Digital Blocks TFT LCD Controller reference design enables you to accelerate the design-in of TFT LCD panel displays in your system. The reference design centers on the Digital Blocks DB9000AVLN TFT LCD Controller intellectual property (IP) core, which is available in netlist or VHDL/Verilog HDL register transfer level (RTL) formats.

The DB9000AVLN core contains an Avalon® Memory-Mapped system interconnect for interfacing to the Nios® II embedded processor and SDRAM or SRAM controllers (either memory can serve as the frame buffer). Software supplied with this reference design runs on the Nios II embedded processor to place an image in the frame buffer memory and invokes the DB9000AVLN core to drive the LCD panel.

Using the Intel® Quartus® Design Software, you can instantiate the TFT LCD Controller reference design in a Cyclone®, Cyclone® II, or Cyclone® III FPGA development kit. See the Demonstrated Intel® Technology section for a complete list of supported Intel® FPGA development kits.

You can connect your LCD panel to the Intel FPGA development kit with the fabrication of an appropriate cable. Please contact Digital Blocks for more details.

4.3″ TFT Color LCD Display Module thatdirectly-plugs into ALINX/OMDAZZ FPGA Development boards. Comes with 40-Pin 0.1 inch spacing female headers supporting 24-Bit parallel bus RGB Interface.

Not long ago, we published some articles about controlling different kinds of displays, using your FPGA. On a VGA screen, on a small LCD screen, on a PSP LCD or even for the old, but nasty-analog-signaled NTSC system.

And today, we share with you another great tutorial on how to control a LCD TFT, that takes advantage of the ability of a FPGA to fully control what happens on every single clock cycle.

You may think, well, another LCD tutorial, more on the same…And you will be wrong. There are no identical systems. Each one has its own features which make it unique, and we want you to know them.

This is a very well explained tutorial that gives you all the files you will need to successfully implement it: schematics, VHDL code files, Project files, datasheets of the display…Everything!

In addition the author takes some extra time to explain what really matters about this project and what makes it different from any other “How to control your LCD screen with your FPGA”. To properly control a TFT display you need two specific timed signals: DCLK (Pixel Clock) and DE (Data Enable). Why the code lines that control these two signal are coded the way they are is carefully explained in the article so you don´t want to miss it. Understanding this will make you capable of playing with any other TFT screen you may find.
