1 ratio. Contrast ratio effects the range of colors the screen can display and the depth of its blacks.

Battery Life:This is less easy to quantify since so many things go into how long batteries last, but OLED screens in the Super Retina HD and XDR screens generally use less power than the LCD screens in the Liquid Retina Display.

An always-on Retina display is a feature of the Apple Watch that means features such as the time, watch face, and most recent active app are always visible.

Apple recommends cleaning your MacBook Retina display (or cleaning any Mac display) with the cloth that came with the device. Or, use any dry, soft, lint-free cloth to wipe away dust. If more cleaning is needed, dampen the cloth with water or a designated screen cleaner and gently wipe the screen. Ensure moisture doesn"t get into any openings.

After the announcement of the three iPhone XS, XS Max and XR devices, it seemed to us that the iPhone XR and iPhone XS were similar in some basic points such as the processor, face fingerprint devices, wireless charging, imaging, and all the sensors. And different in several points, where the XS surpasses the XR in the RAM, the type of screen, the XS has stainless steel edges and the XR has aluminum edges, for more information follow this the article. But the most important difference is the screen that comes with the LCD in the XR. This article will get to know the screen that Apple praised and together we will see the advanced technology that Apple provided in it, and why did it say that it is not like any other LCD screen in the world?

IPhone XS and XS Max are equipped with an "OLED" Super Retina screen as opposed to the iPhone XR screen of the "LCD" Liquid Retina type. Apple described the latter that the phone screen is "the most advanced at all in a smartphone", so what"s new?

It is worth noting that OLED technology has spread widely in consumer technology products in the past few years. And if you are going to buy a smartphone or even a TV, your best option is OLED screens, not LCDs.

As we know that OLED screens lighting is in the same pixel and do not need backlight. This means that the black parts of the pixel are completely off and have no kind of lighting, and are not affected by the lighting of the pixel next to it, thus saving energy greatly. Unlike LCD screens that need backlighting even if the background is black, this lighting works with the phone running directly.

It is assumed that this difference, which we mentioned, makes it difficult to hide the protrusion in the iPhone XR by setting appropriate wallpapers for it. But the matter is different with the iPhone XS, the protrusion can disappear or fade into a background with a black bar at the top of the screen. Accordingly, it is assumed that the LCD screen of the iPhone XR still carries some light around the bump, even if the background is black, and you will not be able to do anything to hide that protrusion.

So how can Apple claim that the LCD screen outperforms all other smartphones? Perhaps thanks to the new technology that Apple developed for the first time in those screens, which is Liquid Retina, what is this new technology and what is its mechanism of action?

It is known that the term Retina means "retina" launched by Apple, starting with the screens of the iPhone 4, after it worked to increase the pixel density, so that the image is high-resolution and clarity. And what Apple presented in the XR screen is as follows:

Can someone explains to me when many non-iPhones have higher LCD PPI than iPhone XR at 326 PPI screen is called advanced by this statement in article ? "the iPhone XR includes a 6.1-inch Liquid Retina Display, which is an advanced LCD display."

Can someone explains to me when many non-iPhones have higher LCD PPI than iPhone XR at 326 PPI screen is called advanced by this statement in article ? "the iPhone XR includes a 6.1-inch Liquid Retina Display, which is an advanced LCD display.”

Have you ever properly checked the display quality of the LCD you habitually use? Very often people become aware of previously unnoticed problems in display quality when they run a check using test patterns and so on. This time we are going to talk about the basic points used to assess LCD display quality, and show you a simple way to test it.

Below is the translation from the Japanese of the ITmedia article "The difference in image quality is perfectly obvious! – Let"s check the LCD"s monitor" published April 22, 2010. Copyright 2011 ITmedia Inc. All Rights Reserved.

That"s right. The answer is "LCD" (it is displayed if you drag the space between the brackets). We assume that probably many users could read the letters concealed in the squares.

This time the answer is "EIZO" (it is displayed if you drag the space between the brackets). Depending on the lighting or the user"s environment it may be hard to make out but, if you can read these four letters, the display quality, or more accurately the still image gradation expression, of your LCD is extremely high.

Let"s get down to details then. "Image quality" is the top priority of the LCD, of course. However, recently LCD prices are fiercely competitive and there are surprisingly few products that insist on high image quality and performance. It may be nice to be able to get hold of a wide-screen monitor with full HD (1920 × 1080 dot) resolution or higher fairly cheaply, but it cannot be denied that such LCDs tend not to place too much importance on display quality.

On the other hand, the increasing opportunities to enjoy things like HD videos and games, and high resolution digital photographs on the computer make LCD display quality even more important. As far as possible it"s best to use an LCD with excellent display quality in order to fully enjoy the charms of the visual content.

Even so, perhaps you think that there can"t really be that much wrong with the LCDs that so many people are using at the moment. Here we would like to show you a simple method to check LCD display quality. You can get a good idea of whether the basic display quality is good or bad just by looking at how some simple test images are displayed, just like in the introductory quiz. First of all, we would like you to get a sense of how important it is that "image data can be properly displayed" by checking the display of the LCD that you currently use, (that"s right, the one you are using to view this page!).

Before starting your visual check of the display quality, please return to your LCD"s setting to default, and select Adobe RGB or sRGB as the image quality mode. If these modes are not available it is fine to set the color temperature to 6500K and gamma to 2.2. If you cannot adjust the color temperature and gamma, simply adjust the brightness and contrast so that they are easier to discern. Of course, if it"s an LCD environment that has been color calibrated it"s OK to leave it as it is.

The average LCD takes some time for the monitor to stabilize after it is switched on so, after start up, please wait at least 30 minutes or so before doing the test. (Most EIZO monitors are an exception to this as they are equipped with our proprietary dimming function and the monitor stabilizes in a short time after start up.)

The surface treatment of an LCD makes a difference to the background reflection. Glare panels impede the surface diffusion of backlight, which does make it easier to achieve high color purity, but also makes distinct reflections of the user or lighting much more likely (photo on the left).

If the lights are similarly trained on a non-glare panel they do not have much effect on the display, only appearing as a fuzzy brightness (photo on the right).

For your reference, we ran a test on an EIZO 24.1-inch wide-screen LCD, the FlexScan SX2462W, for this article. The FlexScan SX series comes with a number of high image quality functions and boasts top class display quality as a general-purpose LCD intended for a computer.

When checking the display quality of an LCD it is comparatively easy to understand the gradation expression capability by a visual check. Let"s display color and monochrome gradation images and check whether the entire image is smoothly reproduced. If there is a problem with the gradation expression it produces things like blocked-up shadows in dark areas and blown-out highlights in light areas, banding (vertical or horizontal stripes) in the middle gradations, and color cast, so you should check for problems like these.

Test images of color / monochrome gradations are shown below. Each test image is prepared for three resolution levels (1280 × 800 dots / 1680 × 1050 dots / 1920 × 1200 dots). When you click on an image it is displayed in that actual resolution. We would like you to download the images in the resolution which matches that of your current LCD. Gradation expression can vary according to whether the image is viewed horizontally or vertically, so it will be more effective if you rotate these images and view them vertically as well.

A gradation pattern where the colors red, green, blue, cyan, magenta and yellow go through 64 gradients as they change to white or black. Each color bar is divided into 64 rectangular blocks. With this many gradients we expect that many LCDs will find it hard to make distinctions in the dark areas or the areas that are close to primary colors.

A smooth gradation pattern where the colors red, green, blue, cyan, magenta and yellow go through 256 gradients as they change to white or black. At this level of difficulty you cannot distinguish between adjoining colors from a distance but, if you have an LCD with excellent gradation expression, if you look closely you should be able to see that each color is divided into thin rectangular blocks.

On an average LCD gradations of gray that are close to black tend to appear as blocked-up shadows (gradations of gray that are close to white are displayed comparatively accurately). If your LCD"s OSD menu allows you to adjust the contrast, please try gradually turning down the contrast. Turning down the contrast often makes it possible to see gradations that had been subject to blocked-up shadows or blown-out highlights.

Probably most LCDs will be able to detect some degree of banding and color cast in the middle gradations. Banding in the middle gradations is tone jump (Missing gradations) and, along with color cast, means that the RGB gamma curves are unequal. Unlike blocked-up shadows or blown-out highlights, this is an area that it is hard to improve with adjustments made by the user.

The answer is "The far right" (it is displayed if you drag the space between the brackets). If the other grays looked correct, color may not be being correctly recognized for a variety of reasons, such as the lighting environment or the LCD settings.

Now let"s assess the gradation expression with some slightly different test images. Below are color patterns with a spread of pale colors in gradations close to the dark range and the light range. They are arranged so that a distinction cannot be made between adjoining colors on an LCD with insufficient gradation expression.

We expect that you could roughly get the whole picture in the gradation patterns on the previous page, but in the patterns this time some parts that cannot be seen may have appeared in some cases. As we mentioned earlier, LCDs tend to display gradations close to black as a blocked-up shadows, and color patterns that are close to black are particularly hard to distinguish.

Since there are some parts that cannot be seen, the possibility arises subtle skin colors and tones cannot be accurately recognized when doing things like retouching photographs, though the misrecognition will vary according to the user"s eyesight. People who place importance on color reproduction should probably bear this in mind when they think about replacing their LCD or buying an extra one.

Every LCD has some degree of brightness and chromaticity variation, but there are many products where the variations become more obvious when the brightness is lowered. A comparison of the brightness and chromaticity variation of a number of LCDs reveals that there is a fairly large difference between products, so this is a point to bear in mind.

If you actually try this test you may be surprised to find more variation than you expected when gray or a near-white pale color is displayed. Generally speaking, the center of an LCD screen is the brightest and it gradually gets darker towards the edges. This is no problem if there is not a big difference in brightness between the central and peripheral areas, but there are some products where this difference is very striking.

Incidentally, this test is also an effective way to test the LCD for dot defects (normal lighting / unlit room). We would like you to check the black display in a darkened environment, for example by switching off all the room lights at night. Although you probably saw the whole screen as uniformly black in a light environment, very often in a dark environment you can find variations in some parts due to light leaks.

Monochrome full-screen displays on a FlexScan SX2462W. Only the screen display is shown. The bottom right is a near-white pale orange. There are not many LCDs that can display this kind of pale color as uniformly as this

However, the pitfall here is that it simply means that "the screen is visible". The thing is that the viewing angle specifications are permitted to use the term "visible" until the display contrast ratio drops to an extremely low 10:1 or 5:1 when the screen is viewed from an angle (the steeper the angle from which the LCD screen is viewed, the more the contrast generally declines). In other words, they do not take into account the display uniformity of the central and peripheral areas of the screen, or the level of chromatic change, when the screen is viewed from an angle.

The ideal viewing angles is that the brightness and chromaticity is very uniform and there is not much chromatic change, even when the screen is viewed from a slight angle. The viewing angles given in the specifications are not really very helpful, but you can judge the standard of the panel type that the LCD (liquid crystal panel) adopts. IPS liquid crystal panels have the least change in brightness or chromaticity when the screen is viewed from an angle, and they are followed by VA panels. An IPS or VA liquid crystal panel can be said to indicate the superior nature of the product itself, so this is often included in the catalog or specifications. It is probably a good idea to look through the catalogs of various products.

On the other hand, monitors installed with cost-effective TN liquid crystal panels are in fact the most numerous. However, the TN type lags far behind the IPS and VA types in terms of characteristic viewing angle changes in brightness and chromaticity. Simply viewing the screen from a slightly different angle makes the coloration change dramatically, and the screen looks completely different according to whether it is viewed vertically or horizontally. If the vertical and horizontal viewing angles in the specifications are different then it is a TN type. There are quite a few products with a 20-inch wide screen or larger where colors look different in the central and peripheral areas even when the screen is viewed straight on.

The display on an IPS panel. Even when viewed from this angle, the displayed content can of course be distinguished completely and the colors also show up really well

The display on a VA panel. Compared with the IPS panel the screen is a little whitish and the chromaticity has slipped, but it is a satisfactory viewing angle for actual use

The display on a TN panel. There is a very clear difference from the IPS and VA panels. The display throughout the entire screen lacks uniformity and there is a yellow cast

When we checked the viewing angles of the FlexScan SX2462W there was absolutely nothing to criticize since, in addition to the use of an IPS panel, it is equipped with many high image quality functions, including the afore-mentioned digital uniformity correction circuit. The brightness and chromaticity throughout the whole screen is very uniform, and the coloration hardly changed at all when the viewing angle was changed.

We explained here about easy ways to check LCD monitor quality. How were the results for your current LCD? We think that many people were probably very bothered by the blocked-up shadows and blown-out highlights when the test images to check gradation were displayed, by the middle gradation banding, and by the variations in brightness and chromaticity when the monochrome images were displayed.

As we mentioned at the beginning, recently the number of LCDs with excellent display quality is on the decline. Although we would not go so far as to say that the display quality of inexpensive products is poor. Of course a high quality LCD is indispensable if you want to enjoy using your computer, properly handle the needs of applications that require color reproducibility, and to fully enjoy all the benefits of rich content.

The EIZO FlexScan LCD series has excellent display quality in those regards, and we have no qualms about recommending them to everyone. The product line-up is diverse but each model is clearly ranked according to the purpose to which it is suited and its screen size, and they all guarantee above-standard display quality. They may cost a little more than you had budgeted for but the clear value they offer exceeds their price.

If, after trying these tests, you have doubts about the display quality of the LCD that you usually use, we would certainly urge you to consider an EIZO LCD. We would also recommend that you construct a multi-display environment by making the new LCD your main monitor and the one that you have been using your sub monitor.

The iPhone XR also has "wireless" -- or more precisely inductive -- charging capability, as well as stereo speakers, a Lightning port, and a side-mounted Nano SIM access panel on the right side. All models support dual SIMs, but the A2108 China/Hong Kong model is the only one with dual physical Nano SIMs with others supporting one physical and one eSIM.

Additionally, the iPhone XR has a haptic-touch capable 6.1" LCD "Liquid Retina HD" display (1792x828, 326 ppi, 1400:1 contrast ratio). This is not an OLED and it does not support 3D Touch, either.

Apple on Friday posted a new promotional video to its official YouTube channel. Running one minute and ten seconds long, it highlights the company’s Liquid Retina display technology along with all the colors that the $749 iPhone XR is available in.

“Make room for color,” reads the video’s description. “See the all-screen Liquid Retina display on iPhone XR with the best battery life in an iPhone.”

Apple claims Liquid Retina Display, which uses LCD technology as opposed to the newer OLED panels used in the iPhone X and XS series, is the most color-accurate mobile LCD out there.
