ER-TFT080-1 is 800x480 pixels 8" color tft lcd display with OTA7001A driver IC,optional capacitive touch panel with controller and connector,optional 4-wire resistive touch panel with connector,superior display quality,super wide view angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO, ARM and Raspberry PI.Equivalent with AT080TN64,AT080TN52.

ER-TFTM080-2 is 800x480 dots 8" color tft lcd module display with RA8875 controller board,superior display quality and easily controlled by MCU such as 8051(C51), PIC, AVR, ARDUINO, and ARM .It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.

It supports 8080 6800 8-bit,16-bit parallel,3-wire,4-wire,I2C serial spi interface.Built-in MicroSD card slot.It"s optional for 4-wire resistive touch panel with controller and capacitive touch panel with controller,font chip, flash chip and microsd card. We offer two types connection,one is pin header and the another is ZIF connector with flat cable mounting on board by default and suggested.

Of course, we wouldn"t just leave you with a datasheet and a "good luck!".Here is the link for 8" TFT Touch Shield with Libraries, Examples.Schematic Diagram for Arduino Due,Mega 2560,Uno. For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and development kit at the bottom of this page.e.

A wide variety of lcd display 640x480 options are available to you, You can also choose from original manufacturer, odm and retailer lcd display 640x480,As well as from tft, ips, and standard.

RFG560B-AIW-DNN is a TN transmissive type color active matrix 640x480 TFT LCD display module. The size of the active area is 5.6” diagonal with module dimension 126.5x100 mm. This 5.6-inch 640x480 TFT display module adopts RGB Interface. It’s brightness (typical value) is 350 cd/㎡, and contrast ratio (typical value) is 500:1.

Power voltage ranges from 3.1V-3.5V; typical value is 3.3V. The module works within the temperature -20 to +70℃, storage temperature covers from -30 to +80℃. Feel free to send us inquiry if you"d like to know more information.

Smart TFT LCD display embeds LCD driver, controller and MCU, sets engineer free from tedious UI & touch screen programming. Using Smart TFT LCD module, our customers greatly reduce product"s time-to-market and BOM cost.

This 640x480 resolution LCD TFT is a standard display with 8-bit parallel interface and a 6:00 optimal view. This Liquid Crystal Display has a built-in SSD1963 controller and a 4-wire resistive touchscreen. The TFT is RoHS compliant and has been discontinued. Purchase now while stock is still available!

Winstar Display released a new 5.6 inch standard higher resolution TFT LCD Display . The dimension is similar to regular 5.7" standard 320x240 TFT modules but with a better resolution of 640x480 dots. The WF56B is a good option for customers while designing a new project which request a better resolution or completive price. The display WF56B is with outline dimension of 126.5 x 100.0 mm and AA size of 112.896 x 84.672 mm. WF56B module can be operating at temperatures from –20℃ to +70℃; its storage temperatures range from -30℃ to +80℃.

Focus Displays offers a wide range of standard full color TFT displays. 64 million unique colors, high brightness, sharp contrast, -30C operating temperature, and fast response time are all good descriptions of a TFT display. This is why TFT technology is one of the most popular choices for a new product.

Thin Film Transistor (TFT) display technology can be seen in products such as laptop computers, cell phones, tablets, digital cameras, and many other products that require color. TFT’s are active matrix displays which offers exceptional viewing experiences especially when compared to other passive matrix technologies. The clarity on TFT displays is outstanding; and they possess a longer half-life than some types of OLEDs and range in sizes from less than an inch to over 15 inches.

CCFL’s are still available, but are becoming a legacy (obsolete) component. TFT displays equipped with a CCFL require higher MOQs (Minimum Order Quantities) than displays with LED backlights.

The majority of TFT displays contain a touch panel, or touch screen. The touch panel is a touch-sensitive transparent overlay mounted on the front of the display glass. Allowing for interaction between the user and the LCD display.

Some touch panels require an independent driver IC; which can be included in the TFT display module or placed on the customer’s Printed Circuit Board (PCB). Touch screens make use of coordinate systems to locate where the user touched the screen.

Resistive touch panels are the lowest cost option and are standard equipment on many TFT modules. They are more common on smaller TFT displays, but can still be incorporated on larger modules.

Capacitive touch panels have become popular with such software as Windows 8®, Android® and Apple®. Additionally it is used in products such as cell phones and tablets, where multi-touch and zoom capabilities are important.

Contrast ratio, or static contrast ratio, is one way to measure the sharpness of the TFT LCD display. This ratio is the difference between the darkest black and the brightest white the display is able to produce. The higher the number on the left, the sharper the image. A typical contrast ratio for TFT may be 300:1. This number ratio means that the white is 300 times brighter than the black.

TFT LCD displays are measured in inches; this is the measurement of the diagonal distance across the glass. Common TFT sizes include: 1.77”, 2.4”, 2.8”, 3”, 4.3”, 5”, 5.7”, 5.8”, 7”, 10.2”, 12.1 and 15”.

TFT resolution is the number of dots or pixels the display contains. It is measured by the number of dots along the horizontal (X axis) and the dots along the vertical (Y axis).

The higher the resolution, the more dots per square inch (DPI), the sharper the display will look. A higher resolution results in a higher cost. One reason for the increase in cost is that more driver chips are necessary to drive each segment.

Certain combinations of width and height are standardized and typically given a name and a letter representation that is descriptive of its dimensions. Popular names given to the TFT LCD displays resolution include:

Transmissive displays must have the backlight on at all times to read the display, but are not the best option in direct sunlight unless the backlight is 750 Nits or higher. A majority of TFT displays are Transmissive, but they will require more power to operate with a brighter backlight.

A primary job of the driver is to refresh each pixel. In passive TFT displays, the pixel is refreshed and then allowed to slowly fade (aka decay) until refreshed again. The higher the refresh frequency, the sharper the displays contrast.

The TFT display (minus touch screen/backlight) alone will contain one controller/driver combination. These are built into the display so the design engineer does not need to locate the correct hardware.

If you do not see a Thin Film Transistor (TFT) Display module that meets your specifications, or you need a replacement TFT, we can build a custom TFT displays to meet your requirements. Custom TFTs require a one-time tooling fee and may require higher MOQs.

Ready to order samples for your TFT design? Contact one of our US-based technical support people today concerning your design requirements. Note: We can provide smaller quantities for samples and prototyping.

The CFAF480640B-035T-TS has a transflective polarizer, and therefore is sunlight readable. The TFT display resolution is 480x640 (portrait) 640x480 (landscape) (VGA, 480xRGBx640, 640x480xRGB), can display 262,000 colors, uses active matrix addressing, and measures 3.5" diagonally. This display also features a 4-wire resistive touch screen, which allows the use of the touch screen while wearing gloves and other insulating materials. It has 10 bright white, series LEDs and the transflective polarizer looks great both in the sun and in the dark. It uses a polarizer specifically designed to provide a wide viewing cone from all sides of the display. This TFT display is perfectly suited for both indoor and outdoor use. Did we mention that the transflective polarizer makes it fully readable in direct sunlight? That same direct sunlight makes the viewing of ordinary TFT displays extremely difficult, but the CFAF480640B-035T-TS is unaffected.

Do you like the display but don"t need the touch screen? The CFAF480640A-035T is the same TFT without a touch screen. It is slightly thinner and the price is lower.

With an active area of 53.57x71.42mm and a resolution of 640 x 480 (landscape) or 480 x 640 (portrait), this display has a very high pixel density. The Himax HX8363-A or compatible controller in this sunlight readable TFT display is the HX8363A which exposes a generic RGB interface so you won"t run into any trouble getting the display up and running. The logic voltage range of 2.5v to 3.3v allows direct connection to 3.3v processors.

This display is available as a standalone part but it can also be purchased with a Breakout Board + Display below. This breakout board brings LCD connections out to 0.1" center pins, and includes the current controlled backlight driver. Perfect for prototyping into your project.
