A few years ago there was widespread exuberance in the A/V consumer world when NEC or Panasonic announced that the newest version of their gas plasma display (that"s what we called them then) delivered an astounding 3000 to 1 contrast ratio. Today manufacturers advertise contrast ratios approaching and above 1,000,000:1.

Truth is that a 3000:1 contrast ratio would be almost unbelievable even today if evaluated on a post calibration, whole screen, ANSI checkerboard pattern basis. The highest I have measured on a recent flat panel display was nearing 1600:1.

For a long time, we in the A/V world have been harboring secrets about the testing methods used for such measurements as contrast. Contrast ratio stands out as probably the most blatant and ridiculous example of irrelevant manufacturers specifications.

used the backlighting to increase contrast by increasing brightness. LCD TVs often suffer from hazy, washed out blacks, especially when viewed from an angle greater than 30° off center.

Panasonic has developed a new type of IPS liquid crystal panel that has a 1,000,000:1 contrast ratio, as well as a peak brightness of up to 1000 nits. Many LCD displays often advertise such contrast ratios which are measured against a dynamic backlight and are essentially meaningless, but in this case Panasonic is talking about the static contrast ratio of the display, which only reaches as high as 2000:1 on a typical IPS display. Little information is available about the technology at this point, but Panasonic claims that it is achieved by implementing pixel-by-pixel control of backlight intensity and that panels featuring the tech can be produced using contemporary LCD manufacturing facilities.

One of the key advantages that OLED displays have over LCD displays is extremely high contrast ratio that results in superior blacks. The reason why OLEDs can display deeper blacks is simple: such panels do not use backlighting and can completely switch pixels off when they need to display blacks. By contrast, LCDs use backlighting that cannot be turned off on a pixel-by-pixel basis, which is why in many cases blacks look like dark greys.

In the most optimal case, an LCD display will use full-array backlighting, where there are several LEDs placed directly behind the liquid crystal layer. This allows for a degree of control by performing local dimming of certain areas, which is how LCD televisions have managed to meet the standards required for HDR certification. However, the precision of the backlight control is not close to that of an OLED display which works at the pixel level. Even more common, especially in monitors and less expensive televisions, is the use of edge lighting where LEDs are placed along the edges of the display and the light is distributed across the panel using a guiding plate, which means you can really only control the overall brightness across the entire display.

As it appears, Panasonic has found a way to substantially increase contrast ratio of IPS LCDs using a high-brightness backlight and a special layer of light-modulating cells that enable pixel-by-pixel control of backlight intensity. These cells are made of light-tolerant liquid crystal material that has different light-transmission properties compared to those used in the display cells. The layer of light-modulating cells is placed between the backlight and the LCD cells and thus can control light leakage. At a high level, one could think of them like gates placed behind each pixel on the display.

Panasonic does not reveal many details about its light-modulating cells, but since it uses the term “cells”, it clearly indicates that we are dealing with a relatively thick layer of liquid crystals, not a thin layer of quantum dots (you can see an illustration from Nanosys (a company that produces quantum dot films that are currently used on Samsung TVs and displays) to compare “cells” versus “quantum dots”).

Usage of a high-brightness backlight and a layer of light-modulating cells enable Panasonic to build display panels with up to 1000 nits brightness as well as a static contrast ratio of 1,000,000:1. These figures mean that a black level of 0.001 nits should be possible, which is well beyond what even the best full-array backlit LCD displays can offer today.

Panasonic claims that the addition of the layer can be done using the existing equipment for LCD manufacturing, but it"s not clear how costly the technology will be to implement or if it requires further components to be added to the LCD stack. The company plans to offer displays featuring the new technology for various professional applications, such as video production, medical, automotive, engineering and so on. Given the positioning, it is obvious that the price of IPS displays with enhanced contrast will be well above that of mainstream monitors.

While OLED may be seen by many as the future of mobile and large panel displays, LCD manufacturers have recently come along with a number of innovations breathing new life into the panel type, including Quantum Dot and fast refresh rate technology. Today, Panasonic has unveiled its latest LCD IPS display that boasts a 1,000,000:1 contrast ratio. That’s up to 600 times more contrast than some of the company’s conventional LCD panels, which offer around 1800:1 ratios, and rivals OLED specifications.

Panasonic has accomplished this through the use of its new light modulating cell technology, which allows the company to switch off individual pixels in the display using a secondary control layer. Typically, LCD backlights mean that either the entire or only large parts of the display can be dimmed at any one time. OLED panels switch of lights entirely for a black pixel to offer very high contrast ratios, and this new LCD technology works on a very similar principle. This is particularly important for reproducing HDR video content, which is becoming increasingly popular.

Furthermore, this new light modulating cell technology allows Panasonic to increase the peak brightness and stability of the display, which can reach 1,000 cd/m2 while also providing HDR colors. Many other HDR TV panels top out in the range of 700 to 800 cd/m2, so colors, highlights, and shadows should appear vivid and realistic.

Unfortunately, Panasonic’s new technology is quite expensive and won’t be heading to small form factor mobile panels, at least not yet. Although it can be built on existing LCD manufacturing lines, so prices should come down. The company states that it will be targeting the technology at panels in the high-end broadcasting, video production, medical, and automotive fields first, with sizes ranging from 55 to 12 inches. Sample shipments are scheduled to begin in January 2017, so we won’t see it in products for a little while yet.

As a first step, try using the calibration settings we recommend (provided we have reviewed your monitor). This will get good, basic contrast - meaning no additional contrast-enhancing settings - and with no loss of detail in dark portions of the image. You can find this information in the "Post Calibration" section of the review.

Contrast:Adjusting this will let you affect how much contrast the monitor has. We list a recommended setting with all of our reviews, but it"s almost always fine to just set this to the maximum. On rare occasions, gamma might be affected, leading to a loss of detail in highlights.

Local Dimming: The local dimming feature dims the backlight behind darker portions of the screen. It can deepen contrast, and it"s worth using when implemented well. It can introduce issues like light blooming off of light objects within dark areas, and when done especially poorly, can dim the entire image. We discuss local dimming in more detail here.

Backlight settings have a very minor impact on contrast, and so you should set it to whatever looks best in your viewing space. With LED Monitors, both white and black will become about equally brighter or dimmer when the backlight is adjusted, preserving the ratio of light to dark. With OLED monitors, adjusting the OLED light only increases the peak brightness; blacks are still perfectly black.

One frequently asked question is which is more important, a panel"s native contrast or contrast with local dimming? It"s a good question. The answer is a bit complicated, but basically, it depends. Unlike TVs, most monitors don"t have a local dimming feature. The few that do, generally speaking, don"t work very well. They usually have very small zone counts, and the algorithms can"t keep up with fast-paced motion, so the leading edge of a bright object in a dark scene ends up looking darker than the rest, and there"s a trail of light behind it.

Because of these issues with local dimming, it"s almost always more important to look at the native capabilities of a monitor instead of the contrast ratio with local dimming. Because most monitors have poor local dimming features, there"s usually not that much of a difference between the native contrast of the panel and the contrast with local dimming when tested with a checkerboard pattern. In fact, of the 23 monitors with local dimming that we"ve tested on our latest test bench, only 4 of them can improve contrast by 10% or more with our test pattern through local dimming.

There are different ways to measure contrast. We measure contrast with a checkerboard pattern and take the average black level from four squares, but some other review sites measure it differently, which can lead to a difference in posted numbers. Some of the other methods we"ve seen websites use include:

Full On/Off: Some websites measure the contrast using a full white screen, and a full black screen. This is generally considered a less accurate way to measure contrast, and it isn"t very realistic. Contrast measurements with local dimming tend to appear much better with this measurement technique, as it"s easy for any monitor with local dimming to turn the entire screen off at once.

Small Samples: Similar to the full-screen method, but instead of large slides, contrast is measured using small slides that only cover part of the screen. This method isn"t ideal either, as imperfect uniformity can significantly skew the results.

ANSI Checkerboard: The most generally accepted way to measure contrast; a checkerboard pattern very similar to ours is used, but with an asymmetric test pattern. The ANSI method measures the output in all 16 squares and averages the values for the white and black squares. It usually produces very similar results to our own.

Because of differences in measurement techniques, equipment used, and even differences between units, it"s extremely common for different websites to report different contrast measurements.

Monitors use different display technologies, each with advantages and disadvantages. Knowing which type of panel is used in your monitor can already give you a good indication of what to expect in terms of contrast ratio:

OLED: Very few OLED monitors exist, but they essentially have perfect contrast, as each pixel is self-emissive, the black level of black pixels is essentially zero.

Even within the same panel types, it"s normal for the contrast to vary a bit between units, even of the same model, due to manufacturing tolerances. Manufacturers used to provide the typical contrast ratio for each monitor, but recently, some brands, including LG, have started listing the minimum contrast ratio you could get. For IPS and TN panels, this difference usually isn"t very significant, and most people shouldn"t worry about it, but for VA panels, the variance between individual units and measurement techniques can be significant. For example, the LG 32GN600-B is advertised to have a typical contrast ratio of 3000:1, but according to LG, it could be as low as 1800:1 for some units. We measured a contrast ratio of 3248:1, almost double the minimum contrast for that model.

A monitor’s contrast ratio indicates the depth of blacks – a higher contrast ratio means deeper blacks – and, by extension, better picture quality. It’s a very important part of picture quality, so if you want something that looks good (particularly in a dark room), be sure to get a monitor that has good contrast.

There are a few things that can be done to improve contrast, but there are limits. As a good first step, look to our recommended picture settings (listed with every review), as those can help you get a good baseline. From there, you can enable or disable a few different settings that might help deepen blacks. Just remember that some of those settings will have other consequences on picture quality.

First, the display screen on a sunlight readable/outdoor readable LCD should be bright enough so that the display is visible under strong sunlight. Second, the display contrast ratio must be maintained at 5 to 1 or higher.

Although a display with less than 500 nits screen brightness and a mere 2 to 1 contrast ratio can be read in outdoor environments, the quality of the display will be extremely poor. At i-Tech, a truly sunlight readable display is typically considered to be an LCD with 1000 nits or greater screen brightness with a contrast ratio greater than 5 to 1. In outdoor environments under the shade, such a display can provide an excellent image quality.

Luminance is a major determinant of perceived picture quality in an LCD. The importance of luminance is enhanced by the fact that the human mind will react more positively to brightly illuminated scenes and objects. Users are typically more drawn to brighter displays that are more pleasing to the eye and easier to read. In indoor environments, a standard active-matrix LCD with a screen luminance around 250 nits looks good. However, a sunlight readable LCD with a screen luminance of 1,000 will look even more beautiful.

Contrast ratio (CR) is the ratio of luminance between the brightest �white� and the darkest �black� that can be produced on a display. CR is another major determinant of perceived picture quality. If a picture has high CR, you will judge it to be sharper and more crisp than a picture with lower CR. For example, a typical newspaper picture has a CR of about 5 to 7, whereas a high quality magazine picture has a CR that is greater than 15. Therefore, the magazine picture will look better even if the resolution is the same as that of the newspaper picture.

A typical AMLCD exhibits a CR between 300 to 700 when measured in a dark room. However, the CR on the same unit measured under ambient illumination is drastically lowered due to surface reflection (glare). For example, a standard 200 nit LCD measured in a dark room has a 300 CR, but will have less than a 2 CR under strong direct sunlight. This is due to the fact that surface glare increases the luminance by over 200 nits both on the white and the black that are produced on the display screen. The result is that the luminance of the white is slightly over 400 nits, and the luminance of the black is over 200 nits. The CR ratio then becomes less than 2 and the picture quality is drastically reduced.

i-Tech sunlight readable LCDs with 1500 nits screen brightness will have a CR over 8 with the same amount of glare under the same strong sunlight, making the picture quality on these units extremely good. For further reading on contrast ratio, please see Tech Note 0101, Page 2, the Display Contrast Ratio.

The viewing angle is the angle at which the image quality of an LCD degrades and becomes unacceptable for the intended application. As the observer physically moves to the sides of the LCD, the images on an LCD degrade in three ways. First, the luminance drops. Second, the contrast ratio usually drops off at large angles. Third, the colors may shift. The definition of the viewing angle of an LCD is not absolute as it will depend on your application.

Most LCD manufacturers define viewing angle as the angles where the CR (contrast ratio)^3 10. For LCDs designed for less demanding applications, the viewing angle is sometimes defined as the angles where the CR^3 5.

For LCDs used in outdoor applications, defining the viewing angle based on CR alone is not adequate. Under very bright ambient light, the display is hardly visible when the screen luminance drops below 200 nits. Therefore, i-Tech defines the viewing angles based on both the CR and the Luminance.

All LCD backlights powered by cold cathode fluorescent lamps (CCFL) require inverters. An inverter is an electronic circuit that transforms a DC voltage to an AC voltage, which drives the CCFLs. i-Tech Technology manufactures inverters for all its products. Additionally, Applied Concepts and ERG also provide inverters for our products as well.

The dimming range or dimming ratio of an inverter specifies its capability of performing backlight luminance adjustment. For inverters used in notebook computers and LCD monitors, the backlight luminance can be adjusted typically over a dimming range of less than 10:1. That is, the luminance is adjusted from 100% down to about 10%.

For very high brightness backlights used in i-Tech Technology sunlight readable LCD modules, the inverters must be able to provide a much wider dimming range. Otherwise, the LCD screen will be too bright during nighttime conditions. Therefore, our inverters provide a typical dimming ratio of 200:1, meaning that the luminance can be adjusted from 100% down to 0.5%.

Any high brightness backlight system will consume a significant amount of power, thereby increasing the LCD temperature. The brighter the backlight, the greater the thermal issue. Additionally, if the LCD is used under sunlight, additional heat will be generated as a result of sunlight exposure. Temperature issues can be handled through proper thermal management design.

We provide TFT LCD with reflective mode of illumination without compromising its transmissive illumination. With the imposed reflective function, the modified LCD can reflect the ambient light passing the LCD cell and utilize the reflected light beams as its illumination. The stronger the ambient light is, the brighter the LCD will appear. As a result, the modified LCD is viewable under all lighting conditions including direct sunlight regardless the LCD"s original brightness.

The market demands for outdoor LCD applications are expanding, such as mobile navigator/video systems, PDA, personal organizer, Tablet PC, notebook computer, and Kiosk display etc. However, a regular transmissive LCD is very difficult to read under strong ambient light. This limits the outdoor applications of a conventional transmissive LCD.

The high bright LCD and the transflective LCD are the solutions generally utilized for outdoor applications. However, both solutions have some shortcomings. Because of the added lamps, high bright LCD creates some undesirable problems, which include high power consumption, excessive heat generation, increased dimensions, electrical circuit alterations, and shortened LCD lifetime. Thus, it is usually troublesome and costly to accommodate a high bright LCD in systems. Though giving good performance under the direct sunlight, the transflective LCD trades of its indoor performances.

Problems noticed in transflective LCD include narrow viewing angle, discoloration, low brightness, and loss of contrast. Moreover, the transflective LCD is currently limited in choice of sizes and resolutions.

On the other hand, a Transflective LCD is readable everywhere including outdoor environments without extra power consumption and excessive heat generation. The indoor viewing qualities are also enhanced. The modified unit fits right back into its original system with no need of any alteration and extra effort. Thus in your choice of size, resolution, and model, a direct sunlight readable LCD is conveniently incorporated into your device.

i-Tech is a premier supplier of optical bonding and performance added passive enhancements for all flat panel . i-Tech Optical Bonding process produces an optical bond between any display cover glass or touch panel, and any size LCD.

In the world of LCD"s, i-Tech takes display enhancement to a new level above all others. Utilizing advanced proprietary optical bonding technology; i-Tech overcomes optical challenges for display product manufacturers at an affordable price. In a wide range of applications, standard liquid crystal appear to "washed out" in high ambient lighting conditions. This wash out is due to excessive reflections and glare caused by bright light.

Commercially available LCDs, especially when protected by a separate cover glass or plastic shield, can not deliver enough brightness to make the display functional in outdoors or in other high ambient light applications. The exclusive Optical Bonding process from i-Tech provides a significant reduction of ambient light reflections at an affordable price, compared to other display enhancement technologies.

Optical Bonding seals either a top cover glass or touch screen directly to the face of the display bezel. Our bonding process eliminates the air-gap between the display and the cover glass, vastly reducing reflective light, which causes visual washout of the display image. Optical Bonding also enhances structural integrity by supporting the LCD assembly with the cover glass. The bond maintains perfect display uniformity while providing shock protection, unlimted humidity protection, and elimination of fogging caused by trapped moisture accumulating in typical air-gap assemblies.

Light travels through a variety of transparent materials; such as air, glass, plastic, and even water. These material"s abilty to transmit light is measured by their "indices of refraction". As light transfers from one material to another, such as air to glass, the differences the index of refraction will cause reflection. In the case of an air-to-glass interface, the reflection will be slightly less than 5% of the ambient light. All surfaces that have an index mismatch will reflect and the reflection is cumulative. In the case of a standard glass or plastic window, there are three surfaces with an index mismatch which will create a total relfection of nearly 15% of the ambient light. If the total reflection (in nits) is close to the displays brightness, the contrast of the display will be reduced to the point where the display"s readabilty is reduced to unacceptable levels.

Aside from the optical quality, Optical Bonding elminates the air-gap which prevents heat build-up from the "greenhouse" effect and prevents fogging from moisture or contamination from dirt or particles. It also offers shock protection and other damage to the LCD itself.

The anti-reflective coatings on the protection glass have excellent performance in tough ambient light conditions. With the normal glass, the strong reflection of the ambient light diminishes visibility and causes problems for viewer. Our special anti-reflective coated protection glass can increase contrast by enhancing light transmission rate over 95% (light reflectance rate less than 5%) and can effectively diminish the mirror images. The multi-layer vapor deposition coating either on one side or two sides of glass is designed to minimize reflectance and maximize transmittance.

Clearing Point - The temperature at which the liquid crystal fluid changes from a nematic into an isotropic state. In practice, a positive image LCD will turn totally black at this temperature and will therefore be unreadable. Because the clearing point is different for every fluid type, ask for design assistance from your supplier if high temperature operation is critical in your application.

Also, for most cases, both TN, HTN and STN utilize the phase known as nematic for display purpose. Within this phase, the liquid crystal has a "rod shape" exists within the solution which has fast response and has excellent electro-optic properties. This phase, however, only exists within a limited temperature range. The higher end of this temperature range is known as clearing point, above which, the liquid crystal lost its birefrigerance properties and cannot bend the light path anymore. Thus the polarizer will then be the only factor which affect incoming and out coming light. When the LCD is cooled down to below its clearing point, the display should be working again. The temperature for the clearing point varies greatly from material to material and you should contact our engineers regarding what you have. Normally a safe margin should be used to avoid clearing point when designing the display.

Light sensor detect the change of illumination outside, then it send the signal to MCU via I�2C interface. MCU will ask inverter to switch the brightness if the outside illumination was change over the default. MCU will transmit PWM signal to the inverter, amd the inverter will change the brightness of panel.

Winmate �light sensor� technology are now available for 8.4�, 10.4�,12.1�, 15�, 17�, and 19� LCD with specific panel option. Please contact with sales for more detail information.

The electronic controls effectively divide the screen into pixel sized sensing cells, using microfine wires which are not visible on a powered display. These wires are connected to a controller board, and an oscillation frequency is established for each wire. Touching the glass causes a change in the frequency of the wires at that particular point, the position of which is calculated and identified by the controller. Unlike other capacitive systems where the operator touches the actual conducting surface of the sensing panel, the active component of the sensor can be embedded up to 25mm from the touch surface ensuring long product life and stability.

The touchscreen can be supplied with the options of anti�glare or anti-reflection coatings, thermal toughening or chemical strengthening and privacy or contrast enhancement filters. The front glass of the touchscreen acts as a dielectric and enhances the capacitance of the touchscreen.

Simple calibration and set-up with Windows 98, NT, 2000, XP and Linux. Mouse emulation with Select on Touch, Select on Dwell, Select on Release and Drag and Drop.

Recently there many end customer was mislead believing high brightness (over 2000nits, even up to 5000nits) is the better solution. But there are few concerns that the so called extreme high brightness (3000nits to 5000nits) panel manufacturer don"t tell you:

1. How much power consumption is the extreme high brightness LCD? It is very important because all of our outdoor LCD is in completely sealed enclosures keeping it cool is a very huge Challenge. Not mentioned the hot temperature around 40-50C area.

2. Also, you need to determine how far is viewer distance. Because high brightness (3000-5000nits LCD) might Damage eyesight if the viewer is too closed. LCD is design with high resolution for people to see it very closely, so extreme high brightness doesn"t make sense for outdoor LCD. If they want to put on extreme high brightness LCD on roof top to attract audience which LCD is not even big enough for seeing from far away. Most case customer will use LED which is more reliable and cost effective if it is larger than 82".

4. Viewable under sunlight is not just brightness only, it involve contrast ratio, reflection of the front glass and content graphics contrast such as (red and white). Sunlight readable is combination of all above, not just brightness only.

4. Viewable under sunlight is not just brightness only, it involve contrast ratio, reflection of the front glass and content graphics contrast such as (red and white). Sunlight readable is combination of all above, not just brightness only.

3. All the major branded LG and Samsung LCD manufacturer the most brightness that they do is only 1000-2000nits because we believe this major LCD maker already done a study on what is the most feasible and comfortable LCD brightness for outdoor. That"s why all the high brightness (3000-5000nits) maker is after market vendor without any study about the what is most suitable brightness for different applications, only advertising high brightness is not the solution. If you ask these vendor for outdoor enclosure which they will not provide or guaranteed it will work because they know it is a huge Challenge to cool down the display. Just like you are buying a 800 horse power car, but you still need to design the car frame and cooler to make this engine run safely on the road, which this extreme high brightness won"t help you to design that.

The current market demands for thin-film transistor (TFT) liquid crystal display (LCD) is high; however, the LCD televisions still have contrast ratio-related issues. To resolve this, researchers conventionally use trial and error methods for parameter optimization and adjustment. However, this method is slow and can delay the development of new products. Therefore, this study focused on the high contrast ratio of the in-plane switching (IPS) panel. The Define-Measure-Analyze-Design-Verify procedure, comprising the methodology of the Design for Six Sigma, was used to help the researchers enhance the ultra-high contrast ratio of LCD panels. In this study, customer requirements were confirmed, after which the quality function deployment method was used to establish the technical requirements of the enhanced high contrast ratio of LCD. The contradiction matrix of TRIZ was then used to find the corresponding principles and thus propose the design scheme for the LCD contrast ratio. Methodologies, such as design failure modes and effect analysis, Taguchi"s parameter design, and reliability tests were used to enhance the ultra-high LCD contrast ratio. After the implementation of an actual case, the ultra-high contrast ratio of LCD panel was enhanced to 1000000:1; the benefits of such an improvement exceeded U.S. $9.5 million. This has also driven market orders for TFT IPS LCD. This study can serve as a reference for product design, product performance enhancement, pilot run yield improvement, and patent applications of LCD panel plants.

The contrast ratio (CR) is a property of a display system, defined as the ratio of the luminance of the brightest shade (white) to that of the darkest shade (black) that the system is capable of producing. A high contrast ratio is a desired aspect of any display. It has similarities with dynamic range.

There is no official, standardized way to measure contrast ratio for a system or its parts, nor is there a standard for defining "Contrast Ratio" that is accepted by any standards organization so ratings provided by different manufacturers of display devices are not necessarily comparable to each other due to differences in method of measurement, operation, and unstated variables.projection screen or emitted by a cathode ray tube, and the only light seen in the room would come from the display device. With such a room, the contrast ratio of the image would be the same as the contrast ratio of the device. Real rooms reflect some of the light back to the displayed image, lowering the contrast ratio seen in the image.

Static contrast ratio is the luminosity ratio comparing the brightest and darkest shade the system is capable of producing simultaneously at any instant of time, while dynamic contrast ratio is the luminosity ratio comparing the brightest and darkest shade the system is capable of producing over time (while the picture is moving). Moving from a system that displays a static motionless image to a system that displays a dynamic, changing picture slightly complicates the definition of the contrast ratio, due to the need to take into account the extra temporal dimension to the measuring process.

Many display devices favor the use of the full on/full off method of measurement, as it cancels out the effect of the room and results in an ideal ratio. Equal proportions of light reflect from the display to the room and back in both "black" and "white" measurements, as long as the room stays the same. This will inflate the light levels of both measurements proportionally, leaving the black to white luminance ratio unaffected.

Some manufacturers have gone as far as using different device parameters for the three tests, even further inflating the calculated contrast ratio. With DLP projectors, one method to do this is to enable the clear sector of the color filter wheel for the "on" part and disable it for the "off" part

Another measure is the ANSI contrast, in which the measurement is done with a checker board patterned test image where the black and white luminosity values are measured simultaneously.

It is useful to note that the full on/full off method effectively measures the dynamic contrast ratio of a display, while the ANSI contrast measures the static contrast ratio.

An LCD technology is dynamic contrast (DC), also called advanced contrast ratio (ACR) and various other designations. When there is a need to display a dark image, a display that supports dynamic contrast underpowers the backlight lamp (or decreases the aperture of the projector"s lens using an iris), but proportionately amplifies the transmission through the LCD panel; this gives the benefit of realizing the potential static contrast ratio of the LCD panel in dark scenes when the image is watched in a dark room. The drawback is that if a dark scene contains small areas of superbright light, the resulting image will be over exposed.

It is also common to market only the dynamic contrast ratio capability of a display (when it is better than its static contrast ratio only on paper), which should not be directly compared to the static contrast ratio. A plasma display with a 4,000,000:1 static contrast ratio will show superior contrast to an LCD (with LED or CCFL backlight) with 30,000,000:1 dynamic and 20,000:1 static contrast ratio when the input signal contains a full range of brightnesses from 0 to 100% simultaneously. They will, however, be on par when input signal ranges only from 0 to 20% brightness.

This animated gif shows a rudimentary representation of how various backlight dimming technologies work on TV. Dimming technology can drastically affect the contrast ratio of the display.

In marketing literature, contrast ratios for emissive (as opposed to reflective) displays are always measured under the optimum condition of a room in total darkness. In typical viewing situations, the contrast ratio is significantly lower due to the reflection of light from the surface of the display, making it harder to distinguish between different devices with very high contrast ratios.luminance of the display, as well as the amount of light reflecting off the display.

The 12.9-inch Liquid Retina XDR display has an IPS LCD panel supporting a resolution of 2732 by 2048 pixels for a total of 5.6 million pixels with 264 pixels per inch. To achieve Extreme Dynamic Range required an entirely new display architecture on iPad Pro. The all new 2D mini-LED backlighting system with individually controlled local dimming zones was the best choice for delivering the extremely high full-screen brightness and contrast ratio, and off-axis color accuracy, that creative professionals depend on for their workflows.

Unlike the previous design that takes light emitting from one edge of the display and evenly distributes it across the entire back, the Liquid Retina XDR display uses over 10,000 custom-designed mini-LEDs spread uniformly across the entire back of the display, delivering higher LED density than any other display of its kind. These mini-LEDs are grouped into an array of over 2,500 individually controlled local dimming zones. This delivers incredibly deep blacks right next to bright image areas, achieving a 1,000,000:1 contrast ratio.

The Liquid Retina XDR display improves upon the trade-offs of typical local dimming systems, where the extreme brightness of LEDs might cause a slight blooming effect because the LED zones are larger than the LCD pixel size. This display is designed to deliver crisp front-of-screen performance with its incredibly small custom mini-LED design, industry leading mini-LED density, large number of individually controlled local dimming zones, and custom optical films that shape the light while maintaining image fidelity and extreme brightness and contrast.

Additionally, custom algorithms run on the advanced display engine of the M1 chip, working at the pixel level to control the mini-LED and LCD layers of the display separately, treating them as two distinct displays. These proprietary algorithms coordinate the mini-LED and LCD layers across transitions to deliver the optimal visual experience. Transitional characteristics of local dimming zones, such as a slight blur or color change while scrolling against black backgrounds, are normal behavior.

ProMotion technology automatically adjusts the display refresh rate up to 120 Hz (twice the rate of typical LCD displays) to the optimal rate for the content. The result is ultra-smooth scrolling and incredible responsiveness on the display, whether you’re using your finger or Apple Pencil. True Tone technology subtly adjusts the white balance onscreen to match the color temperature of the light around you, so images on the display look as natural as on a printed page. The cover glass on the Liquid Retina XDR display has an on-axis reflection of 1.8 percent due to a custom antireflective coating. As a result, iPad Pro delivers industry-leading reflectivity for a more comfortable viewing experience indoors and out.

Extreme Dynamic Range.Extreme Dynamic Range (XDR) takes brightness and contrast to the extreme, surpassing what is considered standard dynamic range (SDR) and high dynamic range (HDR).

1,000,000:1 contrast ratio.A contrast ratio of 1,000,000:1 provides an incredible range of contrast, which along with extreme brightness, better replicates what the eye can see in real life.

Super-wide viewing angle.Polarizer technology reduces light leakage 25x off-axis versus a typical LCD display, providing accurate viewing from any angle.

Note:The Pro Display XDR undergoes a state-of-the-art factory display calibration process on the assembly line to ensure the accuracy of the P3 wide color panel and the individual backlight LEDs. Color professionals who use a workflow tuned to a particular calibration instrument can recalibrate the Pro Display XDR. See the Apple Support article Measuring and calibrating Apple Pro Display XDR.Subscription required for Apple TV+.

The 12.9-inch Liquid Retina XDR display has an IPS LCD panel supporting a resolution of 2732 by 2048 pixels for a total of 5.6 million pixels with 264 pixels per inch. To achieve Extreme Dynamic Range required an entirely new display architecture on iPad Pro. The all new 2D mini-LED backlighting system with individually controlled local dimming zones was the best choice for delivering the extremely high full-screen brightness and contrast ratio, and off-axis color accuracy, that creative professionals depend on for their workflows.

Unlike the previous design that takes light emitting from one edge of the display and evenly distributes it across the entire back, the Liquid Retina XDR display uses over 10,000 custom-designed mini-LEDs spread uniformly across the entire back of the display, delivering higher LED density than any other display of its kind. These mini-LEDs are grouped into an array of over 2,500 individually controlled local dimming zones. This delivers incredibly deep blacks right next to bright image areas, achieving a 1,000,000:1 contrast ratio.

The Liquid Retina XDR display improves upon the trade-offs of typical local dimming systems, where the extreme brightness of LEDs might cause a slight blooming effect because the LED zones are larger than the LCD pixel size. This display is designed to deliver crisp front-of-screen performance with its incredibly small custom mini-LED design, industry leading mini-LED density, large number of individually controlled local dimming zones, and custom optical films that shape the light while maintaining image fidelity and extreme brightness and contrast.

Additionally, custom algorithms run on the advanced display engine of the M1 chip, working at the pixel level to control the mini-LED and LCD layers of the display separately, treating them as two distinct displays. These proprietary algorithms coordinate the mini-LED and LCD layers across transitions to deliver the optimal visual experience. Transitional characteristics of local dimming zones, such as a slight blur or color change while scrolling against black backgrounds, are normal behavior.

ProMotion technology automatically adjusts the display refresh rate up to 120 Hz (twice the rate of typical LCD displays) to the optimal rate for the content. The result is ultra-smooth scrolling and incredible responsiveness on the display, whether you’re using your finger or Apple Pencil. True Tone technology subtly adjusts the white balance onscreen to match the color temperature of the light around you, so images on the display look as natural as on a printed page. The cover glass on the Liquid Retina XDR display has an on-axis reflection of 1.8 percent due to a custom antireflective coating. As a result, iPad Pro delivers industry-leading reflectivity for a more comfortable viewing experience indoors and out.

A higher contrast ratio is not necessarily better. If the contrast ratio is too high, sometimes shadow colors can be too firm, making images appear stiff and rendering it difficult to match colors with output. The ability to adjust contrast ratio can also be used as a criterion for choosing a calibration monitor.

Osaka, Japan - Panasonic Liquid Crystal Display Co., Ltd., a subsidiary of Panasonic Corporation, today announced it has developed a new model of its IPS liquid crystal panel that achieves a contrast ratio[1] of over 1,000,000:1, which is 600 times*2 that of conventional liquid crystal panels. With Panasonic"s unique IPS[2] liquid crystal technologies that feature wide viewing angles, high brightness, and high reliability, the new IPS panel has achieved a high contrast ratio of over 1,000,000:1 by integrating newly developed light-modulating cells that permit pixel-by-pixel control of backlight intensity. This achieves a faithful and high-grade video display, ranging from dazzling light to pitch-black.

The new IPS panel is ideal for use in professional-use High Dynamic Range (HDR) monitors for broadcasting stations and video production studios. HDR displays can reproduce images that are faithful to what people see, ranging from bright light to jet-black darkness. Also, the new high-contrast panel is suitable for use such as medical monitors that require faithful video display and automotive monitors that require clear visibility without black floating[3].

Panasonic"s new IPS Liquid Crystal Panel has the following features:An industry-first high contrast ratio of over 1,000,000:1*1, which is 600 times that of conventional products

The new high-contrast IPS panel solves the problems inherent in conventional liquid crystal panels. Despite their track record in wide-ranging applications from B-to-C to B-to-B fields, conventional liquid crystal panels suffer black floating, white washout phenomenon, in dark parts of the display area when the backlight intensity is increased to raise brightness. When the backlight intensity is lowered to make dark parts clearer, these panels also suffer a loss in sparkle in bright parts.

Conventional liquid crystal panels, with a contrast ratio of approximately 1,800:1, suffer black floating in dark parts when the backlight intensity is increased, and they suffer a loss in sparkle in bright parts when the backlight intensity is lowered.

Panasonic"s new high-contrast IPS panel uses newly developed light-modulating cells, which operate based on the operating principle of liquid crystals, and these cells are integrated into the display cells. As a result, it is capable of controlling the amount of backlight entering the display cells pixel by pixel, thus achieving a contrast ratio of 1,000,000:1.

The light-modulating cells are composed of a liquid crystal material that differs in light-transmission properties from that used in the display cells, allowing independent control of the display and light-modulating cells. This has reduced light leakage significantly, allowing finely-tuned gradation expression. Furthermore, the application of Panasonic"s IPS liquid crystal technologies, developed for industrial use, has achieved a contrast of 1,000,000:1 (maximum brightness: 1,000 cd/m², minimum brightness: 0.001 cd/m²) while maintaining features including wide viewing angles and high light-transmission efficiency.

Consequently, the new high-contrast IPS panel can make HDR-compatible displays for professional use at broadcasting stations and video production studios, and is suitable for uses including medical monitors and automotive monitors.

The new high-contrast IPS panel achieves a maximum brightness of 1,000 cd/m² by enhancing the transmittance of the display and light-modulating cells and adopting a high-brightness backlight. For the light-modulating cells, the company has developed a light-tolerant material that provides stable operation over a long period of time, despite exposure to intense light from the high-brightness backlight, as well as a unique cell structure.

The new panel can be manufactured using the existing equipments for liquid crystal panel manufacturing. Panasonic Liquid Crystal Display Co., Ltd., possesses an industry-leading scale of 8.5th-generation (G8.5)[4] production lines that are capable of manufacturing 10- to 100-inch products.

[Terminology][1] ContrastRatio of the brightness of white to that of black of a display[2] IPS (In-Plane Switching) liquid crystalA liquid crystal operating mode that displays images by rotating liquid crystal molecules in a plane parallel to the substrates to change light transmittance[3] Black floatingPhenomenon in which black parts appear slightly whitish when watching a display screen in a dark room environment[4] 8.5th generation (G8.5)Production lines that use glass substrates of 2,500 mm x 2,200 mm

4. Factory Seconds products may be recondition and may have imperfections, for example physical damage, missing pixels, corrosion, etc that do not affect the operation or performance of the unit. All products are sold on an "as is" basis and the customer is responsible for inspecting the product before purchase and the warranty does not cover any such imperfection.

5. This warranty is on a "return to base" basis. This means the customer is responsible for bringing any product back to the place of purchase for service under warranty and for collecting it afterwards. Subject to our operational constraints, we may carry out an in-home service within our normal service hours on air conditioners, refrigerators, washing machines, dishwashers, LED, LCD, PLASMA, OLED and Projector televisions with a screen size of 47" or more.

c) any defect or injury caused by or resulting from incorrect installation, misuse, abuse, neglect, accidental damage, improper voltage, or any alteration which affects the reliability or the performance of the unit, not attributable to faulty manufacture or components.

f) damage to or faults with video heads, audio heads, lasers, or stylus resulting from wear and tear in normal use; dust or other particles on LCD lenses.

Panasonic"s display arm, Panasonic Liquid Crystal Display Company, has announced the development of an in-plane switching (IPS) panel family boasting 1,000,000:1 static contrast ratio - the highest ever claimed by an LCD manufacturer.

Those who have been shopping for a monitor or TV in the last decade or so will be all too familiar with manufacturers" tendency to overstate the contrast - the distinction between fully-white and fully-black on the same panel - of their displays. Typically, this involves claiming a 1,000,000:1 "dynamic" contrast ratio - a trick which lowers the backlight level in dark scenes and boosts it in bright scenes to simulate high contrast. Panels based around organic light-emitting diode (OLED) technology, by contrast, have a high static contrast thanks to the ability to toggle the lighting on a per-pixel rather than per-panel or per-zone level, but these displays are more costly and complex to manufacture.

Panasonic"s display division"s new screens, though, are claimed to offer a 1,000,000:1 static contrast ratio for the first time in an IPS LCD panel - some 600 times higher, the company claims, than its nearest competition. The company"s technology is based around light-modulating cells permitting pixel-by-pixel control of backlight intensity in much the same way as OLED panels but, it claims, without the need to upgrade existing liquid crystal panel manufacturing equipment - greatly dropping the cost compared to retooling for OLED.

According to Panasonic"s internal testing, the panels treated with the additional layer of light modulating cells are capable of displaying a brightness of 1,000 candela per metre squared (cd/m²) and 0.001cd/m² simultaneously, without losing the viewing angles or colour gamut of the IPS panel. It plans to manufacture the panels in a range of sizes, from large-scale TV panels to professional-grade monitors for medical and industrial use and even down to in-car computer displays.
