This graphic LCD module acts as a shield for Arduino Uno-style microcontrollers. The pins on the carrier board match up to the Arduino Uno"s ports, so the module simply presses on and is fully and correctly connected. Plus, this carrier board is able to be connected to either a 3.3v logic level or a 5v logic level device. (Read our blog post if you have questions about logic level.)

This module is also available with a white-on-blue graphic display, or as a fully built kit with an included Seeeduino (Arduino Uno clone) loaded with code to demonstrate the graphic display.

We come across Liquid Crystal Display (LCD) displays everywhere around us. Computers, calculators, television sets, mobile phones, and digital watches use some kind of display to display the time.

An LCD screen is an electronic display module that uses liquid crystal to produce a visible image. The 16×2 LCD display is a very basic module commonly used in DIYs and circuits. The 16×2 translates a display of 16 characters per line in 2 such lines. In this LCD, each character is displayed in a 5×7 pixel matrix.

Contrast adjustment; the best way is to use a variable resistor such as a potentiometer. The output of the potentiometer is connected to this pin. Rotate the potentiometer knob forward and backward to adjust the LCD contrast.

Sends data to data pins when a high to low pulse is given; Extra voltage push is required to execute the instruction and EN(enable) signal is used for this purpose. Usually, we set en=0, when we want to execute the instruction we make it high en=1 for some milliseconds. After this we again make it ground that is, en=0.

A 16X2 LCD has two registers, namely, command and data. The register select is used to switch from one register to other. RS=0 for the command register, whereas RS=1 for the data register.

Command Register: The command register stores the command instructions given to the LCD. A command is an instruction given to an LCD to do a predefined task. Examples like:

Data Register: The data register stores the data to be displayed on the LCD. The data is the ASCII value of the character to be displayed on the LCD. When we send data to LCD, it goes to the data register and is processed there. When RS=1, the data register is selected.

Generating custom characters on LCD is not very hard. It requires knowledge about the custom-generated random access memory (CG-RAM) of the LCD and the LCD chip controller. Most LCDs contain a Hitachi HD4478 controller.

CG-RAM address starts from 0x40 (Hexadecimal) or 64 in decimal. We can generate custom characters at these addresses. Once we generate our characters at these addresses, we can print them by just sending commands to the LCD. Character addresses and printing commands are below.

LCD modules are very important in many Arduino-based embedded system designs to improve the user interface of the system. Interfacing with Arduino gives the programmer more freedom to customize the code easily. Any cost-effective Arduino board, a 16X2 character LCD display, jumper wires, and a breadboard are sufficient enough to build the circuit. The interfacing of Arduino to LCD display is below.

The combination of an LCD and Arduino yields several projects, the most simple one being LCD to display the LED brightness. All we need for this circuit is an LCD, Arduino, breadboard, a resistor, potentiometer, LED, and some jumper cables. The circuit connections are below.

In this circuit, you’ll learn about how to use an LCD. An LCD, or liquid crystal display, is a simple screen that can display commands, bits of information, or readings from your sensor - all depending on how you program your board. In this circuit, you’ll learn the basics of incorporating an LCD into your project.

Open Up the Arduino IDE software on your computer. Coding in the Arduino language will control your circuit. Open the code for Circuit 15 by accessing the “SIK Guide Code” you downloaded and placed into your “Examples” folder earlier.

This bit of code tells your Arduino IDE to include the library for a simple LCD display. Without it, none of the commands will work, so make sure you include it!

Initially, you should see the words “hello, world!” pop up on your LCD. Remember you can adjust the contrast using the potentiometer if you can’t make out the words clearly. If you have any issues, make sure your code is correct and double-check your connections.

In this circuit, you’ll learn about how to use an LCD. An LCD, or liquid crystal display, is a simple screen that can display commands, bits of information, or readings from your sensor - all depending on how you program your board. In this circuit, you’ll learn the basics of incorporating an LCD into your project.

Open Up the Arduino IDE software on your computer. Coding in the Arduino language will control your circuit. Open the code for Circuit 15 by accessing the “SIK Guide Code” you downloaded and placed into your “Examples” folder earlier.

This bit of code tells your Arduino IDE to include the library for a simple LCD display. Without it, none of the commands will work, so make sure you include it!

Initially, you should see the words “hello, world!” pop up on your LCD. Remember you can adjust the contrast using the potentiometer if you can’t make out the words clearly. If you have any issues, make sure your code is correct and double-check your connections.

Liquid crystal displays (LCD) come in two main types that are of interest to hobby and DIY makers; Character LCD displays and pixel / graphic LCD displays. This intro “How To” will be covering the more popular and less expensive character LCD displays based on the very common Hitachi HD44780 controller.

LCD displays come in many sizes most often named by the number of rows and then the length of the display line. For example a 1x16 LCD display will have one row of sixteen characters and a 4x20 LCD display will have four rows with twenty characters in each.

LCDs can be have backlighting or be reflective (think calculator). In either case the programming that goes into working these displays is the same. LCDs with backlight normally use two pins to provide power to the backlighting.

2x16 character LCD with backlighting. Note, screen is all black, but to display characters the crystals move to allow the backlighting to show through.

Most LCDs that are being made now come with one row of sixteen pins. The first fourteen pins are used to control the display and the last two are for the backlighting (if the display has backlighting).

Older LCDs sometimes came with two rows of seven making a fourteen pin connector. These fourteen pins, most often, have the same signals on them that the 1x16 pin displays do. For example, pin #1 on the 2x7 connector is the same signal as pin #1 on the 1x16 connector, they are just arranged differently. If you have a 2x7 pin display but need to connect it to a 1x14 (1x16) backpack or device, the basic

LCDs based on the Hitachi HD44780 controller must be initialized after they are powered-up. The reason that the LCDs must be initialized is because there are a few critical options that the display must “know” before it can work or communicated properly.

The most import of which is wether to use an eight or four bit data interface. Hitachi and compatible LCDs can be set to use either 8 or 4 of the data pins to communicate with the host controller that is driving it. Using a four pin data bus lets you save on pins, but your controller must divide each instruction into two four bit segments and then send them one at a time to the display. So the trade off is less pins versus more programming and slower communication. (The reduced speed of having to send data twice has little effect on the display, but it does busy your processor for a longer amount of time.)

Ok, so you initialized your new 1x16 display and cleared it so that the cursor is at the first character position. Now you start sending your “Hello World” message to the screen.

When you send the LCD a character to display, you are not actually sending it to the screen part of the display, but rather a memory location that the display uses to know what to display on the screen. The problem here is that the memory location and the mapping to positions on the screen are not always sequential.

The “Hello World” example above is often what gives people trouble using a 1x16 LCD for the first time. Here the “r” “l” “d” went into memory address 0x88,0x89 and 0x8A which are not visible on this display !

Note that from the eight to the ninth character position the memory jumps. So, to finish displaying “Hello World” the controller would have to jump to memory location 0xC0 (at the red arrow) to continue displaying “rld”.

Solution: When you are ready to display a character in the ninth position on a 1x16 display you simply send the memory address to the display, but as a command.

For 1x16 and all the display larger then this, the memory mapping of the DDRAM (Display RAM) is not in the same range as the other commands, such as “clear display”, “home display” etc... so there is no problem sending the memory address as a command.

Here is a short list of popular display sizes and the memory mapping that we have found in them. Note: not all displays will necessarily have the same mapping, even when they are the same size. Use this a “Quick Start” reference when working on your own.

When it is actually time to use an LCD you have a few choices of how to do it. You can connect it directly to your Arduino or micro-controller (MCU) and use a lot of pins and wires or your could use a backpack.

Using a backpack has a few advantages over connecting the LCD directly to your micro-processor. Besides using less wires, (and pins) some backpacks take over the entire job of driving the display. All your code has to do is send the text out of the appropriate interface, I2C, serial, SPI etc ... This can save your micro-controller a lot of memory, and processor time. And, it also lets you get your projects working sooner, since you do not have to code and debug software to drive the display on top of the rest of your project.

A. Backpacks that do all the work, these free your MCU (and you) to do other tasks and when ready to display a message you simply send data to the backpack.

B. Backpacks that reduce the pin-out burden on your MCU. With this type of backpack, your MCU still initializes and drives the LCD, but through an interface with fewer wires.

Most displays work with the standard 128 ASCII characters. Often times, the displays are also able to display other characters, these include Asian characters and other special symbols and icons.

Your micro-controller measures a sensor and returns the value of five. You send the value to the display and you either get nothing or a strange looking character.

But, you can only send a single digit at a time to the display. So if you have the value of 139 to display, first it must be chopped into “1”, “3”, and “9” then you must add 48 to each before sending them to the display to convert the value into ASCII.
