Having checked out your video, I personally will not use the aftermarket screen as a replacement for my X. It just doesn"t have what I expect for a $1000 USD phone. I recognize that $300 USD for a replacement is hefty but the aftermarket screen does not appear to have the quality that I would expect for my phone.

Since the iPhone 7/7 Plus has been released for quite a long time, finally the China made iPhone 7/7 Plus screen replacementscame out in the market. we’ve got some iPhone 7 series LCD screen replacements samples and done some tests on them, now let’s take a closer look at these new iPhone 7 series LCD screen replacements!(TianmaandLGsources for testing)

After installing all the sample screens to the iPhone 7/7 Plus rear housing assembly, we found that all the China made iPhone 7 series screen replacements are fitting well just like the original ones - the home button fits well, the screen assembly and the rear housing also fits well.

From the picture below, we can see that there is no difference between the China made iPhone 7 series display and the original ones, however, back to the rear side, we can easily figure out which one is which, cause the original one has Apple logo on it while the China made screen has none.

By comparing these two iPhone 7 screens, we can find that the screen flex cables are much different, there are extra IC on the China-Made iPhone 7 screen while the original one has none. And the original iPhone 7 series screen flex cable is integrated together while on the China-Made iPhone 7 series screen the touch function flex cable is soldered to the display and 3D touch flex cable.

Another difference between the original and China made iPhone 7 screen replacements is the exposed IC on the after-market iPhone screen, just like other China-Made iPhone 5 or 6 series screen replacement, which has more potential risk of electrostatic damage and more likely to get damaged and this problem needs to be improved.

During our test, we found that the display color between our after-market iPhone 7 screen and original screen seems a little different although they are not effecting the touch function. And to be honest, there may have some black dots on the screen because of impurities within the screen module when laminating the LCD and backlight together, without any doubt, this can be solved with technical improvement.

The screen touch sensitivity is another big concern for all of us, luckily, during our test, almost all home button and touch functionality on both iPhone 7 and 7 Plus works well, except one piece of iPhone 7, the 3D touch function is not acting so well on the central part of the screen.

The China-Made iPhone 7 series LCD screen assembly replacement still remains to be improved in quality and performance compared to the original ones, the exposed IC, heavier screen flex cable ribbon, and the screen color difference, the touch function stability, although the price is attractive. However, the China made iPhone 7 series screen replacement is under the improvement, and sooner or later their quality and performance can be quite close to original ones and acceptable, if you"re going to stock up some non-original iPhone 7 series LCD screen replacement, pay more attention and we’ll keep you updated with further information about after-market iPhone 7 series screen replacement!

“Original” screens are those containing LCDs manufactured for Apple. “Copy” screens are compatible replacements entirely designed and manufactured by third-party companies not associated with Apple.

LCD display panel can have poorer resolution (i.e. looks “coarser”), worse brightness, contrast and vibrancy and reduced refresh rate amongst other problems.

Changes in specification from original can result in battery and performance issues. Certain badly-engineered screens could even damage the backlight circuitry.

Customers who bring their iPhones to us for a screen repair are offered two choices of replacement- an original or a “copy” screen. The most common response is “Is there a difference- and which one would you recommend?”

Originals are those screens containing LCDs that were manufactured for Apple. So-called “copy” screens are compatible replacements, but designed and manufactured entirely independently by third-party companies, typically in China.

Our answer is simple- the original screen is the one we’d go for ourselves, every time. Some people think we make more money on them, but this isn’t the case. We recommend originals because they’re far higher quality and the price difference is fairly small.

We’d rather only fit original screens. The only reason we don’t is that many people will shop around and choose purely on price. As such, we need to offer the cheaper copy screens to remain competitive and avoid losing these customers. In some cases, they didn’t even know there was a difference in the first place- especially since it’s not in some shops’ interest to draw people’s attention to the issue!

This may well be the worst copy screen we’ve ever come across. As a result, the unfortunate customer has ended up paying twice to have their screen replaced- we’re sure that had they been properly informed, they would have chosen an original in the first place.

While the difference in price between copies and originals can vary across devices, it’s generally around £10 – £14 extra to have an original screen fitted. This really isn’t a lot considering the improved quality and reliability.

We compare our prices to our competitors- and we know that we come out of it favourably. While we have to offer copy screens to remain competitive, we always advise customers to go for the original.

When you’ve spent- directly or indirectly- several hundred pounds for an iPhone with a Retina display, it doesn’t make sense to replace it with a lower-quality screen that can make a £400 phone look like a £40 one! Not only that, but you’re likely to have fewer issues, and a longer-lasting screen.

There’s nothing stopping any random person without training or experience opening up a smartphone repair shop. As a result, the industry is full of companies with little skill or experience who are only interested in getting hold of your money and installing the cheapest parts they can find.

Many- if not most- don’t even acknowledge the existence of copy screens, let alone explain the difference to the customer. Hardly in their interest to do so if they only fit cheap, low-quality copies. Some of them can hardly be blamed- they know so little, they’re not even clear on the differences between OEM, non-OEM and copy displays themselves! Others can be more deliberately misleading… and some outright lie.

Generally, these shops are looking for the cheapest price on replacement screens.. When offered a copy at a half or a third of a price of the original, they’re going to go for that. That might be fine if they offered the customer a cheaper price- what we disagree with is selling “supermarket beans” (i.e. the copy screens) at “Heinz beans” prices!

Heading towards the “blatantly fraudulent”, we’re aware of companies that shamelessly fit copy screens while claiming them to be original. Worse, they’ll take your broken original screen and sell that to a recycler for more than they paid for your copy!

Obtained or manufactured “off the clock” via the same production line that produced them for Apple- in some cases, from the stockpile of parts that didn’t meet Apple’s standards, or

Apple tightened up their supply chain around 2015, which reduced the number of screens available for repairs and increased their price dramatically. A lot of companies went bankrupt, and Chinese manufacturers responded by making their own “copy” screens from scratch. At first, these weren’t much cheaper than the Apple ones, but the price soon fell.

We should be clear that- despite the name- “copy” screens aren’t direct copies of the Apple originals. Rather, they’re compatible replacements that have been designed from scratch and- as a result- vary in some respects that have an effect on usability and quality.

One of the most important differences between an original and a “copy” screen is how the digitizer (touch sensor) is designed. Apple has it manufactured as part of the LCD itself, whereas the copies have it on the glass.

Although there are only a small number of manufacturers of the bare LCDs themselves, these are then bought by countless other companies who add the remaining components needed to turn these into a complete working screen. As a result, you could easily end up with an LCD from the best “copy” manufacturer, but the digitizer/touch (as part of the separately-manufactured glass) from the worst.

There are countless digitizers out there, and you can only take the supplier’s word that the quality is good. Many ship good ones at first, then switch to cheaper parts to make more profit. This is particularly bad with the iPhone 6S and 6S+, since Apple moved the chips responsible for touch processing onto the LCD itself. As a result, you’re not just getting a copy screen- you’re getting copy chips too.

The performance specification (power drain, etc.) of most copy screens isn’t identical to the originals. As a result, they can drain the battery more quickly and mislead the operating system which was optimised for the original screen design.

It’s even possible that this mismatch could damage your backlight. We do a lot of subcontracted repairs for less-experienced shops, and get backlight repairs in almost every day. We’ve had cases where we fixed the circuit, fitted the new copy screen to test it, and had it break the circuit again!

Copy screens can disrupt the touch ID fingerprint reader. With the 6S, 6S+, 7 and 7+, the home button- part of the 3D touch- is part of the screen assembly. Frequently the home button flexes on aftermarket designs don’t work properly and stop the touch ID working- annoying if you use it to unlock the phone or log in to your bank.

We’ve seen many lift away from the frame that holds them in place. This usually results in the flex cable getting torn, and the screen needing replacing. You don’t even need to have dropped the phone- this often happens through general everyday wear and tear.

That brings us to another major issue with the copies. When you drop an Apple original, the glass often breaks, but if the LCD itself is intact, you can continue to use it until it’s fixed. With the copies, the touch/digitizer is on the glass and stops working when that’s broken. Even worse, the LCD itself is more likely to break due to the thinner and more fragile glass.

We’re not convinced this will happen, since Apple recently changed their repair policy to accept iPhones with third-party screens. However, it is possible that copy screens could be stopped from working via an iOS update, since those make a number of security checks.

For most customers, visiting a professional repair provider with certified technicians who use genuine Apple parts is the safest and most reliable way to get a repair. These providers include Apple and Apple Authorized Service Providers, and Independent Repair Providers, who have access to genuine Apple parts.* Repairs performed by untrained individuals using nongenuine parts might affect the safety of the device or functionality of the display. Apple displays are designed to fit precisely within the device. Additionally, repairs that don"t properly replace screws or cowlings might leave behind loose parts that could damage the battery, cause overheating, or result in injury.

Depending on your location, you can get your iPhone display replaced—in or out of warranty—by visiting an Apple Store or Apple Authorized Service Provider, or by shipping your iPhone to an Apple Repair Center. Genuine Apple parts are also available for out-of-warranty repairs from Independent Repair Providers or through Self Service Repair.*

* Independent Repair Providers have access to genuine Apple parts, tools, training, service guides, diagnostics, and resources. Repairs by Independent Repair Providers are not covered by Apple"s warranty or AppleCare plans, but might be covered by the provider"s own repair warranty. Self Service Repair provides access to genuine Apple parts, tools, and repair manuals so that customers experienced with the complexities of repairing electronic devices can perform their own out-of-warranty repair. Self Service Repair is currently available in certain countries or regions for specific iPhone models introduced in 2021 or later. To view repair manuals and order parts for eligible models, go to the Self Service Repair page.

With the lack stock of the original iPhone 5 & 6 series LCD screen, the China made LCD screens becomes more and more popular among the repair shops. As the originaliPhone 6 Plus LCD screenprices are still high and not likely to fall down, plus more and more repair shops are tending to accept the China made LCD screens replacement instead, therefore, China made iPhone 6 Plus LCD screen appeared on the market naturally.

Recently we have got some samples of the China Made 6 Plus LCD screen, which have been called ‘LG 1:1 version’ on the market. We did some tests with these samples and found some differences compared to other China made LCD screens.

After tests, we found some differences in LCD frame height, glass screen thickness and the home button location among these 5 samples. You may wonder why these differences exist while they are sourcing from the same manufacturer?

Thus we need to learn the production process of the China made LCD screens, which was assembled by the 3rd party manufacturers, who purchased the China made LCD,LCD frame,glass lens,metal shields, screen foam and digitizer from different manufacturers, which could be original or high copied ones. Since there are some differences among theseglass lenses, LCD frames and so on, even though they shared the same LCD, there will still be some difference.

There is no doubt that significant differences existed between these 2 kinds of LCDs whether in display effect or working stability. In pursuit of greater profits, there is no strict requirements and standards for China made LCDs production process as long as the LCDs can achieve the basic using requirements. Therefore there is quite a gap in color difference, viewing angle and working stability compared to original ones, as the LCDs which are designed for the other brand cellphones, after replacing the IC and flex cable, have been inspected strictly before flowing to the market. (Such as the Samsung GalaxyS3 LCD screen assemblywhich are transformed from the GiONEE phones. Due to the few original stock in availability, most of the S3 LCD screen assemblies are produced by Samsung through transforming GiONEE LCDs.

It is said that these China made iPhone 6 Plus LCD screens are transformed from the MeiZu Meilan Note LCDs (Also features 5.5 inches) which are produced by Sharp and AUO, the overall performances of these LCD screens are better than LT/TM/JDF’s. And what’s big different from the other LCD screens is that there is one more LCD drive IC on the screen flex cable.

Because of the big production MOQ and long R & D cycle, the customized China made LCD screens had some difficulties intechnologyimprovementwith the changes of the marketing demands, while the original LCD features higher quality and reliability.

For these China made iPhone 6 Plus LCD screens, theLCD frametending to pop off and LCD screens are thicker. But in display effects, China made iPhone 6 plus LCD screens are better than5 series. Those customers who cared more about the prices will have one more choice once the improvements of the China made iPhone 6 Plus have been implemented. And we also will continue to focus on the China made iPhone 6 Plus LCD screen assembly.

All the test procedures were analyzed in detail with opinions proposed. Now, let’s take a close look to the first China madeiPhone 7 Plus LCD Screen sample with professional testing report below.

To analyze inside layers of the iPhone screen, we tear it down layer by layer .The sample China made screen applies G + G layer structure, there is a glass base touch layer,

The quality and performance is quite close to OEM and acceptable, and sure it will come with impressive lower price offer. The display panel is China made with G + G layer structure, and the screen is assembled with a third-party driver IC solution.

The rumor that the China made iPhone LCDs can’t survive the upcoming iOS updates existed for quite a long time which aroused panic among repair shops. Many repair shops who want to use/have already used these screens to compete with authorized repair are wondering, will Apple brick these iPhone to kill the third party repair? We ETrade Supply don’t think so and here is why:

Do you still remember that users sued Apple for bricked iPhone due to "error 53"? The situation is almost the same except only few people have let their home button be replaced by third party repair shops. How many China made iPhone LCDs have been sold? We don’t have the exact number. However, from what we know, the number should be over 1 million pieces at least. Will Apple brick millions of iPhones just to kill third party repairs?

Same rumors for the 4/4S screen before. The OEM LCDs for 4/4s died out for quite a long time, all screens supplied were China copy one since 2 years ago. Not a case of bricked phone/unusable have showed for the updating to the new iOS system.

The most possible reason that this rumor has been created—is just to cut the price of the China copy iPhone LCD and more possibly-- the demand for it.

A week before the Apple event in March 2016, the rumor was “China made iPhone LCDs can’t survive in the coming iOS 9.3 updates”, the price of these LCDs dropped significantly and everyone was holding their orders, waiting to see the result. Within one week, the price has dropped around $10/pc. After people found out that they did survive, the price increased again and here came the rumor “the China made iPhone LCDs won’t survive the iOS 10 updates”.

Since last June, more and more repair shops have accepted the China made iPhone LCDs because less OEM screens are supplied. A large certain amount of demand of OEM iPhone screens has been moved the China made ones. The rumor that “the China made iPhone LCDs won’t survive the newest iOS updates” will sure bring some demand back to those crappy OEM screen which have been used for quite a long time/ refurbished for multiple times.

The rumor is “ALL the China made iPhone LCDs won’t survive the iOS 10 updates”, not only for 5 series. As we all know, there are already China Made 6 screens in the market. Those who stocked large amount OEM 6 screens will be happy to see people still paying high price for the OEM 6 screens for quite a long time.

The supply chain of cell phone replacement parts is sophisticated, unclear and without any standards, which make it look more like gambling. Find a reliable long-term relationship partner who can grow with you is the key to success for repair shops. If you have any questions regarding the China made LCDs, please leave your comment below!

Owners of iPhone, iPad, iPod, Mac, or Apple TV products may obtain service and parts from Apple service providers, including Apple Retail Stores and Independent Repair Providers, for a minimum of 5 years from when Apple last distributed the product for sale.

Service and parts may be obtained for longer, as required by law or for up to 7 years, subject to parts availability. Additionally, Mac laptops may be eligible for an extended battery-only repair period for up to 10 years from when the product was last distributed for sale, subject to parts availability.

Apple discontinues hardware service for certain technologically-obsolete products. Your device is supported by ongoing OS updates and backed by a network of more than 5,000 Apple-certified repair locations that you can count on if something unexpected happens.

Apple devices are designed to be long-lasting. They are made of durable materials that are heavily-tested in our Reliability Testing Lab. The longer you use your device, the better it is for the planet. For more information about Apple and the environment, go to https://www.apple.com/environment.

For products purchased in France, see Statutory Warranties of Seller and Spare Parts. Owners of new iPhone or Mac laptop products purchased after December 31, 2020 in France, may obtain service and parts from Apple or Apple service providers for 7 years from the date the product model was last supplied by Apple for distribution into France.

Products are considered obsolete when Apple stopped distributing them for sale more than 7 years ago. Monster-branded Beats products are considered obsolete regardless of when they were purchased.

Apple discontinues all hardware service for obsolete products, with the sole exception of Mac laptops that are eligible for an additional battery-only repair period. Service providers cannot order parts for obsolete products.

Use our “Get an Estimate” tool to review potential costs if you get service directly from Apple. The prices shown here are only for screen repair. If your iPhone needs other service, you’ll pay additional costs.

If you go to another service provider, they can set their own fees, so ask them for an estimate. For service covered by AppleCare+, your fee per incident will be the same regardless of which service provider you choose.

Your country or region offers AppleCare+ for this product. Screen repair (front) is eligible for coverage with a fee by using an incident of accidental damage from handling that comes with your AppleCare+ plan.

The Apple Limited Warranty covers your iPhone and the Apple-branded accessories that come in the box with your product against manufacturing issues for one year from the date you bought them. Apple-branded accessories purchased separately are covered by the Apple Limited Warranty for Accessories. This includes adapters, spare cables, wireless chargers, or cases.

Depending on the issue, you might also have coverage with AppleCare+. Terms and Conditions apply, including fees. Feature availability and options may vary by country or region.

We guarantee our service, including replacement parts, for 90 days or the remaining term of your Apple warranty or AppleCare plan, whichever is longer. This is in addition to your rights provided by consumer law.

Replacement equipment that Apple provides as part of the repair or replacement service may contain new or previously used genuine Apple parts that have been tested and pass Apple functional requirements.

A question we often get asked is “Do you accept copy screens?” Put simply, we don’t- we only accept OEM and Non-OEM screens. However, people still send us copy screens for recycling and refurbishing, possibly because the difference isn’t as clear as it might be.

This didn’t stop wholesalers in China referring to iPhone screens as “original”, “high copy” or “copy”. However, this didn’t refer to the screen per se. This actually meant the quality of the glass, frame and small parts on the screen rather than the LCD itself.

If you bought “original” quality then you would have been sent a screen that came from one of the factories making screens for Apple, which was refurbished with as close to original parts as possible or was pulled from a new phone. “Copy” and “high copy” screens still used an original LCD but were refurbished with lower quality parts– exactly there the “copy” came into play.

In 2015 there was a major shortage of iPhone screens and this drove the price to more than three or four times the regular selling price. This forced the factories in China to develop their own screen so the shortage didn’t affect them. These screens are made in a completely different way to the original Apple screens, and the quality varies depending on the factory making the LCD and the factory assembling it.

Apart from the difference in quality, an OEM screen (i.e. an original Apple one), has the touch on the LCD. During refurbishment the glass is removed and the touch stays with the LCD. This is the same with non-OEM screens as these use the original Apple LCD.

However, copy screens are entirely different as most of those have the touch on the glass. Once the broken glass is removed the touch is lost. While copy screens can be refurbished they take more work than an original screen and have next to no value especially as the cost of copy screens is dropping all the time.

There are a number of identifying marks you can use to determine if the screen is OEM, non-OEM or a copy. This varies from model to model and the lists given below are not exhaustive. These are simply the things we use to determine which type of screen it is.

Copy screens are entirely new screens designed and manufactured by independent third parties without the involvement or endorsement of Apple. To spot a copy screen:-

When you’ve been checking screens for as long as we have it becomes second nature to determine the type of screen it is in seconds. When we’re testing a batch of screens that comes in, any copy screens are filtered out without checking if they work because we don’t recycle or refurbish these. The original screens are then processed to be tested and dealt with under the service you’ve requested.

As part of its new $149 iPhone screen replacement service, Apple has installed advanced display calibration machines at its retail stores that help simplify the process for employees.

A picture of the new machine was published this week by 512pixels.net, offering a glimpse at how iPhone 5 screens are replaced behind the scenes at Apple retail stores. Employees conduct the repair, and the machine is used afterward to automatically calibrate the display"s functionality.

One Apple retail employee reportedly said the new machine is like "bringing China to the Genius Room," referencing the fact that Apple"s iPhones are currently built overseas by Foxconn.

iPhone repairs are said to have been made a priority for employees of Apple"s Genius Bars. With sales of 47.8 million iPhones last quarter alone, Apple"s smartphone sold more than every other product in the company"s portfolio combined.

Word first surfaced earlier this week that Apple began repairing iPhone 5 screens in its stores as part of the company"s overhaul of its AppleCare warranty program. Previously, broken units were swapped out for refurbished devices.

AppleInsider first reported in May that Apple would begin conducting advanced in-store repairs of iOS devices. Beyond iPhone displays, retail employees will be able to replace cameras, sleep/wake buttons, and logic-boards by July.
