lcd module specification quotation

The Displaytech 162J series is a lineup of 16x2 character LCD modules. These modules have an 80x36 mm outer dimension with 66x16 mm viewing area on the display. The 162J 16x2 LCD displays are available in STN or FSTN LCD modes with or without an LED backlight. The backlight color options include yellow green, white, blue, pure green, or amber color. Get a free quote direct from Displaytech for a 16x2 character LCD display from the 162J series.

The Displaytech 204G series is a lineup of 20x4 character LCD modules. These modules have a 98x60 mm outer dimension with 77x25.2 mm viewing area on the display. The 204G 20x4 LCD displays are available in STN or FSTN LCD modes with or without an LED backlight. The backlight color options include yellow green, white, blue, pure green, or amber color. Get a free quote direct from Displaytech for a 20x4 character LCD display from the 204G series.

ERM1202SYG-1 is 12 characters wide,2 rows character lcd module,SPLC780C controller (Industry-standard HD44780 compatible controller),6800 4/8-bit parallel interface,single led backlight with yellow green color included can be dimmed easily with a resistor or PWM,stn-lcd positive,dark blue text on the yellow green color,wide operating temperature range,rohs compliant,built in character set supports English/Japanese text, see the SPLC780C datasheet for the full character set.Optional 3.3v or 5v power supply and optional pin header connection.

NHD-12232KZ-NSW-BBW-P | Monochrome Graphic Module | 122x32 Pixels | Transmissive LCD | Side White Backlight | STN (-) Negative Blue Display | 2x10 Pin Header Soldered

Newhaven 122x32 graphic Liquid Crystal Display module shows white pixels on a blue background. This transmissive LCD Display requires a backlight for visibility and offers a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-12232KZ-NSW-BBW-P display has a 2x10 pin header soldered. It has an optimal view of 6:00, operates at 5V supply voltage and is RoHS compliant.

NHD-19232WG-BTMI-V#T | Monochrome Graphic Module | 192x32 Pixels | Transmissive LCD | White Backlight | STN (-) Negative Blue Display | Built-in Positive Voltage | Non-Stocked

Newhaven 192x32 graphic Liquid Crystal Display module shows white pixels on a blue background. This transmissive LCD Display requires a backlight for visibility and offers a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-19232WG-BTMI-V#T display includes built-in positive voltage. It has an optimal view of 6:00, operates at 5V supply voltage and is RoHS compliant.

This calculator is to be used as a suggestive tool only. The data gathered is based on specifications from the manufacturers and as such Matrix Visual Solutions cannot be held responsible for the absolute precision of the results given. Make sure to review your specific requirements with your Account Executive.

STN, Gray background, Yellow/Green LED, Bottom view, Wide temp, Transflective (positive), 5V LCD, 5V LED, Controller=AIP31066, RoHS Compliant. This display has a wide temperature range: -20° Celcius to +70° Celcius which equates to (-4° Fahrenheit to +158° Fahrenheit).

STN (Super-twisted Nematic) provides a sharper image and wider viewing angle than TN (Twisted Nematic). The cost for STN if approximately 5% higher than TN. STN is an ideal fluid for outdoor products that need to be read at various angles. The Transflective polarizer is a mixture of Reflective and Transmissive. It provides the ability to read the LCD with or without the backlight on. It will work for all lighting conditions from dark with backlight to direct sunlight which makes it the most common choice. There is no cost difference between Transflective, Transmissive and Reflective.

Focus LCDs can provide many accessories to go with your display. If you would like to source a connector, cable, test jig or other accessory preassembled to your LCD (or just included in the package), our team will make sure you get the items you need.Get in touch with a team member today to accessorize your display!

Focus Display Solutions (aka: Focus LCDs) offers the original purchaser who has purchased a product from the FocusLCDs.com a limited warranty that the product (including accessories in the product"s package) will be free from defects in material or workmanship.

Customers who use large fonts should update to the latest firmware. It is recommended that any user who upgrades to the new firmware test the upgrade in their system before upgrading all modules.

As part of our continuous improvement process, CFA635 KS, CFA735 KT, and CFA835 display modules with the ATX (power on / off / reset) functionality enabled will have their RS-232 SERIAL cable bundle options changed from a serial cable and WRPWRY24 to a serial cable and a WRPWRY25. With TX (power on / off / reset) functionality enabled, additional

A typical LED ticker board starts at 48” in length with standard module lengths at 15.2” wide and can be built as long as required. For custom applications, we can use a half module allowing us increments of 7.6”. Get more detailed specs on ourticker product page.
