This item is a color TFT LCD screen for a 2012 – 2018 Ford Focus. This screen will repair your black or blank speedometer display. Installation is simple. Simply remove the cluster, then remove the front lens and rear panel. The TFT LCD screen will easily pop out without disturbing the gauge needles. The small ribbon cable attached to the screen is also attached to the back of the circuit board. Carefully release the clip on the circuit board and remove the screen with the ribbon attached.

When you receive the new screen, you will reuse the original ribbon. Simply transfer it over to your new TAE screen. No programming is required. After installing your new LCD screen, plug your cluster back into your vehicle and enjoy a working display.

PLEASE NOTE: 2013 Ford Escape uses two different versions of this LCD screen. With mounting bracket and without, please use the videos below to determine the correct LCD screen.

ford focus gauge cluster lcd screen free sample

Instrument Sales & Service offers professionally built and tested instrument clustersfor GM and Ford. Our team is ready to help you with instrument cluster replacements or repair work. A dedicated Instrument Cluster Shop that supports lots of different vehicles.

Our technicians can repair your entire instrument cluster or just supply a replacement that we ship to you first, depending on what is best for you. Our repairs fix common issues such as faulty odometer display, speedometer, tachometer, fuel gauge and dimness, flickering or gone backlighting.

We have instrument clusters for the vehicles. If you do not see your vehicle listed please call for availability as we are adding new models regularly 800.587.5456

Yes, Instrument clusters can be replaced relatively easily with minimum skills. It does require some level of care, but generally, it’s plug and play. While most instrument clusters can be replaced without having to remove the steering wheel or disassemble the dashboard, it can be a time-consuming task. If you are not confident in your abilities to remove and replace an instrument cluster, it is best to take the car to a mechanic.

This is a question I get asked quite often, and the answer depends. Some clusters are very easy to repair (I’ve even heard of people doing it with a hot glue gun), while others are more difficult and may require special tools or programming knowledge. The best way to find out is to take your cluster out of the car and take a look at it. If you’re not comfortable doing that, most local auto parts stores will be able to test the cluster’s functionality for free.

Instrument Sales & Service offers instrument clusters, standard repair service and instrument cluster replacements. We have over 30 years experience helping dealerships nationwide and now directly offer our services to the public. Our repair work includes professional testing and quality checks along with our programming.

Instrument Sales & Service offers upgrades to many parts like colored needles called pointers, LED lights, and back faces in carbon and white. Upgrading your cluster is a great way to give your vehicle a modern look.

Some instrument clusters include backlighting that is different colors – red, yellow, blue, green. Some also feature a tachometer or have the ability to be switched from kilometers per hour to miles per hour. Some are even customizable, allowing you to change the colors and fonts of the display.

Instrument clusters can cost anywhere from $200 to $400 to replace, depending on the make and model of your car. Some mechanics may be able to replace an existing cluster, but they will charge your labor costs. The good reason to use a local repair shop is that they will have the ability to properly test your vehicle after putting in the new instrument cluster. For this reason we recommend that you purchase your instrument cluster with Instrument Sales & Service, but have a local shop install — if there is any concern.

If your instrument cluster is not working properly, then you will need to replace it. If it is just the bulbs that are burned out, then you can replace those yourself. But if there are other issues, then you will need to get a new cluster.

You can buy a new instrument cluster from the dealer, but they are usually quite expensive. A better option is to buy a cluster from Instrument Sales & Service. We offer a wide variety of clusters at a fraction of the dealer price. We also offer a lifetime warranty on all of our products.

Whether you need an instrument cluster for a car or a truck, we have what you’re looking for. Browse our selection and find the perfect cluster for your vehicle.

The instrument cluster is in the dashboard (or behind the dashboard). Its a collection or group of gauges, clustered together, that provide different information to the driver. In some cases, the cluster may be in the center console. A working instrument cluster is one of the most important parts of your car. It houses the speedometer, tachometer, fuel gauge, and other important gauges that let you know how your car is performing.

The instrument cluster is made up of different gauges and lights that provide information to the driver. The speedometer, tachometer, fuel gauge, and temperature gauge are all part of the cluster.

The instrument cluster is important because it allows the driver to monitor the condition of the car. The speedometer lets the driver know how fast they are going, the tachometer tells them how fast the engine is running, and the fuel gauge lets them know how much fuel is left in the

Some common problems with instrument clusters include warning lights that stay on or come on when they should not, needles on the gauges that do not move or move erratically, and dim or flickering lights. If you notice any of these problems, you should take your car to a mechanic or car dealership to have it checked out. Other problems may include inaccurate readings or failure to display information. These problems can be caused by a variety of factors, such as loose connections, bad sensors, or a damaged cluster. Service indicators may also appear on the instrument cluster. These indicators can provide information about the status of the car’s systems and need to be addressed by a mechanic. The control module is the central unit that controls the instrument cluster. If this unit fails, it may need to be replaced. A replacement module can be expensive, so it is best to address any problems with the cluster as soon as they are noticed.

You can find a replacement instrument cluster at Instrument Sales & Service. We offer a wide variety of clusters at a fraction of the dealer price. We also offer a lifetime warranty on all of our products.

Whether you need an instrument cluster for a car or a truck, we have what you’re looking for. Browse our selection and find the perfect cluster for your vehicle.

A digital instrument panel or DIP is a type of automotive instrument cluster that displays information to the driver in a digital format as opposed to the traditional analog format. Many cars manufactured in the past few years come equipped with digital instrument panels as standard or optional equipment.

Some drivers love the digital instrument cluster because it can give them more information at a glance. The downside is that some people find it difficult to read in direct sunlight so they prefer analog gauges.

Truck instrument clusters are often larger, providing more space for digital readouts while car instrument clusters are typically smaller and offer more analog gauges. One option is to replace your instrument cluster with one that offers both digital and analog readouts.

Instrument clusters can range in price from $200 to $400. The price will depend on the features of the cluster and the year, make, and model of your car. If you want to upgrade your cluster then that may also increase the price.

Instrument clusters, sometimes called a dashboard, is a panel that contains important information about the vehicle. This information can include the speedometer, tachometer, fuel gauge, and temperature gauge. It may also contain other information such as a compass or clock.

The instrument cluster helps the driver keep track of the car’s performance and make sure everything is working properly. Models with a digital display may also show more information about the car. Inputs from sensors and other systems are used to provide the information on the cluster. Many clusters hook up to your vehicle via a single large connector plug.

It may not always be obvious that the cluster is broken and may require a bit of troubleshooting. For example, we have seen parasitic draws on the battery from bad clusters.

There are several signs that your instrument cluster may not be working properly. Warning lights may stay on or come on when they should not. The needles on the gauges may not move, or they may move erratically. The cluster may be dim, or the lights may flicker. If you notice any of these problems, you should take your vehicle to a mechanic or car dealership to have it checked out.

Yes, Instrument clusters can be replaced relatively easily with minimum skills. It does require some level of care, but generally, it’s plug and play with a large single connector.

While most instrument clusters can be replaced without having to remove the steering wheel or disassemble the dashboard, it can be a time-consuming task. If you are not confident in your abilities to remove and replace an instrument cluster, it is best to take the car to a mechanic.

Whether you need an instrument cluster for a car or a truck, we have what you’re looking for. Browse our selection and find the perfect cluster for your vehicle.

The instrument cluster is made up of different gauges and lights that provide information to the driver. The speedometer, tachometer, fuel gauge, and temperature gauge are all part of the cluster.

The instrument cluster is a part of the car that contains the speedometer, tachometer, fuel gauge, and other important gauges. The instrument cluster is either mounted in the dashboard or in the center console.

The instrument cluster is an important part of the car because it allows the driver to monitor the condition of the car. The speedometer lets the driver know how fast they are going, the tachometer tells them how fast the engine is running, and the fuel gauge lets them know how much fuel is left in the tank. Some cars have a digital instrument cluster, which displays information on a screen instead of using traditional dials.

An instrument cluster typically contains the speedometer, tachometer, fuel gauge, and temperature gauge. It may also contain other information such as a compass, clock, or warning lights. Other word designs may also be on the cluster, such as “ODOMETER” or “TRIP.” A black face color is the most common, but other colors may be available as well. Gauges may be analog or digital. You can also find clusters that are lit up with LED lights. These lights are often brighter and easier to see at night. They function as a backlight and usually come in different colors.

The instrument cluster is used to display important information about the vehicle to the driver. This can include the speedometer, tachometer, fuel gauge, and temperature gauge. It may also contain other information such as power and oil pressure. The cluster is used to help the driver monitor the vehicle’s performance and make sure everything is working properly. Inputs from sensors and other systems are used to provide the information on the cluster. Other words, such as “ODOMETER” or “TRIP,” may also be displayed on the cluster.

An instrument cluster displays precise and important information about the car to the driver. Transmission temperature, engine speed, vehicle speed, and more can be monitored with an instrument cluster. Additionally, some clusters may feature a digital display that can show even more information about the car.

A replacement instrument cluster usually costs around $250 to $500. If you are not sure exactly what you need, we recommend contacting ISS Automotive for more information. We offer customer cluster with carbon back faces, needles, LED lights and more.

If you have any questions about the cost of instrument clusters or need help finding the right one for your car, please contact us and we will be happy to assist you.

There are a few places you can buy a GM Instrument Cluster, but we recommend ISS Automotive. They are experts in instrument cluster manufacturing and will likely have what you are looking for. If you are looking for a digital instrument cluster, they are the place to go. Standard repair service is also available for most GM vehicles.

If you have any questions about instrument clusters or need help finding the right one for your car, please contact us and we will be happy to assist you.

There are a few places you can get a Ford Intrument Cluster, but we recommend ISS Automotive. They are reliable and have a wide selection of Ford instrument clusters. Your existing cluster may be repaired, or a new one may be installed. They will check digital readouts, speedometers, and other gauges to make sure they are functioning properly. The fuel gauge may also be calibrated during this process if your fuel level is inaccurate.

A new cluster may be necessary if your current one is beyond repair, or if you are looking to upgrade to a digital display. Circuit board and warning lights repairs may also be completed. A new cluster may be necessary if your car has been in a serious accident or the old one is too damaged to repair.

Carefully wrap your cluster in bubble wrap and place it in a box to prevent shipping damage – we can not be responsible for items damaged before reaching our facility.

Once we have received your cluster, our technicians will inspect and bench test it. A member of our team will contact you in the rare event that the repairs costs exceed what you have requested in the order form. Your credit card will not be charged until we are ready to start the work.

Our technicians will complete the requested repairs within 1 business day (24 hours) of receipt, and return all items the same or next working day and ship the cluster back to you – ready to install.

We ship your re-manufactured, programmed and fully-functional cluster to you via ground shipping. You can also select our 2nd day or standard overnight shipping for additional cost.

ISS Instrument Cluster Repairs and Service Department specializes in 2003-2013 General Motor Instrumentation repair. Our experience is unparalleled with 2 decades of repairing over 1.5 million General Motors speedometers and instrument clusters.

ford focus gauge cluster lcd screen free sample

The instrument cluster, or digital dash, provides the driver with important information necessary for a safe driving experience. It is located on the driver’s dashboard and includes the speedometer, fuel gauge, and odometer. In some cases, though, it stops working. What causes the instrument cluster to stop working?

This article will go over how instrument clusters work, what causes them to stop working, and how to determine the exact problem. We’ll also include some examples, such as the Jeep Grand Cherokee, to understand why it sometimes doesn’t work.

Sensors in the vehicle generate signals that send to the car’s computer. The computer converts them into something that can be read by the instrument cluster.

If one doesn’t work, such as the speedometer, how can you tell if it’s a problem with the entire instrument cluster or something else? You may immediately think it is a problem with the instrument cluster, but it may actually be a problem with the vehicle sensors, computer, or wiring.

For some vehicles, one wire can have two signals that cause weird behavior. It comes from the computer not correctly functioning, which may be due to corrupted software or a hardware problem. For 2000 Jeep Grand Cherokee instrument cluster problems, this is not the most common cause, and replacing the PCM only renders a 50% success rate in fixing the dashboard problem.

A blown fuse is one of two guaranteed causes for a non-working instrument cluster and only happens when none of the gauges work. It is also a probable cause if your Jeep Cherokee warning lights are not working and should be inspected first before concluding that your warning lights need new bulbs. To verify, access the fuse box in the engine compartment under the driver’s side dash, or refer to your owner’s manual for its exact location.

Connectors that are either loose or have come unplugged are easy to fix and are part of what you need to check when doing a simple circuit trace. If this happens to cause your instrument cluster problem, make sure to disconnect the car battery, plug the connectors back together, fix loose ones, and reconnect the battery. Your instrument panel should come back to life shortly after.

In most cases, only one or two gauges in your instrument cluster do not work. When this occurs, you would probably trace the problem to a bad sensor. The type of sensor that most commonly goes bad is the speedometer sensor. Symptoms include speedometer and cruise control glitches, power loss, and check engine light activation.

Non-working odometers and speedometers usually point to this reason. Defective gauges could likewise be due to a broken cable – that is, if your vehicle uses a physical cable instead of sensors for the speedometer to function. To fix this, you need to pull out your instrument cluster to get at the gears. While you’re at it, use compressed air to remove dust and a microfiber cloth to clean the clear plastic.

A faulty voltage regulator, which sends power to the instrument panel in most current vehicles, may be responsible for what causes the instrument cluster to stop working. When this is defective, your digital dash may not entirely stop working. However, your gauges will read extremely high/low, act up, or become erratic. Even jumpstarting your vehicle or switching out the battery can cause an electrical spike that can lead to, say, a speedometer going berserk.

Should your voltage regulator work just fine, then chances are the issue is caused by a fault with wiring – one of the two causes leading to a fully non-working instrument panel. This fact is especially true for a 2000 Jeep Cherokee, whose wires tend to rub through on the steering column that causes a short with the BCM. A tell-tale sign that wiring triggers your IC to misbehave is when your vehicle’s gauges show the highest possible readings. Any capable mechanic should be able to rectify this. Otherwise, go to a professional who can perform an in-depth circuit trace on your vehicle and pinpoint where the fault is.

A grounding issue one of the last things any vehicle owner would suspect that’s causing the instrument cluster to stop working. However, if you have already looked into all the before causes, this may be the culprit. A grounding issue affects your dash lights, gauges, and indicators.

If you have exhausted all the necessary tests and cannot identify anything wrong with wiring or sensors, you are just unfortunate to receive a vehicle with a lemon dash. Some electronic instrument clusters don’t have separate gauges that receive independent inputs from individual senders. You may need to replace it in this case.

Start your diagnosis by doing an instrument cluster self-check. Generally, this happens when the ignition turns on, during which all the warning lights and display sections come on briefly. Watch closely for any dark segments or non-working indicators. Different vehicles have varying self-check procedures. You can even manually trigger the self-check diagnostic in some applications. Your owner’s manual and OEM service websites should be able to provide you information on how to run it for your specific vehicle.

With the use of a Fluke 87-V Digital Multimeter (view on Amazon), identify the fuse connected to the instrument cluster by turning the ignition key on (there should be light on both sides of the fuse).

If you cannot find any problem with the fuse, remove the whole instrument panel, and check the gauges individually for power. Also, check the ground using a power probe (view on Amazon) and ensure that it does not cause failure or inconsistent readings. This step applies whether all or only some of the gauges are not working. If only some gauges are affected, the problem may be from the gauge, sender, or wiring.

Look for any battery or ignition voltage at the instrument panel harness using a voltmeter rather than a test light. Using a voltmeter ensures that the voltage readings will be sufficient for your vehicle’s instrument cluster to operate correctly.

Check that there are no irregularities with your coolant, oil pressure, or gas gauge, as these lead to the gauges working unpredictably. Make sure to include all other vehicle sensors. Electronic instrument clusters require accurate inputs from the sensors to work problem-free.

Depending on how many gauges in your instrument panel are left working, you may need to perform either a gauge or sensor diagnostic test. You will need an oscilloscope, such as a Siglent SDS1104X-E 100Mhz Digital Oscilloscope (view on Amazon), preferably the 4-channel one. It is one step that not many DIY vehicle owners do – not because of its complexity, but because it requires patience.

Lastly, you may need to pull out the entire digital dash. This method may be the best way to determine what is keeping your instrument cluster from working right. A working IC should have flawless, unburnt silver-laminated traces during an inspection. If you find any in bad shape, a jumper wire or a conductive liquid is good to have in your kit for quick fixes.

There will be instances when there is nothing wrong with components affecting your instrument cluster’s proper function. During these times, your dash simply needs a reset.

How do I know if my instrument cluster is bad?Signs of a bad instrument cluster include dim/flickering gauges, inaccurate or unreliable readings, all gauges dropping to zero while driving, and an unworkable instrument cluster. These error symptoms can result in your vehicle going out while driving, displays failing occasionally, or complete/intermittent failure.

How much does it cost to fix an instrument cluster? Replacing the instrument cluster can cost between $880 and $1,000. The costs depend on your vehicle’s make and model, and condition.

Can you drive your car without the instrument cluster? If you have a Jeep, you are probably aware that you can drive your vehicle with the cluster removed. But even if it is possible to do so, you should not do it. Being on the road without working warning indicators is dangerous. Furthermore, driving in a vehicle without a functioning speedometer is deemed illegal in numerous jurisdictions.

Can a bad instrument cluster cause transmission problems?It depends on where a vehicle’s gearbox gets its road speed signal. On cars with ABS systems, the road speed input is passed on to the ABS’s digital dash or panel and then forwarded to the gearbox control unit. When an instrument cluster fails in this situation, the gearbox may receive incorrect vehicle speed data that could result in premature or delayed gear change timing that could play with the transmission.

What does check gauges mean?The check gauges light specifically indicates the occurrence of a malfunction that requires inspection, service, or repair. A loose gas cap, low engine oil, an overheating engine, or electrical haywire can trigger the check gauges’ light. When it does, you will need to do as this warning light points to – to look at all the gauges in your instrument panel while the engine is running to see which one is not within the standard. For Jeep Cherokee owners, your temperature gauge should be about 195°, the voltage should be about 14V, and the idle’s oil pressure should be about 40 psi.

Generally, your instrument cluster will last the lifetime of your vehicle. But should one or all of your gauges fail, expect to get error symptoms that range from mildly irritating to troublesome. Knowing ahead of time what the probable causes are and how to fix it will save you time, effort, and money in going to the mechanic. It will also help improve the way you take care of your vehicle’s different components.

ford focus gauge cluster lcd screen free sample

MyFord Touch (branded as MyLincoln Touch on Ford"s Lincoln brand productscommunications and entertainment system developed by the Ford Motor Company, based on Microsoft technologies. The technology was factory installed with Ford product offerings and was based on the Microsoft Auto 4.0 software platform. It was regarded as the next-generation of Ford Sync. Announced in January 2010, at the Consumer Electronics Show (CES), the technology launched with the 2011 Ford Edge. Reviews of MyFord Touch were overwhelmingly negative. A USB drive, self-installed software upgrade became available in March, 2012; this update was mailed out free-of-charge to all Ford customers, and Ford also offered free installation of the update by any Ford dealer. The update did not address continuing problems with light-touch capacitor switches (on cars so equipped) that control many functions.Bluetooth pairing, and refinement of the on-screen interface and menus.

MyFord Touch promised to enable drivers of Ford cars to seamlessly integrate nearly all mobile phones, PDAs and digital media players into their cars. Operation of these devices, utilizing advanced Ford Sync functionality, was performed using voice commands, touch-screen inputs, the vehicle"s steering wheel, radio controls, Bluetooth and Wi-Fi connectivity. MyFord Touch is also capable of receiving text messages and reading these text messages aloud to occupants of the car.

Fulfillment of the system"s promise has fallen short, with thousands of MyFord Touch owners complaining that the system is unreliable, that it crashes without warning, that it fails to respond to commands, and that it fails to integrate with common mobile devices, such as the iPhone. Ford reliability ratings, both by J.D. Powers and Associates have plummeted because of the defects in the MyFord Touch system, and Consumer Reports recommends that new car buyers not consider Ford or Lincoln models equipped with MyFord Touch or MyLincoln Touch.

As a stand-alone option, the MSRP for MyFord Touch is $1,000. Purchasers of this option get the MyFord Touch system with two driver-configurable 4.2" color LCD displays in the gauge cluster, one 8" color LCD touch screen in the center stack, a media hub with 2 USB ports, SD card reader, RCA video input jacks and 5-way controls located on steering wheel; Sync voice activated communications and entertainment system (Free three-year pre-paid subscription for 911 Assist, Vehicle Health Reports, traffic reports, GPS-based turn by turn driving directions and information services).

Voice-Activated Commands: Uses Ford Sync technology to control the climate, audio, phone and navigation features in a hands-free manner through the use of only their voice.

Map-based navigation application via an optional SD card – provided by TeleNav (option can be added later to MyFord Touch but it is not supported by Ford dealers, it requires installing a license).

Internet Connectivity: MyFord Touch provides full Wi-Fi capability. The technology also includes hotspot connectivity enabling other devices to share the MyFord Touch system"s internet connection.

Unreliability of the MyFord Touch system has been cited by J.D. Powers & Associates as the primary factor contributing to a decline in Ford"s standing in the 2011 "Initial Quality Survey" of new car purchasers.Consumer Reports recommends that no one consider buying used 2011 Ford Edges equipped with MyFord Touch systems.Consumer Reports has downgraded its ratings for vehicles so equipped.

Early purchasers of the first generation MyFord Touch system complained that MyFord Touch systems crashed without warning, did not reliably respond to touch commands, and often failed to sync with mobile phones and iPods.

Initial reception of the March 2012 software upgrade, which overhauled the user interface and addressed many performance issues, has been largely positive. There has since been several incremental software upgrades, addressing some issues that have plagued the system since its introduction, such as touchscreen menu lag and voice recognition commands.

In order to address the many criticisms on the Microsoft-powered system, Ford decided to use Blackberry"s QNX CAR Platform for Infotainment beginning in 2015, referred to by Ford as Sync 3.

Ford has yet to confirm when it will officially stop producing software updates for SYNC2. Whilst 3.8 was thought to be the last official version, 3.10 was released to address certain bugs in Nov.16, 2017. This has not been readily available in Europe, where Ford does not have a customer self-service portal and dealers are not always willing to tamper due to the very slow download times for the update and the low success rates causing total failure of the unit. Only certain technicians are trained to perform the upgrade leading to limited knowledge and natural avoidance in performing the upgrade in case of problems. A service bulletin regarding the software update suggests that unless specific problems are encountered with the device then the software update should not be performed. Once updated it is impossible to downgrade.

With such natural demand, the update has appeared in an unofficial form on most Ford forums and has been successfully installed by many, without any issues.

Any units which have failed and where the vehicle is under warranty will naturally be rectified under the warranty scheme, however it is likely a SYNC2 unit will be replaced with a SYNC2 unit where on-hand stock permits, unless there are repeated reproducible problems and the customer has noticed one of the many operational issues that exist. Ford has a strict policy relating to repeated failures of a component and this falls into that category suggesting fitment of a SYNC3 unit where applicable to prevent further failures would be an appropriate solution.

ford focus gauge cluster lcd screen free sample

Many people put off replacing their broken or malfunctioning instrument clusters. The biggest reason for that is because shops and dealers charge a lot of money for the job. If you"re in this situation, you really want to replace your instrument cluster ASAP. A broken or malfunctioning instrument or gauge cluster is not giving you the vital information you need about your vehicle.

We"re happy to tell you that you can replace your instrument cluster right at home. It"s not as hard as it looks, and you"ll save a lot of money in labor.

The instrument cluster is in the dashboard behind the steering wheel. You may need to take apart the dashboard to remove the instrument cluster. It"s an easy process. If you have the time for the removal, a plug-and-play replacement is a quick fix. Just be sure to set aside all the parts and hardware while taking apart the dashboard. It also helps to write down the steps during the removal process. This will help you put everything back together with ease.

Use your phone to take pictures of any steps that are complex. Do you have any questions about replacing your instrument cluster? Feel free to contact us!

ford focus gauge cluster lcd screen free sample

The dashboard gauges in your car tell a complex story about everything from your current rate of speed to the state and health of your engine and even whether or not things like your headlights are switched on. Different vehicles have different gauges, and some instrument panels are much more complicated than others. But when the gauges in your car stop working, it’s not a situation you can safely ignore.

When one gauge stops working, the problem may be in the gauge itself or a bad sensor, while all the gauges cutting out at the same time often indicates a blown fuse or a defective instrument cluster.

There are many different types of instrument cluster designs and configurations. Still, when all of the gauges in a car stop working at once, the problem is usually either a fuse or wiring problem. The first step in diagnosing this issue is to identify the fuse associated with the instrument cluster or gauges.

If the fuse is good, the next thing you or your mechanic will want to do is to check for power at the individual gauges. This usually requires removing the instrument cluster, which can be quite difficult and time-consuming in some vehicles.

At a bare minimum, you will probably have to remove some trim pieces and unscrew the cluster to pull it free. The difficulty level is usually on par with installing a new car radio, so you can probably handle this one if you"re comfortable with that job.

If your gauges don’t work and your dash lights and indicators also fail to illuminate, that’s a clue that there may be a ground issue. This assumes that you have already checked the gauges fuse and determined that it’s in good working order.

When an instrument cluster isn’t properly grounded, you’ll typically find that the gauges and dash lights fail to work or only work intermittently. You may be able to check the ground by looking up under the dash with a flashlight, but you will have to remove the instrument cluster in many cases.

When the gauges move erratically or are pegged at the highest possible reading, the problem is usually a bad component like an instrument voltage regulator or a bad ground.

Erratic gauges, or ones that seem to read uniformly low, are usually caused by a bad instrument voltage regulator. In some cases, you may be able to remove the regulator, clean the connector terminals, and reinstall it.

Gauges that all read full all the time are usually caused by a loose or bad ground. If you can locate the ground, either visually or with the help of a wiring diagram, you’ll want to make sure that it is secured tightly and free of rust or corrosion.

In some cases, you may find that the entire instrument cluster is bad. For instance, if you have an electronic instrument cluster that doesn’t have separate gauges that receive independent inputs from individual sending units, a total failure of all the gauges often requires the replacement of the entire cluster.

Early electronic instrument clusters had digital readouts much like an LCD alarm clock, while the modern equivalent often simulates analog gauges much more sophisticatedly. In either case, diagnosing and repairing or reconditioning this type of instrument cluster is outside the typical do-it-yourselfer"s realm, unless you want to replace the entire thing and hope for the best.

When a single gauge stops working, the problem is either in the gauge, the wiring, or the sending unit. If you are comfortable locating and removing sending units and sensors, you can diagnose this problem yourself. Otherwise, you’ll have to take it to a mechanic.

Using your coolant temperature gauge as an example, the diagnostic procedure involves locating and disconnecting the sending unit. With the ignition on, the gauge should register cold. If you connect the sending unit wire to ground, the gauge should switch to read hot.

If the gauge moves as expected, you can suspect a bad sending unit. If the gauge doesn’t move when you ground out the sensor wire, you can suspect a bad gauge. Similar tests can be performed on all of the gauges in your instrument cluster, although the specific procedures can differ from one application to another.

While all gauges can be either analog or digital, speedometers are unique in that they can have either mechanical or electrical inputs. All other dash gauges are connected to sensors or sending units via wires, while your speedometer may utilize either a speed sensor or a physical cable.

The speedometer is physically coupled to the transmission via a cable in vehicles that use cables. The cable is usually square on both ends or square on one end and slotted on the other. When the cable breaks, the gauge may not move, or it may jerk a little intermittently.

The fix for that problem is simply replacing the speedometer cable, which involves unbolting it from the transmission, disconnecting it from the instrument cluster, and sliding it through the firewall. In many cases, this also requires removing the instrument cluster itself.

The only way to know for sure what your car has is to either look up your make, model, and year or physically inspect the instrument cluster"s back. If there is no cable attached to the back of the cluster, then your vehicle has a speed sensor.

In vehicles that have speed sensors, the easiest way to determine whether the sensor or gauge is bad requires the presence of a cruise control system. Since cruise control also uses the speed sensor, it won’t operate correctly, or at all, if the sensor is bad.

While many vehicles have gauges that show specific information about everything from the state of the charging system to the temperature of the coolant, some cars and trucks have warning lights.

If none of your dashboard warning lights turn on, including your check engine light, it’s usually a fuse or a ground issue. This type of problem is diagnosed the same way as a gauge that doesn"t work, so you will have to check for power at the appropriate fuse and verify that the instrument cluster ground is okay. If those things check out, the problem is usually a bad sending unit or wiring.

Regardless of whether you"re dealing with gauges or lights, the basic troubleshooting process will always be determined by the number of failures that happen simultaneously. So if it"s just one gauge or light that doesn"t work, you"ll follow one basic procedure, and you"ll follow another if everything stops working at once.

When all of the gauges or warning lights in your car stop working at once, the problem is something that all of the gauges and lights share in common.

Check the fuses first. The fuse may be labeled gauges, clusters, or something similar. This fuse should have power on both sides with the ignition in the on position.

Disconnecting the sensor is usually the first step. Depending on how the gauge works, disconnecting the sensor, or connecting it to ground, may allow you to test the operation of the gauge.

ford focus gauge cluster lcd screen free sample

Installing a MK2 instrument cluster with green illumination or MK2.5 instrument cluster is perfectly possible. Since 2008 I have done this at least a dozen times. Even an RS instrument cluster is fully compatible with any MK2/MK2.5 Petrol version. Installing an MK2.5 instrument cluster can also be quite cheap. Recently I bought a low mileage, mint condition MK2.5 instrument cluster with large display from a UK based scrap yard I paid less than €100,- including P&P. The Focus MK2/MK2.5 instrument cluster can easily be configured/reprogrammed using a cheap ELM327 in combination with the free ELMconfig and Forscan software.
