​You"re on the right track to successfully repairing your Vizio E601I-A3! Now that you"ve identified your model, we highly recommend matching the part number on the part(s) you"re replacing to ensure compatibility. ​If you don"t see your part listed below, please try searching by your part number or contact us for help!

Bit depth is the number of bits used to indicate the color of a single pixel. The more bits, the more color range a panel displays. An 8-bit panel uses 256 levels per channel and displays 16.7 million colors, while a 10-bit one reaches 1024 and displays 1.07 billion colors.

The most widely used panels are those with 6, 8, and 10 bits for each of the RGB components of the pixel. They provide 18-, 24-, and 30-bit color, respectively.10 bits

Frame Rate Control (FRC) is a method, which allows the pixels to show more color tones. With quick cyclic switching between different color tones, an illusion for a new intermediate color tone is created. For example, by using FRC, a 6-bit display panel is able to show 16.7 millioin colors, which are typical for 8-bit display panels, and not the standard 262200 colors, instead. There are different FRC algorithms.No

The maximum number of colors, which the display is able to reproduce, depends on the type of the panel in use and color enhancing technologies like FRC.1073741824 colors

The backlight is the source of light of the LCD display panels. The type of backlight determines the image quality and the color space of the display. There are various backlights such as CCFL, LED, WLED, RGB-LED, and etc.Edge LED

The RUNTK5261TPZC T-Con board is located in the middle top of the back panel, usually under an aluminum cover held in place by four corner screws. It may also be held in place with foil tape at the top. It’s connected to the Main board through a black LVDS cable and flat ribbon cables.

It’s long been true that if you wait long enough, the price of technology will drop down to meet your budget. Flat-screen HDTVs are prime examples. We’ve recently seen manufacturers respond to the current global financial malaise by squeezing their beans hard enough to produce decent sets for around $1,000. While it’s difficult to say if this trend is due to economic conditions or pressure from price-aggressive new manufacturers, Vizio has been in the vanguard of the young guns making life difficult for traditional HDTV companies. And the company’s not standing still. Exhibit A: Vizio’s new $1,000 E601i-A3. Like its big brother, the 70-inch, $2000 E701i-A3, it’s a true budget buster, but for a change, the budget they’re busting isn’t yours.

The E601i-A3 is remarkably thin for the price, though a bulge in the back panel makes it closer to 2 inches overall rather than the specified 1 inch. The provided stand does not rotate, and the screen is reflective—though less so than some of its pricey competitors. All of its back-panel connections face either down or to the side where they won’t interfere significantly with a wall-mount installation.

The E601i-A3 can perform motion smoothing via two controls: Smooth Motion Effect and Real Cinema Mode. They must be used together if you want motion compensation. With Real Cinema Mode off, all motion compensation is disabled. If you like motion smoothing via frame interpolation, the Vizio’s is as effective as most. It does what it was designed to do on most source material. But apart from checking this feature, I didn’t use it; the slick smoothness of motion interpolation looks bizarre and distracting to me on film-based sources. A good plasma set, which doesn’t need interpolation, can do better than the Vizio (even with motion interpolation) on horizontal movement, though with its Smooth Motion Effect on high, the Vizio excelled on vertical and diagonal motion.

The Vizio offers the usual wide range of Web-based goodies, accessible either through the wired Ethernet port or wirelessly from your home network via the set’s built-in Wi-Fi receiver. You can also view and/or listen to your own photographs, videos, and music through the E601i-A3. The directly available Internet sites include Hulu Plus, Amazon Instant Video, Vudu, Facebook, Pandora, news, weather, and sports sites, and more. The pictures on several HD Hulu Plus trailers were respectable, though such HD streaming, as we’ve noted before, was still not up to full Blu-ray quality.

Up to now, a 60-inch flat-screen HDTV for less than a grand was a fantasy. But with the E601i-A3, that’s no longer true—at least in size and price. But can it stack up against the big boys? In most important respects, definitely. Its video processing was outstanding, equal to or better than that of some significantly more expensive sets. It passed all of our standard processing tests, and even some nonstandard ones, without a misstep.

The Vizio’s off-axis performance could be an issue with some viewers, but no more so than with most LCD sets. The color saturation starts to lighten a bit as you move about 20 degrees off center, and while it remains viewable well beyond that, it deteriorates progressively at wider angles. In screen uniformity, there was a slight unevenness in the set’s reproduction of a full black screen image, but it was barely visible. With a full white field, I sensed a trace of magenta discoloration here and there, but it was almost subliminal and never an issue in real-world viewing.

Bit depth is the number of bits used to indicate the color of a single pixel. The more bits, the more color range a panel displays. An 8-bit panel uses 256 levels per channel and displays 16.7 million colors, while a 10-bit one reaches 1024 and displays 1.07 billion colors.

Do note that the symptoms indicated above may have other causes so do be careful in the troubleshooting process. Case in point, if there are no pictures on the screen, you will need to check if it is not a problem with the LED backlights. You will want to perform the “flashlight test” to see if the LCD panel is really creating images but the backlights are just not functioning. This test was performed in repairing a Vizio TV that has sound but no pictures (you may want to check that out). Granted that the TV also has no sound, there’s good likelihood that the issue is not due to faulty LED backlights but it will not hurt to do a quick check as the flashlight test is very easy to do anyway.

This TV has the same SRS TruSurround speaker system as many of the other entries in the E-series. The TruSurround system is designed to give you a more immersive experience with deep bass and clear dialogue from speakers specifically designed for use in flat panel TVs.

The Vizio E601I-A3 comes enabled for wireless connection out of the box for access to Vizio"s suite of internet apps. This gets you access to just about all of the best places online to stream media, connect to social networks, or read the news.
