SainSmart 2.8" TFT LCD Display is a LCD touch screen module. It has 40pins interface and SD card and Flash reader design. It is a powerful and mutilfunctional module for your project.The Screen include a controllerILI9325, it"s a support 8/16bit data interface , easy to drive by many MCU like arduino families,STM32 ,AVR and 8051. It is designed with a touch controller in it . The touch IC isXPT2046, and touch interface is included in the 40 pins breakout. It is the version of product only with touch screen and touch controller.

Voltage type: 5v or 3v voltage input voltage,input is selectable. Because TFT can only work under 3.3 V voltage, so when the input voltage VIN is 5V, need through the 3.3 V voltage regulator IC step down to 3.3V , when the input voltage of 3.3 V, you need to use the zero resistance make J2 short , is equivalent to not through the voltage regulator IC for module and power supply directly.(Click here)

This is SainSmart UNO R3 and 2.8 inch TFT LCD module with the TFT LCD shield kit For arduino enthusiasts.It includes one pcs of sainsmart UNO R3, one pcs of 2.8 inch TFT LCD display and a TFT LCD shield. We will provided you the whole document including the example project of arduino UNO(R3) with the kit. We will supply you the technical support after your purchase.

The SainSmart Uno R3 is a microcontroller board based on the ATmega328 . It has 14 digital input/output pins (of which 6 can be used as PWM outputs), 6 analog inputs, a 16 MHz ceramic resonator, a USB connection, a power jack, an ICSP header, and a reset button. It contains everything needed to support the microcontroller; simply connect it to a computer with a USB cable or power it with a AC-to-DC adapter or battery to get started.

1.0 pinout: added SDA and SCL pins that are near to the AREF pin and two other new pins placed near to the RESET pin, the IOREF that allow the shields to adapt to the voltage provided from the board. In future, shields will be compatible with both the board that uses the AVR, which operates with 5V and with the Sainsmart Due that operates with 3.3V. The second one is a not connected pin, that is reserved for future purposes.

SainSmart 2.8" TFT LCD Display is a LCD touch screen module. It has 40pins interface and SD card and Flash reader design. It is a powerful and mutilfunctional module for your project.The Screen include a controller ILI9325, it"s a support 8/16bit data interface , easy to drive by many MCU like arduino families,STM32 ,AVR and 8051. It is designed with a touch controller in it . The touch IC is XPT2046 , and touch interface is included in the 40 pins breakout. It is the version of product only with touch screen and touch controller.

Voltage type: 5v or 3v voltage input voltage,input is selectable. Because TFT can only work under 3.3 V voltage, so when the input voltage VIN is 5V, need through the 3.3 V voltage regulator IC step down to 3.3V , when the input voltage of 3.3 V, you need to use the zero resistance make J2 short , is equivalent to not through the voltage regulator IC for module and power supply directly.

This is SainSmart TFT LCD Extend shield for UNO(R3) .Using this shield can help you out of the bothers to use other cables. You just need to plug the module to arduino UNO(R3) through this shield.

If you connect the touch screen LCD with UNO R3, the touch screen function will be useless . If you want to use the touch function, please connect the LCD with Mega2560 (R3) or Due (R3).

2.The LCD is compatible for arduino family,but the Shield is just for the arduino UNO R3. If you need the LCD Extend shield for other arduinos, you need another shield which is also provided from our store.

I have been scouring the web to find all different bits of information for the Sainsmart 2.8 inch touch display with no avail on instructions on how to actually make it work.

I assumed that being it has a compatible 40 pin header that all I needed to do was put a 40 pin cable on it and install software and the os would pick up the display by default.

SainSmart 2.8" TFT LCD Display is a LCD touch screen module. It has 40pins interface and SD card and Flash reader design. It is a powerful and mutilfunctional module for your project.The Screen include a controller ILI9325, it"s a support 8/16bit data interface , easy to drive by many MCU like arduino families，STM32 ,AVR and 8051. It is designed with a touch controller in it . The touch IC is XPT2046 , and touch interface is included in the 40 pins breakout. It is the version of product only with touch screen and touch controller.

Voltage type: 5v or 3v voltage input voltage，input is selectable. Because TFT can only work under 3.3 V voltage, so when the input voltage VIN is 5V, need through the 3.3 V voltage regulator IC step down to 3.3V , when the input voltage of 3.3 V, you need to use the zero resistance make J2 short , is equivalent to not through the voltage regulator IC for module and power supply directly.(Click here)

So I contacted them and they sent me out the documentation etc. As I read all the documentation there was not one mention of how to get the PI to recognize the display. So I contacted them again and the response was to try element14.com. I went there and again no avail.

I am hoping that this is the last stop and that someone might have instructions on how to get the pi to recognize the display. Currently when hooked up the screen lights up, but that is about it, no output what so ever. The only output is what is going through the hdmi port to the tv.

All the accessories listed below tier pricing need to pay.We won"t deliver until you select. Power adaptor should be 5V/2000mA in output and center pin for positive voltage and the outer shield for negative voltage .The temperature for controller RTD2660 would increase during working.That"s normal phenomenon,not quality problem.

ER-TFTV070A1-3 is 800x480 dots 7" color tft lcd module display with small HDMI signal driver board and superior display quality,super wide view angle. It"s optional for optional 4-wire resistive touch panel with USB driver board and cable, optional capacitive touch panel with USB controller board and cable, optional remote control,It can be used in any embedded systems,car,industrial device,security and hand-held equipment which requires display in high quality and colorful video.It"s also ideal for Raspberry PI by HDMI.

I have the same LCD as you do. i was wondering if you could help me with the pinout of the LCD… valdodov has a different lcd and his schematic doesn’t transfer well to the one you have i think. is there a schematic that you could post or tell me where BL_CNT is connected from the 4094s to the LCD?

the Spi (MOSI) is buffering 32 bits (when the strobe is off) then the SPI (MOSI) waits for 32 spi cycles (When strobe is on ) . Am i understanding correctly .

I’m thinking of a Python or C library, or better yet an optimized binary that you can pipe the raw data to from another process to send it to the screen…yes to all the above. You just need to write to the framebuffer

Where did you find the pin out for the sainsmart touch screen? We were looking at the following data sheet and it has different pin assignments. Please help us clear up this confusion. Thank you!!the display in your datasheet uses ILI9325 driver chip for the display.

We were following the instructions on github/notro/fbtft/wiki but I think I just realized that that’s a different method. So in order to install the kernel/modules should we use the compiled files on Voldadov’s site? If so, how do I copy those drivers? I extracted them to the desktop then did:

Finally got it working! (Sort of) Must have had a few dead rails on my breadboard because I purchased an new breadboard, and lo and behold, our screen works. We can see the boot information and there are no errors, but it stops at a blinking command prompt, but I cannot type with the keyboard, and it does not boot into the desktop. So we’re kind of stuck at a blank command prompt. Is there any code I can edit to make it boot into the desktop? Or is there any way to make the keyboard work?Do you have the keyboard directly connected to the Pi? Or are you accessing the Pi via SSH from another PC?

sudo mplayer -vo fbdev2:/dev/fb1 -x 128 -y 160 -zoom fileWe have the keyboard directly conneected to the pi. Should we be using SSH? And we can get it to work by deleting the

I am working for several months with the Raspberry and I also know a few experminete performed. Well me too interested this project. I myself already so bought a 3.2 “touchscreen, but I dunno exactly how to wire the. Could you maybe make a wiring diagram. That would be very nice.For example, with http://fritzing.org/

We are following your circuit for interfacing the raspberry pi with touch screen. We have currently wired on a breadboard and currently working on a better consistent solution like having it on a PCB.

-What driver?I am using the same chips and TFT as you are using. The driver i am using is Raspbian. I am using a breadboard but i have checked the circuit multiple times using a multimeter to confirm the connections so i am not sure if that is an issue.

Thank you for your help. I found a small connection issues with one of the ribbon cables i was using from the raspberry to the breadboard. Now that it is fixed everything works great without any problems. Thanks.

I have a question about kernel: I install the Rpi version 2014-06-20-wheezy-raspbian, kernel version 3.12.25+ #700 after upgrade, but after apply valdodov, kernel come back to 3.6.11 #41 …

Thanks for the Kernel but on my Pi is nothing to go the Display is not working. I have the Sainsmart 3,2 TFT with the Modul that is in the Video (selfmade) but i find no error in my circuit board it is with 3 74HC4094 and 1 74HC4040 . ? Is there a Kernel that Support this Version with no updates.?

anyone a idea where this vertical flashing lines come from?It has been awhile since I have looked at this version of the display with the above SPI interface.

You can also try and force the 4040 to go faster my connecting it to 5vi found the issue…. above GND is a Pin named “VCC” – it was not connected (and looking at your schematics, it didn’t look like it has to be connected to 5v)

I was torn in deciding how many stars to give this. For starters, I must mention that I own 5 of these things -- 3 of the Mega2560R3 kits and 2 of the Due kits. This review is the collective findings of both varieties.I"m going to start with a key problem and warning that everyone who has bought or is thinking of buying these things should read:WARNING: The configuration jumpers on ALL five of the units I"ve received were jumpered incorrectly from the factory. The Mega2560R3 boards had both the 5v and 3.3v selection jumpers soldered, meaning if you plug it in as-is, you"ll short out the two power supplies. Their pictures of the board all show only the 3.3v jumpers selected, which is correct, but the three Mega boards I received, the LCD shield boards were jumpered wrong with both voltages selected. The two Due boards were also jumpered wrong. However, they didn"t have both jumper sets applied, they only had the 5v jumpers applied. Even if the LCD could stand 5v (and would be OK since all of its I/O pins are outputs from the processor), jumping it wrong would also mean powering the touchscreen chip from 5v causing the inputs to the Due processor to see 5v, and the input pins of the SAM micro are NOT 5v tolerant.This problem is likely why some of the other reviewers mentioned processors and things getting hot. So step one, regardless of which board set you get, check your jumpers! The LCD should be configured for 3.3v and only one voltage selection jumper should be applied per option so you don"t short out both supply voltages.Of the five units I received, one LCD screen glass was cracked. It still functions, but the crack renders the touchscreen portion somewhat unusable. Another LCD screen apparently has a panel that was wired backwards (between the driver chip and the LCD panel itself). I thought at first it was defective as the screen had the appearance of the old SSAVI style cable scrambling technique with a "torn" picture. But the pre-init white screen looked OK, so I was suspicious that it was functioning, but in a weird way. After some experimenting, I found that if I swapped the sync settings around and the horizontal/vertical addressing modes around it worked, but exactly backwards from what it should -- addressing was going the wrong way and scrolling was backwards, etc... It is usable, but only if I correct for their problem in software. I didn"t exchange either one of these because the cost and hassle of doing so wouldn"t have been worth it.I was also suspicious that the one screen that was behaving backwards simply had a different LCD driver chip. But, I read the Device ID out of all of them and they all reported 9325. So they should have all functioned the same. And, for what it"s worth, the LCD driver chip at least thinks it"s a 9325.As for software and support, I don"t understand the reviews that say there"s no software or support out there, as the item description posted on Amazon even has a link to a zip file from SainSmart with the CTE UTFT libraries already preconfigured for these screens (maybe those reviews were done before that was posted?). And in any case, this is a clone of the CTE (Cold Tears Electronics) boards and there"s plenty of documentation and software for it, including schematics and even board layouts, if you Google it.One reviewer mentioned it not being a true "CTE" board because no SPI Flash chip was installed. Well, even the original CTE boards don"t come with the flash chip by default -- that"s an optional add-on (as per their "official" website). This clone certainly has the pads, just get a chip and solder it on... Though you"ll probably still want to read the font data out and store it in memory, as the latency of reading it from flash every time text is rendered would serious slow down performance. So why not just put the font you want in the main flash of the micro? Though I guess you could use the chip to store anything you want and aren"t limited to just fonts.Another thing to look out for on the board is solder splash and cold solder joints, specifically on all of the through-hole parts. Two of my boards had a solder splash on the power input connector, shorting it out had I not seen and removed it. Various through-hole connectors were marginally soldered and needed some touch-up work. So expect to do some soldering right out of the gate. And be sure to look your board over thoroughly and fix these things before using it.The processor boards (apart from a couple of soldering issues) were fairly functional and I guess a decent value for the price. But, the Mega, for example, has a old bootloader version installed. One of the first things you"ll want to do is reflash it (via the ISP port) with the current stk500v2 bootloader. Also, it didn"t have the lock bits sets, meaning you could easily accidentally overwrite the bootloader during programming and end up with a brain-dead board until you reflashed the bootloader via the ISP port... So I suggest flashing the current bootloader and setting the lock fuses first thing.I"m suspicious, though, that the ATmega2560 processor is a counterfeit chip as the efuse bits don"t seem to want to stay set. You can program them, and they seem to program OK, even verify correctly, but later on will occasionally randomly read back as 0xFF. I have only seen that happen with the efuse bits, which is primarily just brownout voltage threshold setting, so it isn"t too critical (compared to the other fuse bits), but makes me wonder about the integrity of the processor as a whole and wonder if it"s possibly a "counterfeit chip".I haven"t done as much checking of bootloader code on the Due board, or its ARM micro. It came up and talked to the bossa loader without any issues, so I haven"t had a need to analyze it to the extent I have the Mega boards. Plus, being a newer Arduino board, it"s more likely to have a new bootloader and also the different nature of the programming process on the ARM of the Due isn"t as likely to have flash overwrite issues as the Mega does.The LCD screens themselves are decent, assuming yours isn"t cracked or wired backwards, but be aware that this 9325 chip, at least the way it"s configured on this LCD panel, does NOT support hardware scrolling in the vertical direction when in landscape mode. It does do hardware scrolling, but only vertical for portrait mode (or horizontal for landscape). If your project needs hardware scrolling in the vertical direction of landscape mode (as my project needs), this LCD screen won"t do it!The touchscreen, however, I found to work quite well -- but ONLY after you"ve calibrated it. It didn"t work at all until I did the calibration. Perhaps the reviewers saying they couldn"t get touchscreen to work didn"t calibrate it? You first need to get your LCD working with their demo. Then, load their UTouch calibration program and follow the prompts on the screen for creating the calibration parameters. Then plug those parameters into the UTouch source code, et voila. I was pleasantly surprised at how well the touchscreen seemed to function for the money -- it had good response, was accuracy and seemed repeatable, and didn"t require a lot of excess pressure, etc. From some of the other reviews I"ve seen on this screen, I wasn"t sure what to expect, but was pleasantly surprised to find the touchscreen performing well (at least on the screens I received -- maybe they too have quality control issues?).The UTFT code isn"t the best of code, but is functional and works well on both the Mega and Due. I did tweak it to work a little more efficiently and fix potential memory access faults, and to add hardware scrolling support (the library itself didn"t originally support hardware scrolling at all).A better software library to use with the screen is Andy Brown"s xmemtft, available on GitHub. To use it, you"ll have to use the Gpio16 include files for the ili9325 chip and properly set the port mapping for your processor. Speaking of port mapping, the correct settings on the UTFT library (that"s linked in the item description of these boards) for this 2.8" 320x240 TFT LCD in their example code is as follows:Mega:UTFT myGLCD(CTE28,38,39,40);UTouch myTouch(6,5,4,3,2);Due:UTFT myGLCD(CTE28,25,26,27,28);UTouch myTouch(6, 5, 32, 3, 2); (note: it will support "4" in place of the "32", but only if you add a jumper on the adapter shield)So all-in-all, it"s usable, but only if you do a little work on them, don"t get a bad LCD, and don"t need vertical scroll in landscape. It definitely isn"t a kit for a novice. Don"t expect to plug it together and start using it without doing some soldering and fixing things. And if you are new to programming, you may want to get some experience on a more ready-to-use package, like an Adafruit kit or something, first.But, if you don"t mind learning a little and working through the BS and you happen to get lucky and the one you receive isn"t defective, this is a decent deal for the money, as most vendors sell just the processor board for the cost of this entire kit.So, as a cheap, knock-off clone, it"s usable, but...

I purchased this circular touchscreen on Alibaba to use with a Raspberry Pi in my prototype. I told the manufacturer I was using a Pi and the screen does not connect to the Pi by default as it has a MIPI connector, OK no problem so they sold me this HDMI adapter and even gave me some helpful code to get the screen working on the Pi. However they did not mention that they provided no solution for getting the touch part of the touch screen working (or even connected) and basically stopped responding once I mentioned this...

The documentation refers to this component as the "CTP" which yielded no search results for me. The doc only mentions this component 1 time for this pinout
