The ST7789 TFT is a color display that uses SPI protocol. This display is an IPS display, it comes in different sizes (1.3″, 1.54″ …) but all of them should have the same resolution of 240×240 pixel.

The ST7789 display module shown in project circuit diagram has 7 pins: (from right to left): GND (ground), VCC, SCL (serial clock), SDA (serial data), RES (reset), DC (or D/C: data/command) and BLK (back light).

The ST7789 TFT display works with 3.3V only (power supply and control lines). The display module is supplied with 3.3V that comes from the AMS1117 3V3 voltage regulator, this regulator steps down the 5V into 3.3V (supplies the display controller with regulated 3V3).

To connect the PIC18F46K22 with the display module, I used voltage divider for each line. This means there are 4 voltage dividers. Each voltage divider consists of 2.2k and 3.3k resistors, this drops the 5V into 3V which is sufficient.

If the display module has a CS pin (Chip Select) then it should be connected to the PIC18F46K22 microcontroller through another voltage divider (for example connecting it to pin RD2).

In this project SPI1 module is used with SCK1 on pin RC3 (#18) and SDO1 (MOSI) on pin RC5 (#24). SCK1 and SDO1 pins of the PIC18F46K22 MCU are respectively connected to SCL and SDA pins of the ST7789 display module.

The default connection setting of the mikroC ST7789 TFT library is hardware SPI1 module (SPI1 module must be initialized before initiating the display). Instead of hardware SPI1 module, software SPI or hardware SPI2 module can be used.

If TFT data pin (TFT_DIN) and clock pin (TFT_SCK) are defined in the main code (before #include “ST7789.c”) then the library will automatically use software SPI.

If the display module has a CS pin uncomment its related lines (#define TFT_CS and #define TFT_CS_DIR) and connect it to RD2 pin of the microcontroller through voltage divider.

I have a small 3.5 in TFT LCD display from a Chinese manufacturer. It doesn"t have an integrated LCD controller. The documentation claims it is a "16 bit RGB/parallel interface" and it uses a Renesas R61581B0 driver chip.

These types of displays are very common and cheap. They sell for less than $15 a pop on Alibaba.com, but I don"t really have a high esteem for these manufacturers since they do not provide any good / consistent documentation, and their English is riddled with mistakes! But I did get the display, and the product looks and feels like it will do the job!

My question now is, how do I get started ? I have looked on the internet and cannot find a good starting point. I have a 32MHz microcontroller in mind, but I am stumped on how to interface it with the LCD.

Most display projects online that I"ve seen assume that the LCD module comes with an integrated controller , so the MCU"s job becomes pretty simple.. Provide image updates when necessary, and the controller will do the job of refreshing the LCD module at the required 60hz (or so)

This LCD module that I have has raw data lanes that I need to drive myself at 60hz. Are there any good documents on how to interface an MCU directly with such an LCD module?

I"ll be happy with any info that points me in the right direction, whether it be an answer on stackexchange or a reference to any good documentation online.

In electronics world today, Arduino is an open-source hardware and software company, project and user community that designs and manufactures single-board microcontrollers and microcontroller kits for building digital devices. Arduino board designs use a variety of microprocessors and controllers. The boards are equipped with sets of digital and analog input/output (I/O) pins that may be interfaced to various expansion boards (‘shields’) or breadboards (for prototyping) and other circuits.

The boards feature serial communications interfaces, including Universal Serial Bus (USB) on some models, which are also used for loading programs. The microcontrollers can be programmed using the C and C++ programming languages, using a standard API which is also known as the “Arduino language”. In addition to using traditional compiler toolchains, the Arduino project provides an integrated development environment (IDE) and a command line tool developed in Go. It aims to provide a low-cost and easy way for hobbyist and professionals to create devices that interact with their environment using sensors and actuators. Common examples of such devices intended for beginner hobbyists include simple robots, thermostats and motion detectors.

In order to follow the market tread, Orient Display engineers have developed several Arduino TFT LCD displays and Arduino OLED displays which are favored by hobbyists and professionals.

Although Orient Display provides many standard small size OLED, TN and IPS Arduino TFT displays, custom made solutions are provided with larger size displays or even with capacitive touch panel.

This post shows how to connect ST7735S TFT display to PIC18F4550 microcontroller and display different things (numbers, text, lines, circles …..). The compiler used is CCS PIC C.

To interface PIC18F4550 with the ST7735 TFT display we need a small library (driver) which can be downloaded from its original post at the following url:

The system power supply is 5V and if you are using a microcontroller TFT display of 3.3V remove all the 1K resistors (5 resistors) from the circuit and connect the TFT display directly to the microcontroller.

There are various Kinetis parts with FlexBus that are very efficient with TFTs based on controllers with parallel mode. If highest efficiency is not needed any Kinetis can also bit-bang parallel mode.

Any Kinetis can be used for SPI, I2C or UART connected TFT display with controllers offering these interfaces (or a Kinetis with USB can use a USB device one).

The following FTDI display is quite popular for SPI connected devices, based on a controller with graphic accelerator chip which allows simple control and videos etc.(with touch screen control) for simple Kinetis parts.

The display is a critical component in every project, impacting the case, firmware, electrical design, user interface, and even battery life. For these reasons, and because it is the most visible component of your product, it must be approved by the mechanical design team, management and marketing.Before these teams can approve, they need to see it in action. But it can take days or weeks to connect a display to your platform, initialize it and build a code library able to create believable demonstrations. Meanwhile, the whole project is on hold.Our 8051 development kit / demonstration board can solve this problem. Use it to get the display seen, demonstrated and approved for your project.

ER-DBT032-3 is a microcontroller 8051(80C51) demonstration and development kit for ER-TFT032-3.1 product that is 3.2 inch tft lcd display with ILI9341 controller.The kit includes MCU board controlled by STC12LE5A60S2,ISP(In System Programming) with USB port and cable to customize the demonstration that includes your own bitmap images,personalized fonts,symbols,icons and burn sketches,microSD card that is written graphic and text into it,the power adaptor,the adaptor board with various pitch dimension used to connect MCU board and display.Optional for 8080 8-bit,8080 16-bit parallel interface and 3-wire,4-wire serial interface.

The display is a critical component in every project, impacting the case, firmware, electrical design, user interface, and even battery life. For these reasons, and because it is the most visible component of your product, it must be approved by the mechanical design team, management and marketing.Before these teams can approve, they need to see it in action. But it can take days or weeks to connect a display to your platform, initialize it and build a code library able to create believable demonstrations. Meanwhile, the whole project is on hold.Our 8051 development kit / demonstration board can solve this problem. Use it to get the display seen, demonstrated and approved for your project.

ER-DBTM028-4 is a microcontroller 8051(80C51) demonstration and development kit for ER-TFTM028-4 product that is 2.8 inch tft lcd display with ILI9341 controller and adaptor board.The kit includes MCU board controlled by STC12LE5A60S2,ISP(In System Programming) with USB port and cable to customize the demonstration that includes your own bitmap images,personalized fonts,symbols,icons and burn sketches,microSD card that is written graphic and text into it,the power adaptor,the adaptor board with various pitch dimension used to connect MCU board and display. Optional for 8080 8-bit,8080 16-bit parallel interface and 3-wire,4-wire serial interface.

8080u and tft technology are usually lighter and have the same features as the 8080 tft technology. However, 8080 tft is mainly used for single applications, and the 8080 tft technology is usually lighter than the 8080 ones.

Different technologies offer different benefits, such as the 5-footannel Tft display, 8080u interfaces and Tft machines. As a result, various technologies offer, such as 8080 pure Tft makes it a high-quality option for those that require the use of multiple LEDs.

All of the interfaces have the user experience. The Internet Protocol (Internet Protocol / Internet Protocol / Internet) allows a faster communication of the components and be associated with them, and has a lot of components interfaces with the user experience.

lcd interface with microcontroller are the perfect renewable energy solution capable of generating wind energy and turning it into electricity through innovative aerodynamic forces produced by rotor blades. Alibaba.com has a wide selection of wind turbines of various sizes and capacities that can be used to generate sustainable wind power.

You can find lcd interface with microcontroller with either vertical or horizontal axes that can be used for a variety of applications, from wind turbines for home to wind power generators for wind farms. Source the wind turbine system that works for you.

There are also small wind turbines that can be used for applications that include battery charging for traffic warning signs, as well as boat and caravan power. You also have a choice of blade and bladeless options. The bladeless designs generate energy from vibrations alone. Are you looking to source wholesale lcd interface with microcontroller for your business? Shop from the vast selection from Alibaba.com and take advantage of great deals.

It shouldn"t be a problem to access a TFT from any MSP, but I doubt it will be of much use. Even the biggest MSPs doN"t have so much ram that they could hold a complete TFT image internally. It might be possible, if the TFT has a randomly accessible ram (many don"t) to "draw" directly into the TFT buffer. However, most TFTs require their content linearly written for each screen update. Impossible for any MSP wihtout external support (external ram etc.).

Well, TFT really isn"t a low-power application, so the MSP series probably isn"t the right choice for this application. The few milliamps more for a Stellaris or other processors surely won"t count if you drive a TFT.

The display used in this project is a 1.8” TFT with 128x160 pixels of resolution. The microcontroller used is the SimpleLink MSP-432P401R from Texas Instruments. The TFT display will be interfaced with the microcontroller via a 4-wire serial connection and programmed using the Energia IDE platform.

In just a few steps the TFT can be wired and programmed to display up to 65K colors and 128x160 pixels of resolution. The display can be powered from the 3.3V output of the TI. Various wiring and interface options are available, from 3-4 wire serial, to 16/18-bit RGB and 8/9/16/18-bit MCU parallel. Additional features of this display are below. As always, check out the data sheet for the specs of this specific display. (datasheet)

First you will need to download the Energia IDE software if you have not already. This IDE was chosen because of the similarities is has to the Arduino IDE. This is beneficial because there is a large variety of open sourced examples that demonstrate the features of this display. An alternative programming IDE is Code Composer Studios, which is also compatible with the TI microcontroller. The IDE is up to preference. We will come back to this after the hardware is setup.

There are only a few connections that need to be made between the display for the 4-wire serial interface. The unused parallel data pins will be pinned to GND. Consult the datasheet for a detailed explanation of each pin assignment and their functions. The 4-wire serial data pins are connected to the TI specific serial inputs for the “Hardware SPI” programming option. While any pins can be used, their location must be defined in the “Software SPI” programming option.

Pin definitions and connection points are described in the table below. We will use the 4-wire serial interface for this example to save data pins on the TI. A more in-depth description of each of the pins can be found on thedatasheet. All unused pins are connected to ground, with the exception of the reset pin. This pin is optional to connect to the TI, if not used it needs to be pulled high.

The TI microcontroller has dedicated serial input pins specific to the board. The pin locations can be seen below and are described in the table for how they are connected to the display. These and other hardware pin definitions can be verified on the TI website.

After the screen is connected, and the TI microcontroller is plugged into the computer you will see the white LED backlight come on. That is a good sign that things are connected correctly.

Now it is time to program the microcontroller. For this example, we will be using the Energia IDE. An alternative platform that can be used is Code Composer Studios. I have found that Energia IDE is more practical for this example because of the compatibility with Arduino specific code with only minor changes.

We will need a program for the specific display chip “ILI9163”. For this example, I have created a modified version of a popular Adafruit example that demonstrates the various capabilities of the display. The example can be downloaded from Github here.

You will also need to include Adafruit’s GFX library which can be downloaded here. This is a popular library that contains examples and features for TFT displays that prove to be useful for this application.

You can now test any of these various programs that might be good reference for your specific project. There a lot of good examples in the Adafruit GFX library as a resource to test the various capabilities of the display.

This 1.8” TFT is a good option for displaying 16-bit 65K color images. This is compatible with most microcontrollers as it saves on-board memory. This is beneficial for storing bitmaps on flash memory since the screen is small and the 65K color bitmap image won’t take up all the on-board storage on the TI. This display also has a version with a resistive touch screen. This would be a good option for a digital push button. This may be further discussed in a future application note.
