Almost all the RGB cables you’ll use with your consoles have a SCART connector.  You’ll need special cables to connect SCART to the connector your RGB display or scaler accepts.  Also, if you ever plan on having more than one system hooked up to your RGB display, you’ll definitely want a SCART switch (as described in the next section), but make sure to read this section first.  Here’s the adapters needed for the most common scenarios:

The most common RGB monitors accept RGB via BNC connectors.  If you have a SCART switch with a female output port (switches are explained in the next section), you should get cable with a male SCART end.  This is the most common and recommended choice (bonus:  It’s switchable between input and output):

If you’re only hooking one system into the monitor, or have a SCART switch with a cabled output, you’ll want a female SCART end, so the cable from your system or switch can plug directly into it:

In the rare occasion that your monitor or switch only accepts csync, you’ll need a cable with a sync stripper built in.  Unless you absolutely need one, get the above cable without a sync stripper instead:

– Good quality RCA cables to connect the converter and monitor.  Please don’t use ones left over from your old cable box…and please, please don’t be dumb and spend $100 on Monster cables.  You probably have a good set of RCA’s laying around somewhere, but if not, just get a decent set online.  You’ll need 6 total:  4 for video, 2 for audio.

Personally, I’d recommend getting one of the the direct SCART to BNC cables with audio-out built in listed above.  I wanted to mention the other solution, in case you needed them to accomplish something different (although I’m not sure what), but it’s much easier to just buy the right cable to begin with.

All other monitor, upscaler or converter methods will have similar cable solutions to the ones I described above, or just accept SCART directly.  Basically, if your solution doesn’t have SCART or BNC inputs, I suggest googleing to see if anyone else has successfully used retro consoles through that display.

If not, head over to the section that shows you how to get RGB from each game system!  That section also has info on audio enhancements, which versions of each system output the best quality, plus some other awesome info!

Looking for wholesale monitor with scart? Look no further than Alibaba.com, one of the largest collections of wholesale shipment suppliers in the world. We have a huge range of lcd computer monitor options and lcd display screen options to choose from. Whether you need a small lcd screen or a large one, we have you covered.

These monitor with scart products have become the go to display types for computers today. With tft color monitors slowly being phased out, lcd computer monitor displays are the standard in the industry. All customers need a flat screen computer monitor to interact with their personal computers. For ardent gamers that require high refresh rates to minimize lagging and make use of high performance computers there are a range of lcd gaming monitors available.

We also have more specialised products like rack mounted monitors for IT administrators and network administrators working in commercial settings. These monitors are used to oversee large server rooms and network infrastructure. New transparent lcd screen options are also coming on the market that are futuristic and allow for a sleek look to fit modern aesthetics.

So, start ordering your shipment of monitor with scart today from our suppliers. They are ready and willing to answer any questions you may have about their products and get you started today!

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

These handy little boards are designed to fit inside most common SCART cables and convert composite video to clean sync. Ideal for users of monitors or RGB switches (such as an Extron Crosspoint) that require a clean sync signal, or for XRGB3 users. These sync in SCART boards are much cheaper and much tidier than buying an external sync cleaner such as a Sync Strike. For full fitting instructions see this page.

Please note that the LM1881 outputs TTL-level sync. This is fine for devices like the Extron Crosspint, but If you are connecting to  a device that’s expecting 75 ohm video-level sync (e.g OSSC or any consumer television with SCART input), then you must add a 470 ohm, 1/4 watt resistor to the output line. Usually, there’s no need to use a sync stripper with these particular devices however.

Take the guesswork out of connecting retro consoles, superguns and other hardware to your valuable upscalers or vintage CRT monitors with the Retro Sampling SCART tester board.

This handy device fits between your games console or your SCART output source and your display or upscaler. Once in place, the test board gives you an easy way to test your SCART cable with your scope or multi-meter while it is in-circuit. No more opening up your SCART cables, no more awkward fumbling at the back of the TV.

Using the SCART tester you can verify the correct voltage and resistance on the sync and RGB lines, check for the presence of blanking voltage or simply make sure your cable is correctly grounded.

RetroRGB has discussed at length how badly configured hardware can actually damage your equipment by supplying too much voltage. For anyone interested in this topic we highly recommend his information page on Oscilloscope Basics. Now these voltages can be tested easily and quickly without risking damage to your SCART cable.

Imagine, You have many retro system in use. Amiga, Atari ST, ZX spectrum, etc... And You have only one classical TV/Monitor with one SCART INPUT. Each time, You want to switch system, You have to connect Your machine to Your monitor. Everytime, You do it - You damage scart socket inside. Those days are over. Connect up to 8 computers/consoles to HYDRA, then connect HYDRA to Your TV/Monitor and power on hydra with You mobile phone charger with MICRO USB plug. Since now, HYDRA will detect active scart input and forward all signals to Your monitor. Simple and efficent.

Designing device, I put much effort into ability to passthrough many types of signals: from composite to component. To protect device and not to cut signal`s range, HYDRAs have additional ESD protection diodes, but for a short period of time when scanning for active scart, Hydra is defenseless. If You got hit that moment plugging powered on device, You will damage RGB chip with ESD voltage that may reach thousands of volts (not dangerous for you, but electronics is fragile..). This chip may become very hot and protection will probably brick hydra till one of chips is replaced (NCS2564). Cost of repair is 10Euro !!!

After establishing connection with flat cables between HYDRA (master unit) and HYDRA HEADS (slave unit), user forces HYDRA to work with HEADS expansion and 8 additional scart inputs it offers.

To obtain above functionality, jumper (solder pads) JP1 must be shorted. From that moment, HYDRA does scanning between 16 scart input ports in search for active one to route all signals to output scart.

The SB-5520 is a 4x2 MATRIX SCART RGB/S-Video (Y/C)/ Composite Video/ Stereo Audio switching product. The switcher supports (4) individual inputs with (2) individual outputs. The matrix function of SB-5520 can route any Input to any Output in any combination. The switcher eliminates the need to constantly move around SCART input and output cables. It is ideally suitable for Source devices (such as: Video Game Consoles, SCART Video CDs, DVDs, Satellite Receivers, CATV Set Top Boxes, etc.) to SCART AV destination devices (such as: DVD-Rs, TV Sets, Video Projectors, etc.).

The SB-3715 is a SCART (4) Output Distribution Amplifier for RGB, S-Video, Composite Video/Stereo Audio (R/L) signals. This product provides multiple SCART outputs that are identical to the source signal. There is useful for distributing signals from VCRs, Camcorders, Video Game Consoles, Video CDs, DVDs, Satellite Receivers, CAT5 Set Top Boxes, etc.

Your business with me will be a pleasant experience for you. I am dedicated to bring joy, safe and top-quality products for you. All the products I offer in my store come with fashion style, superior quality but cheaper price all the time. When you place order, please do not hesitate to leave more detailed requirements you want, and then I will arrange the goods for you as soon as possible. First time, we do business; next time, we become friends. Hope you enjoy the whole process!

We offer good quality PC Board, Video Game, Multi Game, Multi Cartridge, Vending machine, Pinball Machine, Kiddy Rides, ABS cabinet available for 21"~25"monitor, heavy steel cabinet for 25"~29" monitor with Jamma connector, and some spare parts, Coin Acceptor, pushbutton, joystick, etc. For Amusement machines.

Converting HDMI “super-resolution” 240p from HDMI to VGA. CPSHDMI & Raspberry Pi can be set to 240p, then along with a cheap DAC and this converter, you can get the signal on your SCART monitor/TV.

The board gets power from VGA pin 9 by default, please ensure your input device outputs +5V on pin 9. If pin 9 is N/C, you may power the VGA2SCART by bridging +5V source jumper pads 1 & 3 and using micro USB instead.

If you are using a consumer CRT TV (B&O, Sony Trinitron etc.) which requires blanking/switching voltage to use RGB, you will get a black screen/very dim picture. If this is the case, connect a micro USB cable to a +5V power source which will supply +3V to SCART pin 16. This is not needed for professional video monitors, consumer TVs with “force RGB” in menu/service menu or TVs modded for RGB SCART which should already have blanking pulled to 5V to force RGB.

The OSSC concept with a delay-free line multiplier will take you into the digital age. Don"t worry about fuzzy graphics, interlaced jams and higher input lag, no need for hard upgrades. This is a solution based on FGPA technology, which can display retro games with excellent image quality on PC monitor or TV. Perfect suitable for sfc/md/ss/ps/ps2/xbox/wii and other old game consoles and arcade board frame. Support rgbs color difference vga signal input and then hdmi high-quality signal output, so that the old game can also get the top screen effect on the LCD monitor, full of nostalgia, with the ossc scan line function to make the picture no longer blur.

In modern games, the lack of scanlines is not a problem, but in retro games with their pixel-based graphics, scanlines are of vital importance. They make the image look sharper, giving more clarity to 2D images. Getting this type of image on a LCD / TFT television was, until recently, impossible since scanlines are an integral part of how CRT technology works.

This adapter is intended for users who want to connect a classic console (Super Nintendo, N64, Megadrive, etc...) with SCART / Euronector output to a modern (PLASMA / LCD / LED) TV equipped with video SCART input.

The Scanlines SLG SCART Generator is Plug & Play. However, we need to connect an external 5V Power supply for it to work properly. This power supply can be purchased HERE. By simply connecting it to the SCART input and output of the console and the TV we would already have this adapter working 100%. The SLG SCART Scanlines Generator has a knob to adjust the density of the scanlines progressively. In addition, the generator has an off and on switch.

Afghanistan - AFGAlbania - ALBAlgeria - DZAAmerican Samoa - ASMAndorra - ANDAngola - AGOAnguilla - AIAAntigua and Barbuda - ATGArgentina - ARGArmenia - ARMAruba - ABWAustralia - AUSAustria - AUTAzerbaijan Republic - AZEBahamas - BHSBahrain - BHRBangladesh - BGDBarbados - BRBBelarus - BLRBelgium - BELBelize - BLZBenin - BENBermuda - BMUBhutan - BTNBolivia - BOLBosnia and Herzegovina - BIHBotswana - BWABrazil - BRABritish Virgin Islands - VGBBrunei Darussalam - BRNBulgaria - BGRBurkina Faso - BFABurma - MMRBurundi - BDICambodia - KHMCameroon - CMRCanada - CANCape Verde Islands - CPVCayman Islands - CYMCentral African Republic - CAFChad - TCDChile - CHLChina - CHNColombia - COLComoros - COMCongo, Democratic Republic of the - CODCongo, Republic of the - COGCook Islands - COKCosta Rica - CRICote d Ivoire (Ivory Coast) - CIVCroatia, Republic of - HRVCyprus - CYPCzech Republic - CZEDenmark - DNKDjibouti - DJIDominica - DMADominican Republic - DOMEcuador - ECUEgypt - EGYEl Salvador - SLVEquatorial Guinea - GNQEritrea - ERIEstonia - ESTEthiopia - ETHFalkland Islands (Islas Malvinas) - FLKFiji - FJIFinland - FINFrance - FRAFrench Guiana - GUFFrench Polynesia - PYFGabon Republic - GABGambia - GMBGeorgia - GEOGermany - DEUGhana - GHAGibraltar - GIBGreece - GRCGreenland - GRLGrenada - GRDGuadeloupe - GLPGuam - GUMGuatemala - GTMGuernsey - GGGuinea - GINGuinea-Bissau - GNBGuyana - GUYHaiti - HTIHonduras - HNDHong Kong - HKGHungary - HUNIceland - ISLIndia - INDIndonesia - IDNIreland - IRLIsrael - ISRItaly - ITAJamaica - JAMJapan - JPNJersey - JEJordan - JORKazakhstan - KAZKenya - KENKiribati - KIRKorea, South - KORKuwait - KWTKyrgyzstan - KGZLaos - LAOLatvia - LVALebanon - LBNLiechtenstein - LIELithuania - LTULuxembourg - LUXMacau - MACMacedonia - MKDMadagascar - MDGMalawi - MWIMalaysia - MYSMaldives - MDVMali - MLIMalta - MLTMarshall Islands - MHLMartinique - MTQMauritania - MRTMauritius - MUSMayotte - MYTMexico - MEXMicronesia - FSMMoldova - MDAMonaco - MCOMongolia - MNGMontenegro - MNEMontserrat - MSRMorocco - MARMozambique - MOZNamibia - NAMNauru - NRUNepal - NPLNetherlands - NLDNetherlands Antilles - ANTNew Caledonia - NCLNew Zealand - NZLNicaragua - NICNiger - NERNigeria - NGANiue - NIUNorway - NOROman - OMNPakistan - PAKPalau - PLWPanama - PANPapua New Guinea - PNGParaguay - PRYPeru - PERPhilippines - PHLPoland - POLPortugal - PRTPuerto Rico - PRIQatar - QATReunion - REURomania - ROURussian Federation - RUSRwanda - RWASaint Helena - SHNSaint Kitts-Nevis - KNASaint Lucia - LCASaint Pierre and Miquelon - SPMSaint Vincent and the Grenadines - VCTSan Marino - SMRSaudi Arabia - SAUSenegal - SENSerbia - SRBSeychelles - SYCSierra Leone - SLESingapore - SGPSlovakia - SVKSlovenia - SVNSolomon Islands - SLBSomalia - SOMSouth Africa - ZAFSpain - ESPSri Lanka - LKASuriname - SURSwaziland - SWZSweden - SWESwitzerland - CHETaiwan - TWNTajikistan - TJKTanzania - TZAThailand - THATogo - TGOTonga - TONTrinidad and Tobago - TTOTunisia - TUNTurkey - TURTurkmenistan - TKMTurks and Caicos Islands - TCATuvalu - TUVUganda - UGAUkraine - UKRUnited Arab Emirates - AREUnited Kingdom - GBRUnited States - USAUruguay - URUUzbekistan - UZBVanuatu - VUTVatican City State - VATVenezuela - VENVietnam - VNMVirgin Islands (U.S) - VIRWallis and Futuna - WLFWestern Sahara - ESHWestern Samoa - WSMYemen - YEMZambia - ZMBZimbabwe - ZWE

A SCART connection isn"t as common as it was. But, if you still need to use SCART with your devices, learn more in this guide to SCART cables & connections.

As you can see from the shape of the connector, the design of SCART leads means they will only fit one way round, so make sure you pay attention when plugging it in.

It has 21 pins to transfer video and audio signals – although some cables are not fully wired, so might not be suitable for transferring some types of video – especially RGB.

SCART can actually support analog high-definition video signals; however, with the introduction of digital HDMI connections, there were hardly any devices built for this.

SCART has always had a poor reputation in the AV world because, although it’s pretty versatile in transferring different types of signals, it never fitted very well – making it hard to get a reliable connection.

Simply connect your device’s HDMI output to the converter’s HDMI input port, and it will convert digital MHL or HDMI video and audio to an analog SCART CVBS signal.

A SCART cable connects AV devices that have SCART connections. Older devices, such as DVD players, set-top boxes and game consoles, used SCART to send video and audio signals.

SCART stands for Syndicat des Constructeurs d’Appareils Radiorécepteurs et Téléviseurs – which is the French television manufacturers association that developed this connection type.

If you want to connect an old DVD player with a SCART output to a modern TV, you must buy a converter box. A SCART to HDMI converter will take the SCART output from your DVD player and convert it to HDMI, which you can then connect to any modern TV.

Paul started the Home Cinema Guide to help less-experienced users get the most out of today"s audio-visual technology. He has been a sound, lighting and audio-visual engineer for around 20 years. At home, he has spent more time than is probably healthy installing, configuring, testing, de-rigging, fixing, tweaking, re-installing again (and sometimes using) various pieces of hi-fi and home cinema equipment. You can find out more here.

Dug your N64 out of the cupboard and set it up only to find it won’t connect to your TV? Don’t panic! Chances are your console still works — it just may not be compatible with your newer TV.

Before purchasing any cables or scalers, check your TV and N64 console are compatible (I accept no responsibility for purchases made in error). I have only linked to scalers for informational purposes, and do not receive any remuneration or incentive in exchange.

Many PAL N64 consoles shipped with an RF adapter rather than a composite AV cable. This method requires tuning the N64 into the TV through the antenna port. I’ve never had any success with getting this to work on a modern digital TV, so I wouldn’t recommend trying it.

Alternatively, look for a SCART port. This is a plastic port about an inch and a half wide that has 21 small slots in it. (AV 1 in photo.) You will need an AV-to-SCART adapter to use this port.

If you have both video and audio, then play the game to see if there is any input lag. Is there a delay between you pressing the joystick/buttons and the resulting action happening on screen? (If supported, activate Game Mode on your TV for best results.)

For this connection you need to use the composite cable without a SCART adapter. Put the yellow cable plug into the green port. Put the red and white cables into the corresponding red and white audio ports.

If you have both video and audio, then play the game to see if there is any input lag. Is there a delay between you pressing the joystick/buttons and the resulting action happening on screen? (If supported, activate Game Mode on your TV for best results.)

If everything works as expected, then congratulations! If your N64 still can’t connect to your TV or doesn’t work properly, then you will need to use a scaler.

If this is the case then you should consider buying a scaler. These devices can convert the signal from your N64 to a format that modern TVs can display.

Instead, consider buying one of the specialist scalers that have been designed with the N64 and other retro game consoles in mind. They correctly process and convert the N64’s original video signal to a supported format with zero (or barely any) lag.

The cable detects the N64’s 240p output signal, processes it into a progressive scan image, and then line doubles this to 480p. It has a mini-HDMI output, so you can connect it to a modern TV using a mini-HDMI to HDMI cable.

A micro-USB cord comes with the 2X-MINI, which you use to power the device and make firmware upgrades. You can power the device using a USB port on your TV, which is pretty handy.

Plug the device into the back of your N64 and then connect it to your TV using an HDMI cable. The device then outputs an S-video signal scaled to 480p resolution with zero lag.

It also has a built-in “slick” mode, which when activated gives a smoother, less-jagged picture. Whether you use it or not is a matter of preference, and the results vary from game to game.

The UltraHDMI mod upscales your N64’s video output to HD resolutions (up to 1080p). It’s a circuit board that goes inside your N64 and adds a mini-HDMI output port.

Using built-in firmware (accessed via a control pad button input), you can change the output resolution and choose from a range of video-processing options (such as scanlines). These extra features only add the slightest amount of input lag, and it’s not noticeable.

While heavy and bulky, CRT TVs are still the best way to play N64. Often you can find decent CRT models in charity/thrift stores at affordable prices.

While it may be tempting to go large, I’d advise finding a smaller CRT TV (14 to 21 inch screen size). It’ll be much easier to lift and carry, and the N64’s video output will look much sharper on a smaller screen.

Your N64 may work with your modern TV using the original composite cable. Check to see if your TV has the right connections and supports the N64’s 240p video output signal. Just be wary that even if it does work, the quality may be noticeably poor.

Failing that, there’s nothing wrong with going back to an old CRT TV — space permitting. After all, they still offer the best experience in terms of picture quality and zero input lag.
