tft lcd lifespan manufacturer

A: All of our TFT LCDs meet or exceed 130 degree (Horizontal) and 110 degree (Vertical) viewing angle. Our wide view film technology achieve viewing angle 160 degree (Horizontal) and 140 degree(Vertical). We also have Super-Wide-View technology that will achieve 85/85/85/85 viewing angle, which is the best technology for viewing angle and color reproduction. Please consult the individual part specification for details.

A: NCM enables vivid reproduction of even the most subtle colors, such as pastels and flesh tones, and provides independent control of six colors without one color influencing any of the others. It supports 18-bit and 24-bit color and full motion video and compensates for any color shifts caused by LCD components such as CCFLs and optical films. Read the NCM Technology WhitePaper.

A: There are basically two approches to increase a display"s sunlight readability: increase the brightness level of the display, or reduce the ambient light reflection on the display surface. Good Display has several technology for outdoor readable applications, such as high brightness panel, transflective panel, anti-reflection and antiglare surface treatment, for more information, please check Outdoor Use TFT Displays for more information.

A: Yes. Good Display TFT LCDs response time is between 16ms to 25ms. Most of our newly developed LCD panels have 16ms response time, which is enough for moving picture. Please check the individual display specification for detail information.

A: LCD displays typically feature a wider viewing angle from straight on or above, compared to the viewing angle from below. The reverse-scan feature enables customers to select either a normal scan or reverse scan to obtain the best intended image, depending on whether the mounted display will be viewed typically from above or below. Good Display TFT LCDs have reverse scan function.

A: The defination of the CCFL lifetime is when the brightness level droped to 50% of its initial full brightness level. All the CCFL backlights for TFT LCDs are rated at 50,000 hours minimum. But most of the CCFL lamp unit can be replaced easily.

A: For industrial grade LED backlits TFT-LCD, the minimum lifetime is 60K hours. Be sure to consult the individual part specification for information on a specific LCM.

A: Many of the Good Display TFT LCDs operate at both 3.3 and 5V. However, as the 3.3V becomes the new standard, the LSI manufactory might decide to only support 3.3V, that is not controlled by Good Display. Please check the individual part specification for information.

The LED backlight lifetime in twenty-six of its TFT LCD modules has been increased by Kyocera. The Japanese display manufacturer will increase the backlight lifetime to 100,000 hours across a range of displays to provide greater usability and improved reliability. The long-life backlight portfolio includes display modules from Kyocera"s range of Advanced Wide View (AWV) displays, Super High Brightness (SHB) panels and a number of popular standard modules.

For most mainstream LCD sizes, we have a solid and continuous relationship with upstream panel and IC manufacturers. And our main employees are from LCD upstream companies and have the most extensive resource information and personal connections in the industry. So we can guarantee the supply.

Perhaps you’ve wondered how long a digital display lasts. It’s a great question. One quick search on Google will tell you that an LCD panel has a lifespan of about 60,000 hours, which is equivalent to almost seven years.

Of course, LCDs aren’t the only kind of displays. You also have LED, OLED, QLED, ELD, PDP, and MicroLED, plus many other variations. Obviously, that 7-year estimation will not apply across the board. For the sake of ease, let’s just focus on some of the common types of displays that most of us are familiar with.

Here’s some LCD alphabet soup: There are LED LCD displays, CFFL LCD displays, LED displays, and more. With all these acronyms, it can get a bit confusing. What"s important to note is whether or not the display uses an LCD panel, and how the LCD panel is illuminated. You can read more about thedifferences between types of LCD and LED signage, but these are the most common types:

LCD displaysgenerate images and colors via a Liquid Crystal Display (LCD) panel, which is not self-emitting and requires an external light source to illuminate the image, typically an LED backlight. Their full name "LED-backlit LCD display" is commonly shortened to "LED displays", which is why they"re often confused with the true LED displays we"ve identified above.

Unfortunately, LED backlights used in LCD displays burn out over time. If used at high or maximum brightness, which is necessary for outdoor applications,an LED backlight will last between 40,000 to 60,000 hours. Or, about 4.5 to 7 years.

OLED stands for Organic Light Emitting Diode. OLED displays differ from common LCD displays in that their pixels are self-illuminating. In other words, there is no LED backlight required to illuminate the the display image; everything occurs within the OLED pixels themselves. According to onearticle from the US Department of Energy,OLED screens have a life expectancy of about 40,000 hours at 25% brightness, and 10,000 hours at full brightness. That equates to about 1 to 4.5 years, which is a much shorter (albeit, brilliant) lifetime than an LCD display.

Perhaps you noticed that the acronym QLED closely resembles the acronym OLED. This is not accidental. QLED is basically Samsung’s original design built to compete with OLED technology. However, the two are not the same. QLED stands for Quantum Light Emitting Diode. While QLED is similar to a regular LED design, it in fact differs by using nanoparticles called “Quantum dots” to achieve its unique brightness and color. Samsung approximates that the lifespan ofQLED panels are likely to last 7-10 years. After that, a user is likely to notice traces of degradation.

MicroLED is an emerging display technology, consisting of small LEDs in tiny arrays within each pixel. This technology goes beyond the offerings of the formerly frontrunning OLEDs, with much darker blacks and more radiant contrast levels. And, unlike OLEDs, MicroLEDs are not organic. They are not as subject to burn-in, and thus, have a longer lifespan than OLEDs. However, they are significantly more expensive - so much, in fact, that they aren’t considered a viable option for the majority of consumers.According to Samsung, the lifespan of its MicroLED panels should last about 100,000 hours, or, roughly 11 years.

PDP stands for Plasma Display Panel, and it refers to displays that use small cells full of plasma. The atoms within the plasma emit light upon being charged by electricity. While PDP is generally considered to offer better colors than LCDs, they consume a lot more power and usually cannot be battery-operated.The average lifespan of the newest generation of PDPs is approximated to be 100,000 hours, or 11 years of continual use.

In some ways,reflective LCD panelsoperate similarly to other LCDs, only they have one key difference - they do not require a backlight. Instead, they rely on ambient light (or sunlight) in order to produce images. This opens the door to some groundbreaking possibilities. The first (and most appreciable) is low power consumption. Reflective displays use up to 95% less energy. Not bad - especially in a world that is continually looking for new ways to go green. Take into consideration the financial implications of this. Lower power means less money spent on operating costs.

Being that reflective displays do not require a backlight (a component that is particularly subject to degradation), and since they do not generate as much heat, it is safe to say that the lifespan of these displays should far exceed that of backlit LCD panels (which was 7 years at the high end). However, being that thisinnovative technologyis relatively new, its actual lifespan is therefore more difficult to estimate -- simply because it has yet to be reached.

One company at the front lines of this research isAzumo. Azumo has created a light guide that laminates to the front of a display. It requires 90% less energy than the backlight of a traditional LCD display. This greatly improves the problem of low light visibility otherwise encountered, and keeps reflective displays in the same low energy consumption ballpark. One issue, however, is that Azumo currently only offers its light guides for smaller-sized units. If you happen to want this feature applied to a display that is over 10” diagonally, then you’re still on the search for a solution.

One other factor to consider regarding reflective technology is its cost. That reflective layer is more costly to manufacture than many of the backlights it replaces, creating a seemingly greater upfront cost for those who are interested in investing in energy-efficient signage. However, these initial price points are quickly justified as buyers will recognize the significantly lower operating costs and increased longevity (not even including replacement costs of other “expired” displays) that comes with their purchase of reflective display signage. If a backlit LCD panel only lasts 7 years, for example, you’ll have paid for that LCD twice in the period of ten years. A very valid question arises… is that “cheaper” backlight really cheaper? Probably not. It only feels that way at first.

To choose the right TFT LCD display for a medical application, engineers and decision-makers need to have a comprehensive understanding of how TFT LCD display specifications affect final products. And it is important to know how a display differs from industrial or consumer LCD.

In the old days, medical device with a display was usually bulky and had many dials & buttons. A machine with buttons and knots makes for a good breeding space for harmful pathogens, as it is harder to clean than modern one with flat touch screen interface. Using TFT LCD touch screen on medical device not only makes disinfecting easy, but also save a lot of front panel spaces for displaying vital medical information.

Medical device can be put through extreme temperature, vibration and shock, moisture and variable ambient lighting. Thus, it demands highly reliable TFT LCD screen, and possibly the use of clear protective cover that safeguards the display from the rigors of day-to-day use.

While normal LCD display"s performance is not sufficient, medical TFT supplier like Topway can add enhancements such as optical bonded front panel with anti-reflection coating, transflective display that combines both reflective and transmissive properties.

Medical TFT LCDs are typically used in three kinds of applications: standard (e.g. bedside monitor), life-support (e.g. glucose meter) and life-critical (e.g. ventilator). These applications have drastically different requirements on functionality, reliability and MTBF (mean time between failure). Two well-known standard organizations" acceptance test rules are generally accepted by the industry, European DIN and American Association of Physicists in Medicine. The two organizations have well defined standard on resolution, noise, viewing angle, glare, color uniformity, distortion, reflection, luminance response and luminance uniformity.

Qualification process for these standards is very tedious and expensive. Device manufacturers are not willing to modify an approved system and are demanding long-term availability for LCD display. Topway guarantees the TFT LCD module"s longevity. A lot of the color LCD models" life span even last over ten years.

Infusion pump is a medical device used to deliver fluids into a patient’s body in a controlled manner. There are many different types of infusion pumps, which are used for a variety of purposes and in a variety of environments. Infusion pumps are better than manual fluid administration pumps because they can deliver fluids at precise frequencies, volumes, and intervals. This device embeds a2.8" color TFT LCD module from Topway.

ECG monitor is a life-saving device that is used to measure the electrical activity of your heart to show whether your heart works normally or not. 8" TFT LCD module is the one, our client chose.

With such a significant role to play, medical device manufacturers understand the importance of sourcing them from trusted display manufacturers like Topway Technology. The company has been providing custom display solutions to medical device manufacturers and pharmaceutical companies for more than 20 years. All Topway medical TFT LCD modules have passed through stringent tests: high/low temperature test, salt spray, EMC test & RoHS.

TFT stands for thin-film transistor, which means that each pixel in the device has a thin-film transistor attached to it. Transistors are activated by electrical currents that make contact with the pixels to produce impeccable image quality on the screen. Here are some important features of TFT displays.Excellent Colour Display.Top notch colour contrast, clarity, and brightness settings that can be adjusted to accommodate specific application requirements.Extended Half-Life.TFT displays boast a much higher half-life than their LED counterparts and they also come in a variety of size configurations that can impact the device’s half-life depending on usage and other factors.TFT displays can have either resistive or capacitive touch panels.Resistive is usually the standard because it comes at a lower price point, but you can also opt for capacitive which is compatible with most modern smartphones and other devices.TFT displays offer exceptional aspect ratio control.Aspect ratio control contributes to better image clarity and quality by mapping out the number of pixels that are in the source image compared to the resolution pixels on the screen.Monitor ghosting doesn’t occur on TFT displays.This is when a moving image or object has blurry pixels following it across the screen, resembling a ghost.

TFT displays are incredibly versatile.The offer a number of different interface options that are compatible with various devices and accommodate the technical capabilities of all users.

There are two main types of TFT LCD displays:· Twisted nematic TFT LCDs are an older model. They have limited colour options and use 6 bits per each blue, red, and green channel.

In-plane switching TFT LCDs are a newer model. Originally introduced in the 1990s by Hitachi, in-plane switching TFT LCDs consist of moving liquid pixels that move in contrast or opposite the plane of the display, rather than alongside it.

The type of TFT LCD monitor or industrial display you choose to purchase will depend on the specifications of your application or project. Here are a few important factors to consider when selecting an appropriate TFT LCD display technology:Life expectancy/battery life.Depending on the length of ongoing use and the duration of your project, you’re going to want to choose a device that can last a long time while maintaining quality usage.

Image clarity.Some TFT displays feature infrared touchscreens, while others are layered. The former is preferable, especially in poor lighting conditions or for outdoor and industrial applications, because there’s no overlay and therefore no obstructions to light emittance.

The environmental conditions make a difference in operation and image clarity. When choosing a TFT for outdoor or industrial applications, be sure to choose one that can withstand various environmental elements like dust, wind, moisture, dirt, and even sunlight.

As a leading manufacturer and distributor of high-quality digital displays in North America, Nauticomp Inc. can provide custom TFT LCD monitor solutions that are suitable for a multitude of industrial and commercial indoor and outdoor applications. Contact us today to learn more.

When it comes to choosing what to use for your displays, going with the standard can get you farther ahead than thinking outside the box. TFT LCD display gives you an edge for your advertising needs, television screens, or even phone screens.

A thin-film transistor (TFT) is one of the technologies commonly used for building LCDs. With this technology, your LCD is guaranteed a sharp, clear, and full-color display and high-quality performance.

When a signal sent to a pixel also affects the pixels next to it, crosstalk This runs the risk of distorting the quality of your image. With TFT, crosstalk is significantly reduced with the TFT layer integrated into the screen itself. With every pixel corresponding to the signals meant only for them, you are guaranteed the best resolution and image quality.

In the LCD industry, the most popular kinds of displays are manufactured and innovated the most. Unlike other types of LCD technologies, the TFT module is available in different sizes, ranging from cellphone sizes to larger TV sizes, to suit your needs.

All LCD displays have a determined number of hours of use before they become half as bright than when they were turned on for the first time. This is called half-life. Although research is still ongoing regarding half-life, TFT displays are said to have more than 14,000 hours of half-life.

This does not mean, however, that the LCD will burn out after reaching its half-life. It means that its brightness will only be half of when it was new.

Compared to CRTs, TFT LCD modules have lower heat release. Moreover, they emit lower electromagnetic emissions which significantly decrease visual fatigue. This means that TFTs are ideal for devices and displays that require an audience’s prolonged attention, such as cell phones and television screens.

While the TFT’s power consumption is significantly lower than OLEDs in white displays, there are also emerging TFT displays in the market that integrate smart technologies that can save up to 50% energy on battery-operated devices.

One of the notable disadvantages of TFTs, however, is its cost. The characteristics detailed in the previous section, however, must be considered worthy of investment. Moreover, as the number of TFTs floods the LCD display market, the price for TFTs are decreasing by the day.

At Microtips Technology USA, we only provide you with the best among the best of TFT modules. Our TFT LCD displays assure only full RGB brilliance with up to 16.7 million colors, better picture quality with high resolutions and IPS technology, and affordability.

Two of the more popular types of custom color LCD modules are TFT LCD Displays and custom FSC LCD modules. Both TFT LCD Displays(Thin Film Transistor) and FSC LCD Modules (Field Sequential Field Color) require a RGB (Red, Green, and Blue) LED backlight.

One concern many customers have with a TFT LCD display and a custom FSC LCD module is the half-life of the LED backlights. In other words, how long before the backlight starts to dim?

An example of this is a 3.5 inch TFT. The half-life of the RGB (Red, Green, and Blue) backlight is rated at 50K hours. When 50K hours rolls around the light will be half as bright as when you first activated the display. When the same display runs for an additional 50K hours, that is a total of 100K hours, the brightness of the backlight is now half of what it was at 50K hours or one quarter, 25%, as bright as when it was first turned on.

It is close to impossible to replace the backlight on a TFT LCD display or a custom FSC LCD module once it is out in the field. Taking the display apart is not difficult; putting it back together is a whole different subject. LCD display modules need to be assembled in a clean room environment.

At this time the only other option is to replace the entire LCD module. This introduces issues that can be expensive. LCD modules have a tendency to be discontinued every few years. This means you may try to purchase replacement displays, only to find they have become impossible to locate. At this point the only option you have is to build a custom LCD display module. This can also be expensive and time consuming.

One possible option to obtain a longer half-life on your TFT LCD display or custom FSC LCD module is to build a custom display when you first design your product. The custom display would contain two RGB backlights. The concept is that the customer’s processor would turn on RGB backlight #1 for 1,000 hours, and then switch to the second RGB backlight for 1,000 hours. This rotating between the two sets of RGB backlight would double the half-life of the TFT LCD display custom FSC LCD.

We do not offer this option on any of our standard LCD modules, but have partnered with a supplier to engineer and design this display on LCD custom modules.

Have you ever thought How long does a monitor last? or wondered what the lifespan of a monitor is? After all, monitors are the significant peripheral device of a PC.

If you’re thinking about buying a new LCD monitor in today’s technological progress, though, you might be wondering how long they last. At the end of the post, you will find tips for extending the life of your Monitor.

LCD monitors usually have a lifespan of 30,000 to 60,000 hoursof use, which equals 10 to 20 years if the monitor is used for eight hours a day. It has a longer life than the plasma and CRT monitors and is somewhat shorter than that of current LED Monitors.

To ensure your LCD display’s lifespan, you definitely need to adjust the contrast setting (an important factor) for the conditions under which you view your LCD display. Higher light levels and contrast levels affect the life expectancy of the LCD monitor and vice versa.

A LED monitor’s lifespan range between 80,000 to about 120,000 hours. Which is equivalent to about 20 years, if we use 8 hours a day, depending on its materials and manufacturers.

LED monitors that are being sold right now in stores to come with the latest screen materials and technology. Their main advantage if they live longer than LCDs, and CRTs by providing bright and vivid display features that are energy efficient.

A significant factor that influences the life span of a LED monitor is the conditions like Usage, Temperature, and Brightness. The harsherthe use, the higher the temperature and brightness can reduce the lifespan, and the less you can expect a LED to last.

The CRT monitor is old since they were used old technology of cathode-ray rubes that illuminate the corresponding pixels ( typically old backlighting technology) leads to less efficiency, often heavy, bulky, and fragile units. result in a short lifespan.

Today the world is moving with great speed along alongside innovative progress. Also, no one will surprise anyone with a thin LCD monitor or TV. They can be seen in almost any office. Many have already swapped out their old fat CRT TVs for new thin LCD panels. Laptops also have an LCD screen, so this also applies to them.

In fact, there is no exact answer to the lifespan of OLED. However, as per the report and research, the OLED monitor can have a lifespan of 100,000 hours. And it can be last long about 8 – 15 years if you use it 8 hours a day.

The LCD monitor is turned on and off frequently or used in an extreme temperature environment, the LCD monitor’s backlight life will be significantly shortened. Therefore, if you want to extend the life of the LCD monitor as much as possible, neither turn it on and off every few minutes nor use the LCD monitor in a harsh temperature environment.

You can spread the knowledge and care for others by sharing the article “How long does a monitor last?” to make aware known of the lifespan of monitors.

How long will your LED display last? In nearly every industry, from retail businesses to concert halls to corporate centers, decision makers need to evaluate the return on investment (ROI) of their LED signage. In most cases, potential buyers go straight to the obvious place: the LED manufacturer’s spec sheet. The industry standard for LED lifespan is 100,000 hours, or about 10 years, and most people assume that’s how long their display will last. But it’s not quite that simple.

The 100,000-hour figure assumes that every diode will be running at full brightness, consistently — which, on an LED screen, is virtually never the case. The lifespan figure can also be misleading because it indicates when a diode degrades to half-brightness, not completely dark. Many other variables affect an LED display’s lifespan; you can’t rely solely on the number on the diode spec sheet.

“The reality is, your screen can often last significantly longer than 100,000 hours,” says Kevin Izatt, a senior product manager in Samsung’s Display division. “We’ve had displays that have been up for 15-plus years with more than adequate brightness. Because the diode is actually only one factor in the lifespan of your LED display.”

The quality of your display’s power supply — and how hard it drives the diodes — can have a significant impact on your screen’s lifespan. The other components being powered, such as fans and electrical components, have their own lifespans as well, which are also impacted by the power supply.

“Fans are mechanical; they break down,” explains Izatt. “And similar to your computer, the electrical components don’t last forever. Together, these factors all contribute to the lifespan of an LED display. Looking at just the diode lifespan doesn’t give you the complete story — almost always, another part will go out first.”

To help businesses transition from LCD to longer-lasting LED signage, Samsung has launched a trade-in program. Samsung will come on site to remove your existing display and provide a discount on a new LED bundle kit.

Traded-in LCD displays that are still operating will be refurbished and resold, and your business will receive a cash rebate. Nonworking displays will be recycled and their parts reused.

You can’t rely on the number on the diode spec sheet; the lifespan of your LED display depends on many more factors. “Overall quality has a tremendous impact on the life of the display that diode specs just don’t take into account,” says Izatt. Your best bet is to look at the purchase holistically and invest in a top-tier product.

TFT is an abbreviation for Thin Film Transistor, a flat panel display used to improve the operation and utility of LCD screens. In order to portray an appearance to the audience, a liquid crystal display (LCD) utilizes a crystalline-filled fluid to modify rear lighting polarized origin through the use of an electromagnetic force among two relatively thin metal wires such as indium oxide (ITO). However, color TFT displays are associated with this method, which can be employed in both divided and pixelated display systems.

With motion pictures displayed on an LCD, the intrinsic sluggish rate of increase between liquid phases over a significant number of pixel components can be an issue due to capacitance impacts, which can create a blurring of the visuals. Placing a high-velocity LCD control device inside the formation of a thin-film transistor immediately next to the cell component just on a glass screen, the issue of LCD picture speed may be substantially improved, and image blur can be eliminated for all useful purposes entirely.

Organic light-emitting diodes (AMOLEDs) are a type of flat light-emitting advanced technologies that are created by interspersing a succession of organic thin sheets over two conducting conductors. An electrical charge causes a brilliant light to be produced when the current flows. AMOLED displays are light-emitting screens that do not require a backlight, making them thinner and more energy-efficient than liquid crystal displays (LCDs) (which will need a white backlight).

Half-Life has been expanded. TFT displays have a far longer half-life than its LED equivalents, and they are available in a number of sizes, which might have an effect on the device"s half-life based on the phone"s usage as well as other variables. Touch panels for TFT screens can be either resistant or capacitance in nature.

Backlighting is unnecessary for AMOLEDs. LCDs produce images by selectively blocking parts of the illumination, whereas AMOLEDs produce light. AMOLEDs utilize less energy than LCDs since they don"t need backlighting. This is critical for battery-powered devices such as phones.

While AMOLED light-emitting sheets are lightweight, the substrate can also be elastic rather than stiff. AMOLED films are not limited to glass-like LEDs and LCDs.

AMOLEDs offer 170-degree ranges of vision. LCDs operate by obscuring the light. Hence they have intrinsic viewing obstacles. In addition, AMOLEDs have a substantially wider viewing spectrum.

AMOLEDs outperform LEDs. Since AMOLED organic coatings are less than LED inorganic crystal levels, AMOLED conducting and particle emitters layers can just be multi-layered. Also, LEDs and LCDs need glass backing, which absorbs light. AMOLEDs don"t need it.

While red and green AMOLED sheets have a greater lifespan (46,000 to 230,000 hours), azure compounds have significantly shorter longevity (up to roughly 14,000 hours).

Due to the fact that AMOLED displays inherently emit illumination, they do not need a backlight when used on a monitor screen. Conversely, LCDs require backlights since the liquid crystals themselves are incapable of producing light under their own. Direct light emission from AMOLED displays also allows for the developing of lightweight display devices than others using TFT LCDs.

LCD displays have a higher brightness than AMOLED panels. This is owing to the LCD"s usage of led backlight, which may provide a brilliant illumination of the entire display. Despite the fact that AMOLEDs produce high levels of brilliance from their illumination, they will never be able to match the intensity of LCD lighting.

LCD screens use less power than AMOLED displays, which provides a slight advantage. The amount of energy consumed by AMOLED displays is dependent on the intensity of the screen. Lowered luminance results in lower energy usage, however, it might not be the best solution because the contrast would suffer as a result of the decreased brightness. In some situations, such as when to use an AMOLED device in direct sunlight, it is not an optimal situation.

However, the backlit keys of TFT displays account for the majority of their power usage. TFT screens" efficiency is considerably improved when the backlight is set to a lesser brightness level than the default setting. For example, replacing the light of an LCD TV with just an Led flash will have no effect on the image quality, but will result in lower power usage than replacing the light of an AMOLED TV.

With the exception of phones, numerous other technologies make use of displays to allow customers to engage in direct communication with them. To determine whether or not TFT LCD will be able to withstand the development of AMOLED innovation, we should first review the benefits of LCD technology. The backlighting quality ensures that whites are strong and brightness is superb but will deplete a battery much more quickly than just an AMOLED display. Furthermore, the cost of LCD screens is a considerable consideration. In addition to being less expensive and more easily accessible, they are produced in standard industry sizes, allowing them to be purchased for innovative products with relative ease.

FANNAL new 8” TFT-LCD display offers a display area of 162.048(H) x 121.536(V)mm, high brightness of 600 cd/m² and a wide viewing angle of 80/80/80/80deg. The operating temperature range is another key feature, the display can operate between a standard -10 to +50°C.

The Displaytech DT028 series LCD is a 2.8in active matrix TFT module with 240 x 320 resolution (RGB). The device is available now from RS Components. This touch screen provides an active viewing area with a width of 43.2mm and a height of 57.6mm. It uses a-Si-based TFT LCD that employs Ilitek ILI9341 as a chip driver. This display provides a response time of 10ms. The device has a width of 50mm, a height of 69.2mm and depth of 2.7mm.

In order to choose the right TFT LCD screen for medical applications, engineers and decision makers need to fully understand how the specifications of the TFT LCD screen affect the final product. It is also important to understand the difference between medical displays and industrial or consumer LCD screens.

In the past, medical devices with displays were usually bulky, with many scales and buttons. Machines with buttons and knots provide a breeding ground for harmful pathogens because they are more difficult to clean than modern machines with flat touch screen interfaces. The use of TFT screens on medical equipment not only facilitates disinfection, but also saves a lot of front panel space, which can be used to display important medical information.

Medical equipment may be affected by extreme temperatures, vibration and shock, humidity, and environmental changes. Therefore, it needs a highly reliable TFT LCD screen, and may need to use a transparent protective cover to protect the display from damage from daily use. Although the performance of ordinary LCD screens is not enough, medical TFT LCD screen suppliers can add some enhanced functions, such as optical bonding of the front panel and anti-reflection coating, and transflective displays with both reflection and transmission characteristics.

Medical TFT LCD screens are commonly used in three applications: standard (such as monitors), life support (such as blood glucose meters), and life-critical equipment (such as ventilators). These applications have very different requirements in terms of functionality, reliability, and mean time between failures. There are clear standards in terms of resolution, noise, viewing angle, glare, color uniformity, distortion, reflection, brightness response, and brightness uniformity.

The certification process for these standards is cumbersome and expensive. The LCD screen suppliers are unwilling to modify the standards and require long-term use of LCD screens to ensure the life of the TFT screen. Many color liquid crystal displays have a life span of more than ten years.

(4) The ECG monitor is a life-saving device used to measure the electrical activity of the heart to show whether the heart is working normally. The commonly used choice is the 8-inch TFT screen.

We aim to offer TFT LCD displays of the best quality for the price, and where we can secure a continuity of supply. The quality of products reflects on our business, and so we do not want to be linked to inferior quality stock. We also understand that there is a certain amount of development time, approvals and cost if a product changes.

With every development we look at the impact and consult with our clients the best route forward in order to meet requirements. When we choose a partner, unlike some TFT display suppliers, we do not just add on without understanding how the range fits within our business model. It is also important that we can add value to a suppliers range for an improved solution for the end customer.

We know all our TFT monitors will require support from other components within our range, including touch screens, interface cards or backlight controllers. Therefore we endeavour to fully test new panels for compatibility prior to releasing onto the market.

In market, LCD means passive matrix LCDs which increase TN (Twisted Nematic), STN (Super Twisted Nematic), or FSTN (Film Compensated STN) LCD Displays. It is a kind of earliest and lowest cost display technology.

LCD screens are still found in the market of low cost watches, calculators, clocks, utility meters etc. because of its advantages of low cost, fast response time (speed), wide temperature range,  low power consumption, sunlight readable with transflective or reflective polarizers etc.  Most of them are monochrome LCD display and belong to passive-matrix LCDs.

TFT LCDs have capacitors and transistors. These are the two elements that play a key part in ensuring that the TFT display monitor functions by using a very small amount of energy without running out of operation.

Normally, we say TFT LCD panels or TFT screens, we mean they are TN (Twisted Nematic) Type TFT displays or TN panels, or TN screen technology. TFT is active-matrix LCDs, it is a kind of LCD technologies.

TFT has wider viewing angles, better contrast ratio than TN displays. TFT display technologies have been widely used for computer monitors, laptops, medical monitors, industrial monitors, ATM, point of sales etc.

Actually, IPS technology is a kind of TFT display with thin film transistors for individual pixels. But IPS displays have superior high contrast, wide viewing angle, color reproduction, image quality etc. IPS screens have been found in high-end applications, like Apple iPhones, iPads, Samsung mobile phones, more expensive LCD monitors etc.

Both TFT LCD displays and IPS LCD displays are active matrix displays, neither of them can produce color, there is a layer of RGB (red, green, blue) color filter in each LCD pixels to make LCD showing colors. If you use a magnifier to see your monitor, you will see RGB color. With switch on/off and different level of brightness RGB, we can get many colors.

Neither of them can’t release color themselves, they have relied on extra light source in order to display. LED backlights are usually be together with them in the display modules as the light sources. Besides, both TFT screens and IPS screens are transmissive, it will need more power or more expensive than passive matrix LCD screens to be seen under sunlight.  IPS screens transmittance is lower than TFT screens, more power is needed for IPS LCD display.

An AMOLED display consists of an active matrix of OLED pixels generating light (luminescence) upon electrical activation that have been deposited or integrated onto a thin-film transistor (TFT) array, which functions as a series of switches to control the current flowing to each individual pixel.

Typically, this continuous current flow is controlled by at least two TFTs at each pixel (to trigger the luminescence), with one TFT to start and stop the charging of a storage capacitor and the second to provide a voltage source at the level needed to create a constant current to the pixel, thereby eliminating the need for the very high currents required for PMOLED.

TFT backplane technology is crucial in the fabrication of AMOLED displays. In AMOLEDs, the two primary TFT backplane technologies, polycrystalline silicon (poly-Si) and amorphous silicon (a-Si), are currently used offering the potential for directly fabricating the active-matrix backplanes at low temperatures (below 150 °C) onto flexible plastic substrates for producing flexible AMOLED displays. Brightness of AMOLED is determined by the strength of the electron current. The colors are controlled by the red, green and blue light emitting diodes.  It is easier to understand by thinking of each pixel is independently colored, mini-LED.

IPS technology is like an improvement on the traditional TFT LCD display module in the sense that it has the same basic structure, but with more enhanced features and more widespread usability compared with the older generation of TN type TFT screen (normally used for low-cost computer monitors). Actually, it is called super TFT.  IPS LCD display consists of the following high-end features. It has much wider viewing angles, more consistent, better color in all viewing directions, it has higher contrast, faster response time. But IPS screens are not perfect as their higher manufacturing cost compared with TN TFT LCD.

Utilizing an electrical charge that causes the liquid crystal material to change their molecular structure allowing various wavelengths of backlight to “pass-through”. The active matrix of the TFT display is in constant flux and changes or refreshes rapidly depending upon the incoming signal from the control device.
