Due to the increasingly widespread use of data projectors, there are now even stronger desires for brighter and higher resolution projectors. To respond to these desires, Sony has developed a product line of 786K-dot XGA data projector LCDs based on the unique Sony-developed DMS structure and taking full advantage of high light resistance technology and a newly-developed high aperture ratio structure. All three sizes, cm (0.9-type), and cm (1.3-type), achieve the highest brightness in their size class in the industry, and can be used in a wide range of applications, from mobile PC-based presentations to conference rooms, and even in large conference halls.

To respond to our customers desires for even brighter images with even higher picture quality, we are simultaneously releasing three new XGA data projector LCDs, a high-brightness 1.3-type device, a 0.9-type device, and a 0.7-type device. All us on this project team grappled with the main development issues, which were to achieve both high optical transmittance and high light resistance. We are convinced that Sony"s customers will be fully satisfied with this new lineup of XGA LCD products for use in applications from ultrasmall mobile projectors to high picture quality portable projectors.

tance of 26% (with ML), and the cm (1.3-type) models achieve an aperture ratio of 67% and an optical transmittance of 30% (with ML). For the cm (0.9-type) models this corresponds to an improvement by a factor of 1.2 over conventional products. To improve the light resistance, we developed the DMS structure used in previous products even further, and achieved light resistances of 1000 ANSI lm in the 0.7-type models, 1500 ANSI lm in the 0.9-type models, and 3000 ANSI lm in the 1.3-type models. In particular, the LCX038ART/AST is the industry"s first cm (0.7-type) XGA data projector LCD, and can be used to implement ultraportable data projectors. (See table 1.)

thus these devices can achieve highpicture quality images with greater evenness. All three of the model types in this release feature a contrast of 400:1 (typical), which was achieved by optimizing both the LCD design and the LCD orientation technology.

To support a wide range of applications, Sony data projector LCDs include both up/down and/or right/left inversion functions and input level shifter circuit to allow 5 V drive of the timing system. Related Sony products create an environment that allows users to get the best performance from the characteristics provided by the LCDs themselves. These products include, for the analog system, the CXA2111R signal driver and the CXA3512R high voltage drive sample-and-hold IC, which has been well-received by the market, and the CXD2467AQ, which integrates a programmable TG and RGB drivers on a single chip as the digital system structure.

The three model types in this release all adopt the TFT circuit technology developed in Sony"s previous data projector LCD products, and achieve crosstalkfree and ghost-free display. The device structure is a high-brightness structure consisting of a high light resistance DMS structure and an OCS structure, and achieves excellent uniformity. Furthermore, by adopting this device structure and the CXD3503R color shading correction IC, it is possible to correct not only for color shading in the LCD panel itself, but also for color shading in the illumination system, and

First, you need to check whether this display has On-cell or In-cell touch panel, if has, it only needs to add a cover glass on it. If not, it needs an external touch panel.

Because the shape of the cover glass depends on the design of the clients, to avoid infringement of appearance, most of the developers need different customized touch panels.

Multi Monitoring & Control Software, Early Warning Software, Logo Transfer Software, Presenter Light Software (for Windows®)*7, Wireless Projector for iOS/Android™*8

Multi Monitoring & Control Software, Early Warning Software, Logo Transfer Software, Presenter Light Software (for Windows®)*7, Wireless Projector for iOS/Android™*8

Multi Monitoring & Control Software, Early Warning Software, Logo Transfer Software, Presenter Light Software (for Windows®)*7, Wireless Projector for iOS/Android™*8

*3 ET-WML100 Series and AJ-WM50 Series devices are both compatible with supported projectors in this series, and either can be used to enable the wireless network function.

*6 When [LAMP POWER] is set to [NORMAL] and the projector is operated at an elevation of 1,400 m (4,593 ft) or less, if the ambient temperature exceeds 35 °C (95 °F), [LAMP POWER] will be switched to [ECO] automatically to protect the projector. When [LAMP POWER] is set to [NORMAL] and the projector is operated at an elevation between 1,400 m (4,593 ft) and 2,700 m (8,858 ft), if the ambient temperature exceeds 30 °C (86 °F), [LAMP POWER] will be switched to [ECO] automatically to protect the projector.

*8 When using the Wireless Projector app, display resolution differs depending on your iOS/Android™ device and the display device. The maximum supported display resolution is WXGA (1280 x 800).

Guaranteeing the perfect support for successful lectures and presentations, the compact multi-purpose ME301X projector delivers crisp images and natural colours to your classroom and meeting facility thanks to LCD technology and 3000 ANSI lumen brightness. Comprehensive connectivity and optional WiFi provide the utmost flexibility and time saving operation. The pre-installed MultiPresenter function enables simultaneous wireless presenting and sharing for up to 16 devices when the optional WiFi is chosen. Extended lamp and filter life are lowering both maintenance time and cost ensuring a smooth operation over 5 years*.

The ME301X is the perfect choice when considering replacing M Series XGA LCD projectors. With the same footprint, lens position and throw angle it has never been easier to bring the latest technology to your classroom or meeting facility saving both time and money with no maintenance. With its downward compatibility for lamps of the M LCD series, even your stock is a safe investment!

The NEC P603X brings brightness of up to 6,000 ANSI lumen to your meeting and learning spaces. Enjoy smooth operation over five years* with low maintenance, long lamp life and the NEC patented LCD panel dust protection. The NEC P603X is the perfect replacement device for preceding models because it offers the same mounting options and with its wide zoom range, it is easy to adjust the projection to the existing screen. LCD technology delivers natural colours with a high contrast whilst the wide horizontal and vertical lens shift offers broad flexibility in installation. With its low power consumption, the NEC P603X offers a low total cost of ownership (TCO) and helps you to reduce your carbon footprint.

a line of extreme and ultra-narrow bezel LCD displays that provides a video wall solution for demanding requirements of 24x7 mission-critical applications and high ambient light environments

Choosing for Room Size/Viewing Distance Every projector has a throw ratio. This refers to the size of image the projector can create for a given distance. This is usually a range, thanks to the optical zoom – you can find it in the user manual or specifications page online (if it"s for a projector you plan to buy). You can calculate the projection image size by dividing the distance between wall and the projector by the throw ratio of the projector. So if your projector is placed 10 feet away from the screen and has a throw ratio of 1.8-2.22, then you can get an image size that ranges between 54 – 66 inches. Ideally, you should be sitting at a distance that is more than twice the width of the image. To make things simpler, many manufacturers offer a distance calculator on their website for various models. Here, you just input a distance or required screen size.

Tip: Some aberrations can be corrected in-projector (keystone for example) but proper placement is the most preferable. If not possible due to placement/room constraints, then you can move on to digital corrections.

Screens are the best way to get the best performance from a projector. A screen will always be smoother than a wall and it will offer higher, more even reflectance. Some screens have gain – they reflect light better, thanks to shiny particles – and this helps in brighter rooms or if your projector is old or has low brightness. Some screens have black borders that add to the perceived contrast – making the image seem better. Finally, screens are also the correct shade of white/grey, solving the problem of a colour cast that some walls may cause. Having said all this, you can use a wall too – there are obvious cost advantages. If you must use a wall, make sure it is as smooth as possible (a plaster of Paris coat helps) and painted in flat white.

There are three main technologies used for projection – DLP, LCD and LED. DLP (Digital Light Processing) uses a chip made of tiny microscopic mirrors and a spinning colour wheel to create an image. DLP projectors deliver sharp images, don"t need any filters, have a better response time as well as 3D capabilities. The effective lamp life of a DLP projector is only 2000-5000 hours and some people see colour ghosting/banding in some scenes. On the other hand, LCD projectors use liquid crystal displays, have no moving parts and thus are generally less expensive. If you are on a budget a single chip LCD projector is ideal while 3-chip LCDs offer better colour saturation, lower noise levels and work better for movies. However, LCDs require constant filter maintenance and output less contrast. The LEDs in LED projectors have a lifespan of over 20,000 hours. They deliver better colours, have lower power consumption and virtually zero maintenance costs. Also, LED projectors are smaller and generate less heat. Do keep in mind that LED projectors have limited brightness compared to LCD or DLP so they are not recommended if your room has a lot of ambient light.

Tip: Some high-end projectors come with a feature called lens-shift. This is a physical rail that adjusts the lens up/down & sideways to move the image around. Obviously, this offers a lot more flexibility with regards to projector placement.

Pico projectors use LEDs as the light source due to which they can be extremely compact in size. Pico projectors can fit in your palm or be integrated into various devices like mobile phones (Samsung Galaxy Beam), tablets (Lenovo Yoga Tab 3), computers, and even digital cameras (Nikon S1000pj). While these projectors do not offer very high resolution or brightness, they are good enough to use in a small, dark room. You can get a 60-inch screen and you can connect multiple devices like smartphones, gaming consoles and laptops. Moreover, the portable size enables manufacturers to add internal storage as well as rechargeable battery in devices that weight less than 200 grams.

Tip: It"s always better to ceiling mount a projector because there are less chances of it being moved once setup. It also places the projector a fair distance away from the viewer so that fan noise and while becomes less audible.

If the projector is not placed perpendicular to the screen, the image is not rectangular – this is a keystone error. Most projectors offer digital keystone correction in the horizontal and vertical planes.

A 3 colour LCD system uses individual LCDs for red, green and blue. The light from each LCD is combined using a prism to create a final image. It usually offers better quality than single chip LCD or DLP designs.

This happens if you"re sitting too close to a projector – fine lines will be seen between the individual pixels on the screen/wall. A screendoor effect usually doesn"t matter if you"re displaying static images (or a presentation) but it affects movies/videos.

Featuring an IP5X/IP6X optical engine and up to 30,000 hours of light source life, InFocus laser projectors powered by Quantum Laser technology deliver virtually maintenance-free durability for a lower total cost of ownership and a more environmentally friendly option than traditional high-pressure lamp projectors.

Bring the ultimate 4K experience to your professionally installed home theater with the Epson® Pro Cinema 4050 4K PRO-UHD projector. Epson 4K PRO-UHD projectors use our proprietary, advanced pixel-shifting resolution-enhancement technology1 to display native 4K content. Wide Color Gamut, HDR High Dynamic Range and 100% Balanced Color Brightness deliver an exceptional 4K experience. Show movies the way they were meant to be seen — on the big screen, with bright, full color; stunning resolution; and no rainbow effect. It’s an exceptionally immersive viewing experience that will impress any guest.

This stylish and compact projector supports 360 degree installation without compromising the display quality and supports 16:6 ultra-widescreen, HDMI output and edge blending for multi-projector installs.
