This is a page where you can find common laptop/desktop LCD panel pinouts and see if your laptop screen"s pinout matches any one of them (it likely does!).

This is a very common pinout for higher-resolution CCFL displays. If you have a 1440x900, 1400x1050 or 1680x1050 panel, it"s likely using this pinout.

This is a pinout for desktop LCD monitor screens - laptop panels do not use this pinout (if there are some, let me know). If you"re ordering a MT6820 (MT561) board, it will arrive with a cable that has this specific pinout and is therefore incompatible with laptop screens - as you"re likely here to reuse a laptop screen, you will want to either rewire the cable you get, or order a suitable cable (for either A or B pinout, whichever you need) from the beginning.

This is a pinout for older, 1024x768 and similar laptop screens, CCFL-equipped ones. 1024x768 screens used both the A pinout, this pinout and even a different pinout with a connector I haven"t made a description for yet, so if you have a 1024x768 screen you"d like to reuse, there"s three possible options and you need to check which one you have before you buy/reuse/build a cable.

This is a pinout that"s, apparently, specific to a select range of 18.5" 1366x768 displays used in desktop LCD monitors. It"s not compatible with either A, B or C pinouts, and requires a specifically wired cable.

In some datasheets, the pinout will list extra pins - one before and one after the main pins, both would be described something like "shield GND". So, for a FI-X 30-pin connector, you might find a pinout in your datasheet that lists 32 pins instead of 30. These two pins are not "real" connector pins and you shouldn"t worry about them - they"re pins that the manufacturer decided to mention for some reason, but they"re not relevant when you are actually connecting to the panel.

You can get lcd panel pinout with an operation range that suits your specific application, choosing from a wide selection of suppliers. Source wholesale lcd panel pinout on Alibaba.com for your business and enjoy a wide variety and great deals.

With Alibaba.com, one of the world"s largest network of wholesale business suppliers, you can find the right shipment of wholesale lcd panel pinout. We have lcd screens for phone repairs available for all major brands and models. This includes models for which the manufacturer has discontinued replacement products, just look for old phone replacement lcd screens.

Explore the extensive selection of wholesale lcd panel pinout LCD displays, TFT, and HMI that can be used across a range of industries, including domestic, medical, industrial, automotive, and many others. You can choose from a number of standard industry sizes and find the lcd panels pinout that are applicable to your required use. If you would like options that allow a smaller environmental footprint due to low power consumption, you can browse the Chip-on-Glass (COG) LCDs. COGs are designed without PCBs so have a slimmer profile.

LCD panel interfaces have changed over the years as resolutions have moved from 640×480 to 3840×2160. The following outlines the common ones that we support with our LCD controllers and cable kits. They cover most of the large size and higher resolution LCD panels on the market:

LVDS: LVDS was introduced in the late 1990’s and enabled connection for higher resolution panels with the benefit of reducing EMI. The LVDS interface is supported by most Digital View LCD controllers and covers panel resolutions from 640×480 to 3840×2160 though newer formats are replacing it for higher resolutions. It remains very popular for HD type resolutions, ie up to around 1920×1200. Most LCD panel manufacturers have LCD panels supporting LVDS, including AUO, BOE, Innolux, JDI, Kyocera, LG, Mitsubishi, Sharp, Tianma. LVDS is Low Voltage Differential Switching.

V-by-One: Increasingly common on 4K resolution panels typically 55″ and larger though I did find a 32″ 1920×1080 panel and 28″ 3840×2160 panel listed as in production. A benefit of V-by-One compared to LVDS is the reduction in cables for high resolution signal support and reduced EMI. LCD panel brands using V-by-One include AUO, BOE, Innolux, LG, Samsung, Sharp. I thought of V-by-One as replacing LVDS but apparently it was developed to replace FPD-Link.

eDP: First introduced in 2008 it is widely adopted by LCD panels used in laptops and similar devices. We are also now seeing it being used in higher resolution and brightness LCD panels but still typically smaller sizes, ie 30″ or smaller. Digital View LCD controller models supporting eDP include SVX-4096, SVX-2560, SVH-1920v2 and the new DD-1920-HDMI-EDPT. Brands using it include AUO, BOE, Innolux, LG, Panasonic, Samsung, Sharp, Tianma.

TTL: Supported by the ALR-1400v2 and HLR-1400v2 controllers this was the common panel interface when Digital View was founded in 1995. VGA (640×480) to XGA (1024×768) resolutions were mainstream at that time. Still used in commercial and industrial display applications AUO, Innolux, Kyocera, Mitsubishi, Samsung, Sharp, Tianma have LCD panels in production with resolutions such as 640×480, 800×480, 800×600, 1024×768. The name TTL is short for Transistor-Transistor Logic.

FPD-Link: The original low voltage differential switching signal but not to be confused with the LVDS interface on many panels as described above. It is now often used in the automotive market and currently up to FPD-Link III. It is not currently supported by any Digital View’s standard controller models though we are looking at it as a custom development option.

Elastomeric connectors, also known as ZEBRA strips, are a common connection type for LCDs with surface mount connections. A ZEBRA strip connector is comprised of a malleable insulation strip with alternating conduction lines and can be used as a substitute for a hardwire connection. These connectors get their name from their alternating conduction lines that appear as stripes, similar to a Zebra.

ZEBRA strips are positioned between a display’s connection ports and its controller. They then require a bezel to ensure a proper connection with the display. Once the bezel has been applied, the ZEBRA strips compress against an LCD’s surface mount connection ports. The resulting pressure from the bezel allows for a solid connection between the conductive strips and the display.

This connection type is a good option for testing and prototyping displays as there is no need to permanently connect pins to the display. ZEBRA strips are also a good option for thin, compact LCD and PCB designs. For example, if limited space is available within the enclosure, a ZEBRA strip can be used as an alternative to metal pins or ZIF connectors. ZEBRA connectors can also often be a cheaper alternative to other connection types.

Flexible printed circuit (FPC) and flexible flat circuit (FFC) cables (hereinafter both interchangeably referred to as “FPC” or “FPC Cable”) are widely used connectors that provide access to the internal circuitry embedded in the display. Such connectors are standard in laptops and mobile phone displays.

The flexibility of an FPC cable is ideal for compact devices. The cable is made of a flat, bendable material that insulates the conductive wire connected to the LCD. The conductive leads to the display are heat sealed between durable insulative strips.

Throughholesarea standard connection type for many displays that offer a connection through small holes on the PCB. This connection type is most common for LCDs that have an external PCB controller circuit mounted to the display, such as most character and segment LCDs. Typically, the PCB will include the required liquid crystal driver, a voltage converting circuit, and backlight control.

Metal pins are a connection type for LCDs that have metal pins already mounted and connected to the display. Metal pins can be connected to the internal display controller or to the COM and Segment lines of an LCD. Typically, this connection type is used for character and segment LCDs.

Metal pins are good for applications that have standard pin mappings so that the display can be plugged into the controlling device. This connection type is less versatile than the previous LCD connection types as the pins are hardwired into place and cannot be moved unless unsoldered. The standard distance between pins is 2.54 mm.

Heat seal connections for LCDs are a reliable connection type utilizing a flexible cable connector that is heated and sealed to a displays’ interface ports. This connection uses a special heat seal paper that is then adhered to the display using a conductive glue and sealed by applying heat.

While FPC cables will degrade or become damaged with continuous bending, a heat seal connector will maintain the performance with continuous bending and will not become damaged.
