The back has a large hole to allow the display and RS232 cable to pass into the case as well as enough room for the cables to mount and flex without pinching.

Holes in each corner that mounts through the top of the case, through the TFT5 and then into the back. Uses 4 M3x10mm. For the bracket, you will need M3 Tnuts.

I"ve been working on a project that used a 16x2 LCD display and wanted a nice finish that also allowed me to seal against water and other liquids. I also needed impact resistance, low cost and the ability to be changed easily if worn or broken.

So, eventually I tried something else and ended up with what I think is a nice professional finish that is easy to do, cheap, and results in an iPhone type black glass frame style, with a clear window exactly the right size to show the display properly. It can also be easily adapted to any other type or size of display.

I took the original dimensions of the 16x2 LCD display I had and drew it up, including the stand-off holes. I then added an additional 5mm surround to give my bezel additional strength around the fixing holes, and also to make it look better since the holes wouldn"t be right on the edge.

For the 16x2 LCD the display area is approx 15mm x 65mm. I made my window 14mm x 64mm so there is a slight overlap to the display so no edges can be seen.

Remove the template and then peel the outer area of tape away and this will leave a nice clean cut 14mm x 64mm piece where our display will eventually show through.

These correspond exactly to the stand-off holes in the LCD PCB. This means we can use a single metal or plastic bolt to mount both our bezel and the LCD when finished.

We now want to spray paint the area that will be the bezel outer border. Choose your colour for this, although I used black and found it produced a lovely black glass type finish.

EDIT: On making one for a 64x128 1.8" TFT display it occurred to me that we can simply mask the back side of the acrylic completely. This ensures 100% that you don"t get any overspray on what will become the top face. When everything is dry just peel off the masking on the other side too.

You can now mount the bezel to your enclosure, using the mounting holes and some 3mm bolts. The same bolts can be used to mount the LCD behind. I found 3mm x 20mm bolts are ideal. You can also use nylon ones that are used for PCB stand-offs.

Awesome idea! I"m just starting on an Arduino based chess timer project with a small VFD display and a couple of those big "arcade" style microswitch buttons for my son and was thinking about how to make a decent looking hole / bezel for the display. Your instructable solved my problem elegantly! Thanks and thumbs up for you!

Another trick is to use stand-offs behind the front panel, bolted to the front panel via countersunk holes at the front with the relevant bolts, then mount the operstional display etc to the stand-offs. The front bezel can then be applied OVER the countersunk bolts using double-sided adhesive or using a silicone bead as it should never need to come off again. I am using this process currently for a frequency meter display.

I made this to contain a 1.8"TFT screen ST7735 and attach it to a project box which contained an Arduino. The template allowed me to precisely cut out the holes for the cables and the screws to hold it in place and then seal the main box from the bezel and the screen with hot glue. Obviously you don"t need to print the template and it is overly thick.

You will need to cut a piece of clear plastic which needs to be exactly 2mm thick to cover the opening. The screen of the display will push up against this and hold it in position.
